  • Page 1 T E C H N I C A L M A N U A L D I G I 2 S Y S T E M...
  • Page 2 • Install the equipment by carefully following the instructions given by the manufacturer and in compliance with the legislation in force. • All the equipment must only be used for the purpose it was built for Fortessa declines any responsibility for improper use of the apparatus, for modifications made by others under any title or scope, and for the use of accessories and materials which are not the original ones.

  • Page 3: Table Of Contents

    Video door entry system with DIGI-2 cabling SUMMARY CONFIGURATION OF THE DEVICES EXTERNAL UNITS • • - Programming bracket FT5714 and Digi2 telephone - Instructions for installing external audio-video unit FT2428W/A pag. 39 standard pag. 2 - Programming switching device FT1224A pag.

  • Page 4: External Units

    EXTERNAL UNITS Instructions for installing external audio-video unit standard...
  • Page 5 Alternative position of the microphone 360˚ open close...

  • Page 6: Instructions For Assembling An Informative Module Ft3326, Ft3344 And Ft3346

    Instructions for assembling an informative module FT3326, FT3344 and FT3346 Name tags can be best produced as follows: Use a transparent adhesive strip for a label maker (of the Dymo type) as shown in the figure. A l d...

  • Page 7: Digital Call Ft3340

    Digital call FT3340 2) ACCESSING THE CONFIGURATION STAGE OPERATION ON DISPLAY DESCRIPTION Arrange the modules only as indicated in the following drawing. Powered up with PR NAME DIRECTORY The module is in terminal connected ACCESS CONTROL programming mode: to terminal - . SETTINGS to select the menu ▲▼...
  • Page 8 5) USING THE NAME DIRECTORY 6) USING THE CALL MODULE 5A) SCROLLING AND CALLING THE USER SELECTED INITIAL CONDITION INITIAL CONDITION During normal operation. SCROLL NAMES SEARCH NAME During normal operation. ENTER TENANT Followed by: CODE ENTER TENANT CODE If some users have been Followed by: stored in the directory.
  • Page 9 7C) ENTERING BY MEANS OF SOFTWARE FT1249/A OPERATION ON DISPLAY DESCRIPTION INITIAL CONDITION Select the NAME ENTER PART The user name to be During normal operation. ENTER TENANT The directory must DIRECTORY/ CHANGE OF THE NAME modified is requested. Connect the cable be empty.
  • Page 10 7H) CANCELLING A NAME BY MEANS OF FT1230 Entry of the list with the listed fields can only be carried out by means of the software (not available if the call mode is Indirect Code - see point 8) FT1249/A. The indirect code can have a maximum of 6 figures.
  • Page 11 9B) DISPLAYING THE PORTER FT1602 – FT4660 PARAMETERS 10C) RESETTING THE SUPERCODE (door opening time, conversation time and reset wait time). OPERATION ON DISPLAY DESCRIPTION OPERATION ON DISPLAY DESCRIPTION Access to the configuration NAME DIRECTORY stage has been carried out ACCESS CONTROL Access to the configuration NAME DIRECTORY...
  • Page 12 10F) CANCELLING ALL THE PASSWORD CODES 10I) DISPLAYING THE NUMBER OF PASSWORDS ENTERED OPERATION ON DISPLAY DESCRIPTION OPERATION ON DISPLAY DESCRIPTION Access to the configuration NAME DIRECTORY Access to the configuration NAME DIRECTORY stage has been carried out ACCESS CONTROL stage has been carried out ACCESS CONTROL (see point 2).

  • Page 13: Electronic Name Directory Module Ft3342

    Electronic name directory module FT3342 3B) CHANGING THE LANGUAGE SET PREVIOUSLY: OPERATION ON DISPLAY DESCRIPTION INTRODUCTION Access to the configuration NAME DIRECTORY The electronic name directory module FT3342 can be used in audio and video stage has been carried out ACCESS CONTROL settings, is fitted with a name directory to store a list of user names.
  • Page 14 6C) ENTERING BY MEANS OF SOFTWARE FT1249/A OPERATION ON DISPLAY DESCRIPTION INITIAL CONDITION Select the initial SELECT INITIAL: using the ▲▼ keys. During normal operation. SCROLL NAMES A B C D E F G ….. To exit press the key. Connect the cable SEARCH NAME EXAMPLE: A...
  • Page 15 6G) DISPLAYING THE NUMBER OF NAMES ENTERED IN THE DIRECTORY, THE 7C) SETTING THE ID CODE ( Default = 0 ) SOFTWARE VERSION INSTALLED AND THE ID CODE The ID code is only used in special applications. OPERATION ON DISPLAY DESCRIPTION OPERATION ON DISPLAY...

