Safety warnings

Damage
Never use your TV if it is damaged in
any way. Always place your TV on a
flat level surface avoiding anywhere
which may be subject to strong
vibration.
Weather
It is advisable to unplug the aerial
during an electrical storm.
Moisture
Do not allow your TV to be exposed
to rain, moisture, dust. If any liquid is
spilt into your TV it can cause serious
damage. If you spill any liquid into
your TV switch it off at the mains
immediately. Contact your store.
Interference
Do not place your TV on or near
appliances which may cause
electromagnetic interference (TV or
HiFi speakers). If you do, it may
adversely affect the working of the
unit, and cause a distorted picture or
sound.
ATTENTION! If a bright stationary image is left on any TV for a long enough
period of time, (longer than 4 hours continuous display), it is possible that some
screen burn may result - this leaves a shadow of the image on the screen even
after the original image has been removed.
Stationary images to watch out for are:
TV games with static scenes (background, scores, time remaining, etc)
Programme channel identifiers shown in corner of TV screen and the red
interactive logo on BBC channels via satellite
DVD on-screen logos and displays (eg the logo displayed during audio CD
playback)
Radio station identifier screen on satellite
If a still picture cannot be avoided, then reduce the brightness and contrast levels
of the picture to minimise any damage that might occur.
Temperature
Avoid extremes of temperature, either
hot or cold, place your TV well away
from heat sources such as radiators or
gas/electric fires.
Ventilation
The TV must be well ventilated. Do not
cover your TV or position in a small
confined space. It is recommended
that you leave a 10cm gap all around
your TV.
Batteries
Batteries are easily swallowed by
young children. Do not allow young
children to play with the remote
control unit.
Covers
Do not remove any fixed covers as
this may expose dangerous voltages.
Standby
Do not leave your TV in standby for
long periods of time e.g. overnight or
while on holiday.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LCXW30NN6 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Logik LCXW30NN6

  • Page 1: Safety Warnings

    Safety warnings Damage Temperature Avoid extremes of temperature, either Never use your TV if it is damaged in hot or cold, place your TV well away any way. Always place your TV on a from heat sources such as radiators or flat level surface avoiding anywhere gas/electric fires.
  • Page 2: Table Of Contents

    Contents Basic TV features Connection leads supplied page 1 TV connections page 2 Controls page 3 Tuning your TV page 4-5 Basic TV functions page 6-8 Teletext features page 9 Using external VCR/DVD connections page 10 External VCR/DVD AV connection page 11 External VCR/DVD SV connection page 12...
  • Page 3: Connection Leads Supplied

    Connection Leads Supplied VGA cable AV cable AC Power cord...
  • Page 4: Tv Connections

    TV Connections PC VGA(Analog) Scart (Euro Region) PC Audio Input RS232 S-Video Video Audio Output(L/R) Subwoofer Output RF lead (not supplied) Tuner Power AC 220V TV Connections 1. Connect an RF lead (not supplied) into the aerial socket and into a TV wall socket.
  • Page 5: Controls

    Controls Buttons on the Right at the Top of the LCD TV SOURCE MENU CH./ADJ. VOL./ADJ. Remote Control Power PIP Function Buttons Scale of Screen Button Sound Select Freeze Button (for American NTSC system only) Menu Function Buttons Sleep Control Volume Control Source Select Channel Control...
  • Page 6: Tuning Your Tv

    Tuning in your LCD TV Switch your LCD TV ON If you only want TV connection, connect Turn power on at the mains socket to put your unit as shown the LCD TV into standby mode (the standby in the diagram and indicator on the front will light up in red).
  • Page 7 Tuning your LCD TV Identify channel & "PR" number Channel Press the CH buttons to find each Name good quality picture. eg PR1 Use your TV guide or T eletext to identify eg PR4 BBC1 the channel (eg BBC1, BBC2, ITV, etc) and make a note of both this and the PR number (on the top left of the TV screen) in the chart opposite.
  • Page 8: Basic Tv Functions

    Basic TV functions Changing channels ++++ Press the "CH " button to change channels up or down. Alternatively, use the numbered buttons (0-9) to go directly to a specific channel. Adjusting the volume Press the "VOL " button to turn the volume up or down.
  • Page 9: Adjusting Picture Settings

    Basic TV functions Using the MODE INF. function Press the "MODE INF." button to show the 1: TV 2: OFF VGA YPbPr1 YPbPr2 setting information on the screen. CHANNEL NO.: 40 MONO Adjusting picture settings Press the "MENU" (a) button in TV mode. Press the "...
  • Page 10 Basic TV Functions Using the SCALING button Use the SCALING button on the remote control to switch the aspect ratio as indicated here: FILL ALL Use FILL ALL to stretch programs to occupy more of the screen. Use FILL ALL to view wide format DVD movies, or enhanced for 16:9 TV.
  • Page 11: Teletext Features

