Summary of Contents for Jeep Cherokee 2015

Page 1 U S ER GUI DE 2015 Jeep Cherokee...
Page 2 Roadside Assistance (new vehicles purchased in the U.S.) or Roadside Assistance (new vehicles purchased in Canada) in electronic format. We hope you find it useful. Replacement DVD kits may be purchased by visiting www.techauthority.com. Jeep and Cherokee are registered ®...
Page 3: Table Of Contents
TABLE OF CONTENTS INTRODUCTION/WELCOME Uconnect ® 8.4AN ... . . 123 Uconnect PHONE ... . 138 ® WELCOME FROM FCA US LLC .
Page 4: Table Of Contents
TABLE OF CONTENTS CUSTOMER ASSISTANCE MOPAR® ACCESSORIES FCA US LLC CUSTOMER CENTER . . . 219 AUTHENTIC ACCESSORIES BY FCA CANADA INC. CUSTOMER MOPAR ® ....221 CENTER .
Page 5: Welcome From Fca Us Llc
INTRODUCTION/WELCOME WELCOME FROM FCA US LLC Congratulations on selecting your new FCA US LLC vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality - all essen- tials that are traditional to our vehicles. Your new FCA US LLC vehicle has characteristics to enhance the driver's control under some driving conditions.
Page 6 INTRODUCTION/WELCOME VEHICLES SOLD IN CANADA With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution (excluding legal lines). WARNING! • Pedals that cannot move freely can cause loss of vehicle control and increase the risk of serious personal injury.
Page 8: Driver Cockpit
CONTROLS AT A GLANCE DRIVER COCKPIT 1. Driver Memory Seat pg. 32 2. Headlight Switch pg. 39 3. Turn Signal/Light Lever pg. 38 4. Tachometer pg. 8 5. Electronic Vehicle Information Center (EVIC) Or Driver Information Display (DID) pg. 149 6.
Page 9 CONTROLS AT A GLANCE 10. Shift Lever 11. Engine Start/Stop pg. 15 12. Speed Control pg. 41 13. Electronic Vehicle Information Center (EVIC) Or Driver Information Display (DID) Controls pg. 149 14. Opening The Hood pg. 197 15. Power Mirror Switch 16.
Page 10: Instrument Cluster
CONTROLS AT A GLANCE INSTRUMENT CLUSTER 1. Tachometer 2. Electronic Vehicle Information Center (EVIC) Or Driver Information Display (DID) 3. Speedometer (See page 168 for Instrument Cluster Warning Lights information.)
Page 11 CONTROLS AT A GLANCE 4. Fuel Gauge 5. Fuel Filler Door Location 6. Temperature Gauge (See page 175 for Instrument Cluster Indicator Lights information.)
Page 12 GETTING STARTED KEY FOB • This feature allows the driver to oper- ate the ignition switch with the push of a button as long as the Remote Keyless Entry (RKE) transmitter is in the pas- senger compartment. • The Keyless Ignition Node (KIN) has four operating positions, three of which are labeled and will illuminate when in position.
Page 13: Remote Start
GETTING STARTED Panic Alarm • Push PANIC button once to turn the panic alarm on. • Wait approximately three seconds and push button a second time to turn the panic alarm off. WARNING! • When leaving the vehicle, always remove the Key Fob from the ignition and lock your vehicle.
Page 14: Vehicle Security Alarm
GETTING STARTED VEHICLE SECURITY ALARM The Vehicle Security Alarm monitors the vehicle doors for unauthorized entry and the Keyless Enter-N-Go™ START/STOP button for unauthorized operation. While the Vehicle Security Alarm is armed, interior switches for door locks and decklid release are disabled.
Page 15: Keyless Enter-N-Go
GETTING STARTED KEYLESS ENTER-N-GO™ The Keyless Enter-N-Go™ system is an enhancement to the vehicle’s Remote Keyless Entry (RKE) feature. This feature allows you to lock and unlock the vehicle's door(s) and liftgate without having to push the Key Fob LOCK or UNLOCK buttons, as well as starting and stopping the vehicle with the push of a button.
Page 16 GETTING STARTED To Lock The Vehicle: • Both front door handles have buttons located on the outside of the handle. With one of the vehicle’s Keyless Enter-N-Go™ Key Fobs located outside the vehicle and within 5 ft (1.5m) of the driver's or passenger front door handle, push the door handle button to lock all four doors and liftgate.
Page 17 GETTING STARTED Lock Or Unlock The Liftgate • To Lock The Liftgate — With a valid Passive Entry RKE transmitter within 5 ft (1.5 m) of the liftgate, push passive entry lock button located to the right of electronic liftgate handle. •...
Page 18: Seat Belt Systems
GETTING STARTED Accessory Positions With Engine Off NOTE: The following functions are with the driver’s foot OFF the Brake Pedal (Transmission in PARK or NEUTRAL Position). Starting With The Ignition Switch In The OFF Position: • Push the ENGINE START/STOP button once to change the ignition switch to the ACC position.
Page 19: Supplemental Restraint System Srs) — Air Bags
GETTING STARTED WARNING! • In a collision, you and your passengers can suffer much greater injuries if you are not properly buckled up. You can strike the interior of your vehicle or other passengers, or you can be thrown out of the vehicle. Always be sure you and others in your vehicle are buckled up properly.
Page 20 GETTING STARTED Advanced Front Air Bags • This vehicle has Advanced Front Air Bags for both the driver and front passenger as a supplement to the seat belt restraint systems. The Advanced Front Air Bags will not deploy in every type of collision. •...
Page 21 GETTING STARTED • After any collision, the vehicle should be taken to an authorized dealer immediately. • Do not drive your vehicle after the air bags have deployed. If you are involved in another collision, the air bags will not be in place to protect you. •...
Page 22 GETTING STARTED The OCS determines the front passenger’s most probable classification. The OCS estimates the seated weight on the front passenger seat and where that weight is located. The OCS communicates the classification status to the ORC. The ORC uses the classification to determine whether the Passenger Advanced Front Air Bag inflation rate should be adjusted.
Page 23 GETTING STARTED Lighter Weight Passengers (Including Small Adults) When a lighter weight passenger, including a small adult, occupies the front passenger seat, the OCS may reduce the inflation rate of the Passenger Advanced Front Air Bag. This does not mean that the OCS is working improperly. Do not decrease OR increase the front passenger’s seated weight on the front passenger seat The front passenger’s seated weight must be properly positioned on the front...
Page 24 GETTING STARTED The OCS determines the front passenger’s most probable classification. If an occupant in the front passenger seat is seated improperly, the occupant may provide an output signal to the OCS that is different from the occupant’s properly seated weight input, for example: Not Seated Properly Not Seated Properly...
Page 25 GETTING STARTED The Air Bag Warning Light will turn on whenever the OCS is unable to classify the front passenger seat status. A mal- function in the OCS may affect the opera- tion of the air bag system. If the Air Bag Warning Light does not come on, or stays on after you start the vehicle, or it comes on as you drive, take...
Page 26 GETTING STARTED Supplemental Knee Air Bags This vehicle is equipped with a Supplemental Driver Knee Air Bag mounted in the instrument panel below the steering column and a Supplemental Passenger Knee Air Bag mounted in the instrument panel below the glove compartment. The Supple- mental Knee Air Bags provide enhanced protection during a frontal impact by working together with the seat belts, pretensioners, and Advanced Front Air Bags.
Page 27 GETTING STARTED Supplemental Side Air Bags • Your vehicle is equipped with Supplemental Seat-Mounted Side Air Bags (SABs) located in the outboard side of the front and rear (in vehicles equipped with outboard rear seat SABs) seats. The SABs are marked with a SRS AIRBAG or AIRBAG label sewn into the outboard side of the seats.
Page 28: Child Restraints
GETTING STARTED CHILD RESTRAINTS Children 12 years or younger should ride properly buckled up in a rear seat, if available. According to crash statistics, children are safer when properly restrained in the rear seats rather than in the front. Every state in the United States and all Canadian provinces require that small children ride in proper restraint systems.
Page 29 GETTING STARTED Locating Tether Anchorages In addition, there are tether strap anchorages behind each rear seating position located on the back of the seat. Tether Anchors Center Seat LATCH The center seating position in this vehicle has a single dedicated anchorage. Use anchorages 3 and 4 to install a child seat in the center position.
Page 30 GETTING STARTED Installing The Child Restraint Using The LATCH Lower Anchors NOTE: Never “share” a LATCH anchorage with two or more child restraints. 1. Loosen the adjusters on the lower straps and on the tether strap of the child seat so that you can more easily attach the hooks or connectors to the vehicle anchorages.
Page 31 GETTING STARTED 7. If the child restraint has a top tether strap and the seating position has a top tether anchorage, connect the tether strap to the anchorage and tighten the tether strap. See below for directions to attach a tether anchor. 8.
