Summary of Contents for Jeep CHEROKEE 2017

  • Page 1 CHE RO K E E U S ER G U I D E 2 01 7...
  • Page 2 If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Owner’s Manual, Navigation/ Uconnect Manuals or Warranty Booklets by calling 1 877 426-5337 (U.S.) or 1 800 387-1143 (Canada) or by contacting your dealer. Important: The driver’s primary responsibility the vehicle is moving is dangerous...
  • Page 3 When it comes to service, remember that your This User Guide has been prepared to help eyes from the road or your attention from authorized dealer knows your Jeep ® vehicle you quickly become acquainted with the im- driving.
  • Page 4: How To Use This Manual

    HOW TO USE THIS MANUAL Chapters can be rapidly identified with dedi- Do not attempt sharp turns, abrupt maneu- cated graphic tabs, at the side of each odd vers, or other unsafe driving actions that can Essential Information page. A few pages further there is a key for cause loss of vehicle control.
  • Page 5: Warnings And Cautions

    WARNINGS AND CAUTIONS VEHICLE CHANGES/ ALTERATIONS While reading this User Guide you will find a series of WARNINGS to prevent procedures IMPORTANT: Any change or alteration of the that could damage your vehicle. vehicle might seriously affect its safety and There are also CAUTIONS that must be care- road holding, thus causing accidents, in fully followed to prevent incorrect use of the...
  • Page 7 GRAPHICAL TABLE OF CONTENTS GETTING TO KNOW YOUR VEHICLE GETTING TO KNOW YOUR INSTRUMENT PANEL SAFETY STARTING AND OPERATING IN CASE OF EMERGENCY SERVICING AND MAINTENANCE TECHNICAL SPECIFICATIONS MULTIMEDIA CUSTOMER ASSISTANCE INDEX...
  • Page 9 GRAPHICAL TABLE OF CONTENTS GRAPHICAL TABLE OF CONTENTS INSTRUMENT PANEL...8 INTERIOR ....9...
  • Page 10 INSTRUMENT PANEL Instrument Panel 1 — Air Vents 4 — Instrument Cluster 2 — Multifunction Lever 5 — Windshield Wiper Lever 3 — Steering Wheel 6 — Glove/Storage Compartment...
  • Page 11 INTERIOR Interior Features 1 — Power Window Switches 4 — Switch Bank 7 — Seats 2 — Ignition Start/Stop Button 5 — Climate Controls 3 — Uconnect Radio 6 — Gear Selector...
  • Page 13: Table Of Contents

    GETTING TO KNOW YOUR VEHICLE GETTING TO KNOW YOUR VEHICLE KEYS .....13 Child-Protection Door Lock System — EXTERIOR LIGHTS... .35 Rear Doors .
  • Page 14 CLIMATE CONTROLS ..40 POWER SUNROOF ...60 UNIVERSAL GARAGE DOOR OPENER (HomeLink) ..66 Manual Climate Control Without A Opening.
  • Page 15: Keys

    “Uconnect Settings” in “Multimedia” in your 4 — Remote Start NOTE: 5 — Panic Owner’s Manual at www.jeep.com/en/owners/ In case the ignition switch does not change manuals/ for further information. with the push of a button, the key fob may have a low or dead battery.
  • Page 16: Ignition Switch

    Vehicles Equipped With Keyless Enter-N-Go — Duplication of key fobs may be performed at NOTE: Passive Entry an authorized dealer. This procedure consists Changes or modifications not expressly ap- of programming a blank key fob to the vehicle proved by the party responsible for compli- If one or more doors are open, or the liftgate electronics.
  • Page 17 WARNING! • Driving position. could operate power windows, other con- • All the electrical devices are available. trols, or move the vehicle. • Do not leave children or animals inside NOTE: parked vehicles in hot weather. Interior The vehicle will not start if the key fob is heat build-up may cause serious injury located inside the cargo area and the liftgate or death.
  • Page 18: Remote Starting System - If Equipped

    REMOTE STARTING 2. This device must accept any interference All of the key fobs provided with your new vehicle have been programmed to the vehicle received, including interference that may SYSTEM — IF EQUIPPED electronics. cause undesired operation. • Push the remote start button on the key General Information NOTE: fob twice within five seconds.
  • Page 19: Irregular Operation

    Know Your Vehicle" in your Owner’s • The horn will pulse seconds for a bulb check. If the light remains manual at www.jeep.com/en/owners/ • The turn signals will flash on after the bulb check, it indicates that manuals/ for further information.
  • Page 20: To Disarm The System

    To Know Your Vehicle" in your Owner’s arming sequences has occurred, the vehicle rotate the door lock button until the red Manual www.jeep.com/en/owners/ security alarm will arm regardless of whether indicator is visible. To unlock the rear doors, manuals/ for further information.
  • Page 21: Power Door Locks

    Power Door Locks WARNING! The power door lock switches are located on • When exiting the vehicle, always remove each front door panel. Push the switch to lock the key fob from the vehicle and lock or unlock the doors. your vehicle.
  • Page 22: Keyless Enter-N-Go - Passive Entry

    “Uconnect Settings” in “Multimedia door automatically. At the third attempt, the doors will lock even in the Owner’s Manual on www.jeep.com/en/ if the key is inside. owners/manuals for further information.
  • Page 23 To Unlock From The Passenger Side FOBIK-Safe only executes in vehicles with NOTE: passive entry. There are three situations that The vehicle will only unlock the doors when a With a valid Passive Entry key fob within 5ft trigger a FOBIK-Safe search in any passive valid Passive Entry key fob is detected inside (1.5m) of the passenger door handle, grab entry vehicle:...
  • Page 24 NOTE: To Lock The Vehicle’s Doors And Liftgate The liftgate passive entry lock button will lock With one of the vehicle’s Passive Entry key all doors and the liftgate. The liftgate unlock fob within 5ft (1.5m) of the driver or passen- feature is built into the electronic liftgate ger front door handles, push the Passive release.
  • Page 25: Locking The Doors With One Or More Doors Open

    • If Passive Entry is disabled using the NOTE: To use the system, open each rear door, use a flat blade screwdriver (or emergency key) and Uconnect System, the key protection de- Changes or modifications not expressly ap- rotate the dial to the lock or unlock position. scribed in "Preventing Inadvertent Locking proved by the party responsible for compli- When the system on a door is engaged, that...
  • Page 26: Seats

    SEATS WARNING! Manual Seat Adjustment • Adjusting a seat while driving may be dangerous. Moving a seat while driving Manual Front Seat Forward/Rearward Ad- could result in loss of control which justment could cause a collision and serious in- jury or death. On models equipped with manual seats, the •...
  • Page 27: Power Adjustment Front - If Equipped

    Manual Recline WARNING! To adjust the seatback, lift the lever located Do not ride with the seatback reclined so on the outboard side of the seat, lean back to that the shoulder belt is no longer resting the desired position and release the lever. To against your chest.
  • Page 28: Manual Adjustment Rear

    Manual Adjustment Rear Recliner Adjustment The rear seatback also reclines for additional Rear Seat Forward/Rearward Adjustment — passenger comfort. Pull on the pull strap If Equipped while sitting in the rear seat to recline the Lift up on the adjusting bar located at the seatback.
  • Page 29: Heated/Ventilated Seats

    “Uconnect Settings” in “Multimedia” in time to turn the heating elements OFF. the Owner's Manual on www.jeep.com/en/ NOTE: If the HI-level setting is selected, the system owners/manuals/ for further details. The Easy Entry/Exit feature is not enabled...
  • Page 30: Head Restraints

    “Multimedia” in the Owner’s exercise care when using the seat ambient temperatures. The fans operate at Manual on www.jeep.com/en/owners/manuals/ heater. It may cause burns even at low two speeds, HI and LO. temperatures, especially if used for long for further details.
  • Page 31: Front Adjustment

    To raise the head restraint, pull upward on the WARNING! WARNING! head restraint. To lower the head restraint, • Head restraints should never be ad- push the adjustment button, located at the • A loose head restraint thrown forward in justed while the vehicle is in motion.
  • Page 32: Rear Adjustment

    remove the head restraint. To reinstall the WARNING! head restraint, put the head restraint posts Active Head Restraint during sudden into the holes and push downward. Then, stops. Failure to follow this warning adjust the head restraint to the appropriate could cause personal injury if the Active height.
  • Page 33: Rear Removal

    NOTE: STEERING WHEEL For proper routing of a Child Seat Tether, refer Adjustment to “Occupant Restraint Systems” in “Safety” for further information. This feature allows you to tilt the steering Rear Removal column upward or downward. It also allows you to lengthen or shorten the steering col- To remove the head restraint, raise it as far as umn.
  • Page 34: Heated Steering Wheel

    To lock the steering column in heated steering wheel can shut off early or may Owner’s Manual www.jeep.com/en/ position, push the control handle upward not turn on when the steering wheel is already owners/manuals/ for further details. until fully engaged.
  • Page 35: Mirrors

    MIRRORS Electrochromic Mirror NOTE: The automatic dimming feature is disabled A single ball joint mirror is provided in the Interior Mirrors when the vehicle is in REVERSE to improve vehicle. It is a twist on mirror that has a fixed rear view viewing.
  • Page 36: Exterior Mirrors

    Exterior Mirrors WARNING! Power Mirrors Vehicles and other objects seen in an out- side convex mirror will look smaller and The power mirror switches are located on the farther away than they really are. Relying driver's door trim panel. too much on side convex mirrors could To receive maximum benefit, adjust the out- cause you to collide with another vehicle side mirror(s) to center on the adjacent lane...
  • Page 37: Exterior Lights

    Daytime Running 3 — Ambient Light Dimmer Lights can be turned on and off using the 4 — Instrument Panel Dimmer Uconnect System, refer to “Uconnect Set- tings” in “Multimedia” in the Owner’s Manual www.jeep.com/en/owners/ manuals/ for further details.
  • Page 38: High Beams

    “Uconnect Settings” in “Multimedia” in mating high beam control through the use of the Owner’s Manual on www.jeep.com/en/ Headlight Delay a digital camera mounted above the inside owners/manuals for further details. rearview mirror. This camera detects vehicle...
  • Page 39: Front Fog Lights

    Front Fog Lights Turn Signals Lane Change Assist Tap the lever up or down once, without mov- The front fog light switch is built into the Move the multifunction lever up or down and ing beyond the detent, and the turn signal headlight switch.
  • Page 40: Instrument Panel Dimmer Control

    Instrument Panel Dimmer Control WIPER AND WASHERS are operated by rotating a switch, located on the end of the lever. For information on the The instrument panel dimmer control is part rear wiper/washer, refer to “Rear Wiper” in of the headlight switch and is located on the this section.
  • Page 41: Rain Sensing Wipers

    “Uconnect Settings” in “Multimedia” ignition switch in the RUN position, rain sition one is the least sensitive, and wiper in the Owner's Manual on www.jeep.com/ sensing wiper operation can resume, if it has delay position four is the most sensitive.
  • Page 42: Rear Wiper

    Rear Wiper CLIMATE CONTROLS The rear wiper/washer controls are located on Manual Climate Control Without A the windshield wiper/washer lever on the Touchscreen Overview right side of the steering column. The rear wiper/washer is operated by rotating a switch, The controls for the manual heating and air located at the middle of the lever.
  • Page 43 Manual Climate Controls Without A Touchscreen Manual Climate Control Without A Touchscreen Descriptions Icon Description Blower Control Use this control to regulate the amount of air forced through the system in any mode you select. The blower speed increases as you move the control clockwise from the off position. NOTE: Depending on the configuration, your vehicle may be equipped with four blower speeds.
  • Page 44 Icon Description Temperature Control Use this control to regulate the temperature of the air inside the passenger compartment. Rotating the knob counter- clockwise, from top center into the blue area of the scale, indicates cooler temperatures. Rotating the knob clockwise, into the red area, indicates warmer temperatures.
  • Page 45 Icon Description Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield. This setting is good for maintaining comfort while reducing moisture on the windshield.
  • Page 46 Icon Description Rear Defrost Button Push and release the Rear Defrost Control button to turn on the rear window defroster and the heated outside mirrors (if equipped). An indicator will illuminate when the rear window defroster is on. The rear window defroster automatically turns off after ten minutes.
  • Page 47: Climate Controls With A Touchscreen Overview