  • Page 16: Instructions For Installing External Audio-Video Unit Vandal Resistant

    Instructions for installing external audio-video unit vandal resistant...
  • Page 17 yellow green...
  • Page 18 SOLUTION “A” SOLUTION “B”...

  • Page 19: Digital Call Module Ft3070/A

    Digital call module FT3070/A 3) HOW TO USE THE DIGITAL MODULE 3A) CALL TO A USER: INTRODUCTION INITIAL CONDITION The digital call module FT3070/A can be used in audio and video settings, and allows a door entry phone user to be called by entering their code. The main characteristics are as follows: Module supplied ENTER •...
  • Page 20 OPERATION ON DISPLAY DESCRIPTION OPERATION ON DISPLAY DESCRIPTION Select the SETTINGS / SPEAKER PAR. It is possible to modify Select the SETTINGS / DOWNL. TYPE( 0 -1 ) N.B: The values in SYSTEM PARAM. / SPEAKER ENTER t AUDIO the conversation time, the SYSTEM PARAM.
  • Page 21 5) ACCESS CONTROL OPERATION ON DISPLAY DESCRIPTION This function allows activation of the door-opening relay in the porter module (Contact Select the SETTINGS / ADD.RS485 ( 1 -255 ) N.B: The values in SE / SE) by entering a previously stored password code (see paragraph CARRYING SYSTEM PARAM.
  • Page 22 5C) ELIMINATION OF A PASSWORD CODE 5F) DISPLAYING THE NUMBER OF PASSWORDS ENTERED AND THE SOFTWARE VERSION INSTALLED IN MODULE FT3070/A INITIAL CONDITION INITIAL CONDITION Access to the configuration MAIN The module is in the Access to the configuration The module is in the MAIN stage has been carried out SETTINGS...
  • Page 23 7) PARAMETER TABLE OPERATION ON DISPLAY DESCRIPTION The explanatory table of the configuration parameters of module FT3070/A is given Connect the small cable ENTER below: provided with the software TENANT CODE PARAMETER POSSIBILE VALUE DEFAULT VALUE FT1249/A to terminals TX / RX / - ( or D / D- if there LANGUAGE 1=ITALIAN...

  • Page 24: Electronic Name Directory Module Ft3072/A

    3) USING THE NAME DIRECTORY Electronic name directory module FT3072/A 3A) SCROLLING THE LIST OF USERS AND CALLING INTRODUCTION INITIAL CONDITION The electronic name directory module FT3072/A can be used in audio and video settings, and allows a door entry phone user to be called by selecting them from a list stored in the memory: Module supplied SEARCH THE •...
  • Page 25 4) SETTINGS OPERATION ON DISPLAY DESCRIPTION 4A) SYSTEM PARAMETERS After the modification 4A-1) MODIFYING THE CONVERSATION, DOOR-OPENING AND PORTER MODULE has been made, remove RESET TIME PARAMETERS the connections between This operation allows the conversation, door-opening relay closing and reset wait times PR and –...
  • Page 26 5) MANAGEMENT OF THE USER LIST 4B) SETTING THE LANGUAGE The value of this parameter is used to set the language for the messages. 5A) ENTERING A NAME BY MEANS OF FT1230 If it is the first time module FT3072/A has been turned on, you must proceed as described below: OPERATION ON DISPLAY...
  • Page 27 5B) CANCELLING A NAME BY MEANS OF FT1230 5E) READING THE STORED LIST ( UPLOAD ) By means of the software FT1249/A it is possible to read the list with the User OPERATION ON DISPLAY DESCRIPTION name and Code fields from module FT3072/A. It is necessary to carry out the fol- lowing operations: Select the user name BIANCHINI...

  • Page 28: Standard Combined Access Ft3328 And Vandal Combined

    6) Wait 10 seconds or a confirmation tone. FT3188 like showed on page 27. 7) Remove the bridge. FORTESSA reserves the right to change the characteristics and E.g. to insert supercode 12345, proceed as follows: dimensions of the equipment without prior warning.
  • Page 29 Connection to the ground of electronic standard key FT3328 and electronic vandal resistant key FT3188 • In case of an error during programming, press button 4) Deletion of relay codes “key” to cancel the operation being carried out. The following procedure must be followed to delete a previously set •...
  • Page 30 2) Re insert the code with the required functionning way: Procedure for programming the number of accept errors start of programming 1) Key in “0” “E” (start of programming control). 12345 E supercode 2) Make sure the LED is on. identification 3) Key in the supercode (see point 1), followed by “E”.

