Honeywell Dolphin 70e User Manual

Hide thumbs Also See for Dolphin 70e:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Dolphin 70e Wearable Solution
with Windows Embedded Handheld 6.5
User's Guide

Advertisement

Table of Contents
loading

Related Manuals for Honeywell Dolphin 70e

Summary of Contents for Honeywell Dolphin 70e

  • Page 1 Dolphin 70e Wearable Solution with Windows Embedded Handheld 6.5 User’s Guide...
  • Page 2 Disclaimer Honeywell International Inc. (“HII”) reserves the right to make changes in specifications and other information contained in this document without prior notice, and the reader should in all cases consult HII to determine whether any such changes have been made.

  • Page 3: Table Of Contents

    Table of Contents Contact Customer Support Product Service and Repair ....................iii Limited Warranty ........................iii Send Feedback ........................iii Chapter 1 - Getting Started Overview ..........................1-1 What You Need........................1-2 Belt Mount with Voice.....................1-2 Arm Mount with Tethered Ring Scanner ................1-2 Arm Mount with Voice and Tethered Ring Scanner ............1-2 About this Guide ........................1-2 Additional Documents ....................1-2...
  • Page 4 About the 8620 Ring Scanner ..................... 3-6 Ring Scanner Features....................3-6 Eject the Ring Scanner ....................3-7 Remove the Ring Strap/C-Ring ..................3-7 Replace the Ring Strap/C-Ring ..................3-8 Remove the Trigger ....................... 3-8 Replace the Trigger ....................... 3-9 Battery Specifications ......................3-10 Storing Batteries ......................

  • Page 5: Contact Customer Support

    Support. Contact your service center to obtain a Return Material Authorization number (RMA #) before you return the product. To obtain warranty or non-warranty service, return your product to Honeywell (postage paid) with a copy of the dated pur- chase record.Limited Warranty...

  • Page 7: Chapter 1 - Getting Started

    • Belt Mount Sled (page 2-4) The wearable version of the terminal is available in either standard or extended battery versions. The Dolphin 70e Wearable Solution is IP 54 rated. The wearable version of the terminal can be identified as follows: •...

  • Page 8: What You Need

    This User’s Guide provides assembling and mounting instructions as well as information about terminal setup and configuration as a wearable solution. Daily use instructions are included. This document describes only those features of the Dolphin 70e unique to the Wearable Solution.

  • Page 9: Before You Begin

    Here is a list of things you should check before you begin. Battery The Dolphin 70e Black wearable model is designed for use with battery part numbers BAT-STANDARD-02 (Li-ion 3.7 V, 6.179 watt hour) and BAT-EXTENDED-02 (Li-ion 3.7 V, 12.358 watt hour) manufactured for Honeywell International Inc.
  • Page 10 1 - 4...

  • Page 11: Chapter 2 - Installing And Mounting

    3. Pull the end cap off the sled. 4. Make sure the USB door is closed. Rotate the door on the right side of the Dolphin 70e Black to close. 5. Press until the door is flush with the side of the terminal.
  • Page 12 6. Slide the Dolphin 70e Black into the sled. 7. If using the audio end cap, make sure audio jack door is open. Pull the rubber door out and rotate the door 180º as shown to prevent damage. 8. If using the audio end cap, make sure the audio cable is not installed in the end cap.

  • Page 13: Mount The Arm Band And Attach The Terminal

    Mount the Arm Band and Attach the Terminal It is recommended that each user have their own arm band for hygiene reasons. The arm band can be washed between uses. Be sure to remove the sled from the arm band before washing the arm band. Note: The illustrations in this procedure assume the sled has not yet been mounted to the arm band.