    Climate Controls With A Touchscreen Overview 5.0 With Manual Temperature Controls...
  • Page 48 8.4/8.4 NAV With Manual Temperature Controls...
  • Page 49 Manual Temperature Faceplate Controls...
  • Page 50 5.0 With Automatic Temperature Controls...
  • Page 51 8.4/8.4 NAV With Automatic Temperature Controls...
  • Page 52 Automatic Temperature Faceplate Controls...
  • Page 53 Climate Control With A Touchscreen Descriptions Icon Description MAX A/C Button Press and release the button on the touchscreen, or push and release the button on the faceplate, to change the current setting, the indicator illuminates when A/C is on. A/C Button Press and release to change the current setting, the indicator illuminates when A/C is on.
  • Page 54 Icon Description Front Defrost Button Press and release the touchscreen button, or push and release the button on the faceplate, to change the current airflow setting to Defrost mode. The indicator illuminates when this feature is on. Air comes from the windshield and side window demist outlets.
  • Page 55 Icon Description SYNC Button — If Equipped Press the SYNC button on the touchscreen to toggle the SYNC feature on/off. The SYNC indicator is illuminated when this feature is enabled. SYNC is used to synchronize the passenger temperature setting with the driver temperature setting.
  • Page 56 Icon Description Floor Mode Floor Mode Air comes from the floor outlets. A slight amount of air is directed through the defrost and side window demister outlets. Mix Mode Mix Mode Air is directed through the floor, defrost, and side window demister outlets. This setting works best in cold or snowy conditions that require extra heat to the windshield.
  • Page 57: Automatic Temperature Control (Atc) - If Equipped

    and manually adjust the blower and airflow In MAX A/C, the blower level and mode posi- prove window clearing operation. Recircula- mode settings. Also, make sure to select only tion can be adjusted to desired user settings. tion will be disabled automatically if this Panel, Bi-Level, or Floor modes.
  • Page 58: Operating Tips

    “Uconnect Settings” in “Multimedia” froster performance, make sure the engine shield. Defrost mode must be manually se- in your Owner’s Manual on www.jeep.com/ lected to clear the windshield and side glass. cooling system is functioning properly and en/owners/manuals for further information.
  • Page 59 Window Fogging Outside Air Intake Cabin Air Filter Vehicle windows tend to fog on the inside in Make sure the air intake, located directly in The climate control system filters out dust mild, rainy and/or humid weather. To clear front of the windshield, is free of obstructions and pollen from the air.
  • Page 60 Operating Tips Chart...
  • Page 61: Windows

    WINDOWS There are single window controls on each Auto-Up Feature With Anti-Pinch passenger door trim panel, which operate the Protection Power Window Controls passenger door windows. The window con- NOTE: trols will operate only when the ignition is in The window controls on the driver's door the ACC or ON/RUN position.
  • Page 62: Reset Auto-Up

    Reset Auto-Up Window Lockout Switch POWER SUNROOF Should the Auto-Up feature stop working, the The window lockout switch on the driver's The power sunroof switches are located on window probably needs to be reset. To reset door trim panel allows you to disable the the overhead console.
  • Page 63: Opening

    Opening Venting Sunroof — Express Wind Buffeting Push and release the button and the sunroof Wind buffeting can be described as a Opening Sunroof — Express will open to the vent position. helicopter-type percussion sound. If buffet- • Push the sunroof switch rearward and re- ing occurs with the rear windows open, adjust This is called “Express Vent”...
  • Page 64: Pinch Protection Feature

    Manual Open Pinch Protection Feature WARNING! To open the shade, push and hold the switch This feature will detect an obstruction in the • Do not let children play with the sunroof. rearward. The shade will open and stop auto- opening of the sunroof during Express Close Never leave children unattended in a matically at the half-open position.
  • Page 65: Sunroof Maintenance

    Sunroof Maintenance Closing The Hood Use only a non-abrasive cleaner and a soft WARNING! cloth to clean the glass panel. Be sure the hood is fully latched before HOOD driving your vehicle. If the hood is not fully latched, it could open when the vehicle is Opening The Hood in motion and block your vision.
  • Page 66: Liftgate

    LIFTGATE The liftgate passive entry unlock feature is Closing built into the electronic liftgate release. With Grasp the liftgate closing handle and initiate Opening a valid Passive Entry key fob within 5 ft lowering the liftgate. Release the handle (1.5 m) of the liftgate, push the electronic To Unlock/Enter The Liftgate when the liftgate takes over the closing effort.
  • Page 67 Cargo Extension Panels WARNING! WARNING! Cargo extension panels can be folded and • Place as much cargo as possible in front • Cargo tie-downs are not safe anchors for unfolded. When the rear seats are moved to of the rear axle. Too much weight or a child seat tether strap.
  • Page 68: Universal Garage Door Opener (Homelink)

    UNIVERSAL GARAGE DOOR • The HomeLink buttons that are located in NOTE: Erasing all channels should only be per- the overhead console or sunvisor desig- OPENER (HomeLink) formed when programming HomeLink for the nate the three different HomeLink chan- first time. Do not erase channels when pro- nels.
  • Page 69: Programming A Non-Rolling Code

    2. Place the hand-held transmitter 1 to 6. Return to the vehicle and push the pro- 3. Push and hold the HomeLink button you want to program while you push and hold 3 inches (3 to 8 cm) away from the grammed HomeLink button twice (hold- the hand-held transmitter button.
  • Page 70: Using Homelink

    Using HomeLink INTERNAL EQUIPMENT The center console 12 Volt power outlet is powered directly from the battery (power To operate, push and release the pro- Power Outlets available at all times). Items plugged into grammed HomeLink button. Activation will this outlet may discharge the battery and/or There are three 12 Volt electrical power out- now occur for the programmed device (i.e., prevent the engine from starting.
  • Page 71 There is also a 12 Volt power outlet located in NOTE: the rear cargo area of the vehicle. This power • Do not exceed the maximum power of outlet has power available directly from the 160 Watts (13 Amps) at 12 Volts. If the battery (power available at all times).
  • Page 72 Power Outlets Fuse Locations 1 — F75 Fuse 20A Yellow Front Power Outlet/Cigar Lighter Console Bin 2 — F81 Fuse 20A Yellow Rear Power Outlet (battery powered at all times) 3 — F91 Fuse 20A Yellow Rear Power Outlet (powered when the ignition switch is in the ON or ACC position) 4 —...
  • Page 73: Power Inverter

    Power Inverter The power inverter is designed with built-in Wireless Charging Pad — If Equipped overload protection. If the power rating of Your vehicle may be equipped with a wireless 150 Watts is exceeded, the power inverter charging pad located inside the upper portion will automatically shut down.
  • Page 74 Your mobile phone must be designed for Qi 3. If the LED does not transition from red to wireless charging, be equipped with an after- flashing green, and just turns off, pick up market sleeve or equipped with a back plate your mobile phone and reposition it on the from your mobile phone provider, or an online charging pad.
  • Page 75 NOTE: WARNING! CAUTION! The initial adjustment will only need to be done once as long as only one mobile Do not place metal object(s) between the Do not place your vehicle key fob on the phone is used. If a different mobile phone mobile phone and wireless charging pad.
  • Page 77 GETTING TO KNOW YOUR INSTRUMENT PANEL GETTING TO KNOW YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER ..76 WARNING/INDICATOR LIGHTS ONBOARD DIAGNOSTIC SYSTEM — AND MESSAGES ... . .78 OBD II .
  • Page 78: Instrument Cluster

    INSTRUMENT CLUSTER Instrument Cluster 1 — Tachometer 4 — Fuel Gauge 2 — Instrument Cluster Display 5 — Temperature Gauge 3 — Speedometer...
  • Page 79: Instrument Cluster Display - If Equipped

    INSTRUMENT CLUSTER Instrument Cluster Display Controls • Push the up button to scroll upward through the main menus (Speedometer, DISPLAY — IF EQUIPPED Vehicle Info, Driver Assist, Fuel Economy, Trip, Audio, Messages, Screen Set Up). Your vehicle may be equipped with an instru- ment cluster display, which offers useful in- •...
  • Page 80: Instrument Cluster Display Selectable Items

    NOTE: All active telltales will display first, if appli- onds as a bulb check when the ignition Refer to your Owner's Manual on www.jeep.com/ cable. The system check menu may appear switch is first turned to ON/RUN. If the light en/owners/manuals for further information.
  • Page 81 — Brake Warning Light The dual brake system provides a reserve Vehicles equipped with the Anti-Lock Brake System (ABS) are also equipped with Elec- braking capacity in the event of a failure to a This light monitors various brake functions, tronic Brake Force Distribution (EBD).
  • Page 82 — Vehicle Security Light If the temperature reading does not return to WARNING! normal, turn the engine off immediately and This light will flash at a fast rate for approxi- call for service. Refer to “If Your Engine If you continue operating the vehicle when mately 15 seconds when the vehicle security Overheats”...
  • Page 83: Yellow Telltale Lights

    — Electronic Throttle Control (ETC) — Electric Power Steering Fail Yellow Telltale Lights Warning Light Light — Engine Malfunction Warning Light This light is used to manage the electrical This light informs you of a problem with the The Engine Check/Malfunction Indicator warning of the EPS (Electric Power Steering).
  • Page 84 — Electronic Stability Control (ESC) • The ESC system will make buzzing or WARNING! clicking sounds when it is active. This is Indicator Light normal; the sounds will stop when ESC A malfunctioning catalytic converter, as The “ESC Indicator Light” in the instrument becomes inactive following the maneuver referenced above, can reach higher tem- cluster will come on when the ignition is...
  • Page 85 — Tire Pressure Monitoring System (If your vehicle has tires of a different size than Your vehicle has also been equipped with a TPMS malfunction indicator to indicate when the size indicated on the vehicle placard or tire (TPMS) Warning Light the system is not operating properly.
  • Page 86 If the ABS light remains on or turns on while — Service Forward Collision CAUTION! driving, then the Anti-Lock portion of the Warning (FCW) Light brake system is not functioning and service is The TPMS has been optimized for the This light indicates a potential system fault required.
  • Page 87: Blue Telltale Lights

    rotate at the same speed. Low range provides — LaneSense Failure Indicator Light Green Telltale Lights a greater gear reduction ratio to provide in- — If Equipped — Park/Headlight ON Indicator Light creased torque at the wheels. This light will turn on when the LaneSense This indicator will illuminate when the park Refer to “Four-Wheel Drive Operation —...
  • Page 88: White Telltale Lights

    — Stop/Start Active Indicator Light — Adaptive Cruise Control (ACC) Set White Telltale Lights — If Equipped With Target Detected Light — — Cruise Control ON Indicator If Equipped This telltale will illuminate when the Stop/ This light will turn on when the speed control Start function is in “Autostop”...
  • Page 89: Onboard Diagnostic System - Obd Ii

    is less then 30 mph (48 km/h). If these — Adaptive Cruise Control (ACC) Set ONBOARD DIAGNOSTIC conditions are not met while attempting to Light — If Equipped SYSTEM — OBD II use the HDC feature, the HDC indicator light This light will turn on when the vehicle will flash on/off.
  • Page 90: Cybersecurity

    • Access, or allow others to access, information stored in your vehicle systems, including personal infor- mation. For further information, refer to “Cybersecu- rity” in “Multimedia” in your Owner's Manual at www.jeep.com/en/owners/manuals/.
  • Page 91 SAFETY SAFETY SAFETY FEATURES...90 OCCUPANT RESTRAINT SAFETY TIPS ....146 SYSTEMS ....109 Anti-Lock Brake System (ABS) .
  • Page 92: Safety Features

    SAFETY FEATURES • The clicking sound of solenoid valves. WARNING! • Brake pedal pulsations. Anti-Lock Brake System (ABS) • The ABS cannot prevent the natural laws • A slight drop of the brake pedal at the end of physics from acting on the vehicle, The Anti-Lock Brake System (ABS) provides of the stop.
  • Page 93: Electronic Brake Control System