Page 32: Head Restraints
GETTING STARTED WARNING! • In a collision, an unrestrained child, even a tiny baby, can become a projectile inside the vehicle. The force required to hold even an infant on your lap could become so great that you could not hold the child, no matter how strong you are.
Page 33 GETTING STARTED Reactive Head Restraints — Front Seats The front driver and passenger seats are equipped with Reactive Head Restraints (RHR). In the event of a rear impact the RHRs will automatically extend forward minimizing the gap between the back of the occupants head and the RHR. The RHRs will automatically return to their normal position following a rear impact.
Page 34: Front Seats
GETTING STARTED FRONT SEATS Power Seats The power seat switches are located on the outboard side of the front seat cushions. The power seat switch controls forward, rearward, up and down adjustments. The recline switch controls the angle of the seatback. •...
Page 35 GETTING STARTED To program a Key Fob to the memory position: 1. Cycle the vehicles ignition to the OFF position. 2. Select the desired memory profile 1 or 2. 3. Push and release the S (SET) button on the memory switch, then within five seconds push and release the 1 or 2 button accordingly.
Page 36: Rear Seats
GETTING STARTED CAUTION! Do not place any article under a power seat or impede its ability to move as it may cause damage to the seat controls. Seat travel may become limited if movement is stopped by an obstruction in the seat’s path. WARNING! •...
Page 37: Heated/Ventilated Seats
GETTING STARTED Recliner Adjustment • The rear seatback also reclines for additional passenger comfort. Pull on the pull strap while sitting in the rear seat to recline the seatback. WARNING! Be certain that the seatback is securely locked into position. If the seatback is not securely locked into position, the seat will not provide the proper stability for child seats and/or passengers.
Page 38: Heated Steering Wheel
GETTING STARTED Front Ventilated Seats Located in the seat cushion and seatback are small fans that draw the air from the passenger compartment and pull air through fine perforations in the seat cover to help keep the driver and front passenger cooler in higher ambient temperatures. There are two ventilated seat control buttons located in the touchscreen that allow the driver and passenger to operate the seats independently.
Page 39: Tilt/Telescoping Steering Column
GETTING STARTED WARNING! • Persons who are unable to feel pain to the skin because of advanced age, chronic illness, diabetes, spinal cord injury, medication, alcohol use, exhaus- tion, or other physical conditions must exercise care when using the steering wheel heater.
Page 40: Engine Break-In Recommendations
OPERATING YOUR VEHICLE ENGINE BREAK-IN RECOMMENDATIONS A long break-in period is not required for the engine and drivetrain (transmission and axle) in your vehicle. Drive moderately during the first 300 miles (500 km). After the initial 60 miles (100 km), speeds up to 50 or 55 mph (80 or 90 km/h) are desirable. While cruising, brief full-throttle acceleration within the limits of local traffic laws contributes to a good break-in.
Page 41: Headlight Switch
OPERATING YOUR VEHICLE HEADLIGHT SWITCH Automatic Headlights/Parking Lights/Headlights The headlight switch is located on the instrument panel to the left of the steer- ing wheel. • Rotate the headlight switch to the first detent for parking lights and to the second detent for headlights.
Page 42: Wiper/Washer Lever
OPERATING YOUR VEHICLE Ambient Light Dimmer • Rotate the left dimmer control upward or downward to increase or decrease the brightness of the ambient light located in the overhead console, door handle lights, under I/P lights, door map pocket lights, and cubby bin lights. •...
Page 43: Electronic Speed Control
OPERATING YOUR VEHICLE ELECTRONIC SPEED CONTROL The Electronic Speed Control switches are located on the right side of the steering wheel. Cruise ON/OFF • Push the ON/OFF button to acti- vate the Electronic Speed Control. CRUISE CONTROL READY will appear in the Electronic Vehicle Information Center (EVIC) or Driver Information Display (DID) to indicate the Electronic Speed...
Page 44 OPERATING YOUR VEHICLE Metric Speed (km/h) • Pushing the SET + button once will result in a 1 km/h increase in set speed. Each subsequent tap of the button results in an increase of 1 km/h. • If the button is continually pushed, the set speed will continue to increase until the button is released, then the new set speed will be established.
Page 45: Adaptive Cruise Control (Acc)
OPERATING YOUR VEHICLE ADAPTIVE CRUISE CONTROL (ACC) If your vehicle is equipped with Adaptive Cruise Control the controls operate ex- actly the same as the electronic speed control with only a couple of differences. With this option you can set a specified distance you would like to maintain be- tween you and the vehicle in front of you.
Page 46 OPERATING YOUR VEHICLE Metric Speed (km/h) • Pushing the SET + button once will result in a 1 km/h increase in set speed. Each subsequent tap of the button results in an increase of 1 km/h. • If the button is continually pushed, the set speed will continue to increase in 10 km/h increments until the button is released.
Page 47 OPERATING YOUR VEHICLE Distance Setting (ACC Only) The specified following distance for ACC can be set by varying the distance setting between four bars (longest), three bars (long), two bars (medium) and one bar (short). Using this distance setting and the vehicle speed, ACC calculates and sets the distance to the vehicle ahead.
Page 48 OPERATING YOUR VEHICLE WARNING! Adaptive Cruise Control (ACC) is a convenience system. It is not a substitute for active driving involvement. It is always the driver’s responsibility to be attentive of road, traffic, and weather conditions, vehicle speed, distance to the vehicle ahead; and, most importantly, brake operation to ensure safe operation of the vehicle under all road conditions.
Page 49: Forward Collision Warning (Fcw With Mitigation
OPERATING YOUR VEHICLE FORWARD COLLISION WARNING (FCW) WITH MITIGATION The Forward Collision Warning (FCW) system with mitigation provides the driver with audible warnings, visual warnings (within the EVIC/DID), and may apply a brake jerk to warn the driver when it detects a potential frontal collision. The warnings and limited braking are intended to provide the driver with enough time to react, avoid or mitigate the potential collision.
Page 50 OPERATING YOUR VEHICLE The default status of FCW is the “Far” setting. The far setting provides warnings for potential collisions more distant in front of the vehicle, allowing the driver to have the most reaction time to avoid a collision. This setting is designed to provide early warnings per NHTSA (National Highway Traffic Safety Administration) recommendations.
Page 51: Manual Climate Controls Without Touchscreen
OPERATING YOUR VEHICLE MANUAL CLIMATE CONTROLS WITHOUT TOUCHSCREEN Manual Climate Controls Without Touchscreen 1 — Blower Control Knob 5 — A/C Button 2 — Air Recirculation Button 6 — Mode Control Knob 3 — Temperature Control Knob 7 — Rear Defroster Button 4 —...
Page 52: Manual Climate Controls With Touchscreen
OPERATING YOUR VEHICLE MANUAL CLIMATE CONTROLS WITH TOUCHSCREEN Uconnect® 5.0 Touchscreen Manual Climate Controls 6 — Mode Control Button 1 — MAX A/C Button 7 — OFF Button 2 — A/C Button 8 — Temperature Control Button 3 — Air Recirculation Button 9 —...
Page 53 OPERATING YOUR VEHICLE Uconnect® 8.4 Touchscreen Manual Climate Controls 6 — Blower Speed Buttons 1 — MAX A/C Button 7 — Mode Control Button 2 — A/C Button 8 — OFF Button 3 — Air Recirculation Button 9 — Temperature Control Buttons 4 —...
Page 54 OPERATING YOUR VEHICLE Manual Climate Controls 1 — Temperature Down Control 5 — Front Defrost Button 2 — Blower Control Knob 6 — Off Button 3 — Temperature Up Control 7 — Air Recirculation Button 4 — Rear Defrost Button 8 —...
Page 55 OPERATING YOUR VEHICLE AUTOMATIC TEMPERATURE CONTROLS (ATC) Uconnect® 5.0 Touchscreen Automatic Climate Controls 1 — MAX A/C Button 7 — OFF Button 2 — A/C Button 8 — AUTO Button 3 — Air Recirculation Button 9 — SYNC Button 4 — Front Defroster Button 10 —...
Page 56 OPERATING YOUR VEHICLE Uconnect® 8.4 Touchscreen Automatic Climate Controls 1 — MAX A/C Button 7 — Passenger Temperature Control 2 — A/C Button 8 — SYNC Button 3 — Air Recirculation Button 9 — Blower Speed Buttons 4 — AUTO Button 10 —...
Page 57 OPERATING YOUR VEHICLE Automatic Climate Controls 1 — Driver Temperature Control 6 — Front Defroster Button 2 — OFF Button 7 — AUTO Button 3 — Blower Control Knob 8 — Air Recirculation Button 4 — Passenger Temperature Control 9 — A/C Button 5 —...
Page 58 OPERATING YOUR VEHICLE MAX A/C • MAX A/C sets the control for maximum cooling performance. • Press and release to toggle between MAX A/C and the prior settings. The button on the touchscreen illuminates when MAX A/C is ON. • In MAX A/C, the blower level and mode position can be adjusted to desired user settings.
