  • Page 1 26” Full HD LED TV Instruction Manual L26FE12 L26FE12_IB_120308_Annie.indd 1 12年3月8日 上午10:40...
  • Page 2 L26FE12_IB_120308_Annie.indd 2 12年3月8日 上午10:40...

  • Page 3: Table Of Contents

    Contents Preparation ......................................5 Unpacking the TV ..........................................5 Installing / Removing the Base Stand ..................................6 Front / Right Side View and Controls ...................................7 Rear View and Sockets ........................................8 Installing Batteries in the Remote Control ................................9 Remote Control Operation Range ....................................9 Remote Control ..........................................10 Making Video and Audio Connections ..................................13 Connecting an AV Device Using an HDMI Cable..............................13 Connections ......................................13...
  • Page 4 Using the Features ...................................39 EPG (Electronic Programme Guide) (DTV Mode) ..............................39 − Switch On / Off EPG ......................................39 − Select a Programme ......................................39 Teletext (ATV Mode) ........................................40 − To Turn on Teletext Function................................... 40 Digital Teletext (DTV Mode) ......................................41 −...

  • Page 5: Preparation

    Preparation Thank you for purchasing your new Logik 26" Full HD LED TV. Your new TV has many features and incorporates the latest technology to enhance your viewing experience. We recommend that you spend some time reading this instruction manual so that you fully understand these features.

  • Page 6: Installing / Removing The Base Stand

    Installing / Removing the Base Stand The LCD display is very fragile, and must be protected at all times when installing and removing the base stand. Be sure that no hard or sharp object, or anything that could scratch or damage the LCD display, comes into contact with it. DO NOT exert pressure on the front of the TV at any time because the screen could crack.

  • Page 7: Front / Right Side View And Controls

    Front / Right Side View and Controls Item Description Illuminates blue when the TV is turned on. Illuminates red when the TV is in standby POWER LED mode. The LED will flash blue and red when the timer programming has started in standby mode.

  • Page 8: Rear View And Sockets

    Rear View and Sockets SCART VIDEO Socket Description Connects to a DVD player, Digital Set-Top-Box, or other AV devices with component Y, PB, PR / AUDIO (L/R) (YPbPr) video and audio output sockets. Connects to the Composite VIDEO and AUDIO (L/R) output sockets on external video VIDEO / AUDIO (L/R) devices.

  • Page 9: Installing Batteries In The Remote Control

    Installing Batteries in the Remote Control 1. Press and lift the back cover to open the battery compartment of the remote control. 2. Insert two AAA size batteries. Make sure the (+) and ( - ) ends of the batteries match the (+) and ( - ) ends indicated in the battery compartment.

  • Page 10: Remote Control

    Remote Control Switch the TV between on and standby mode. MUTE Mute and restore your TV sound. 3. 0-9 Number Button • Press to select a programme. • Select numbered items in a menu. (DVD mode) 4. LIST • Display the channel list. (ATV / DTV mode) • Display the text page on the teletext screen.
  • Page 11 19. FAV Display the favourite channel list. (ATV / DTV mode) SETUP Display and exit the DVD setup menu. (DVD mode) 20. i Display the present screen information such as the current channel on ATV / DTV mode and the input source except ATV / DTV mode.
  • Page 12 Skip to the beginning of the next chapter / track / photo. (DVD / USB mode) REVEAL Reveal hidden information such as the answer to a quiz in teletext. (ATV mode) To skip to the beginning of the previous chapter / track / photo.

  • Page 13: Making Video And Audio Connections

    Connections Making Video and Audio Connections Not all AV devices have the ability to connect to a TV, please refer to the owner’s manual of your AV device for compatibility and connection procedures. When connecting any external AV device, do not connect the mains cable to the mains socket until all other connections are complete.

  • Page 14: Connecting A Computer Using A Vga Cable

    Connecting a Computer Using a VGA Cable Rear Right Side View of TV 1. Use a VGA cable to connect the TV’s PC IN input socket to a computer’s VGA output socket. Use an COMMON INTERFACE (CI) HDMI2 HDMI1 PC IN audio cable to connect the TV’s PC AUDIO input HEADPHONE PC AUDIO...