    Anti-Lock Brake Warning Light Assist (HSA), Traction Control System (TCS), If the “Brake System Warning Light” remains Electronic Stability Control (ESC), and Elec- on or comes on while driving, it indicates that The yellow “Anti-Lock Brake Warning Light” tronic Roll Mitigation (ERM). These systems the brake system is not functioning properly will turn on when the ignition is turned to the work together to enhance both vehicle stabil-...
  • Page 94 The following conditions must be met in WARNING! WARNING! order for HSA to activate: active driving involvement. It is always the The Brake Assist System (BAS) cannot • The feature must be enabled. driver’s responsibility to be attentive to prevent the natural laws of physics from •...
  • Page 95 For vehicles not equipped with an instrument Towing With HSA Traction Control System (TCS) cluster display, perform the following steps: HSA will also provide assistance to mitigate This system monitors the amount of wheel 1. Center the steering wheel (front wheels roll back while towing a trailer.
  • Page 96 ESC uses sensors in the vehicle to determine WARNING! WARNING! the vehicle path intended by the driver and ing system, tire type and size or wheel compares it to the actual path of the vehicle. • Electronic Stability Control (ESC) can- size may adversely affect ESC perfor- When the actual path does not match the not prevent the natural laws of physics...
  • Page 97 Partial Off “ESC OFF” message will display in the in- WARNING! strument cluster. To turn ESC ON again, The “Partial Off” mode is intended for times momentarily push the “ESC Off” switch. • When in “Partial Off” mode, the TCS when a more spirited driving experience is functionality of ESC, (except for the lim- desired.
  • Page 98 ESC Activation/Malfunction Indicator Light Light” begins to flash during acceleration, WARNING! and ESC OFF Indicator Light ease up on the accelerator and apply as little • With the ESC switched off, the en- throttle as possible. Be sure to adapt your hanced vehicle stability offered by ESC speed and driving to the prevailing road con- “ESC...
  • Page 99 Electronic Roll Mitigation (ERM) NOTE: WARNING! TSC cannot stop all trailers from swaying. This system anticipates the potential for Always use caution when towing a trailer and Many factors, such as vehicle loading, wheel lift by monitoring the driver’s steering follow the trailer tongue weight recommenda- road conditions and driving conditions, wheel input and the speed of the vehicle.
  • Page 100 Ready Alert Braking (RAB) Dynamic Steering Torque (DST) Hill Descent Control (HDC) — If Equipped Ready Alert Braking may reduce the time Dynamic Steering Torque is a feature of the HDC is intended for low speed off road driv- required to reach full braking during emer- ESC and Electric Power Steering (EPS) mod- ing while in 4WD Low Range.
  • Page 101 Activating HDC Disabling HDC NOTE: During HDC the +/- shifter input is used for Once HDC is enabled it will activate auto- HDC will be deactivated and disabled if any HDC target speed selection, but will not af- matically if driven down a grade of sufficient of the following conditions occur: fect the gear chosen by the transmission.
  • Page 102 • The cluster icon and switch lamp will flash Selec Speed Control (SSC) — If Equipped Activating SSC for several seconds then extinguish when Once SSC is enabled it will activate automati- SSC is intended for off road driving in 4WD the driver pushes the HDC switch but Low Range only.
  • Page 103 • 8th = 5 mph (8 km/h) Deactivating SSC Feedback To The Driver: • 9th = 5.6 mph (9 km/h) – If Equipped SSC will be deactivated but remain available The instrument cluster has an SSC icon and if any of the following conditions occur: •...
  • Page 104: Auxiliary Driving Systems

    AUXILIARY DRIVING SYSTEMS Blind Spot Monitoring The Blind Spot Monitoring (BSM) system uses two radar-based sensors, located inside the rear bumper fascia, to detect highway licensable vehicles (automobiles, trucks, mo- torcycles etc.) that enter the blind spot zones from the rear/front/side of the vehicle. Rear Detection Zones BSM Warning Light The BSM detection zone covers approxi-...
  • Page 105: Forward Collision Warning (Fcw)

    Chime mode, the BSM system will provide a BSM or RCP systems. Refer to “Blind Spot Monitoring” in “Safety” visual alert in the appropriate side view mirror in the Owner's Manual on www.jeep.com/en/ based on a detected object. If the turn signal NOTE: owners/manuals for further details.
  • Page 106 Owner's Manual allows the system to warn you of a possible More cautious drivers that do not mind fre- www.jeep.com/en/owners/manuals/ for fur- collision with the vehicle in front of you. ther details. quent warnings may prefer this setting. • Changing the FCW status to “off” prevents...
  • Page 107: Tire Pressure Monitor System (Tpms)

    Tire Pressure Monitor System (TPMS) The TPMS will warn the driver of a low tire The system will automatically update and the pressure if the tire pressure falls below the “Tire Pressure Monitoring Telltale Light” will The Tire Pressure Monitor System (TPMS) low-pressure warning limit for any reason, turn off once the system receives the updated will warn the driver of a low tire pressure...
  • Page 108 NOTE: • The TPMS is not a substitute for proper CAUTION! tire maintenance, and it is the driver’s When filling warm tires, the tire pressure may your vehicle to an authorized dealer to responsibility to maintain correct tire pres- need to be increased up to an additional 4 psi have your sensor function checked.
  • Page 109 The TPMS consists of the following the instrument cluster will return to their original color, and the “Tire Pressure Monitor- components: ing Telltale Light” will turn off. • Receiver module NOTE: • Four tire pressure monitoring sensors When filling warm tires, the tire pressure may •...
  • Page 110 If the ignition key is cycled, this sequence Vehicles With Compact Spare or Non-Matching 4. For each subsequent ignition key cycle, a will repeat, providing the system fault still Full Size Spare chime will sound, the “TPMS Telltale exists. If the system fault no longer exists, the Light”...
  • Page 111: Occupant Restraint

    TPMS Deactivation — If Equipped the vehicle for up to 20 minutes above NOTE: 15.5 mph (25 km/h). The TPMS will chime, Changes or modifications not expressly ap- The TPMS can be deactivated if replacing all the "TPM Telltale Light" will flash on and off proved by the party responsible for compli- four wheel and tire assemblies (road tires) for 75 seconds and then turn off.
  • Page 112: Important Safety Precautions

    Important Safety Precautions children who do not use child restraints or WARNING! belt-positioning booster seats should ride Please pay close attention to the information properly buckled up in a vehicle with a • Never place a rear-facing child restraint in this section. It tells you how to use your rear seat.
  • Page 113 Enhanced Seat Belt Use Reminder System BeltAlert Warning Sequence Change Of Status (BeltAlert) The BeltAlert warning sequence is activated If the driver or outboard front seat passenger when the vehicle is moving above a specified (if equipped with outboard front passenger Driver And Passenger BeltAlert —...
  • Page 114 NOTE: WARNING! WARNING! If BeltAlert has been deactivated and the • Be sure everyone in your vehicle is in a driver or outboard front seat passenger (if • Relying on the air bags alone could lead seat and using a seat belt properly. Oc- equipped with outboard front passenger seat to more severe injuries in a collision.
  • Page 115 Lap/Shoulder Belt Operating Instructions WARNING! WARNING! 1. Enter the vehicle and close the door. Sit • A seat belt that is worn under your arm is • A lap belt worn too high can increase the back and adjust the seat. dangerous.
  • Page 116 3. When the seat belt is long enough to fit, 4. Position the lap belt so that it is snug and Lap/Shoulder Belt Untwisting Procedure insert the latch plate into the buckle until lies low across your hips, below your ab- Use the following procedure to untwist a you hear a “click.”...
  • Page 117 Adjustable Upper Shoulder Belt Anchorage As a guide, if you are shorter than average, WARNING! you will prefer the shoulder belt anchorage in In the driver and front passenger seats, the your seat belt safely and to keep your a lower position, and if you are taller than top of the shoulder belt can be adjusted passengers safe, too.
  • Page 118 Seat Belts And Pregnant Women Seat Belt Pretensioner WARNING! The front seat belt system is equipped with • ONLY use a Seat Belt Extender if it is pretensioning devices that are designed to physically required in order to properly remove slack from the seat belt in the event fit the original seat belt system.
  • Page 119 Energy Management Feature In Automatic Locking Mode, the shoulder belt is automatically pre-locked. The seat This vehicle has a seat belt system with an belt will still retract to remove any slack in the Energy Management feature in the front seat- shoulder belt.
  • Page 120: Supplemental Restraint Systems (Srs)

    3. Allow the seat belt to retract. As the seat • Driver and Front Passenger Air Bags WARNING! belt retracts, you will hear a clicking • Supplemental Side Air Bags used to install rear-facing or forward- sound. This indicates the seat belt is now •...
  • Page 121 position. After the self-check, the Air Bag NOTE: Redundant Air Bag Warning Light If the speedometer, tachometer, or any en- Warning Light will turn off. If the ORC detects gine related gauges are not working, the Oc- a malfunction in any part of the system, it If a fault with the Air Bag Warning Light is cupant Restraint Controller (ORC) may also turns on the Air Bag Warning Light, either...
  • Page 122 Front Air Bags WARNING! This vehicle has front air bags and lap/ • Being too close to the steering wheel or shoulder belts for both the driver and front instrument panel during front air bag passenger. The front air bags are a supple- deployment could cause serious injury, ment to the seat belt restraint systems.
  • Page 123 The first stage inflator is triggered immedi- Front Air Bag Operation WARNING! ately during an impact that requires air bag Front Air Bags are designed to provide addi- deployment. A low energy output is used in • No objects should be placed over or near tional protection by supplementing the seat less severe collisions.
  • Page 124 When the ORC detects a collision requiring Occupant Classification Module (OCM) • The front passenger seat is occupied by a rear-facing child restraint; or the front air bags, it signals the inflator units. And Sensor A large quantity of non-toxic gas is generated •...
  • Page 125 In order for the OCS to operate as designed, it Lighter Weight Passengers WARNING! is important for the front passenger to be (Including Small Adults) seated properly and properly wearing the seat • Never place a rear-facing child restraint When a lighter weight passenger, including a belt.
  • Page 126 weight on the front passenger seat may result The OCS determines the front passenger’s in a full-power deployment of the Passenger most probable classification. If an occupant Advanced Front Air Bag. in the front passenger seat is seated improp- erly, the occupant may provide an output Examples of improper front passenger seat- signal to the OCS that is different from the ing include:...
  • Page 127 If the Air Bag Warning Light does not WARNING! come on, or stays on after you start the the center of the seat, with your feet vehicle, or it comes on as you drive, take the comfortably on or near the floor. vehicle to an authorized dealer for service •...
  • Page 128 • Do not use prior or future model year seat WARNING! WARNING! covers or cushions not designated by FCA Standards (FMVSS) and/or Canadian US LLC for the specific model being re- Make sure that objects inside the Flip 'n Motor Vehicle Safety Standards (CM- paired.
  • Page 129 Supplemental Side Air Bags The SABs may help to reduce the risk of WARNING! occupant injury during certain side im- Your vehicle is equipped with two types of • Do not mount any accessories to the pacts and/or vehicle rollover events, in side air bags: knee impact bolsters such as alarm addition to the injury reduction potential...
  • Page 130 SABICs may help reduce the risk of head WARNING! WARNING! or other injuries to front and rear seat • In order for the SABICs to work as in- outboard occupants in certain side im- Do not use accessory seat covers or place tended, do not install any accessory pacts and/or vehicle rollover events, in objects between you and the Side Air...
  • Page 131 that require Side Air Bag occupant protec- WARNING! WARNING! tion. In side impacts, the Side Air Bags de- ploy independently; a left side impact de- • Occupants, including children, who are • Side Air Bags need room to inflate. Do ploys the left Side Air Bags only and a right up against or very close to Side Air Bags not lean against the door or window.
  • Page 132 priate. A slower-developing event may deploy • Driver and Front Passenger Air Bags are not caused by contact with chemicals. They are not permanent and normally heal the seat belt pretensioners on both sides of • Supplemental Side Air Bags quickly.
  • Page 133 Enhanced Accident Response System Maintaining Your Air Bag System WARNING! In the event of an impact, if the communica- WARNING! Deployed air bags and seat belt preten- tion network remains intact, and the power sioners cannot protect you in another col- remains intact, depending on the nature of •...
  • Page 134: Child Restraints