Page 59: Stop/Start System — 3.2L Engine
OPERATING YOUR VEHICLE STOP/START SYSTEM — 3.2L ENGINE The Stop/Start function is developed to reduce fuel consumption. The system will stop the engine automatically during a vehicle stop if the required conditions are met. Releasing the brake pedal or pressing the accelerator pedal will automatically re-start the engine.
Page 60: Electric Park Brake (Epb)
OPERATING YOUR VEHICLE To Manually Turn On The Stop/Start System Press the STOP/START Off switch (located on the switch bank). The light on the switch will turn off. For complete details on the Stop/Start System refer to the “Stop/Start System” in the “Starting and Operating”...
Page 61 OPERATING YOUR VEHICLE • Safehold is a new feature that will automatically apply the park brake under certain conditions. The EPB monitors the status of the driver’s seat belt, driver’s door and pedal positions to determine if the driver may have exited while the vehicle is still capable of moving and will then automatically apply the park brake to prevent the vehicle from rolling.
Page 62: Parksense
OPERATING YOUR VEHICLE PARKSENSE® ParkSense® Front And Rear Park Assist ParkSense can be enabled and disabled by pushing the ParkSense switch located ® ® on the switch panel below the Uconnect display. ® The six ParkSense ® sensors, located in the rear fascia/bumper, monitor the area behind the vehicle that is within the sen- sors’...
Page 63 OPERATING YOUR VEHICLE ParkSense® Active Park Assist The ParkSense ® Active Park Assist system can be enabled and disabled with the ParkSense ® Active Park Assist switch, located on the switch panel below the Uconnect ® display. The ParkSense Active Park Assist sys- ®...
Page 64: Lanesense
OPERATING YOUR VEHICLE LANESENSE The LaneSense system can be enabled and disabled with the LaneSense button located on the switch panel below the Uconnect ® display. • Push the LaneSense button to turn the system ON (LED turns off). The LaneSense system is operational at speeds above 37 mph (60 km/h) and below 112 mph (180 km/h).
Page 65: Power Sunroof
OPERATING YOUR VEHICLE WARNING! Drivers must be careful when backing up; even when using the ParkView Rear ® Back-Up Camera. Always check carefully behind your vehicle, and be sure to check for pedestrians, animals, other vehicles, obstructions, or blind spots before backing up.
Page 66 OPERATING YOUR VEHICLE Manual • To close the sunroof, push and hold the sunroof switch in the forward position. NOTE: Any release of the sunroof switch will stop the movement and the sunroof will remain in a partially closed condition until the switch is pushed and held forward again. Venting Sunroof Push and release the button and the sunroof will open to the vent position.
Page 67: Wind Buffeting
OPERATING YOUR VEHICLE Pinch Protection Feature This feature will detect an obstruction in the opening of the sunroof during Express Close operation. If an obstruction in the path of the sunroof is detected, the sunroof will automatically retract. Remove the obstruction if this occurs. Next, push the switch forward and release to Express Close.
Page 68: Your Vehicle's Sound System
ELECTRONICS YOUR VEHICLE'S SOUND SYSTEM 1. Uconnect ® Phone Button pg. 138 2. Uconnect ® Voice Command Button pg. 108 3. Phone Hang Up Button 4. Steering Wheel Audio Controls (Right) pg. 148 5. Steering Wheel Audio Controls (Left) pg. 148 6.
Page 69 ELECTRONICS 8. Uconnect 8.4 Radio pg. 95 ® 9. Volume Knob/Audio Mute Button 10. Screen Off Button 11. Back Button 12. Tune/Scroll Knob/Browse/Enter Button 13. Media Hub: Audio Jack, USB Port, and SD Card Slot (Located Inside Front Console) pg. 102 14.
Page 70: Identifying Your Radio
ELECTRONICS IDENTIFYING YOUR RADIO Uconnect® 5.0 • 5” Touchscreen • Three buttons on the faceplate on either side of the display Uconnect® 5.0 Uconnect® 5.0 Uconnect® 8.4A • 8.4” Touchscreen • Climate button on the touchscreen in lower menu bar Uconnect®...
Page 71 ELECTRONICS Uconnect® 8.4AN • 8.4” Touchscreen • Climate button on the touchscreen in lower menu bar • HD Button will be visible on right side of screen when viewing AM or FM • SiriusXM Travel Link feature listed within Apps (US Market Only) Uconnect®...
Page 72 ELECTRONICS Included Trial Period For New Vehicles Your new vehicle may come with an included trial period for use of the Uconnect ® Access Services starting at the date of vehicle purchase (date based on vehicle sales notification from your dealer). To activate the trial, you must first register with Uconnect ®...
Page 73 ELECTRONICS NOTE: For security reasons, this link is valid for 72 hours from the time you’ve submitted your email address into the radio touchscreen. If the link has expired, simply re-enter your email address into the Uconnect ® Registration App on the radio touchscreen to receive another link.
Page 74 ELECTRONICS Set Up Your Via Mobile Profile — If Equipped Setting up your Via Mobile profile means entering your login information for each App so that they can work in your vehicle. Complete your Via Mobile Profile online during registration of your Uconnect ®...
Page 75 ELECTRONICS 3. From the Uconnect ® Store, select the WiFi Hotspot service you wish to purchase or renew your subscription. 4. This will launch the selected App into purchase mode along with providing additional information. The purchase process begins when you press the “Buy” button on the touchscreen.
Page 76 ELECTRONICS Get started with your Uconnect ® Access apps by pressing the Uconnect ® “Apps” button on the menu bar at the bottom right corner of the radio touchscreen. Available apps and features are organized by the tabs on the left of the screen. Favorite Apps —...
Page 77 ELECTRONICS Maintaining Your Uconnect® Access Account Reinstalling An App (Uconnect® 8.4A/8.4AN) You can easily correct many Application related issues you may be experiencing by resetting the App back to the factory setting. From the vehicle’s radio touchscreen, complete the following steps: 1.
Page 78 ELECTRONICS Built-In Features (Uconnect® 8.4AN Only) CAUTION! • Ignoring the rearview mirror light could mean you may not have 9-1-1 Call service if needed. If the rearview mirror light is illuminated, have an authorized dealer service the 9-1-1 Call system immediately. •...
Page 79 ELECTRONICS 2. Emergency 9-1-1 Call (If Equipped) — The rearview mirror contains a 9-1-1 button that, when pressed, may place a call from your vehicle to a local 9-1-1 operator to request help from local police, fire or ambulance personnel. If this button is accidentally pressed, you will have 10 seconds to stop the call.
Page 80 ELECTRONICS 6. Stolen Vehicle Assistance — If your vehicle is stolen, contact local law enforce- ment immediately to file a stolen vehicle report. Once this report has been filed, Uconnect ® care can help locate your vehicle. The Uconnect ® Care agent will ask for the stolen vehicle report number issued by local law enforcement.
Page 81 ELECTRONICS Remote Door Lock/Unlock — This feature provides the ability to lock or unlock the door on your vehicle, without the keys and from virtually any distance. You can send a request to your vehicle in one of three ways: 1.
Page 82 ELECTRONICS To Send A Text Message: 1. Push the Uconnect Phone Button on the steering wheel. ® 2. Wait for the beep. 3. Say “Text.” 4. Uconnect ® will prompt you “Say the phone number, or full name and phone type of the contact you want to send a message to.”...
Page 83 ELECTRONICS Uconnect® Access Via Mobile — If Equipped (Available On Uconnect® 8.4AN) Via Mobile uses the Uconnect Access App and your smartphone's data plan to ® access your personal Pandora ® , iHeartRadio, Aha™ by HARMAN and Slacker Radio accounts from the vehicle and control them using the vehicle touchscreen. Custom- er’s data plan charges will apply.
Page 84 ELECTRONICS Using Uconnect® Access The Uconnect ® Access App is compatible with select iPhone ® and Android smart- phones. Visit UconnectPhone.com to confirm that your smartphone is compatible with Uconnect . Once you’ve confirmed your smartphone is compatible, pair it to the ®...
Page 85 ELECTRONICS Each time you want to use a Via Mobile app in your vehicle, the Uconnect ® Access App must be running on your smartphone and the smartphone must be paired via Bluetooth ® Via Mobile apps can also be launched through Voice Recognition by pressing the VR button on the steering wheel and stating “launch”...
Page 86: Uconnect ® 5.0
ELECTRONICS Uconnect® 5.0 Uconnect® 5.0 1 — Radio Mode Button 8 — Uconnect ® Phone Button 2 — Presets Button 9 — FM/SXM Button 3 — Compass Information Button 10 — Manual Tune Button 4 — Media Mode Button 11 — Info Button 5 —...
Page 87 ELECTRONICS Equalizer, Balance And Fade To adjust the Audio settings: 1. Push the + MORE button on the faceplate, then press the “Settings” button on the touchscreen. 2. Scroll down and press the “Audio” button on the touchscreen to open the Audio menu.