  • Page 15: Connecting An Av Device Using A Scart Cable

    Connecting an AV Device Using a SCART Cable Rear Right Bottom View of TV 1. Use a SCART cable to connect the TV’s SCART input SCART socket to an external AV device’s SCART output socket. VIDEO 2. Plug the connected devices into the mains socket before switching on the TV.

  • Page 16: Connecting Headphones

    Connecting Headphones Rear Right Side View of TV Connect your headphones to the TV’s HEADPHONE COMMON INTERFACE (CI) socket. HDMI2 HDMI1 PC IN HEADPHONE PC AUDIO Before putting on the headphones, turn the volume down then put the headphones on and slowly increase the volume until you reach a comfortable listening level.

  • Page 17: Initial Setup

    Initial Setup Turning the TV On for the First Time 1. Connect one end of the RF coaxial cable to the aerial socket on the wall and the other end of the cable to the RF (75Ω) socket at the rear right side of your TV.

  • Page 18: Target Region Descriptor

    7. Channel tuning will commence. This operation may take up to 6 minutes. Channel Tuning The display will show the progress of the tuning and the number of channels found. : 3 Channel(s) 8. If you want to skip the ATV tuning, press the MENU button to interrupt : 0 Channel(s) the tuning half way.

  • Page 19: Channel Selection

    Channel Selection • Press the CH + / – buttons on the remote control repeatedly or the 0-9 buttons to select the channel. Alternative Press the LIST button to enter the Channel List. Then use the buttons to highlight and select the channel. Press the OK button to view the selected channel.

  • Page 20: Customising Tv Settings

    Customising TV Settings Channel Setting (TV, DTV or Radio Mode) Auto Tuning Use this to automatically find and store all available channels. This is normally recommended if some channels have been added or removed by the broadcaster or if you have moved house. 1.

  • Page 21: Dtv Manual Tuning

    DTV Manual Tuning Allows you to make manual fine tuning adjustments to the channel under DTV mode. 1. Press the MENU button and then press the buttons to select the CHANNEL menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION...

  • Page 22: Channel Edit (Atv / Dtv Mode)

    3. The ATV Manual Tuning screen will pop up. Use the buttons to select ATV Manual Tuning the following options and the buttons to adjust the setting. Storage To 1 Storage To Presets the channel number. Sound System I Selects the sound system: I / DK / BG / L (for Sound System SECAM).

  • Page 23: Signal Information (Dtv Mode)

    c. Move Press the YELLOW button and then press the buttons to move to the selected channel. Press the YELLOW button or the OK button to confirm. d. Skip Press the BLUE button to skip the selected channel. Press the BLUE button again to undo it.

  • Page 24: Ci (Common Interface) (Dtv Mode)

    CI (Common Interface) (DTV Mode) The common interface allows the use of a Common Access Module to enable you to view scrambled (pay to view) services. These services are provided by TopUp TV (UK only) and others. The Common Access Module and viewing card can be obtained from the service provider.

  • Page 25: Software Update (Over Air Download)

    Software Update (Over Air Download) The TV auto detects the latest firmware through the DTV signal and allows you to accept or refuse the firmware upgrade service. 1. Press the MENU button and then press the buttons to select the CHANNEL menu and then press the OK button.

  • Page 26: Picture Setting

    Picture Setting Allows you to set your preferred picture mode. 1. Press the MENU button and then press the buttons to select the PICTURE menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK EXIT EXIT 2. Press the buttons to select the following picture options and then press the OK button.
  • Page 27 Aspect Ratio Allows you to watch the screen in various picture formats: Auto / 4:3 / 16:9 / Zoom / Subtitle / Smart Zoom / Full. Input Signal 4:3 Input Signal 16:9 Auto This selection will display This selection will display the picture according to the picture according to the aspect ratio of the...

  • Page 28: Sound Setting

    Sound Setting Allows you to select an audio-enhancement technique. 1. Press the MENU button and then press the buttons to select the SOUND menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK EXIT EXIT 2. Press the buttons to select the following sound options and then press the OK button.