    Teletext features Teletext is the name given to the magazine services operated Using the Teletext feature by television companies. A variety of information Slide the cover downwards on the bottom is available including of the remote control. News, Weather, Teletext is ready for use. Financial and Press the "ON/OFF"...
  • Page 12: Using External Vcr/Dvd Connections

    Using external VCR/DVD connections VCR/DVD connection Connect your unit to a VCR/DVD as Connect your VCR or DVD as shown on page 10-13. shown in the diagram Start to play a Video/DVD in your VCR or DVD. and instructions on page 10-13.
  • Page 13: External Vcr/Dvd Av Connection

    External VCR/DVD AV Connection NOTE: Connect your LCD TV as shown in the TV Connections diagram on page 2 before using the VCR/DVD connections shown below. Scart (Euro Region) White VIDEO or DVD S-Video Video External VCR/DVD AV Connection 1. Connect the video lead on the lefthand side (viewed from the back) of your LCD TV and to the video socket on your DVD or VCR player as shown above.
  • Page 14: External Vcr/Dvd Sv Connection

    External VCR/DVD SV Connection NOTE: Connect your LCD TV as shown in the TV Connections diagram on page 2 before using the VCR/DVD connections shown below. Scart (Euro Region) White VIDEO or DVD S-Video Video Audio In External VCR/DVD SV Connection 1.
  • Page 15: External Vcr/Dvd Component Connection

    External VCR/DVD Component Connection NOTE: Connect your LCD TV as shown in the TV Connections diagram on page 2 before using the VCR/DVD connections shown below. Green Scart Blue (Euro Region) White VIDEO or DVD Audio In S-Video Video Blue Component Green White...
  • Page 16: External Vcr/Dvd Scart Connection

    External VCR/DVD Scart Connection NOTE: Connect your LCD TV as shown in the TV Connections diagram on page 2 before using the VCR/DVD connections shown below. Scart (Euro Region) VIDEO or DVD Scart Cable S-Video Video External VCR/DVD Scart Connection 1.
  • Page 17: Using Your Pip Functions

    Using your PIP Functions Connect your unit Selecting main picture to a PC as shown 1: TV 2: OFF VGA YPbPr1 YPbPr2 CHANNEL NO.: 40 MONO in the diagram Press the "MAIN MODE" button on the and instructions on remote control. page 16.
  • Page 18 Using your PIP Functions Select the Size of PIP Connect your unit to a PC as shown 1: VGA 2: OFF TV AV SV Scart Press the "PIP-SIZE" button to bring up the in the diagram OSD menu. and instructions on Press the "PIP-SIZE"...
  • Page 19: Pc Connections

    PC Connections PC VGA(Analog) PC Audio Input VGA cable RS232 Audio Output(L/R) Audio In Subwoofer Output Audio Out (not supplied) RF lead (not supplied) Tuner Power AC 220V PC Connection NOTE: Make sure that your PC is shut down and switched off before you make any of the connections described and shown above.
  • Page 20: Troubleshooting And Specifications

    Troubleshooting and Specifications Symptom Cause Solution Poor or no colour Aerial or connection cable is not Check al aerial connections connected or is damaged. for broken or damaged wires. If necessary replace with new cables. Try using aerial booster to improve the quality of the signal.
  • Page 21: External Specifications

    External Specifications Display Panel Screen Size 643.2mm x 385.92mm (29.54" Diagonal) Aspect Ratio 16:9 Number of Pixels 1280x768x3(R/G/B) Pixel Pitch 0.5025mm pixel pitch. Display Color 16.7M(R/G/B 8Bits) Luminance 550 cd/m2 (Typ @ Center) Contrast (CR>=10) 600: 1 (Typ) Viewing Angel Horizontal: 170 Degrees Vertical: 170 Degrees Response Time (Gray to gray) 16 ms (typ) Expected Life Time...
  • Page 22 External Specifications Weight Net Weight 22.5 KG Gross Weight 29.0 KG Stand Weight 4.6 KG Wall mount weight 17.9 KG Environment Temperature(Operation/Storage) 32 F to 104 F(0 C to 40 C) / -4 F to 140 F (-20 C to 60 C) Relative Humidity (Operation/Storage) 10% to 90% (no condensation) / 10% to 90% (no condensation)