Page 88 ELECTRONICS SiriusXM Premier Over 160 channels Get every channel available on your satellite radio, and enjoy all you want, all in one place. Hear commercial-free music plus sports, news, talk and entertainment. Get all the premium programming, including Howard Stern, every NFL game, Oprah Radio ®...
Page 89 ELECTRONICS USB/Audio Jack (AUX)/Bluetooth® Manual Operation To select a specific audio source, push the MEDIA button on the touchscreen. To allow music to play from your portable device through the vehicle’s speakers, push the “Source” button then select one of the following modes: USB/iPod®...
Page 90 ELECTRONICS Uconnect® 5.0 VOICE RECOGNITION QUICK TIPS Introducing Uconnect® Start using Uconnect ® Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your Uconnect ® system. Key Features: •...
Page 91 ELECTRONICS Get Started 1. Visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition. 3. Speak clearly at a normal pace and volume while facing straight ahead. The microphone is positioned on the rearview mirror and aimed at the driver.
Page 92 ELECTRONICS Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect ® system. Push the VR button . After the beep, say: • Cancel to stop a current voice session • Help to hear a list of suggested Voice Commands •...
Page 93 ELECTRONICS Radio Use your voice to quickly get to the AM, FM or SiriusXM™ Satellite Radio stations ® you would like to hear. (Subscription or included SiriusXM™ Satellite Radio trial required.) Push the VR button . After the beep, say: •...
Page 94 ELECTRONICS Media Uconnect offers connections via USB, SD, Bluetooth and auxiliary ports (If ® ® Equipped). Voice operation is only available for connected USB and iPod ® devices. (Remote CD player optional and not available on all vehicles.) Push the VR button .
Page 95 ELECTRONICS Phone Making and answering hands-free phone calls is easy with Uconnect . When the ® Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit UconnectPhone.com to check mobile device and feature compatibility and to find phone pairing instructions. Push the Phone button .
Page 96 ELECTRONICS Additional Information © 2015 FCA US LLC. All rights reserved. Mopar, Mopar Owner Connect and Uconnect are registered trademarks of FCA US LLC. Android is a trademark of Google Inc. SiriusXM and all related marks and logos are trademarks of SiriusXM Radio Inc. Yelp, Yelp logo, Yelp burst and related marks are registered trademarks of Yelp.
Page 97: Uconnect ® 8.4A
ELECTRONICS Uconnect® 8.4A Uconnect® 8.4A — If Equipped At A Glance Uconnect® 8.4A 1 — Status Bar 5 — Climate Button 2 — Menu Bar 6 — Controls Button 3 — Uconnect Apps Button 7 — Media Button ® 4 — Uconnect ®...
Page 98 ELECTRONICS Setting The Time Model 8.4AN synchronizes time automatically via GPS, so it should not require any time adjustment. If you do need to set the time manually, follow the instructions below for Model 8.4A. 1. Turn the unit on, then press the “Time Display” at the top of the screen. Press “Yes.”...
Page 99 ELECTRONICS Equalizer 1. Press the “Media” or “Radio” button on the touchscreen. 2. Press the “Audio” button on the touchscreen to activate the Audio settings screen to adjust Balance/Fade, Equalizer and Speed Adjusted Volume. 3. Press the “Equalizer” button on the touchscreen to activate the Equalizer screen. 4.
Page 100 ELECTRONICS RADIO Uconnect® 8.4A Radio 1 — Radio Station Presets 5 — Direct Tune To A Radio Station 2 — Toggle Between Presets 6 — Seek Down 3 — Audio Setting 7 — Browse And Manage Presets 4 — Seek Up 8 —...
Page 101 ELECTRONICS Direct Tune • Tune directly to a radio station by pressing the “Tune” button on the screen, and entering the desired station number. Store Radio Presets Manually Your radio can store 36 total preset stations, 12 presets per band (AM, FM and SXM). They are shown at the top of your radio screen.
Page 102 ELECTRONICS Jump Jump automatically tells you when Traffic & Weather for a favorite city is available, and gives you the option to switch to that channel. • Press “Jump” to activate the feature. After listening to Traffic and Weather, press “Jump”...
Page 103 ELECTRONICS Replay Lets you replay up to 44 minutes of the content of the current SiriusXM channel. Replay Option Option Description Play/Pause Press to Pause content playback. Press Pause/Play again to re- sume playback. Rewind/RW Rewinds the channel content in steps of five seconds. Press and hold to rewind continuously, then release to begin playing content at that point.
Page 104 ELECTRONICS MEDIA HUB — PLAYING iPod®/USB/MP3 DEVICES There are many ways to play music from iPod /MP3 players or USB devices through ® your vehicle's sound system. Press your “Media” button on the touchscreen to begin. USB Port • Connect your iPod ®...
Page 105 ELECTRONICS Audio Jack (AUX) • The AUX allows a portable device, such as an MP3 player or an iPod , to be ® plugged into the radio and utilize the vehicle’s sound system, using a 3.5 mm audio cable, to amplify the source and play through the vehicle speakers. •...
Page 106 ELECTRONICS iPod®/CD/AUX CONTROLS iPod®/CD/AUX Controls 1 — Repeat Music Track 5 — Music Track Information 2 — Music Track And Time 6 — Show Songs Currently In Cue To 3 — Shuffle Music Tracks Be Played 4 — Music Source 7 —...
Page 107 ELECTRONICS NAVIGATION (DEALER-ACTIVATED OPTION) Your Uconnect 8.4A is “Navigation-Ready”, and can be equipped with Navigation ® at an extra cost. Please see your dealer for details. The information in the section below is only applicable if the Navigation has been activated.
Page 108 ELECTRONICS Finding Points Of Interest (POI) From the main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Points of Interest” button on the touchscreen. • Select a Category and then a subcategory, if necessary. • Select your destination and press the “Yes” button on the touchscreen. Finding A Place By Spelling The Name From the Main Navigation Menu press the “Where to?”...
Page 109 ELECTRONICS Go Home A Home location must be saved in the system. From the Main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Go Home” button on the touchscreen. Uconnect® 8.4 Map 1 — Distance To Next Turn 5 —...
Page 110 ELECTRONICS Taking A Detour To take a detour you must be navigating a route. • Press the “Detour” button on the touchscreen. NOTE: If the route you are currently taking is the only reasonable option, the device might not calculate a detour. For more information, see your Uconnect Supplement Manual.
Page 111 ELECTRONICS Get Started 1. Visit UconnectPhone.com for mobile device and feature compatibility and to find phone pairing instructions. 2. Reduce background noise. Wind and passenger conversations are examples of noise that may impact recognition. 3. Speak clearly at a normal pace and volume while facing straight ahead. The microphone is positioned on the rearview mirror and aimed at the driver.
Page 112 ELECTRONICS Basic Voice Commands The basic Voice Commands below can be given at any point while using your Uconnect ® system. Push the VR button . After the beep, say: • Cancel to stop a current voice session • Help to hear a list of suggested Voice Commands •...
Page 113 ELECTRONICS Radio Use your voice to quickly get to the AM, FM or SiriusXM™ Satellite Radio stations ® you would like to hear. (Subscription or included SiriusXM™ Satellite Radio trial required.) Push the VR button . After the beep, say: •...
Page 114 ELECTRONICS Media Uconnect offers connections via USB, SD, Bluetooth and auxiliary ports (If ® ® Equipped). Voice operation is only available for connected USB and iPod ® devices. (Remote CD player optional and not available on all vehicles.) Push the VR button .
Page 115 ELECTRONICS Phone Making and answering hands-free phone calls is easy with Uconnect . When the ® Phonebook button is illuminated on your touchscreen, your system is ready. U.S. residents can visit: • UconnectPhone.com for mobile phone compatibility and pairing instructions. Canadian residents can visit: •...
Page 116 ELECTRONICS Climate (8.4A/8.4AN) Too hot? Too cold? Adjust vehicle temperatures hands-free and keep everyone comfortable while you keep moving ahead. (If vehicle is equipped with climate control.) Push the VR button . After the beep, say one of the following commands: •...
Page 117 ELECTRONICS Navigation (8.4A/8.4AN) The Uconnect navigation feature helps you save time and become more productive ® when you know exactly how to get to where you want to go. (Navigation is optional on the Uconnect ® 8.4A system. See your dealer to activate navigation at any time.) 1.
Page 118 ELECTRONICS Uconnect® Access — If Equipped (8.4A/8.4AN) An included trial and/or subscription is required to take advantage of the Uconnect ® Access services in the next section of this guide. To register with Uconnect ® Access, press the “Apps” button on the 8.4-inch touchscreen to get started. Detailed registration instructions can be found on the next page.
Page 119 ELECTRONICS Register (8.4A/8.4AN) 1. Press the “Apps” button on the bottom of the 8.4-inch touchscreen. 2. If a pop-up message appears, press “Register” or go to the “Favorite Apps” or “All Apps” menu and press “Uconnect® Registration.” 3. Read through the registration instructions. Enter and confirm your personal email address.