  • Page 29: Stereo / Dual Sound Reception (Atv Mode)

    Stereo / Dual Sound Reception (ATV Mode) When a programme is selected, press the AD button to display the sound information for the selected station. Broadcast On Screen Display Mono MONO / NICAM MONO Stereo MONO / NICAM STEREO Dual MONO / NICAM DUAL I, NICAM DUAL II, NICAM DUAL I+II Mono sound selection If the stereo signal is weak, you can switch to mono by pressing the AD button.

  • Page 30: Option Setting

    3. Press the buttons to select the options. Press the OK button and then press the buttons to adjust each option’s setting. Clock The clock is set automatically when receiving a digital signal. Off Time Allows you to set the off time that will automatically switch off the TV. Cycle through and select from the following off time options: Off / Once / Every Day / Mon.~Fri.

  • Page 31: Audio Language (Dtv Mode)

    2. Press the buttons to select OSD Language and then press the OK button. The default on-screen menu language is English. OSD Language English Audio Language Subtitle Language Hearing Impaired Country PVR File System Restore Factory Default 3. Press the buttons to navigate the menu and change the OSD Language settings.

  • Page 32: Subtitle Language (Dtv Mode)

    Subtitle Language (DTV Mode) Allows you to select your desired subtitle language or turn off the subtitle. (Available for digital channels if multiple subtitle languages are broadcast.) 1. Press the MENU button and then press the buttons to select the OPTION menu and then press the OK button.

  • Page 33: Pvr File System (Dtv Mode)

    PVR File System (DTV Mode) Allows you to select your preferences in the PVR File System. 1. Press the MENU button and then press the buttons to select the OPTION menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK...

  • Page 34: Cec (Consumer Electronics Control)

    CEC (Consumer Electronics Control) Allows you to command and control two or more CEC-enabled devices, that are connected through HDMI, by using only one of the TV remote controls (e.g. controlling a TV set, set-top box and DVD player using only the remote control of the TV). CEC also allows individual CEC-enabled devices to command and control each other without user intervention.

  • Page 35: Lock Setting

    3. Press the button to select “Yes”. The TV will turn off and restart after a few seconds. Press the button to select "No" to cancel and return to the main menu. Are you sure? All channel and user settings will be lost and the TV will revert to "First Time Installation".

  • Page 36: Set Password

    Set Password 1. Press the MENU button and then press the buttons to select the LOCK menu and then press the OK button. CHANNEL PICTURE SOUND TIME OPTION LOCK EXIT EXIT 2. Press the buttons to select Lock System and then press the OK button.

  • Page 37: Block Channel

    Block Channel Block Channel is designed to prevent children watching unsuitable programmes. When a channel is blocked, a valid password must be entered. 1. Press the MENU button and then press the buttons to select the LOCK menu and then press the OK button. CHANNEL PICTURE SOUND...

  • Page 38: Parental Guidance

    Parental Guidance This function allows you to set up blocking schemes to block specific channels and ratings. It operates according to information from the broadcasting station, therefore if the signal has incorrect information, this function will not operate. This allows you to set up blocking schemes to block specific channels and ratings.

  • Page 39: Using The Features

    Using the Features EPG (Electronic Programme Guide) (DTV Mode) This system has an Electronic Programme Guide (EPG) to help you navigate through all the possible viewing options. The EPG supplies information such as programme listings, start and end times for all available services. In addition, detailed information about the programme is often available in the EPG (the availability and amount of programme information will vary, depending on the particular broadcaster).

  • Page 40: Teletext (Atv Mode)

    Teletext (ATV Mode) Teletext is a free service broadcast by some TV stations which gives up-to-the-minute information on news, weather, television programmes, share prices and many other topics. Using the Teletext control buttons you can view pages of information that are listed in the teletext index.

  • Page 41: Digital Teletext (Dtv Mode)

    Digital Teletext (DTV Mode) Digital teletext can access special digital teletext services and specific services which broadcast digital teletext. You will need to turn off Subtitle Function before using teletext (refer to page 32 for details). Teletext within Digital Service 1.

  • Page 42: Entertainment

    Entertainment Connecting a USB Storage Device 1. Switch off the TV before connecting any USB Rear Right Side View of TV storage device. COMMON INTERFACE (CI) HDMI2 HDMI1 PC IN 2. Connect your USB storage device to the USB port HEADPHONE PC AUDIO of your TV.