    • How far (if at all) the driver was depressing Child Restraints WARNING! the accelerator and/or brake pedal; and, Everyone in your vehicle needs to be buckled needs to be serviced in any way (includ- • How fast the vehicle was traveling. up at all times, including babies and chil- ing removal or loosening/tightening of dren.
  • Page 135 There are different sizes and types of re- Before buying any restraint system, make NOTE: straints for children from newborn size to the sure that it has a label certifying that it meets • For additional information, refer to child almost large enough for an adult safety all applicable Safety Standards.
  • Page 136 Infant And Child Restraints All children whose weight or height is above WARNING! the forward-facing limit for the child seat Safety experts recommend that children ride should use a belt-positioning booster seat • Never place a rear-facing child restraint rear-facing in the vehicle until they are two until the vehicle’s seat belts fit properly.
  • Page 137 2. Do the child’s knees bend comfortably WARNING! WARNING! over the front of the vehicle seat – while the vehicle seat has been adjusted, re- they are still sitting all the way back? Never allow a child to put the shoulder belt install the child restraint.
  • Page 138 Recommendations For Attaching Child Restraints Restraint Type Combined Weight of the Use Any Attachment Method Shown With An “X” Below Child + Child Restraint LATCH – Seat Belt Only LATCH – Lower Anchors Seat Belt + Lower Anchors Only + Top Tether Anchor Top Tether Anchor Rear-Facing Up to 65 lbs...
  • Page 139 Lower Anchors And Tethers For CHildren There are two lower anchorages located at the LATCH Positions For Installing back of the seat cushion where it meets the (LATCH) Restraint System Child Restraints In This Vehicle seatback and one top tether anchorage lo- cated behind the seating position.
  • Page 140 Frequently Asked Questions About Installing Child Restraints With LATCH What is the weight limit (child’s weight + 65 lbs (29.5 kg) Use the LATCH anchorage system until the combined weight of the weight of the child restraint) for using the child and the child restraint is 65 lbs (29.5 kg).
  • Page 141 Locating The LATCH Anchorages Locating The Upper Tether Anchorages and some rear-facing child restraints will also be equipped with a tether strap. The tether strap will have a hook at the end to attach to The lower anchorages are round bars that are There are tether strap anchorages behind the top tether anchorage and a way to tighten found at the rear of the seat cushion where it...
  • Page 142 2. Right outboard and center seating posi- WARNING! tions (1 and 2): Install the first child seat • If you are installing three child re- in the right outboard seating position us- straints next to each other, you must ing lower anchorages A and B. Install the use the seat belt and the center tether second child seat using the center an- anchor for the center position.
  • Page 143 To Install A LATCH-Compatible 3. Attach the lower hooks or connectors of How To Stow An Unused Switchable-ALR the child restraint to the lower anchorages (ALR) Seat Belt: Child Restraint in the selected seating position. When using the LATCH attaching system to If the selected seating position has a Switch- 4.
  • Page 144 Please see the table below and the following WARNING! WARNING! sections for more information. • Improper installation of a child restraint • Improper installation or failure to prop- Frequently Asked Questions About Installing to the LATCH anchorages can lead to erly secure a child restraint can lead to Child Restraints With Seat Belts failure of the restraint.
  • Page 145 Frequently Asked Questions About Installing Child Restraints With Seat Belts What is the weight limit (child’s weight + weight Always use the tether anchor when using the seat of the child restraint) for using the Tether Anchor Weight limit of the Child Restraint belt to install a forward facing child restraint, up to with the seat belt to attach a forward facing child the recommended weight limit of the child restraint.
  • Page 146 5. To lock the seat belt, pull down on the 8. If the child restraint has a top tether strap Installing Child Restraints Using The Top shoulder part of the belt until you have and the seating position has a top tether Tether Anchorage pulled all the seat belt webbing out of the anchorage, connect the tether strap to the...
  • Page 147: Transporting Pets

    1. Look behind the seating position where WARNING! you plan to install the child restraint to find the tether anchorage. You may need • An incorrectly anchored tether strap to move the seat forward to provide better could lead to increased head motion and access to the tether anchorage.
  • Page 148: Safety Tips

    SAFETY TIPS Exhaust Gas The best protection against carbon monoxide entry into the vehicle body is a properly WARNING! maintained engine exhaust system. Transporting Passengers Whenever a change is noticed in the sound of Exhaust gases can injure or kill. They con- NEVER TRANSPORT PASSENGERS IN THE the exhaust system, when exhaust fumes can tain carbon monoxide (CO), which is col-...
  • Page 149 Front seat belt assemblies must be replaced Defroster WARNING! after a collision. Rear seat belt assemblies Check operation by selecting the defrost must be replaced after a collision if they have An improperly attached, damaged, folded, mode and place the blower control on high been damaged (i.e., bent retractor, torn web- or stacked floor mat, or damaged floor mat speed.
  • Page 150: Periodic Safety Checks You Should Make Outside The Vehicle

    and cracks. Inspect sidewalls for cuts, WARNING! WARNING! cracks, and bulges. Check the wheel nuts for • ONLY use the driver’s side floor mat on • If the vehicle carpet has been removed tightness. Check the tires (including spare) the driver’s side floor area. To check for and re-installed, always properly attach for proper cold inflation pressure.
  • Page 151 STARTING AND OPERATING STARTING AND OPERATING STARTING THE ENGINE ..151 Rear Electronic Locker (E-Locker) ADAPTIVE CRUISE System — If Equipped ...161 CONTROL (ACC) ... .167 Normal Starting —...
  • Page 152 Operation With A Trailer ..174 Changing LaneSense Status..179 RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) . .183 General Warnings ....175 PARKVIEW REAR BACK-UP Towing This Vehicle Behind PARKSENSE ACTIVE PARK...
  • Page 153: Starting The Engine

    STARTING THE ENGINE Tip Start Feature WARNING! Place the ignition in the START mode and Before starting your vehicle, adjust your seat, children, and do not leave the ignition of release it as the starter engages. The starter adjust both inside and outside mirrors, and a vehicle equipped with Keyless Enter- motor will automatically disengage itself N-Go in the ACC or ON/RUN mode.
  • Page 154: If Engine Fails To Start

    1. Install a battery charger or jumper cables If Engine Fails To Start After Starting to the battery to ensure a full battery The idle speed is controlled automatically, charge during the crank cycle. WARNING! and it will decrease as the engine warms up. 2.
  • Page 155 To apply the park brake manually, pull up on • The new Auto Park Brake feature can be CAUTION! the switch momentarily. The BRAKE telltale used to apply the park brake automatically every time you park the vehicle. Auto Park light in the instrument cluster and an indica- If the Brake System Warning Light remains Brake can be enabled and disabled in the...
  • Page 156: Automatic Transmission

    Auto Park Brake • The seat belt is unbuckled. WARNING! • The driver door is open. The electric park brake can be programmed be warned not to touch the parking to be applied automatically whenever the SafeHold can be temporarily bypassed by brake, brake pedal or the transmission vehicle is at a standstill and the automatic gear selector.
  • Page 157 WARNING! WARNING! CAUTION! • Unintended movement of a vehicle • Your vehicle could move and injure you Damage to the transmission may occur if could injure those in or near the vehicle. and others if it is not in PARK. Check by the following precautions are not ob- As with all vehicles, you should never trying to move the gear selector out of...
  • Page 158: Key Ignition Park Interlock

    Key Ignition Park Interlock Nine-Speed Automatic Transmission on a new vehicle may be somewhat abrupt. This is a normal condition, and precision This vehicle is equipped with a Key Ignition The transmission gear range (PRND) is dis- shifts will develop within a few hundred miles Park Interlock which requires the transmis- played both beside the gear selector and in (kilometers).
  • Page 159: Four-Wheel Drive Operation

    gear. In ERS mode, toggling the gear selector If the front wheels begin to lose traction, forward (-) or rearward (+) will change the power is shifted automatically to the rear highest available gear. Refer to “Electronic wheels. The greater the front wheel traction Range Select (ERS) Operation”...
  • Page 160: 2-Speed Four-Wheel Drive (4X4) - If Equipped

    When additional traction is required, the CAUTION! 4WD LOW range position can be used to provide an additional gear reduction which All wheels must have the same size and allows for increased torque to be delivered to type tires. Unequal tire sizes must not be used.
  • Page 161: Shift Positions

    Shift Positions 4WD LOW This range is for low speed four-wheel drive. It For additional information on the appropriate provides an additional gear reduction which use of each 4WD system mode position, see allows for increased torque to be delivered to the information below: both the front and rear wheels while providing NEUTRAL...
  • Page 162 Shifting Out Of 4X4 LOW 6. Using a ballpoint pen or similar object, 3 mph (0 to 5 km/h). If the vehicle is moving faster than 3 mph (5 km/h), the push and hold the recessed power transfer With the vehicle at speeds of 0 to 3 mph (0 to 4WD system will not allow the shift.
  • Page 163: System - If Equipped

    7. After the shift is completed and the NEU- Rear Electronic Locker (E-Locker) System 2. The ignition in the ON mode and the engine running. TRAL (N) light stays on, release the NEU- — If Equipped TRAL (N) button. 3. To disengage Rear E-Locker, push the The Rear E-Locker System features a me- REAR LOCK button once.
  • Page 164: Selec-Terrain

    shift completion to occur. The preferred tain operating conditions), the transmis- method is for the vehicle to be rolling, sion may use second gear (rather than first below 15 MPH (24 km/h), while including gear) during launches, to minimize wheel right and left steering maneuvers to allow slippage.
  • Page 165: Stop/Start System - If Equipped

    Stop/Start Screen. In the following situ- Panel” in your Owner’s information at ations the engine will not stop: STOP/START SYSTEM — IF www.jeep.com/en/owners/manuals for fur- • Driver’s seat belt is not buckled. ther details. EQUIPPED • Driver’s door is not closed.
  • Page 166: To Start The Engine While In Autostop Mode

    To Know Your Instrument Panel” in your Own- • HVAC system temperature or fan speed is It may be possible for the vehicle to be driven er’s manual at www.jeep.com/en/owners/ manually adjusted. several times without the STOP/START sys- manuals for further information.
  • Page 167: To Manually Turn Off The Stop/Start System

    Refer to “Instrument Cluster Display” in 1 — Push Cancel “Getting To Know Your Instrument Panel” 2 — Push Set+/Accel in your Owner’s manual at www.jeep.com/ 3 — Push Resume en/owners/manuals for further information. 4 — Push On/Off 5 — Push Set-/Decel...
  • Page 168: Activation

    Instrument Panel” in the Owner’s Manual at trol and have an accident. Always leave the crease speed by pushing the SET (-) button. www.jeep.com/en/owners/manuals/ for more system off when you are not using it. information. The speed increment shown is...
  • Page 169: Resume

    U.S. Speed (mph) Accelerating For Passing • Pushing the SET (-) button once will result Press the accelerator as you would normally. in a 1 mph decrease in set speed. Each When the pedal is released, the vehicle will subsequent tap of the button results in a return to the set speed.
  • Page 170: Activation

    Panel” in the Owner’s Manual at ACC cannot be set if there is a stationary erate, if the engine’s braking power does www.jeep.com/en/owners/manuals/ for more vehicle in front of your vehicle in close prox- not slow the vehicle sufficiently to reach information.
  • Page 171: Resume

    Instrument Panel” in the Owner’s Manual at subsequent tap of the button results in an 10 km/h decrements until the button is www.jeep.com/en/owners/manuals/ for more increase of 1 mph. released. The decrease in set speed is information. The speed increment shown is •...
  • Page 172: Deactivation

    Each time the button is pushed, the trol Mode” in “Starting And Operating” in tions could cause the vehicle to accelerate distance setting increases by one bar (lon- your Owner's Manual at www.jeep.com/en/ or decelerate too sharply for safe opera- ger). owners/manuals/ for further details.
  • Page 173: Parksense Rear Park Assist

    “Normal (Fixed Speed) Cruise Control system will release the brakes and that the obstacle. Mode” in your Owner’s Manual on the brakes must be applied manually. An www.jeep.com/en/owners/manuals/ for audible chime will sound when the Enabling And Disabling ParkSense further details. brakes are released.
  • Page 174: Instrument Cluster Display - Warning

    Owner's Manual the system is disabled, the instrument clus- The sensors must not be covered with ice, www.jeep.com/en/owners/manuals/ for fur- ter display will show the “PARKSENSE OFF” snow, slush, mud, dirt or debris. Failure to ther details. message for as long as the vehicle is in do so can result in the system not working REVERSE.
  • Page 175: Parksense Front And Rear Park Assist

    • ParkSense should be disabled when the PARKSENSE FRONT AND WARNING! liftgate is in the open position and the REAR PARK ASSIST continuous tone. Also, the sensors could vehicle is in REVERSE. An open liftgate detect the ball mount and hitch ball could provide a false indication that an ParkSense Sensors assembly, depending on its size and...
  • Page 176: Enabling And Disabling Parksense

    Enabling And Disabling ParkSense ting To Know Your Instrument Panel” in your System disengaged: ParkSense switch LED on Owner’s Manual www.jeep.com/en/ ParkSense can be enabled and disabled with constantly. owners/manuals/ for further details. When the ParkSense switch, located on the switch the gear selector is moved to REVERSE and panel below the Uconnect display.
  • Page 177: General Warnings

    Do not scratch or poke the sensors. on the right. To search for a parking spot on the left, use the left turn signal. Otherwise, you could damage the sensors. Refer to your Owner's Manual on www.jeep.com/ PARKSENSE ACTIVE PARK en/owners/manuals/ for further details. ASSIST...
  • Page 178: Lanesense

    The driver may manually override the haptic WARNING! CAUTION! warning by applying torque into the steering • Before using ParkSense, it is strongly • The vehicle must be driven slowly when wheel at any time. recommended that the ball mount and using ParkSense in order to be able to When only a single lane marking is detected hitch ball assembly is disconnected...
  • Page 179: Lanesense Warning Message

    To turn the LaneSense system on, push the Left Lane Departure — Only Left Lane Detected to provide visual warnings in the instru- LaneSense button (LED turns off). A “Lane- ment cluster display and a torque warning • When the LaneSense system is on, the Sense On”...
  • Page 180 NOTE: NOTE: For example: If approaching the left side of The LaneSense system operates with the the lane the steering wheel will turn to the The LaneSense system operates with the similar behavior for a right lane departure right. similar behavior for a right lane departure. when only the right lane marking has been •...
  • Page 181: Changing Lanesense Status

    Equipped” in “Starting And Operating” in The ParkView camera is unable to view your Owner's Manual at www.jeep.com/en/ • The system will not apply torque to the every obstacle or object in your drive owners/manuals/ for further details.
  • Page 182: Refueling The Vehicle

    REFUELING THE VEHICLE 1. Push the fuel filler door release switch 2. Open the fuel filler door, and remove the (located on the driver’s side door trim). fuel filler cap. The gas cap is located behind the fuel filler door, on the passenger side of the vehicle. If the gas cap is lost or damaged, be sure the replacement cap has been designed for use with this vehicle.
  • Page 183 NOTE: CAUTION! WARNING! • In certain cold conditions, ice may prevent • Damage to the fuel system or emission • Never have any smoking materials lit in the fuel door from opening. If this occurs, lightly push on the fuel door to break the control system could result from using or near the vehicle when the gas cap is ice buildup and re-release the fuel door...
  • Page 184: Trailer Towing

    TRAILER TOWING Trailer Towing Weights (Maximum Trailer Weight Ratings) Maximum GTW Maximum Tongue Wt. Engine/Transmission Model Frontal Area (Gross Trailer Wt.) (See Note) 2.4L/Automatic with or FWD or 4WD 32 sq ft (2.97 sq m) 2,000 lbs (907 kg) 200 lbs (90 kg) without Trailer Tow Package 3.2L/Automatic FWD or 4WD...
  • Page 185: Recreational Towing (Behind Motorhome, Etc.)