Page 120 ELECTRONICS Mobile App (8.4A/8.4AN) Securely link your mobile device to your vehicle with the Uconnect Access App. ® Once you have downloaded the App, you may start your vehicle or lock it from virtually any distance. (Vehicle must be properly equipped with factory-installed Remote Start.) Download the Uconnect ®...
Page 121 ELECTRONICS Voice Texting (8.4A/8.4AN) You must be registered with Uconnect Access and have a compatible MAP – ® enabled smartphone to use your voice to send a personalized text message. (Not compatible with iPhone ® 1. To send a message, push the Phone button .
Page 122 ELECTRONICS Yelp® (8.4A/8.4AN) Once registered with Uconnect Access, you can use your voice to search for the ® most popular places or things around you. 1. Push the VR button . After the beep, say: Launch YELP® 2. Once the YELP home screen appears on the touchscreen, push the VR button ®...
Page 123 ELECTRONICS SiriusXM Travel Link™ (8.4A/8.4AN — US Market Only) Need to find a gas station, view local movie listings, check a sports score or the 5 - day weather forecast? SiriusXM Travel Link™ is a suite of services that brings a wealth of information right to your Uconnect ®...
Page 124 ELECTRONICS Additional Information © 2015 FCA US LLC. All rights reserved. Mopar, Mopar Owner Connect and Uconnect are registered trademarks of FCA US LLC. Android is a trademark of Google Inc. SiriusXM and all related marks and logos are trademarks of SiriusXM Radio Inc. Yelp, Yelp logo, Yelp burst and related marks are registered trademarks of Yelp.
Page 125: Uconnect ® 8.4An
ELECTRONICS Uconnect® 8.4AN Uconnect® 8.4AN — If Equipped At A Glance Uconnect® 8.4AN 1 — Status Bar 6 — Uconnect ® Navigation Button 2 — View Small Navigation Map 7 — Climate Button 3 — HD Radio Available 8 — Controls Button 4 —...
Page 126 ELECTRONICS Setting The Time Model 8.4AN synchronizes time automatically via GPS, so it should not require any time adjustment. If you do need to set the time manually, follow the instructions below for Model 8.4A. 1. Turn the unit on, then press the “Time Display” at the top of the screen. Press “Yes.”...
Page 127 ELECTRONICS Equalizer To adjust the equalizer settings: 1. Press the “Media” or “Radio” button on the touchscreen. 2. Press the “Audio” button on the touchscreen to activate the Audio settings screen to adjust Balance/Fade, Equalizer and Speed Adjusted Volume. 3. Press the “Equalizer” button on the touchscreen to activate the Equalizer screen. 4.
Page 128 ELECTRONICS RADIO Uconnect® 8.4AN Radio 1 — Radio Station Presets 6 — Direct Tune To A Radio Station 2 — Toggle Radio Station Presets 7 — Seek Down 3 — HD Radio Available 8 — Browse And Manage Presets 4 — Audio Settings 9 —...
Page 129 ELECTRONICS Direct Tune • Tune directly to a radio station by pressing the “Tune” button on the screen, and entering the desired station number. Store Radio Presets Manually Your radio can store 36 total preset stations, 12 presets per band (AM, FM and SXM). They are shown at the top of your radio screen.
Page 130 ELECTRONICS Jump Jump automatically tells you when Traffic & Weather for a favorite city is available, and gives you the option to switch to that channel. • Press “Jump” to activate the feature. After listening to Traffic and Weather, press “Jump”...
Page 131 ELECTRONICS Replay Lets you replay up to 44 minutes of the content of the current SiriusXM channel. Replay Option Option Description Play/Pause Press to Pause content playback. Press Pause/Play again to re- sume playback. Rewind/RW Rewinds the channel content in steps of five seconds. Press and hold to rewind continuously, then release to begin playing content at that point.
Page 132 ELECTRONICS MEDIA HUB — PLAYING iPod®/USB/MP3 DEVICES There are many ways to play music from iPod /MP3 players or USB devices through ® your vehicle's sound system. • Press your “Media” button on the touchscreen to begin. USB Port • Connect your iPod ®...
Page 133 ELECTRONICS Audio Jack (AUX) • The AUX allows a portable device, such as an MP3 player or an iPod , to be ® plugged into the radio and utilize the vehicle’s sound system, using a 3.5 mm audio cable, to amplify the source and play through the vehicle speakers. •...
Page 134 ELECTRONICS iPod®/CD/AUX CONTROLS iPod®/CD/AUX Controls 1 — Repeat Music Track 5 — Music Track Information 2 — Music Track And Time 6 — Show Songs Currently In Cue To 3 — Shuffle Music Tracks Be Played 4 — Music Source 7 —...
Page 135 ELECTRONICS NAVIGATION Press the “Nav” button on the touchscreen in the menu bar to access the Navigation system. Changing The Navigation Voice Prompt Volume 1. Press the “Settings” button on the touchscreen. 2. In the Settings menu, press the “Guidance” button on the touchscreen. 3.
Page 136 ELECTRONICS Finding Points Of Interest (POI) From the main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Points” of Interest button on the touchscreen. • Select a Category and then a subcategory, if necessary. • Select your destination and press the “Yes” button on the touchscreen. Finding A Place By Spelling The Name From the Main Navigation Menu, press the “Where to?”...
Page 137 ELECTRONICS Go Home A Home location must be saved in the system. From the Main Navigation menu, press the “Where To?” button on the touchscreen, then press the “Go Home” button on the touchscreen. Uconnect® 8.4AN Map 1 — Distance To Next Turn 5 —...
Page 138 ELECTRONICS Taking A Detour To take a detour you must be navigating a route. • Press the “Detour” button on the touchscreen. NOTE: • If the route you are currently taking is the only reasonable option, the device might not calculate a detour. •...
Page 139 ELECTRONICS SiriusXM Travel Link feature is completely integrated into your vehicle. A few minutes after you start your vehicle, Travel Link information arrives and updates in the background. You can access the information whenever you like, with no waiting. To access SiriusXM Travel Link, press “Apps” button on the touchscreen, then press the “SiriusXM Travel Link”...
Page 140: Uconnect ® Phone
ELECTRONICS Uconnect® PHONE Uconnect® Phone (Bluetooth® Hands Free Calling) Uconnect® 5.0 Phone Menu 1 — Call/Redial/Hold 7 — Uconnect Phone Settings Menu ® 2 — Mobile Phone Signal Strength 8 — Text Messaging 3 — Currently Paired Mobile Phone 9 — Direct Dial Pad 4 —...
Page 141 ELECTRONICS Uconnect® 8.4A/8.4AN Phone Menu 1 — Favorite Contacts 11 — Recent Call Log 2 — Mobile Phone Battery Life 12 — Browse Phone Book Entries 3 — Currently Paired Mobile Phone (Contains 911) 4 — Mobile Phone Signal Strength 13 —...
Page 142 ELECTRONICS The hands-free calling feature is made possible through Bluetooth ® technology — the global standard that enables different electronic devices to connect to each other wirelessly. If the Uconnect Phone Button exists on your steering wheel, you then have the ®...
Page 143 ELECTRONICS Start Pairing Procedure On The Radio Uconnect® 5.0: 1. Place the ignition in the ACC or ON position. 2. Press the “Phone” button. 3. Select “Settings.” 4. Select “Paired Phones.” 5. Select “Add device.” • Uconnect Phone will display an ®...
Page 144 ELECTRONICS Complete The iPhone® Pairing Procedure: 1. When prompted on the mobile phone, accept the connection request from Uconnect ® Phone. NOTE: Some mobile phones will require you to enter the PIN number. Pairing Request Select The iPhone's Priority Level When the pairing process has successfully completed, the system will prompt you to choose whether or not this is your favorite mobile phone.
Page 145 ELECTRONICS Complete The Android Pairing Procedure: 1. Confirm the passkey shown on the mobile phone matches the passkey shown on the Uconnect system then accept the Bluetooth pairing re- ® quest. NOTE: Some mobile phones require the PIN to be entered manually, enter the PIN num- ber shown on the Uconnect screen.
Page 146 ELECTRONICS Common Phone Commands (Examples) • “Call John Smith” • “Call John Smith mobile” • “Dial 1 248 555 1212” • “Redial” Mute (Or Unmute) Microphone During Call • During a call, press the “Mute” button on the Phone main screen to mute and unmute the call.
Page 147 ELECTRONICS NOTE: To access help, push the Uconnect ® Phone button on the steering wheel and say "help." Press the display or press either the Phone or VR button and say "cancel" to cancel the help session. Incoming Text Messages After pairing your Uconnect ®...
Page 148 ELECTRONICS Android Devices 1. Push the Menu button on the mobile phone. 2. Select Settings. 3. Select Connections. 4. Turn “Show Notifications” to On. • A pop up will appear asking you to accept a request for permission to connect to your messages.