  • Page 43: Listening To Music

    4. Press the buttons to navigate in the picture folder and then press the OK button. If you want to select the specified photos, press the buttons to select the picture file and then press the OK button. A tick box will be displayed.

  • Page 44: Viewing Movies

    6. Select the music you want to play, it will show the music information (Album / Title / Bit Rate / Artist / Sampling / Year / Size). Then press the PLAY button to play. 7. Press the buttons and then press the OK button to select the function: Pause / FB / FF / Prev / Next / Stop / Repeat All / Playlist / Goto Time.

  • Page 45: My Text

    My Text 1. Press the button on the right side panel of the TV or the INPUT button on the remote control then press the buttons to select the USB mode and then press the OK button. 2. Press the buttons to select TEXT and then press the OK button.

  • Page 46: Pvr (Personal Video Recorder)

    PVR (Personal Video Recorder) Time Shift Function This function allows the TV to virtually record the live viewing broadcast programme. If the transfer rate of the USB storage device is too slow • Time Shift Mode and Recording functions for recording or time shift function, a warning statement may not work if the signal strength is weak.

  • Page 47: Recording Dtv Programme Onto A Usb Storage Device

    Recording DTV Programme onto a USB Storage Device Use this function to record the DTV programme you are watching on the main screen and save it for future viewing. The recording from timer programme or direct recording may have a little bit of delay when it starts to record the broadcast programme.

  • Page 48: Timer Programming

    Timer Programming This function is used to perform scheduled recording. The recording from timer programme or direct recording may have a little bit of delay when it starts to record the broadcast programme. Please make sure the USB device is inserted. If not, a warning message will pop up. 1.

  • Page 49: Play Recorded Programme

    Play Recorded Programme You can play a recorded programme from the recorded programme list or from a USB Storage Device. 1. Press the button on the right side panel of the TV or the INPUT button buttons to select the USB on the remote control and then press the mode and then press the OK button.

  • Page 50: Maintenance

    Maintenance Maintenance Careful and regular cleaning can prolong the life of your TV. Be sure to press the button at the front right side of the TV or on the remote control to turn off the TV. Disconnect the mains cable from the mains socket before any cleaning.
  • Page 51 The audio function does not work. • Press the VOL + / – buttons. Picture OK but no sound • Sound muted? Press the MUTE button. • Try another channel. The problem may be caused by the broadcaster. No output from one of the speakers • Adjust the Balance settings in the SOUND menu.

  • Page 52: Display Modes

    Display Modes Display Modes The screen resolution has been optimised during production for the display modes listed below. YPbPr Mode Resolution Vertical Frequency (Hz) Aspect Ratio 480I: 720 x 480 480P: 720 x 480 576I: 720 x 576 576P: 720 x 576 Auto / Smart Zoom / Subtitle / 720P: 1280 x 720 Zoom / 16:9 / 4:3 / Full...

  • Page 53: Specifications

    Specifications Specifications Model L26FE12 Panel System 26 inch LED Backlit LCD Panel Display Resolution 1920 pixels (horizontal) x 1080 pixels (vertical) Television System PAL I / BG / DK SECAM L / BG / DK Brightness 250 cd/m Contrast Ratio...
  • Page 54 ENERG L26FE12 kWh/annum Watt inch - 2011 2010/1062 L26FE12_IB_120308_Annie.indd 54 12年3月8日 上午10:41...

  • Page 55: Safety Warnings

    Safety Warnings Safety Warnings Safety • Read all the instructions carefully before using the unit and keep them for future reference. • Always disconnect the unit from the mains supply before connecting / disconnecting other devices or • Retain the manual. If you pass the unit onto a third moving the unit.
  • Page 56 Service Standby • To reduce the risk of electric shock, do not remove • button on the remote control does not switch screws. The unit does not contain any user-serviceable off the unit completely. The unit will continue to draw parts.
  • Page 57 If you require a replacement for any of the items listed below, please quote their corresponding part numbers: Replacement Part Part Number TV Stand Support 105C2661102 TV Base 102C2661112 Remote Control 504C1961101 AAA Batteries 32200007158 Screw A 209100430B1 Screw B 209060410B1 Visit Partmaster.co.uk today for the easiest way to buy electrical spares and accessories.