    RECREATIONAL TOWING (BEHIND MOTORHOME, ETC.) Towing This Vehicle Behind Another Vehicle 4X4 Models Front-Wheel 1-Speed Towing Wheels OFF Drive (FWD) Power 2-Speed Power Transfer Unit Condition the Ground Models Transfer Unit See Instructions: • Before towing, see your authorized dealer for the Mopar flat tow wiring kit •...
  • Page 186: Recreational Towing

    Recreational Towing — Front-Wheel Drive 8. Turn the ignition OFF, remove the key fob, CAUTION! and release the brake pedal. (FWD) Models Towing this vehicle with ANY of its wheels DO NOT flat tow this vehicle. Damage to the CAUTION! on the ground can cause severe transmis- drivetrain will result.
  • Page 187 Use the following procedure to shift the 4WD CAUTION! CAUTION! system into NEUTRAL (N). • DO NOT dolly tow any 4x4 vehicle. Tow- • Ensure that the Electric Park Brake is ing with only one set of wheels on the released, and remains released, while CAUTION! ground (front or rear) will cause severe...
  • Page 188 6. Using a ballpoint pen or similar object, 7. After the shift is completed and the NEU- NOTE: push and hold the recessed NEUTRAL (N) TRAL (N) light stays on, release the NEU- • Steps 1 through 5 are requirements that button (located by the selector switch) for TRAL (N) button.
  • Page 189 Shifting Out Of NEUTRAL (N) NOTE: When shifting the power transfer unit out Use the following procedure to prepare your of NEUTRAL (N), the engine should re- vehicle for normal usage. main OFF to avoid gear clash. 1. Bring the vehicle to a complete stop, 9.
  • Page 190 NOTE: • The ignition must be in the ON/RUN mode for a shift to take place and for the position • Steps 1 through 5 are requirements that indicator lights to be operable. If the igni- must be met before pushing the NEU- tion is not in the ON/RUN mode, the shift TRAL (N) button, and must continue to be will not take place and no position indica-...
  • Page 191 IN CASE OF EMERGENCY IN CASE OF EMERGENCY HAZARD WARNING TIRE SERVICE KIT — GEAR SELECTOR OVERRIDE . . .215 FLASHERS ....190 IF EQUIPPED....207 FREEING A STUCK VEHICLE.
  • Page 192: Hazard Warning Flashers

    HAZARD WARNING This is an emergency warning system and it should not be used when the vehicle is in FLASHERS motion. Use it when your vehicle is disabled and it is creating a safety hazard for other Control motorists. The Hazard Warning flasher switch is located When you must leave the vehicle to seek on the switch bank just above the climate assistance, the Hazard Warning flashers will...
  • Page 193: Bulb Replacement

    BULB REPLACEMENT Replacement Bulbs Interior Bulbs Bulb Number Cargo Lamp TL212–2 Overhead Console Lamp PLW214–2A Reading Lamp WL212–2 Exterior Bulbs Bulb Number Low Beam/High Beam (Bi-Halogen) Headlamps 9005HL + Low Beam/High Beam (Bi-Xenon) Headlamps D3S (Serviced at an authorized dealer) Front Park/Daytime Running Lamps LED (Serviced at an authorized dealer) Front Turn Signal Lamps...
  • Page 194: Replacing Exterior Bulbs

    Replacing Exterior Bulbs Bi-Halogen Headlamps 6. Install the bulb and connector assembly into the headlamp housing and rotate 1. Remove the three hex head screws from Bi-Xenon High Intensity Discharge (HID) clockwise to lock it in place. the wheel liner. Headlamps —...
  • Page 195 4. Install the bulb and socket assembly into 5. Reconnect the wiring harness to the new Liftgate Mounted Back-up Lamp the housing, and rotate the socket clock- bulb and reinstall by inserting the new 1. Open the liftgate. wise to lock it in place. bulb straight into the fog lamp housing 2.
  • Page 196: Fuses

    License Plate Lamp FUSES General Information 1. Using a small screwdriver, press inward The fuses protect electrical systems against WARNING! the locking tab on the side of the lamp excessive current. assembly and pull down on the lamp as- When a device does not work, you must check •...
  • Page 197 Cavity Blade Fuse Cartridge Fuse Description – – Not Used 15 Amp Blue – Powertrain Control Module - PCM (Diesel Only) 25 Amp Clear – Engine Control Module (ECM)/Fuel Injection – – Not Used 20 Amp Yellow – Power Transfer Unit (PTU) – If Equipped –...
  • Page 198 Cavity Blade Fuse Cartridge Fuse Description – 30 Amp Pink Fuel Heater – Diesel Only – – Not Used 15 Amp Blue – Transmission Control Module (TCM) – – Not Used 10 Amp Red – Engine Control Module (ECM)/(EPS)/(PCM) – –...
  • Page 199 Cavity Blade Fuse Cartridge Fuse Description – 25 Amp Clear Sunroof – If Equipped – 30 Amp Pink Driver Door Module – If Equipped – 30 Amp Pink Power Inverter (115V A/C) — If Equipped – 30 Amp Pink Power Liftgate – If Equipped –...
  • Page 200 Cavity Blade Fuse Cartridge Fuse Description 10 Amp Red – In Vehicle Temperature Sensor/Humidity Sensor/ Driver Assist System Module (DASM)/Park Assist (PAM) – If Not Equipped With Stop/Start Option – – Not Used 10 Amp Red – Power Transfer Unit Switch (TSBM)/Active Grill Shutter (AGS) – If Equipped With Gas Engine 10 Amp Red –...
  • Page 201 Cavity Blade Fuse Cartridge Fuse Description – 20 Amp Blue Engine Controller Module (Gas) – 30 Amp Pink Electric Park Brake (EPB) – Left – – Not Used 20 Amp Yellow – Horns – If Equipped With Stop/Start Engine Option F87A 20 Amp Yellow –...
  • Page 202: Interior Fuses

    Interior Fuses The interior fuse panel is located on the Body Control Module (BCM) in the passenger com- partment on the left side dash panel under the instrument panel. Cavity Blade Fuse Description 15 Amp Blue Low Beam Left 10 Amp Red Interior Lighting 10 Amp Red Intrusion Module/Siren –...
  • Page 203: Jacking And Tire Changing

    JACKING AND TIRE Jack Location/Spare Tire Stowage 3. Remove the hook from the stowed posi- tion on the back side of the load floor and CHANGING The jack, wheel chocks and spare tire are place the hook over the top body flange stowed under the load floor behind the rear and weather seal.
  • Page 204 5. Turn the ignition off to the LOCK position. Jacking Instructions WARNING! 6. Chock both the front and rear of the wheel WARNING! A loose tire or jack thrown forward in a diagonally opposite of the jacking posi- collision or hard stop could endanger the tion.
  • Page 205 1. Remove the spare tire, jack, and wheel WARNING! bolt wrench. • If working on or near a roadway, be 2. If equipped with aluminum wheels where extremely careful of motor traffic. the center cap covers the wheel bolts, use •...
  • Page 206 Jacking Locations...
  • Page 207 • Refer to “Tires” in “Servicing And Main- tenance” in the Owner's Manual on Raising the vehicle higher than necessary www.jeep.com/en/owners/manuals/ for can make the vehicle less stable. It could additional warnings, cautions, and in- slip off the jack and hurt someone near it.
  • Page 208: Changing Procedure

    9. Install the wheel bolts with the threaded 12. Securely stow the jack, tools, chocks, 3. Lower the vehicle to the ground by turning end of the wheel bolt toward the wheel. and flat tire. the jack handle counterclockwise. Lightly tighten the wheel bolts. 4.
  • Page 209: Tire Service Kit - If Equipped

    TIRE SERVICE KIT — Tire Service Kit Components And Operation Using The Mode Select Knob And Hoses IF EQUIPPED Your Tire Service Kit is equipped with the following symbols to indicate the air or seal- Small punctures up to 1/4 inch (6 mm) in the ant mode.
  • Page 210: Tire Service Kit Usage Precautions

    Tire Service Kit Usage Precautions • For optimum performance, make sure the WARNING! valve stem on the wheel is free of debris • Replace the Tire Service Kit Sealant Bottle before connecting the Tire Service Kit. • Do not attempt to seal a tire on the side (1) and Sealant Hose (6) prior to the •...
  • Page 211: Sealing A Tire With Tire Service Kit

    Sealing A Tire With Tire Service Kit (B) Setting Up To Use Tire Service Kit: WARNING! 1. Push in the Mode Select Knob (5) and (A) Whenever You Stop To Use Tire Service stow the Tire Service Kit in the place turn to the Sealant Mode position.
  • Page 212 NOTE: 2. Connect the Power Plug (8) to a different 2. The pump will start to inject air into the 12 Volt power outlet in your vehicle or tire immediately after the Sealant Bottle Manual transmission vehicles must have another vehicle, if available. Make sure (1) is empty.
  • Page 213 2. Remove the Speed Limit sticker from the (D) Drive Vehicle: 2. Uncoil the power plug and insert the plug top of the Sealant Bottle (1) and place the into the vehicle's 12 Volt power outlet. Immediately after injecting sealant and in- sticker on the instrument panel.
  • Page 214: Jump Starting Procedures

    2. Disconnect the Tire Service Kit from the (F) Sealant Bottle And Hose Replacement: JUMP STARTING valve stem, reinstall the cap on the valve PROCEDURES 1. Uncoil the Sealant Hose (6) (clear in stem and unplug from 12 Volt outlet. color).
  • Page 215: Preparations For Jump-Start

    Preparations For Jump-Start WARNING! WARNING! The battery in your vehicle is located in the • Take care to avoid the radiator cooling Do not allow vehicles to touch each other front of the engine compartment, behind the as this could establish a ground connec- fan whenever the hood is raised.
  • Page 216: Refueling In Emergency

    Connecting The Jumper Cables 5. Start the engine in the vehicle that has CAUTION! the booster battery, let the engine idle for 1. Connect the positive (+) end of the jumper a few minutes, and then start the engine Accessories plugged into the vehicle cable to the positive (+) post of the dis- in the vehicle with the discharged battery.
  • Page 217: If Your Engine Overheats

    IF YOUR ENGINE NOTE: GEAR SELECTOR OVERRIDE There are steps that you can take to slow OVERHEATS If a malfunction occurs and the gear selector down an impending overheat condition: cannot be moved out of the PARK position, In any of the following situations, you can •...
  • Page 218: Freeing A Stuck Vehicle

    5. Insert a small screwdriver or similar tool FREEING A STUCK VEHICLE WARNING! down into the gear selector override ac- If your vehicle becomes stuck in mud, sand cess hole (at the right front corner of the Fast spinning tires can be dangerous. or snow, it can often be moved using a rock- gear selector assembly), and push and Forces generated by excessive wheel...
  • Page 219: Towing A Disabled

    TOWING A DISABLED CAUTION! CAUTION! VEHICLE • When “rocking” a stuck vehicle by shift- • Racing the engine or spinning the ing between DRIVE/ SECOND gear and This section describes procedures for towing wheels may lead to transmission over- REVERSE, do not spin the wheels faster heating and failure.
  • Page 220: Front-Wheel Drive (Fwd) Models

    Proper towing or lifting equipment is required If you must use the accessories (wipers, de- CAUTION! to prevent damage to your vehicle. Use only frosters, etc.) while being towed, the ignition • When securing the vehicle to a flat bed tow bars and other equipment designed for must be in the ON/RUN mode, not the ACC truck, do not attach to front or rear...
  • Page 221: 4X4 Models With 1-Speed Power Transfer Unit