  • Page 14: Belt Mount Applications

    • Trim the straps to length and use the provided clips to terminate the strap end. 2. Align the sled assembly with the arm band and press on the sled until it latches onto the arm band. Be sure to align tabs on the back of sled with the notches on the arm band.
  • Page 15 3. Pull the end cap off the sled. 4. Make sure the USB door is closed. Rotate the door on the right side of the Dolphin 70e Black to close. 5. Press until the door is flush with the side of the terminal.
  • Page 16 Make sure audio jack door is open. Pull the rubber door out and rotate the door 180º as shown to prevent damage. 8. Make sure the audio cable is not installed in the end cap. 9. Slide the end cap straight onto the sled until it clicks in place. 10.

  • Page 17: Attach The Sled To The Belt Clip

    Attach the Sled to the Belt Clip 1. Align the sled assembly with the belt clip and press on the sled until it latches onto the belt clip. Be sure to align tabs on the back of sled with the notches on the belt clip.

  • Page 18: Adjusting Headset / Microphone And Securing Cable

    4. Slide the cable ends together until they click. Do not twist or bend the connectors. Adjusting Headset / Microphone and Securing Cable The headset consists of an earpiece, a microphone, a clothing clip and a cable. The headset attaches to the audio cable end of the voice cable which attaches to the audio end cap.

  • Page 19: Connect The Ring Scanner (Optional)

    It is not necessary to remove the ring scanner from the sled before removing the Dolphin 70e Black from the sled. 2. When connected to a terminal that is powered up, the terminal emits 3 beeps and the ring scanner LED blinks green one time.
  • Page 20 2 - 10...

  • Page 21: Chapter 3 - About The Hardware

    There are three types of system resets: a soft reset, a hard reset, or a factory reset. The soft and hard resets preserve all data stored in the file system. Contact a Honeywell technical support representative for more information on how to perform a factory reset.

  • Page 22: About The Arm Mount Sled

    Remove the Terminal from the Arm Mount Sled 1. If the audio end cap is used, remove the audio cable. To prevent damage to the Dolphin 70e Black always unplug the audio cable (if used) before removing the end cap.
  • Page 23 4. Pull the end cap off of the sled. 5. Slide the Dolphin 70e Black out of the sled. Use the notch in the bottom of the sled to push the Dolphin 70e Black. 3 - 3...

  • Page 24: About The Belt Mount Sled

    • Internal scanner. Remove the Terminal from the Belt Mount Sled 1. If the audio end cap is used, remove the audio cable. To prevent damage to the Dolphin 70e Black always unplug the audio cable before removing the end cap.
  • Page 25 4. Pull the end cap off of the sled. 5. Slide the Dolphin 70e Black out of the sled. Use the notch in the bottom of the sled to push the Dolphin 70e Black. 3 - 5...

  • Page 26: About The 8620 Ring Scanner

    About the 8620 Ring Scanner Ring Scanner Features The ring scanner is shipped with 3 different finger attachments: • Ring strap which is adjustable to your finger size • Gray C-ring for small to medium sized fingers (self adjustable) • Black C-ring for medium to large sized finger (self adjustable) The trigger and ring strap/C-ring are user replaceable as described in this section.

  • Page 27: Eject The Ring Scanner

    Eject the Ring Scanner 1. To eject the ring scanner, open the connector ring with one hand, pulling toward the outside of the sled. 2. Push the ring scanner connector out of the sled. Remove the Ring Strap/C-Ring 1. Turn the scanner 90°. 2.

  • Page 28: Replace The Ring Strap/C-Ring

    Replace the Ring Strap/C-Ring 1. Connect ring latch with trigger catch. 2. Press together until a click occurs. 3. Turn 90°. 4. Ready to scan. Remove the Trigger 1. Remove ring strap or c-ring. 2. Unscrew the 4 screws. 3. Remove trigger. Note: When removing the trigger be careful that the metal spring is not dislodged.

  • Page 29: Replace The Trigger

    Replace the Trigger 1. Place trigger on the scanner. 2. Screw in the 4 screws to secure the trigger. 3. Snap on ring strap or c-ring. 3 - 9...

  • Page 30: Battery Specifications

    Honeywell International Inc. or an authorized service center for inspection. • If you are not sure the battery or charger is working properly, send it to Honeywell International Inc. or an authorized service center for inspection, see...