Page 149 ELECTRONICS Here’s How: 1. Push the Uconnect ® Phone button and wait for the beep, then say “reply.” Uconnect will give the following prompt: “Please say the message you would like ® to send.” 2. Wait for the beep and say one of the pre-defined messages. (If you are not sure, you can say “help”).
Page 150: Steering Wheel Audio Controls
ELECTRONICS Mobile Phonebook didn’t download: • Check “Do not ask again,” then accept the “phonebook download” request on your mobile phone. • Up to 5,000 contact names with four numbers per contact will transfer to the Uconnect ® 8.4A/8.4AN system phonebook. •...
Page 151: Center (Evic) And Driver Information Display (Did)
ELECTRONICS ELECTRONIC VEHICLE INFORMATION CENTER (EVIC) AND DRIVER INFORMATION DISPLAY (DID) Your vehicle may be equipped with one of the following vehicle information systems: • Electronic Vehicle Information Center (EVIC). • Driver Information Display (DID). The EVIC/DID features a driver interac- tive display that is located in the instru- ment cluster.
Page 152: Programmable Features
ELECTRONICS PROGRAMMABLE FEATURES Uconnect® Customer Programmable Features The Uconnect system allows you to access Customer Programmable feature ® settings such as Display, Voice, Clock, Safety & Driving Assistance, Lights, Doors & Locks, Auto-On Comfort & Remote Start, Engine Off Options, Compass Settings, Audio, Phone/Bluetooth , SiriusXM Setup and System Information through buttons ®...
Page 153 ELECTRONICS Before You Begin Programming HomeLink® Ensure that your vehicle is parked outside of the garage before you begin program- ming. For efficient programming and accurate transmission of the radio-frequency signal, it is recommended that a new battery be placed in the hand-held transmitter of the device that is being programmed to the HomeLink ®...
Page 154 ELECTRONICS 6. Return to the vehicle and push the programmed HomeLink ® button twice (holding the button for two seconds each time). If the device is plugged in and activates, programming is complete. NOTE: If the device does not activate, push the button a third time (for two seconds) to complete the training.
Page 155: Power Inverter
ELECTRONICS WARNING! • Your motorized door or gate will open and close while you are programming the universal transceiver. Do not program the transceiver if people or pets are in the path of the door or gate. • Do not run your vehicle in a closed garage or confined area while programming the transceiver.
Page 156: Power Outlet
ELECTRONICS POWER OUTLET There are three 12 Volt electrical power outlets on this vehicle. The front 12 Volt power outlet is located below the climate controls in the Center Console Media Center, and is powered when the ignition switch is in the ON/RUN position.
Page 157 ELECTRONICS There is also a 12 Volt power outlet located in the rear cargo area of the vehicle. This power outlet has power available directly from the battery (power available at all times). Items plugged into this outlet also may discharge the battery and/or prevent the engine from starting.
Page 158: Wireless Charging Pad
ELECTRONICS WIRELESS CHARGING PAD Wireless Charging Pad — If Equipped Your vehicle may be equipped with a wireless charging pad located inside the upper portion of the center console. This charging pad is designed to wirelessly charge your Qi enabled mobile phone. Qi is a standard that uses magnetic induction to transfer power to your mobile device.
Page 159 ELECTRONICS 4. Use the adjustable cradle to hold the mobile phone in position. The cradle moves by pushing down on the finger tabs and moving the cradle in or out. NOTE: The initial adjustment will only need to be done once as long as only one mobile phone is used.
Page 160: Four-Wheel Drive Operation
OFF-ROAD CAPABILITIES FOUR-WHEEL DRIVE OPERATION 1–SPEED FOUR-WHEEL DRIVE (4X4) This feature provides on-demand Four-Wheel Drive (4X4) with no driver inputs or additional driving skills required. Under normal driving conditions, the front wheels provide most of the traction. If the front wheels begin to lose traction, power is shifted automatically to the rear wheels.
Page 161 OFF-ROAD CAPABILITIES Shifting Procedures 4X4 HI To 4X4 LOW With the vehicle at speeds of 0 to 3 mph (0 to 5 km/h), the ignition switch in the ON position or the engine running, shift the transmission into NEUTRAL, and press the “4WD LOW”...
Page 162 OFF-ROAD CAPABILITIES 11. Shift the transmission to NEUTRAL. 12. Apply the parking brake. NOTE: Repeat these Steps to shift out of NEUTRAL. REAR ELECTRONIC LOCKER (E-LOCKER) SYSTEM • The Rear E-Locker System features a mechanical locking rear differential to provide better traction in the 4WD LOW position. The “REAR LOCK” button is on the Selec-Terrain Knob Activating The Rear E-Locker To activate the Rear E-Locker System, the following conditions must be met:...
Page 163: Selec-Terrain
OFF-ROAD CAPABILITIES SELEC-TERRAIN™ • Selec-Terrain™ combines the capa- bilities of the vehicle control systems, along with driver input, to provide the best performance for all terrains. Rotate the mode control knob to select the following Selec-Terrain™ positions: • Auto — Fully automatic full time four- wheel drive operation can be used on and off road.
Page 164: Cargo Area Features
UTILITY CARGO AREA FEATURES • The cargo load floor system has a load capacity of 400 lbs (181 kg). The load floor has a built-in storage bin that can hold a variety of items. The underside of the storage bin cover also contains a plastic-lined tray. The cover can be installed with either side facing up for added utility.
Page 165: Recreational Towing (Behind Motorhome, Etc.)
UTILITY RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle 4X4 Models Front-Wheel Towing Con- Wheels OFF the 1-Speed Power 2-Speed Power Drive (FWD) dition Ground Transfer Unit Transfer Unit Models See Instructions: • Transmission in PARK Flat Tow NONE NOT ALLOWED NOT ALLOWED...
Page 166 UTILITY Recreational Towing — 4X4 Models With 1-Speed Power Transfer Unit Recreational towing is not allowed. These models do not have a NEUTRAL (N) position in the power transfer unit. NOTE: This vehicle may be towed on a flatbed or vehicle trailer provided all four wheels are OFF the ground.
Page 167 UTILITY Shifting Into NEUTRAL (N) WARNING! You or others could be injured or killed if you leave the vehicle unattended with the power transfer unit in the NEUTRAL (N) position without first fully engaging the parking brake. The NEUTRAL (N) position disengages both the front and rear driveshafts from the powertrain and will allow the vehicle to roll, even if the transmission is in PARK.
Page 168 UTILITY 14. Attach the vehicle to the tow vehicle using a suitable tow bar. 15. Release the parking brake. NOTE: • Steps 1 through 5 are requirements that must be met before pressing the NEUTRAL (N) button, and must continue to be met until the shift has been completed.
Page 169 UTILITY 9. Shift the transmission into PARK. 10. Release the brake pedal. 11. Disconnect vehicle from the tow vehicle. 12. Start the engine. 13. Press and hold the brake pedal. 14. Release the parking brake. 15. Shift the transmission into DRIVE, release the brake pedal, and check that the vehicle operates normally.
Page 170: Roadside Assistance
WHAT TO DO IN EMERGENCIES ROADSIDE ASSISTANCE Dial toll-free 1-800-521-2779 for U.S. Residents or 1-800-363-4869 for Canadian Residents. • Provide your name, vehicle identification number, license plate number, and your location, including the telephone number from which you are calling. •...
Page 171 WHAT TO DO IN EMERGENCIES If the ABS light is on, the brake system should be serviced as soon as possible to restore the benefits of Anti-Lock brakes. If the ABS light does not turn on when the ignition switch is turned to the ON/RUN position, have the light inspected by an authorized dealer.
Page 172 WHAT TO DO IN EMERGENCIES IF THE LIGHT STARTS FLASHING INDICATING A LOW TIRE PRESSURE, ADJUST THE AIR PRESSURE IN THE LOW TIRE TO THE AIR PRESSURE SHOWN ON THE VEHICLE PLACARD OR TIRE INFLATION PRESSURE LABEL LOCATED ON THE DRIVER'S DOOR. NOTE: After inflation, the vehicle may need to be driven for 20 minutes before the flashing light will turn off.
Page 173 WHAT TO DO IN EMERGENCIES - Engine Temperature Warning Light • This light warns of an overheated engine condition. • If the light turns on and a warning chime sounds while driving, safely pull over and stop the vehicle. If the A/C system is on, turn it off. Also, shift the transmission into NEUTRAL and idle the vehicle.
Page 174 WHAT TO DO IN EMERGENCIES – Brake Warning Light This light monitors various brake functions, including brake fluid level and parking brake application. If the brake light turns on, it may indicate that the parking brake is applied, that the brake fluid level is low, or that there is a problem with the anti-lock brake system reservoir.