    • Ensure that the Electric Park Brake is CAUTION! WARNING! released, and remains released, while be- • Towing this vehicle in violation of the ing towed. Towing this vehicle in violation of the above requirements can cause severe above requirements can cause severe Refer to “Recreational Towing”...
  • Page 222: Enhanced Accident Response System (Ears)

    Using Recovery Strap ENHANCED ACCIDENT WARNING! RESPONSE SYSTEM (EARS) 1. Review all warnings and instructions first. Recovery straps should only be used in 2. Position the recovery vehicle. This vehicle is equipped with an Enhanced emergencies to rescue stranded vehicles. Only use Recovery straps on vehicles that fit Accident Response System.
  • Page 223 SERVICING AND MAINTENANCE SERVICING AND MAINTENANCE SCHEDULED SERVICING ..222 Windshield Wiper Blades ..232 DEPARTMENT OF TRANSPORTATION UNIFORM Cooling System ....236 Maintenance Plan .
  • Page 224: Scheduled Servicing

    To Know Your Instrument Panel” in your Own- • Check the fluid levels of the coolant reser- voir and brake master cylinder, fill as er's Manual at www.jeep.com/en/owners/ Your vehicle is equipped with an automatic manuals/ for further information. needed.
  • Page 225 Mileage or time passed (whichever comes first) Or Years: Or Kilometers: Additional Inspections Inspect the CV joints. Inspect front suspension, boot seals. tie rod ends, and replace if necessary. Inspect the brake linings, parking brake function. Inspect front accessory drive belt, tensioner, idler pulley, and replace if necessary.
  • Page 226: Heavy Duty Use Of The Vehicle

    Heavy Duty Use Of The Vehicle WARNING! Change Engine 4,000 miles • You can be badly injured working on or (6,500 km) if the vehicle is operated in a around a motor vehicle. Do only service dusty and off road environment or is operated work for which you have the knowledge predominately at idle or only very low engine and the right equipment.
  • Page 227: Engine Compartment

    ENGINE COMPARTMENT 2.4L Engine 1 — Engine Coolant Reservoir 5 — Battery 2 — Oil Fill Cap 6 — Washer Fluid Reservoir 3 — Brake Fluid Reservoir 7 — Engine Oil Dipstick 4 — Power Distribution Center (Fuses) 8 — Air Cleaner Filter...
  • Page 228: 3.2L Engine

    3.2L Engine 1 — Engine Coolant Reservoir 6 — Washer Fluid Reservoir 2 — Oil Filter Access Cover 7 — Engine Oil Dipstick 3 — Brake Fluid Reservoir 8 — Engine Oil Fill 4 — Power Distribution Center (Fuses) 9 — Air Cleaner Filter 5 —...
  • Page 229: Checking Oil Level

    Checking Oil Level CAUTION! WARNING! To assure proper engine lubrication, the en- Overfilling or underfilling the crankcase Commercially available windshield washer gine oil must be maintained at the correct will cause aeration or loss of oil pressure. solvents are flammable. They could ignite level.
  • Page 230: Dealer Service

    WARNING! CAUTION! WARNING! • Battery gas is flammable and explosive. • If a “fast charger” is used while the You can be badly injured working on or Keep flame or sparks away from the battery is in the vehicle, disconnect both around a motor vehicle.
  • Page 231: Engine Air Cleaner Filter

    Engine Air Cleaner Filter Engine Air Cleaner Filter Selection Engine Air Cleaner Filter Installation The quality of replacement engine air cleaner Refer to the “Maintenance Plan” in this sec- NOTE: tion for the proper maintenance intervals. filters varies considerably. Only high quality Inspect and clean the housing if dirt or debris filters should be used to assure most efficient is present before replacing the air filter ele-...
  • Page 232 Refrigerant Recovery And Recycling — WARNING! CAUTION! R–1234yf • Use only refrigerants and compressor Do not use chemical flushes in your air R–1234yf Air Conditioning Refrigerant is a conditioning system as the chemicals can lubricants approved by the manufac- hydrofluoroolefin (HFO) that is endorsed by damage your air conditioning components.
  • Page 233 The A/C air filter is located in front of the 3. Pull down the passenger hush panel un- 4. Remove the filter door by pushing down evaporator on the lower right of center con- der the dash panel the tab on the top of the door to release sole.
  • Page 234: Windshield Wiper Blades

    5. Remove the A/C air filter by pulling it Avoid using the wiper blades to remove frost CAUTION! straight out of the housing. Take note of or ice from the windshield. Keep the blade the air filter position indicators. rubber out of contact with petroleum prod- The cabin air filter is identified with an ucts such as engine oil, gasoline, etc.
  • Page 235 Front Wiper Blade Removal/Installation 1. Lift the wiper arm to raise the wiper blade 2. To disengage the wiper blade from the off of the glass, until the wiper arm is in wiper arm, flip up the release tab on the the full up position.
  • Page 236 3. With the wiper blade disengaged, remove the Installing The Front Wipers NOTE: wiper blade from the wiper arm by holding The rear wiper arm cannot be fully raised 1. Lift the wiper arm off of the glass, until the wiper arm with one hand and separating off the glass unless the wiper arm pivot the wiper arm is in the full up position.
  • Page 237 2. Lift the rear wiper arm fully off the glass. 3. To remove the wiper blade from the wiper arm, grasp the bottom end of the wiper blade nearest to wiper arm with your right hand. With your left hand hold the wiper arm as you pull the wiper blade away from the wiper arm past its stop far enough to unsnap the wiper blade pivot pin from the...
  • Page 238: Cooling System

    Installing The Rear Wiper Cooling System WARNING! 1. Lift the rear wiper arm pivot cap away • You or others can be badly burned by hot WARNING! from the glass to allow the rear wiper engine coolant (antifreeze) or steam blade to be raised off of the glass.
  • Page 239: Automatic Transmission

    Check the engine cooling system hoses for Tire Markings CAUTION! brittle rubber, cracking, tears, cuts, and tightness of the connection at the coolant If a transmission fluid leak occurs, visit recovery bottle and radiator. Inspect the en- your authorized dealer immediately. Se- tire system for leaks.
  • Page 240 NOTE: • LT (Light Truck) — Metric tire sizing is • High flotation tire sizing is based on U.S. based on U.S. design standards. The size design standards and it begins with the • P (Passenger) — Metric tire sizing is designation for LT-Metric tires is the same tire diameter molded into the sidewall.
  • Page 241 Tire Sizing Chart EXAMPLE: Example Size Designation: P215/65R15XL 95H, 215/65R15 96H, LT235/85R16C, T145/80D18 103M, 31x10.5 R15 LT P = Passenger car tire size based on U.S. design standards, or "..blank.." = Passenger car tire based on European design standards, or LT = Light truck tire based on U.S.
  • Page 242 EXAMPLE: Service Description: 95 = Load Index • A numerical code associated with the maximum load a tire can carry H = Speed Symbol • A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions •...
  • Page 243 Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall tires as mounted on the vehicle. If The TIN may be found on one or both sides of the TIN is not found on the outboard side, the tire;...
  • Page 244 Tire Terminology And Definitions Term Definition B-Pillar The vehicle B-Pillar is the structural member of the body located behind the front door. Cold Tire Inflation Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least three hours, or driven less than 1 mile (1.6 km) after sitting for a minimum of three hours.
  • Page 245 Tire Loading And Tire Pressure This placard tells you important information about the: NOTE: 1. Number of people that can be carried in The proper cold tire inflation pressure is the vehicle. listed on the driver’s side B-Pillar or the rear edge of the driver's side door.
  • Page 246 To determine the maximum loading condi- (4) The resulting figure equals the Metric Example For Load Limit tions of your vehicle, locate the statement available amount of cargo and luggage For example, if “XXX” amount equals 635 kg “The combined weight of occupants and load capacity.
  • Page 247 • For the following example, the combined weight of occupants and cargo should never exceed 865 lbs (392 kg).
  • Page 248: Tires - General Information

    Safety Both under-inflation and over-inflation affect WARNING! the stability of the vehicle and can produce a WARNING! feeling of sluggish response or over respon- Overloading of your tires is dangerous. siveness in the steering. Overloading can cause tire failure, affect •...
  • Page 249 Tire Inflation Pressures pressure after the vehicle has not been driven Tire Pressures For High Speed Operation for at least three hours, or driven less than The proper cold tire inflation pressure is The manufacturer advocates driving at safe 1 mile (1.6 km) after sitting for a minimum of listed on the driver's side B-Pillar or rear edge speeds and within posted speed limits.
  • Page 250 Radial Ply Tires Damaged Run Flat tires, or Run Flat tires that Tire Spinning have experienced a loss of pressure should be When stuck in mud, sand, snow, or ice con- replaced immediately with another Run Flat WARNING! ditions, do not spin your vehicle's wheels tire of identical size and service description above 30 mph (48 km/h) or for longer than Combining radial ply tires with other types...
  • Page 251 Tread Wear Indicators Life Of Tire Keep dismounted tires in a cool, dry place with as little exposure to light as possible. Tread wear indicators are in the original The service life of a tire is dependent upon Protect tires from contact with oil, grease, equipment tires to help you in determining varying factors including, but not limited to: and gasoline.
  • Page 252: Tire Types

    It is recommended to replace the two front WARNING! CAUTION! tires or two rear tires as a pair. Replacing just one tire can seriously affect your vehicle’s • Do not use a tire, wheel size, load rating, Replacing original tires with tires of a handling.
  • Page 253: Spare Tires - If Equipped

    For more information, contact an Service Kit” in “In Case Of Emergency” in adversely affect the safety authorized dealer. your Owner’s Manual on www.jeep.com/en/ and handling of your vehicle. owners/manuals for further information. Summer tires do not contain the all season...
  • Page 254 Spare Tire Matching Original Equipped Tire Since this tire has limited tread life, the Full Size Spare — If Equipped original equipment tire should be repaired (or And Wheel — If Equipped The full size spare is for temporary emer- replaced) and reinstalled on your vehicle at gency use only.
  • Page 255: Wheel And Wheel Trim Care

    Your wheels are susceptible to deterioration Mopar Chrome Cleaner or their equivalent is WARNING! recommended or select a non-abrasive, non- caused by salt, sodium chloride, magnesium acidic cleaner for aluminum or chrome chloride, calcium chloride, etc., and other Limited use spares are for emergency use wheels.
  • Page 256: Tire Chains (Traction Devices)

    Dark Vapor Chrome, Black Satin Chrome, • Due to limited clearance, the following WARNING! or Low Gloss Clear Coat Wheels traction devices are recommended: Using tires of different size and type Front Wheel Drive (FWD) Models CAUTION! (M+S, Snow) between front and rear axles •...
  • Page 257: Tire Rotation Recommendations

    Refer to the “Maintenance Plan” for the CAUTION! CAUTION! proper maintenance intervals. The reasons To avoid damage to your vehicle or tires, • Observe the traction device manufactur- for any rapid or unusual wear should be observe the following precautions: er’s instructions on the method of instal- corrected prior to rotation being performed.
  • Page 258: Transportation Uniform

    The suggested Four Wheel Drive (4WD) Tire DEPARTMENT OF Treadwear rotation method is the “rearward cross” TRANSPORTATION The Treadwear grade is a comparative shown in the following diagram. UNIFORM TIRE QUALITY rating, based on the wear rate of the tire when tested under controlled con- GRADES ditions on a specified government test The following tire grading categories...
  • Page 259: Traction Grades

    Traction Grades Temperature Grades WARNING! The Traction grades, from highest to The Temperature grades are A (the The temperature grade for this tire is lowest, are AA, A, B, and C. These highest), B, and C, representing the established for a tire that is properly grades represent the tire's ability to tire's resistance to the generation of inflated and not overloaded.
  • Page 260: Bodywork

    • If you do not disconnect the battery from • Whenever you leave the vehicle is station- BODYWORK the electrical system, check the battery ary for two weeks or more, run idle the charge every 30 days. Preserving The Bodywork engine for approximately five minutes, with the air conditioning system on and •...
  • Page 261: Interiors

    • If you carry special cargo such as chemi- Seat Belt Maintenance CAUTION! cals, fertilizers, de-icer salt, etc., be sure Do not bleach, dye or clean the belts with powder that will scratch metal and that such materials are well packaged and chemical solvents or abrasive cleaners.
  • Page 262: Plastic And Coated Parts

    Plastic And Coated Parts Leather Parts NOTE: If equipped with light colored leather, it Use Mopar Total Clean to clean vinyl upholstery. Mopar Total Clean is specifically recom- tends to show any foreign material, dirt, and mended for leather upholstery. fabric dye transfer more so than darker col- CAUTION! Your leather upholstery can be best preserved...
  • Page 263 TECHNICAL SPECIFICATIONS TECHNICAL SPECIFICATIONS VEHICLE IDENTIFICATION FUEL REQUIREMENTS ..264 FLUID CAPACITIES ..265 NUMBER ....262 Materials Added To Fuel .
  • Page 264: Vehicle Identification Number