  • Page 31: Remove The Battery

    Remove the Battery Remove the Terminal from the Arm Mount Sled (page 3-2) or Remove the Terminal from the Belt Mount Sled (page 3- 4) changing the battery. 2. Place the terminal in Suspend mode by pressing and releasing the Power button 3.
  • Page 32 3 - 12...

  • Page 33: Chapter 4 - Using The Ring Scanner And Headset

    Using the Ring Scanner and Headset Overview The 8620 ring scanner is a wearable external image engine that connects to the Dolphin 75e Wearable Solution. It reads popular 1D and 2D bar codes and supports omni-directional aiming and decoding for greater flexibility in real-world settings. Note: This document describes the 8620 model ring scanner only.

  • Page 34: Power Tools

    Power Tools When ordered as part of the Honeywell Wearable Solution, the following additional Power Tools are installed on the Dolphin 70e Black terminal so that it can work with the ring scanner. This section will discuss software that is unique to the wearable version of the terminal.
  • Page 35 4-2) and select Exit in the command bar menu. Modifying the ScanWedge NGW Configuration File A ScaneWedgeNGW.exm file is inserted in the \Honeywell folder when ScanWedge NGW is installed, This file specifies configuration parameters for ScanWedge NGW and must not be moved.

  • Page 36: Ngw Settingsconfig

    To launch NGW SettingsConfig, open Power Tools and tap the NGW SettingsConfig icon once. Orientation The automatic screen rotation is disabled on the wearable version of the Dolphin 70e Black. Instead the screen is locked in the selected orientation: • Portrait •...

  • Page 37: Headset Volume

    Keyboard Layout Hot Key Select the hot key that is used to scroll through the available on-screen keyboard layouts. If no keyboard is displayed, pressing the hot key calls up the on-screen keyboard. When the on-screen keyboard is displayed, pressing the hot key scrolls through the available layouts.

  • Page 38: Upgrading Ring Scanner Firmware

    7. Using Explorer, go to the c:\windows\temp file. 8. Double click on the Setup.exe file. Follow the screen prompts to install the EZConfig-Scanning program. 9. If you’ve selected the defaults during installation, you can click on Start Menu-All Programs-Honeywell-EZConfig- Scanning and select EZConfig for your browser.

  • Page 39: Appendix A - Ring Scanner Specifications

    Ring Scanner Specifications 8620 Ring Scanner Specifications Parameter Specification Dimensions (Typical): 50 mm x 30 mm x 30 mm (2.0 in. x 1.2 in. x 1.2 in.) Weight: 71 g (2.5 oz.) Illumination LED: White LED Cool white (5700K) IEC62471: “Exempt Risk Group” Aiming: Peak Wavelength Laser 650nm...

  • Page 40: Supported Bar Code Symbologies

    Supported Bar Code Symbologies Symbology Type Symbology Name Codabar ISBN Code 11 ISBN with Add On Code 32 Pharmaceutical (PARAF) ISBT 128 Code 39 Matrix 2 of 5 Code 93 Code 128 Straight 2 of 5 IATA 1D Symbologies EAN with Add On Straight 2 of 5 Industrial EAN with Extended Coupon Code Telepen...

  • Page 41: Required Safety Labels

    Guaranteed Performance Symbology Distance 5 mil C39 81 - 132 mm (3.2 - 5.2 in) 10 mil C39 38 - 295 mm (1.5 - 11.6 in) 100% 13 mil UPC 43 - 371 mm (1.7 - 14.6 in) 6.7 mil PDF417 54 - 158 mm (2.1 - 6.2 in) 10 mil DataMatrix 64 - 175 mm (2.5 6.9 in)
  • Page 42 A - 4...
  • Page 44 Honeywell 9680 Old Bailes Road Fort Mill, SC 29707 www.honeywellaidc.com HWC-WEH-UG Rev C 2/16...