Page 175 WHAT TO DO IN EMERGENCIES - Malfunction Indicator Light (MIL) The Malfunction Indicator Light (MIL) is part of an onboard diagnostic system called OBD II that monitors engine and automatic transmission control systems. The light will illuminate when the key is in the ON/RUN position before engine start. If the bulb does not come on when turning the key from OFF to ON/RUN, have the condition checked promptly.
Page 176 WHAT TO DO IN EMERGENCIES Oil Life Reset • Your vehicle is equipped with an engine oil change indicator system. The “Oil Change Due” message will flash in the EVIC display for approximately 10 seconds after a single chime has sounded to indicate the next scheduled oil change interval.
Page 177: Instrument Cluster Indicator Lights
WHAT TO DO IN EMERGENCIES INSTRUMENT CLUSTER INDICATOR LIGHTS - Stop/Start Indicator — If Equipped This icon indicates that the Stop/Start System is active. Whenever the system is active, the telltale will illuminate in the instrument cluster. Refer to “Stop Start System”...
Page 178 WHAT TO DO IN EMERGENCIES - Adaptive Cruise Control (ACC) ON Indicator • If your vehicle is equipped with adaptive cruise control, the controls operate exactly the same as the normal (fixed speed) cruise control with one difference. You can set a specified distance you would like to maintain between you and the vehicle in front of you.
Page 179 WHAT TO DO IN EMERGENCIES – Hill Descent Control Indicator — If Equipped This indicator will illuminate when Hill Descent Control (HDC) has been selected using the Hill Descent Control Switch. – Park/Headlight ON Indicator This indicator will illuminate when the park lights or headlights are turned on. –...
Page 180: If Your Engine Overheats
WHAT TO DO IN EMERGENCIES IF YOUR ENGINE OVERHEATS In any of the following situations, you can reduce the potential for overheating by taking the appropriate action: • On the highways — slow down. • In city traffic — while stopped, shift the transmission to NEUTRAL, but do not increase engine idle speed.
Page 181 WHAT TO DO IN EMERGENCIES TIRE SERVICE KIT STORAGE • The Tire Service Kit is located in the cargo compartment behind the rear seat underneath the load floor. Tire Service Kit Components And Operation Using The Mode Select Knob And Hoses Your Tire Service Kit is equipped with the following symbols to indicate the air or sealant mode.
Page 182 WHAT TO DO IN EMERGENCIES • For optimum performance, make sure the valve stem on the wheel is free of debris before connecting the Tire Service Kit. • You can use the Tire Service Kit air pump to inflate bicycle tires. The kit also comes with two needles, located in the Accessory Storage Compartment (on the bottom of the air pump) for inflating sport balls, rafts, or similar inflatable items.
Page 183 WHAT TO DO IN EMERGENCIES (C) Injecting Tire Service Kit Sealant Into The Deflated Tire: Always start the engine before turning ON the Tire Service Kit. NOTE: Manual transmission vehicles must have the parking brake engaged and the shift lever in NEUTRAL. After pushing the Power Button (4), the sealant (white fluid) will flow from the Sealant Bottle (1) through the Sealant Hose (6) and into the tire.
Page 184 WHAT TO DO IN EMERGENCIES If the tire does not inflate to at least 26 psi (1.8 Bar) pressure within 15 minutes: The tire is too badly damaged. Do not attempt to drive the vehicle further. Call for assistance. NOTE: If the tire becomes over-inflated, push the Deflation Button to reduce the tire pressure to the recommended inflation pressure before continuing.
Page 185 WHAT TO DO IN EMERGENCIES 4. Have the tire inspected and repaired or replaced at the earliest opportunity at an authorized dealer or tire service center. 5. Remove the Speed Limit sticker from the instrument panel after the tire has been repaired.
Page 186 WHAT TO DO IN EMERGENCIES WARNING! • Do not attempt to seal a tire on the side of the vehicle closest to traffic. Pull far enough off the road to avoid the danger of being hit when using the Tire Service Kit.
Page 187: Jacking And Tire Changing
WHAT TO DO IN EMERGENCIES JACKING AND TIRE CHANGING Jack Location • The scissor-type jack and tire changing tools are located in the cargo compartment behind the rear seat underneath the load floor. Spare Tire Stowage • The spare tire is stowed underneath the rear cargo load floor behind the rear seat along with the jack and wheel chocks.
Page 188 WHAT TO DO IN EMERGENCIES Jacking Instructions 1. Remove spare tire. Warning Label 2. Remove spare tire, jack and tools from storage. Jacking Locations...
Page 189 WHAT TO DO IN EMERGENCIES 3. Loosen (but do not remove) the wheel lug bolts by turning them to the left one turn while the wheel is still on the ground. 4. For the front tires, place the jack on the body flange just behind the front tire as indicated by the triangular lift point symbol on the sill molding.
Page 190 WHAT TO DO IN EMERGENCIES 9. Position the spare wheel/tire on the vehicle and install lug bolts with the cone-shaped end toward the wheel. Lightly tighten the bolts. 10. Lower the vehicle by turning the jack screw to the left, and remove the jack. 11.
Page 191 WHAT TO DO IN EMERGENCIES WARNING! • Being under a jacked-up vehicle is dangerous. The vehicle could slip off the jack and fall on you. You could be crushed. Never put any part of your body under a vehicle that is on a jack. If you need to get under a raised vehicle, take it to a service center where it can be raised on a lift.
Page 192: Jump-Starting
WHAT TO DO IN EMERGENCIES JUMP-STARTING • If your vehicle has a discharged battery it can be jump-started using a set of jumper cables and a battery in another vehicle or by using a portable battery booster pack. • Jump-starting can be dangerous if done improperly so please follow the proce- dures in this section carefully.
Page 193 WHAT TO DO IN EMERGENCIES Jump-Starting Procedure 1. Connect the positive (+) end of the jumper cable to the positive (+) post of the vehicle with the discharged battery. 2. Connect the opposite end of the positive (+) jumper cable to the positive (+) post of the booster battery.
Page 194 WHAT TO DO IN EMERGENCIES CAUTION! • Do not use a portable battery booster pack or any other booster source with a system voltage greater than 12 Volts or damage to the battery, starter motor, alternator or electrical system may occur. •...
Page 195: Freeing A Stuck Vehicle
WHAT TO DO IN EMERGENCIES FREEING A STUCK VEHICLE • If your vehicle becomes stuck in mud, sand or snow, it can often be moved by a rocking motion. Turn your steering wheel right and left to clear the area around the front wheels.
Page 196: Recovery Strap
WHAT TO DO IN EMERGENCIES RECOVERY STRAP • Your vehicle may be included with a recovery strap. Recovery straps do not act like traditional tow straps, chains, or winch cables. Using Recovery Strap 1. Review all warnings and instructions first. 2.
Page 197: Shift Lever Override
WHAT TO DO IN EMERGENCIES SHIFT LEVER OVERRIDE • If a malfunction occurs and the shift lever cannot be moved out of the PARK position, you can use the following procedure to temporarily move the shift lever: • Turn the engine OFF. •...
Page 198: Event Data Recorder (Edr)
WHAT TO DO IN EMERGENCIES EVENT DATA RECORDER (EDR) This vehicle is equipped with an Event Data Recorder (EDR). The main purpose of an EDR is to record, in certain crash or near crash-like situations, such as an air bag deployment or hitting a road obstacle, data that will assist in understanding how a vehicle’s systems performed.
Page 199: Opening The Hood
MAINTAINING YOUR VEHICLE OPENING THE HOOD 1. Pull the hood release lever located under the left side of the instrument panel. 2. Move to the outside of the vehicle, raise the hood and locate the safety latch behind the center front edge of the hood. 3.
Page 200: Engine Compartment
MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT 2.4L Engine 1. Engine Coolant Reservoir 2. Engine Oil Fill 3. Brake Fluid Reservoir 4. Battery Terminals (Jump Starting) 5. Battery...
Page 201 MAINTAINING YOUR VEHICLE 6. Power Distribution Center (Fuses) 7. Washer Fluid Reservoir 8. Engine Oil Dipstick 9. Air Cleaner Filter...
Page 202 MAINTAINING YOUR VEHICLE 3.2L Engine 1. Engine Coolant Reservoir 2. Engine Oil Fill 3. Brake Fluid Reservoir 4. Battery Terminals (Jump Starting) 5. Battery...
Page 203 MAINTAINING YOUR VEHICLE 6. Power Distribution Center (Fuses) 7. Washer Fluid Reservoir 8. Engine Oil Dipstick 9. Air Cleaner Filter...
Page 204: Fluid Capacities
MAINTAINING YOUR VEHICLE FLUID CAPACITIES U.S. Metric Fuel (Approximate) 2.4L and 3.2L Engines 15.8 Gallons 60 Liters Engine Oil With Filter 2.4 Liter Engine (SAE 0W-20, 5.5 Quarts 5.2 Liters API Certified) 3.2 Liter Engine (SAE 5W-20, 6 Quarts 5.6 Liters API Certified) Cooling System* 2.4 Liter Engine (MOPAR...