    VEHICLE IDENTIFICATION NUMBER The Vehicle Identification Number (VIN) is found on the left front corner of the instru- ment panel. The VIN is visible from outside of the vehicle through the windshield. The VIN number also is stamped into the right front body, on the right front seat cross member.
  • Page 265: Wheel And Tire Torque Specifications

    WHEEL AND TIRE TORQUE Inspect the wheel mounting surface prior to After 25 miles (40 km), check the lug nut/ mounting the tire and remove any corrosion bolt torque to be sure that all the lug nuts/ SPECIFICATIONS or loose particles. bolts are properly seated against the wheel.
  • Page 266: Fuel Requirements

    Gasoline Only and a yellow fuel cap. Refer to lar” gasoline having a posted octane number of detergents to fur- the Owner’s Manual at www.jeep.com/en/ of 87 as specified by the (R+M)/2 method. owners/manuals/ for more information. ther aide in minimiz- The use of higher octane “Premium”...
  • Page 267: Fluid Capacities

    FLUID CAPACITIES U.S. Metric Fuel (Approximate) 2.4L and 3.2L Engines 15.8 Gallons 60 Liters Engine Oil With Filter 2.4 Liter Engine (SAE 0W-20, API Certified) 5.5 Quarts 5.2 Liters 3.2 Liter Engine (SAE 5W-20, API Certified) 6 Quarts 5.6 Liters Cooling System* 2.4 Liter Engine (Mopar Antifreeze/Engine 7.2 Quarts...
  • Page 268: Fluids And Lubricants

    FLUIDS AND LUBRICANTS Engine Component Fluid, Lubricant, or Genuine Part Engine Coolant We recommend you use Mopar Antifreeze/Coolant 10 Year/150,000 Mile Formula OAT (Organic Additive Technology) or equivalent meeting the requirements of FCA Standard MS.90032. Engine Oil – 2.4L Engine We recommend you use SAE 0W-20 API Certified Engine Oil, meeting the requirements of FCA Material Standard MS-6395 such as Mopar, Pennzoil, and Shell Helix.
  • Page 269 CAUTION! CAUTION! • Do not use water alone or alcohol-based • Mixing of engine coolant (antifreeze) engine coolant (antifreeze) products. Do other than specified Organic Additive not use additional rust inhibitors or an- Technology (OAT) engine coolant (anti- tirust products, as they may not be com- freeze), may result in engine damage patible with the radiator engine coolant and may decrease corrosion protection.
  • Page 270: Chassis

    Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission Use only Mopar ZF 8&9 Speed ATF Automatic Transmission Fluid, or equivalent. Failure to use the correct fluid may affect the function or performance of your transmission. Brake Master Cylinder We recommend you use Mopar DOT 3 Brake Fluid, SAE J1703 should be used. If DOT 3, SAE J1703 brake fluid is not available, then DOT 4 is acceptable.
  • Page 271: Mopar Accessories

    MOPAR ACCESSORIES • In choosing Authentic Accessories you • For the full line of Authentic Jeep Acces- gain far more than expressive style, pre- sories by Mopar, visit your local dealership Authentic Accessories By Mopar mium protection, or extreme entertain- or online at mopar.com for U.S.
  • Page 272 ELECTRONICS: • Mopar Web (WiFi) • Park Distance Sensors • Rear View Camera • Remote Start • Speaker Upgrades • Electronic Vehicle Tracking System CARRIERS: • Hitch-mount Bike Carrier • Sport Utility Bars • Roof-mount Bike Carrier • Roof Top Cargo Basket •...
  • Page 273 MULTIMEDIA MULTIMEDIA CYBERSECURITY... .273 Maintaining Your Uconnect Access UCONNECT SETTINGS ..300 Account ....280 TIPS CONTROLS AND IPOD/USB/SD CARD/MEDIA Built-In Features .
  • Page 274 Uconnect Phone (Bluetooth Voice Text Reply (Not Compatible Climate (8.4/8.4 NAV) ...322 Hands Free Calling) ... .306 With iPhone) ....313 Navigation (8.4/8.4 NAV) .
  • Page 275: Cybersecurity

    Instrument Panel” in your Owner’s Manual on tential risk of unauthorized and unlawful ac- ately. www.jeep.com/en/owners/manuals/. cess to your vehicle systems. NOTE: The risk of unauthorized and unlawful access • FCA US LLC or your dealer may contact to your vehicle systems may still exist, even if you directly regarding software updates.
  • Page 276: Tips Controls And General Information

    TIPS CONTROLS AND Right Switch Care And Maintenance Observe the following precautions to ensure GENERAL INFORMATION • Push the switch up or down to increase or the system is fully operational: decrease the volume. Steering Wheel Audio Controls • Push the button in the center to change •...
  • Page 277: Uconnect Access

    UCONNECT ACCESS Uconnect Access enhances your ownership • Listen to your text messages or send free- and driving experience by connecting your form text messages with your voice while Uconnect Access — If Equipped keeping your hands on the wheel, using vehicle to an operable 1X (voice/data) or 3G the Voice Texting feature.
  • Page 278: Uconnect Access Registration (Uconnect 8.4/8.4 Nav, U.s. 48 Contiguous States, Alaska And Hawaii)

    NOTE: To activate the trial, you must first register with Vehicles sold in Canada and Mexico DO Uconnect Access. After the trial period, if you NOT have 9-1-1 call system capabilities. wish to continue your Uconnect Access Ser- 9-1-1 or other emergency line operators in vices you can choose to purchase a subscrip- Canada and Mexico may not answer or tion.
  • Page 279: Download The Uconnect Access App

    Why sign up for Uconnect Access? Here are Download The Uconnect Access App • Once on the “Remote” screen, you can just a few examples of things you’ll be able to begin using Remote Door Lock/Unlock, You’re only a few steps away from using Remote Vehicle Start, and activate your remote commands and playing your favorite horn and lights remotely, if equipped.
  • Page 280: Send 'N Go

    2. Select the “Vehicle” icon to determine 3. Select the “Find Route” button that ap- To send a navigation route to your vehicle: the location of your vehicle. pears, once your vehicle is located. 1. Press the “Location” tab on the Uconnect Access Mobile App bottom bar.
  • Page 281: Renewing Subscriptions And Purchasing 3G Wi-Fi Hotspot (Uconnect 8.4/8.4 Nav, U.s. 48 Contiguous States, Alaska And Hawaii)

    4. Press the “Send To Vehicle” button, and Renewing Subscriptions And Purchasing The types of apps you can use with Uconnect then confirm the destination by pressing Access are: 3G Wi-Fi Hotspot (Uconnect 8.4/8.4 NAV, “Yes,” to send the navigation route to the U.S.
  • Page 282: Maintaining Your Uconnect Access

    App Manager Maintaining Your Uconnect Access WARNING! Account Press the “App Manager” button to access • ALWAYS obey traffic laws and pay atten- the following categories: Selling Your Vehicle tion to the road. Some Uconnect Access Favorite Apps services, including 9-1-1 and Assist, When you sell your vehicle, we recommend will NOT work without an operable 1X that you remove your Uconnect Access Ac-...
  • Page 283 NOTE: Assist Call (8.4/8.4 NAV) WARNING! • Your vehicle may be transmitting data as The rearview mirror contains an ASSIST push • If anyone in the vehicle could be in authorized by the subscriber. button, and the touchscreen contains a danger (e.g., fire or smoke is visible, •...
  • Page 284 • Roadside Assistance Call — If you get a flat nated. Have an authorized dealer service the Uconnect Care or Vehicle Care, whether such tire, or need a tow, you’ll be connected to vehicle if the rearview mirror light is continu- conversations are initiated through the someone who can help anytime.
  • Page 285: Vehicle Health Report/Alert

    Security Alarm Notification Your vehicle must have an operable 1X (voice/ Vehicle Health Report/Alert data) or 3G (data) network connection and The Theft Alarm Notification feature notifies Your vehicle will send you a monthly email must be registered with Uconnect Access you via email or text (SMS) message when the report, which summarizes the performance of with an active subscription that includes the...
  • Page 286 Visit UconnectPhone.com to determine if To use this feature after the Uconnect Access To use this feature after the Uconnect Access your device is compatible. For Uconnect App is downloaded, login using your user App is downloaded, login using your user Phone customer support and to determine if name and password.
  • Page 287 To use this feature after the Uconnect Access including all iPhones (Apple iOS). Visit 6. Uconnect will prompt you “Please say the UconnectPhone.com for system and de- message that you would like to send.” (If App is downloaded, login using your user name vice compatibility information.
  • Page 288 Sample Commands For Voice Text Reply And Voice Texting Example Command Action “Text John Smith” Send a message to specific contact in address book “Text 123 456 7890” Send 123 456 7890 a message from your phonebook “Show messages” See recent text messages listed by number on Uconnect screen “Listen to/view (message number four, for example)”...
  • Page 289: Uconnect 5.0

    UCONNECT 5.0 Controls On The Front Panel Uconnect 5.0 Radio 1 — RADIO Button 3 — CLIMATE Button 5 — Uconnect PHONE Button 2 — COMPASS Button 4 — MORE Functions Button 6 — MEDIA Button...
  • Page 290: Clock Setting

    Clock Setting Equalizer, Balance And Fade Press the Center “C” button on the touch- screen to reset the balance and fade to the 1. Push the MORE button on the faceplate. To start the clock setting procedure: factory setting. Press the “Back Arrow” but- Next press the “Settings”...
  • Page 291: Radio Mode

    Radio Mode During a Seek Down function, if the radio 2. Press and hold the desired numbered but- ton on the touchscreen for more than two reaches the starting station after passing Seek Previous/Next Buttons seconds or until you hear a confirmation through the entire band two times, the radio beep.
  • Page 292 Media Mode is entered by pushing the ME- You can press the “Source,” “Pause/Play” or If you insert a disc with the ignition ON and DIA button located on the faceplate. Once in the “Info” button on the touchscreen for the radio ON, the unit will switch to disc Media Mode, press the “Source”...
  • Page 293 USB/iPod Mode AUX Mode Track Selection AUX Mode is entered by inserting a AUX USB/iPod Mode is entered by either inserting Seek Up /Seek Down device using a stereo cable with a 3.5 mm a USB Jump Drive or iPod cable into the USB Press and release the “Right Arrow”...
  • Page 294: Bluetooth Source

    Info Before proceeding, the Bluetooth device 1. Place the ignition in the ACC or ON position. must be paired with the Uconnect Phone to Press the “Info” button on the touchscreen to communicate with the Uconnect system. 2. Push the PHONE button on the faceplate. display the current track information.
  • Page 295: Siriusxm Premier Over 160 Channels

    • Search for available devices on your Only one Bluetooth device can be con- • SiriusXM services require subscriptions, Bluetooth enabled device (see below). sold separately after the 12-month trial nected to the Uconnect system at a time. included with the new vehicle purchase. When prompted on the device, select If “No”...
  • Page 296: Uconnect 8.4/8.4 Nav

    UCONNECT 8.4/8.4 NAV Uconnect 8.4/8.4 NAV At A Glance Uconnect 8.4 NAV Radio Screen...
  • Page 297 • If the time is not displayed at the top of the Audio Settings WARNING! screen, press the “Settings” button on the • Press of the “Audio” button on the touch- touchscreen. In the Settings screen, press ALWAYS drive safely with your hands on screen to activate the Audio settings the “Clock”...
  • Page 298: Personalized Menu Bar

    Speed Adjusted Volume 1. Press the “Apps ” button to open the Radio Mode App screen. Press the “Speed Adjusted Volume” button 2. Press and hold, then drag the selected on the touchscreen to activate the Speed App to replace an existing shortcut in the Adjusted Volume screen.
  • Page 299: Media Mode

    Direct Tune • With an HD radio receiver, the listener is WARNING! provided with a clear sound that enhances • Tune directly to a radio station by pressing the listening experience. HD radio can ALWAYS drive safely with your hands on the “Tune”...
  • Page 300: Siriusxm Premier Over 160 Channels

    The controls are accessed by pressing the The following describes features that are Jump desired button on the touchscreen and available when in SiriusXM Satellite Radio • Automatically tells you when Traffic & choosing between Disc, AUX, USB, mode: Weather for a favorite city is available, and Bluetooth or SD Card.
  • Page 301 SiriusXM Parental Controls • SiriusXM also offers the option to perma- Browse nently block selected channels. Call • You can skip or hide certain channels from Lets you browse the SiriusXM channel listing (1-888-601-6297 for U.S. customers, view if you do not want access to them. or Genre listing.
  • Page 302: Uconnect Settings

    Replay • SiriusXM services require subscriptions, UCONNECT SETTINGS sold separately after the 12-month trial Lets you replay up to 44 minutes of the The Uconnect system allows you to access included with the new vehicle purchase. content of the current SiriusXM channel. Customer Programmable feature settings If you decide to continue your service at the such as Display, Voice, Clock, Safety &...
  • Page 303: Ipod/Usb/Sd Card/Media Player Control

    Features” in “Multimedia” in the Owner’s of the console. There are many ways to play music from Manual www.jeep.com/en/owners/ MP3 players, USB devices, or SD Cards manuals/ for further information. through your vehicle's sound system. Press your Media button on the touchscreen to...
  • Page 304: Usb Port

    USB Port Bluetooth Streaming Audio NOTE: When connecting your device for the first • Connect your compatible device using a If using a Bluetooth equipped device you may time, the system may take several minutes to USB cable into the USB Port. USB also be able to stream music to your vehicle's read your music, depending on the number of Memory sticks with audio files can also be...
  • Page 305: Changing The Navigation Voice Prompt Volume

    Press the “Nav” button on the touchscreen in Finding Points Of Interest the menu bar to access the Navigation sys- • From the main Navigation menu, press the tem. “Where To?” button on the touchscreen, then press the “Points of Interest” button Changing The Navigation Voice Prompt on the touchscreen.
  • Page 306: One-Step Voice Destination Entry

    One-Step Voice Destination Entry • You may enter your address directly, use your current location as your home ad- • Enter a navigation destination without tak- dress, or choose from recently found loca- ing your hands off the wheel. tions. •...
  • Page 307: Adding A Stop

    Adding A Stop UCONNECT PHONE NOTE: The Browse Phone Book button contains Operation • To add a stop you must be navigating a 9-1-1 route. • Press the “Menu” button on the touch- screen to return to the Main Navigation menu.
  • Page 308: Uconnect Phone Features

    NOTE: 16 — Reply with Text Message * — Conference call feature only available • The Uconnect Phone requires a mobile on GSM mobile devices phone equipped with the Bluetooth ** — Text messaging feature not available Hands-Free Profile, Version 1.0 or higher. on all mobile phones (requires •...
  • Page 309: Uconnect System

    The hands-free calling feature is made pos- Pairing (Wirelessly Connecting) Your Start Pairing Procedure On The Radio sible through Bluetooth technology — the Mobile Phone To The Uconnect System Uconnect 5.0: global standard that enables different elec- Mobile phone pairing is the process of estab- tronic devices to connect to each other wire- lishing a wireless connection between a cel- lessly.
  • Page 310 Uconnect 8.4, 8.4 NAV: Pair Your iPhone 3. When your mobile phone finds the Uconnect system, select “Uconnect”. Complete The iPhone Pairing Procedure Uconnect 8.4 & 8.4 NAV 1. Place the ignition in the ACC or ON position. Pairing Request 2.
  • Page 311 Select The iPhone's Priority Level Pair Your Android Device 4. Turn Bluetooth setting to “On.” When the pairing process has successfully • Ensure the Bluetooth feature is en- completed, the system will prompt you to abled. Once enabled, the mobile phone choose whether or not this is your favorite will begin to search for Bluetooth mobile phone.
  • Page 312: Common Phone Commands (Examples)

    Complete The Android Pairing Procedure Select The Android Mobile Phone's Priority Common Phone Commands (Examples) Level • “Call John Smith” When the pairing process has successfully • “Call John Smith mobile” completed, the system will prompt you to • “Dial 1 248 555 1212” choose whether or not this is your favorite •...
  • Page 313: Voice Command Tips

    If your phone book entries do not appear, • If you are listening to available voice com- Using Do Not Disturb mand options, you do not have to listen to check the settings on your phone. Some With Do Not Disturb, you can disable notifi- the entire list.
  • Page 314: Incoming Text Messages

    • Auto reply with text message is only avail- 2. Select Bluetooth. 2. Select Settings. able on phones that support Bluetooth • Ensure Bluetooth is enabled, and the 3. Select Connections. MAP. mobile phone paired 4. Turn “Show Notifications” to On. Uconnect system.
  • Page 315: Voice Text Reply (Not Compatible With Iphone)

    Voice Text Reply Here’s How PRE-DEFINED VOICE TEXT REPLY RESPONSES (Not Compatible With iPhone) 1. Push the Uconnect Phone button Stuck Yes. See you later. in traffic. and wait for the beep, then say “reply.” NOTE: Start Uconnect will give the following prompt: I’ll be late.
  • Page 316: Helpful Tips And Common Questions To Improve Bluetooth Performance With Your Uconnect System

    Helpful Tips And Common Questions To Mobile Phone won’t pair to system: Text messaging won’t work: Improve Bluetooth Performance With • Perform a hard reset in the mobile phone • Check “Do not ask again,” then accept the Your Uconnect System by removing the battery (if removable —...
  • Page 317: General Information

    General Information This device complies with Part 15 of the FCC rules and RSS 210 of Industry Canada. Op- eration is subject to the following conditions: • Changes or modifications not expressly approved by the party responsible for com- pliance could void the user’s authority to operate the equipment.
  • Page 318: Uconnect Voice Recognition Quick Tips

    UCONNECT VOICE RECOGNITION QUICK TIPS Introducing Uconnect Start using Uconnect Voice Recognition with these helpful quick tips. It provides the key Voice Commands and tips you need to know to control your Uconnect 5.0 or 8.4/8.4 NAV system. Uconnect 5.0 Uconnect 5.0...
  • Page 319 Uconnect 8.4/8.4 NAV If you see the icon on your touchscreen, you have the Uconnect 8.4 NAV system. If not, you have a Uconnect 8.4 system. Uconnect 8.4 NAV...
  • Page 320: Get Started

    4. Each time you give a Voice Command, you 2. Uconnect Voice Recognition Button WARNING! must first push either the VR or Phone button, wait until after the beep, then say ALWAYS drive safely with your hands on a. Short Press: Push and release the VR your Voice Command.
  • Page 321: Radio

    Notice the visual cues that inform you of your Radio voice recognition system’s status. Cues ap- Use your voice to quickly get to the AM, FM or pear on the touchscreen. SiriusXM Satellite Radio stations you would like to hear. (Subscription or included SiriusXM Satellite Radio trial required.) Push the VR button .
  • Page 322: Phone

    • Play artist Beethoven; Play album Greatest Push the Phone button . After the beep, Hits; Play song Moonlight Sonata; Play say one of the following commands… genre Classical • Call John Smith TIP: Press the Browse button on the touch- •...
  • Page 323: Voice Text Reply

    PRE-DEFINED VOICE TEXT REPLY RESPONSES Stuck Yes. See you later. in traffic. Start I’ll be late. without me. Where Okay. I will be are you? <number> Are you minutes late. Call me. there yet? I’ll call I need See you in Uconnect 8.4/8.4 NAV Phone you later.
  • Page 324: Climate (8.4/8.4 Nav)

    Climate (8.4/8.4 NAV) Navigation (8.4/8.4 NAV) Too hot? Too cold? Adjust vehicle tempera- The Uconnect navigation feature helps you tures hands-free and keep everyone comfort- save time and become more productive when able while you keep moving ahead. (If vehicle you know exactly how to get to where you is equipped with climate control.) want to go.
  • Page 325: Register (8.4/8.4 Nav)

    An included trial and/or subscription is required • Uconnect Access is available only on prop- **If vehicle is properly equipped. to take advantage of the Uconnect Access ser- erly equipped vehicles purchased within ***Extra charges apply. the continental United States, Alaska and vices in the next section of this guide.
  • Page 326: Vehicle Health Alert

    2. Press the “Uconnect Care” button on the Mobile App (8.4/8.4 NAV) • Once on the “Remote” screen, you can touchscreen. begin using Remote Door Lock/Unlock, You’re only a few steps away from using Remote Vehicle Start, and activate your 3.
  • Page 327: Yelp (8.4/8.4 Nav)

    3. The Uconnect system will repeat your To enable this feature on your Apple iPhone, TIP: message and provide a variety of options follow these 4 simple steps: • Voice Texting is not compatible with to add to, delete, send or hear the mes- iPhone, but if your vehicle is equipped sage again.
  • Page 328: Siriusxm Travel Link (8.4/8.4 Nav - Us Market Only)

    TIP: Once you perform a search, you can Push the VR button . After the beep, say Siri Eyes Free — If Equipped reorganize the results by selecting either the one of the following commands: Siri lets you use your voice to send text Best Match, Rating or Distance tab on the top •...
  • Page 329 Getting Started 1. Pair your Siri enabled device to the ve- 2. Push and Hold, then release the Uconnect hicles sound system. Refer to “Uconnect Voice Recognition (VR) button Ensure Siri is enabled on your iPhone. Phone” in “Multimedia” for a detailed the steering wheel.
  • Page 330: Do Not Disturb

    NOTE: Do Not Disturb NOTE: • Reply with text message is not compatible • Speak clearly at a normal pace and With Do Not Disturb, you can disable notifi- with iPhones. volume while facing straight ahead to cations from incoming calls and texts, allow- ensure your command is understood.
  • Page 331 CUSTOMER ASSISTANCE CUSTOMER ASSISTANCE SUGGESTIONS FOR OBTAINING In Mexico Contact ....331 REPORTING SAFETY SERVICE FOR YOUR VEHICLE . .330 DEFECTS ....332 Puerto Rico And U.S.
  • Page 332: Suggestions For Obtaining

    SUGGESTIONS FOR and list the items in order of priority. At many • If for some reason you are still not satis- authorized dealers, you may obtain a rental fied, talk to the general manager or owner OBTAINING SERVICE FOR of the authorized dealer.
  • Page 333: Fca Canada Inc. Customer Center

    FCA Canada Inc. Customer Center Customer Assistance For The Hearing If you purchased a manufacturer's service contract, you will receive Plan Provisions and Or Speech Impaired (TDD/TTY) P.O. Box 1621 an Owner Identification Card in the mail To assist customers who have hearing diffi- within three weeks of the vehicle delivery Windsor, Ontario N9A 4H6 culties, the manufacturer has installed spe-...
  • Page 334: Warranty Information

    We appreciate that you have made a major WARRANTY INFORMATION If NHTSA receives similar complaints, investment when you purchased the vehicle. it may open an investigation, and if it See the Warranty Information Booklet for the An authorized dealer has also made a major finds that a safety defect exists in a terms and provisions of FCA US LLC warran- investment in facilities, tools, and training to...
  • Page 335: In Canada

    Jeep Contact Us page at Transport Canada, Motor Vehicle De- the drop down lists. www.jeep.com scroll to the bottom of the fect Investigations and Recalls at page and select the “Contact Us”...
  • Page 337 INDEX Access Air Cleaner, Engine Automatic Temperature Control (ATC) . . .55 Uconnect ..275, 276, 280 (Engine Air Cleaner Filter) ..229 Automatic Transaxle ... .154 Accessories .
  • Page 338 Caps, Filler Child Safety Locks ....23 Do Not Disturb....328 Fuel ....180, 214 Cleaning Door Ajar .
  • Page 339 Fails To Start ....152 Fluid Level Checks Automatic ....35, 36 Flooded, Starting ... .152 Engine Oil .
  • Page 340 Jack Operation ..201, 202, 237 Daytime Running ... .35 Power Door ....19 Jump Starting .
  • Page 341 Checking ....227 Placard, Tire And Loading Rear Cross Path ....102 Dipstick .
  • Page 342 Roll Over Warning ....2 Adjustable Upper Shoulder Sentry Key Replacement ..14 Rotation, Tires ....255 Anchorage .
  • Page 343 Mode Setting (ACC Only) ..170 Text Messaging ..312, 313, 321, 324 Spare Tire ... . .251, 252 Spinning ....248 .
  • Page 344 Uconnect Uconnect (Hands-Free Phone) Washer Access ... .275, 276, 280 Making A Phone Call ..305, 311 Rear ....40 Account .
  • Page 347: Driving And Alcohol

    Driving and Alcohol: This guide has been prepared to help you get quickly acquainted with your new Jeep brand vehicle and to provide a Drunken driving is one of the most frequent causes of collisions. Your convenient reference source for common driving ability can be seriously impaired with blood alcohol levels far below questions.
  • Page 348 DOWNLOAD A FREE ELECTRONIC COPY of the Owner’s Manual and Warranty Booklet by visiting: www.mopar.com/Jeep www.jeep.com/en/owners/manuals or www.jeep.com/en/warranty (U.S.); www.owners.mopar.ca/en (Canada). ©2017 FCA US LLC. All Rights Reserved. Jeep is a registered trademark of FCA US LLC.

Table of Contents

Save PDF