Page 205 MAINTAINING YOUR VEHICLE CAUTION! • Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Technology (HOAT) engine coolant (antifreeze) or any “globally compatible”...
Page 206: Maintenance Procedures
MAINTAINING YOUR VEHICLE MAINTENANCE PROCEDURES For information on the maintenance procedures for your vehicle, please refer to “Maintenance Procedures” in “Maintaining Your Vehicle” in your Owner’s Manual or applicable supplement on the DVD for further details. MAINTENANCE SCHEDULE Your vehicle is equipped with an automatic oil change indicator system. The oil change indicator system will remind you that it is time to take your vehicle in for scheduled maintenance.
Page 207 MAINTAINING YOUR VEHICLE Severe Duty All Models Change Engine Oil at 4000 miles (6,500 km) if the vehicle is operated in a dusty and off road environment. This type of vehicle use is considered Severe Duty. Once A Month Or Before A Long Trip: •...
Page 208 MAINTAINING YOUR VEHICLE...
Page 209 MAINTAINING YOUR VEHICLE...
Page 210: Fuses
MAINTAINING YOUR VEHICLE FUSES Power Distribution Center The Power Distribution Center is located in the engine compartment near the battery. This center contains cartridge fuses, mini-fuses and relays. A label that identifies each component is printed on the inside of the cover. Cavity Blade Fuse Cartridge Fuse...
Page 211 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description – 30 Amp Pink Fuel Heater - Diesel Only – – Not Used 15 Amp Blue – Transmission Control Module (TCM) – – Not Used 10 Amp Red – Engine Control Module (ECM)/ (EPS)/(PCM) –...
Page 212 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description – 30 Amp Pink Brake System Module & Valves – 30 Amp Pink Body Control Module (BCM) Feed 3 10 Amp Red – Blind Spot Sensors / Compass / Rearview Camera / Trunk Lamp With Flashlamp Charger - If Equipped 15 Amp Blue...
Page 213 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description 5 Amp Tan – Intelligent Battery Sensor If Equipped with Stop/Start Engine Option 20 Amp Yellow – HID Headlamp Right if Equipped with Stop/Start Engine Option 10 Amp Red – Heated Mirrors - If Equipped –...
Page 214 MAINTAINING YOUR VEHICLE Cavity Blade Fuse Cartridge Fuse Description – 30 Amp Pink Electric Park Brake (EPB) - Right 10 Amp Red – Electrochromatic Mirror / Rain Sensor / Sunroof - If Equipped / Passenger Window Switch / Power Outlet Console 10 Amp Red –...
Page 215: Adding Fuel
MAINTAINING YOUR VEHICLE ADDING FUEL The gas cap is located behind the fuel filler door, on the passenger side of the vehicle. If the gas cap is lost or damaged, be sure the replacement cap has been designed for use with this vehicle. NOTE: When removing the fuel filler cap, lay the cap tether in the hook, located on the fuel filler door reinforcement.
Page 216 MAINTAINING YOUR VEHICLE CAUTION! • Damage to the fuel system or emission control system could result from using an improper fuel filler cap. A poorly fitting cap could let impurities into the fuel system. Also, a poorly fitting aftermarket cap can cause the “Malfunction Indicator Light (MIL)”...
Page 217: Tire Pressures
MAINTAINING YOUR VEHICLE TIRE PRESSURES Check the inflation pressure of each tire, including the spare tire (if equipped), at least monthly and inflate to the recommended pressure for your vehicle. The tire pressures recommended for your vehicle are found on the “Tire and Loading Information”...
Page 218: Spare Tires — If Equipped
MAINTAINING YOUR VEHICLE SPARE TIRES — IF EQUIPPED NOTE: For vehicles equipped with Tire Service Kit instead of a spare tire, please refer to “Tire Service Kit” in “What To Do In Emergencies” on your DVD for further information. CAUTION! Because of the reduced ground clearance, do not take your vehicle through an automatic car wash with a compact or limited-use temporary spare installed.
Page 219: Wheel And Wheel Trim Care
MAINTAINING YOUR VEHICLE Full Size Spare — If Equipped The full size spare is for temporary emergency use only. This tire may look like the originally equipped tire on the front or rear axle of your vehicle, but it is not. This spare tire may have limited tread life.
Page 220: Replacement Bulbs
MAINTAINING YOUR VEHICLE REPLACEMENT BULBS Interior Bulbs Bulb Number Cargo Lamp TL212–2 Overhead Console Lamp PLW214–2A Reading Lamp WL212–2 Exterior Bulbs Bulb Number Low Beam/High Beam (Bi-Halogen) HIR2LL Headlamps Low Beam/High Beam (Bi-Xenon) Head- D3S (Serviced at an Authorized Dealer) lamps Front Park/Daytime Running Lamps LED (Serviced at an Authorized Dealer)
Page 221: Fca Us Llc Customer Center
CUSTOMER ASSISTANCE FCA US LLC CUSTOMER CENTER P.O. Box 21–8004 Auburn Hills, MI 48321–8004 Phone: 1-877-426-5337 FCA CANADA INC. CUSTOMER CENTER P.O. Box 1621 Windsor, Ontario N9A 4H6 Phone: 1-800-465-2001 (English) Phone: 1-800-387-9983 (French) ASSISTANCE FOR THE HEARING IMPAIRED To assist customers who have hearing difficulties, the manufacturer has installed special TDD (Telecommunication Devices for the Deaf) equipment at its customer center.
Page 222: Publications Ordering
Warranty Booklet. United States customers may visit the Jeep Contact Us page at www.jeep.com scroll to the bottom of the page and select the “Contact Us” link, then select the “Owner’s Manual and Glove Box Material” from the left menu.
Page 223: Mopar
MOPAR® ACCESSORIES AUTHENTIC ACCESSORIES BY MOPAR® • The following highlights just some of the many Authentic Jeep Accessories by MOPAR ® featuring a fit, finish, and functionality specifically for your Jeep Cherokee. • In choosing Authentic Accessories you gain far more than expressive style, premium protection, or extreme entertainment, you also benefit from enhancing your vehicle with accessories that have been thoroughly tested and factory-approved.
Page 224: Frequently Asked Questions
FAQ’s FREQUENTLY ASKED QUESTIONS GETTING STARTED How do I install my LATCH Equipped Child Seat? pg. 28 How do I program my Front Seat Memory? pg. 32 ELECTRONICS Which radio is in my vehicle? • Uconnect ® 5.0 pg. 84 •...
Page 225 How do I shift into different four-wheel drive selections? pg. 158 UTILITY How do I know how much I can tow with my Jeep Cherokee? pg. 162 WHAT TO DO IN EMERGENCIES What do I do if my TPMS warning light is blinking? pg. 169 How do I change a flat tire? pg.
Page 226: Index
INDEX Adaptive Cruise Control (ACC) (Cruise Brake System ... . .204 Control)....43 Fluid Check ... .203 Adding Engine Coolant Master Cylinder .
Page 227 INDEX Cooling System ... .204 Cooling ....204 Adding Coolant (Antifreeze) . .204 Malfunction Indicator (Check Coolant Capacity ..202 Engine) .
Page 228 INDEX Fuses....208 Arm The Alarm ...12 Disarm The Alarm ..12 Gas Cap (Fuel Filler Cap) .
Page 229 INDEX Oil, Engine ...202, 204 Shifting Out Of Power Transfer Unit Neutral (N) ... .166 Capacity ....202 Shifting Out Of Transfer Case Change Interval .
Page 230 INDEX Specifications Turn Signals ...38, 175 Fuel (Gasoline) ..202 Uconnect ® Oil ....202 Set Up Your Via Mobile Profile .
Page 231 NOTES...
Page 232 NOTES...
Page 233 NOTES...
Page 234 NOTES...
Page 235 This guide has been prepared to help you get quickly acquainted with your new Jeep and to provide a convenient reference source for common questions. However, it is not a substitute for your Owner’s Manual. For complete operational instructions, maintenance procedures and important safety messages, please consult your Owner’s Manual, Navigation/Uconnect®...
Page 236 Jeep.com (U.S.) Jeep.ca (Canada) Download a FREE electronic copy of the Owner’s Manual and Warranty Booklet by visiting: www.jeep.com/en/owners/manuals or www.jeep.com/en/warranty (U.S.); www.owners.mopar.ca/en (Canada). Jeep and Cherokee are registered trademarks of FCA US LLC. ® 15KL74-926-AA Jeep Cherokee Fourth Edition Rev 1...

Jeep Cherokee 2015 User Manual

Introduction/Welcome

Controls at a Glance

Getting Started

Operating Your Vehicle

Off-Road Capabilities

Utility

What to Do in Emergencies

Quick Links

Related Manuals for Jeep Cherokee 2015

Summary of Contents for Jeep Cherokee 2015

Table of Contents