  • Page 31: And Vandal Resistant Lock Ft3195

    Access control device standard lock FT3335 and FT1028 vandal resistant lock FT3195 General information: The standard lock access control device FT3335 and vandal resistant lock FT3195 are extremely easy to install. It is possible to memorize 1 Master Card and up to 660 User Cards (expandable to a maximum of 2708 User Cards).
  • Page 32 REGISTRATION OR CHANGING A MASTER CARD PROGRAMMING AN ACCESS KEY USING THE MASTER CARD When the module is turned on for the first time, it is necessary to register a Master Card: OPERATION DESCRIPTION OPERATION DESCRIPTION The buzzer will “bip” every 3 seconds and the Enter the programming mode the buzzer will ”bip”...
  • Page 33 DELETING ALL ACCESS KEYS USING THE PROGRAMMER FT1028 OPERATION DESCRIPTION The buzzer will “bip” every 3 seconds and the Enter the programming mode programming led will flash at the same timing (programming mode) Scroll the menu using the UP or DN buttons The programmer requests the Master Card till option: Del All number...

  • Page 34: Internal Units

    INTERNAL UNITS Description of the monitor Genius and user information The Monitor Genius FT5801 (Black and white Monitor) can be used on bracket FT5714 and with desk conversation support FT5712. For the installation and the cabling refer to the products just mentioned.

  • Page 35: Instructions For Installation Of The Internal Unit Genius

    Instructions for installation of the internal unit Genius Overall dimensions of the Monitor Installation on wall with bracket FT5714 with 4 expansion anchoring screws 10,3 cm 10,1 cm 14,4 cm 8,1 cm 1,4 cm 1,4 cm Procedure for mounting Monitor to the bacjkplate Procedure for removing the Monitor...
  • Page 36 Installation of monitor on desk support FT5712...

  • Page 37: Technical Characteristics Of Bracket Ft5714

    Technical characteristics of bracket FT5714 for Genius monitor 1. Bracket-Monitor connector. Terminals for system connection: +20 0 Connection terminals FT1212/B or FT1205/B. L L Bus line connection. CFP CFP local floor call input. P1 C1 Connection terminal regarding Pushbutton 1 for various uses. To have a clean C.NO.

  • Page 38: Digi2 Wall Telephone For Mixed Systems Ft2428W/A

    Digi2 wall telephone for mixed systems FT2428W/A 2-wire digital telephone, with electronic call with adjustable volume, Technical characteristics: conversation privacy, conversation button on the base, door 1. Door-opening push-button. opening pushbutton and pushbutton for calling the switchboard, or 2. Switchboard call push-button/push-button for various uses free (C.N.O).

  • Page 39: Accessories Relay Module Ft1256

    FT1256, is factory-set to be used on audio settings.* video entry phone. The closure time of the relay can be To use the relay module in DIGI-2 systems after FT4896: programmed by means of Dip switches - see table A on page 38.
  • Page 40 E) Activation on apartment unit pushbutton. (**) Function which can be used in audio and video settings.* To activate this function, set jumper JP1 as shown in figure 5. The relay C.NO. contact is activated when relevant pushbutton is pressed on a telephone or a video entry phone. The closure time of the relay can be programmed by means of Dip switches, see table A under.

  • Page 41: Configuration Of The Devices

    CONFIGURATION OF THE DEVICES Programming bracket FT5714 and Digi2 telephone FT2428W/A • Each telephone or bracket in the system is identified by means of its own code. This code must be set by means of the Dip switches on the telephone card or on the bracket (see figures). •...

  • Page 42: Programming Switching Device Ft1224A

    Programming switching device FT1224A 1216 1216 • Each switching device module is fitted with a pair of Dip switches with 8 selectors (see figure). FT5801 FT5801 1214/2 1214/2 The two Dip switches define the minimum and maximum range - MIN - MAX - of codes which can be recognised by the switching device.

  • Page 43: Push-Button Programming With Audio-Video Ft4660 Group

    Push button programming with audio-video FT4660 group and modules FT3323/3, FT3323/4 and FT3323/6 Fig. 2A Fig. 2B FT 3309 Fig. 1 Fig. 3 Fig. 2 WARNING: • Modules FT4660 normally function as main external unit 4. Press the push-button to be associated with the telephone (timed engaged signal).

  • Page 44: Table For Programming The Dip Switches

    Table for programming the Dip switches User code Dip switches to ON User name User code Dip switches to ON User name User code Dip switches to ON User name User code Dip switches to ON User name 1,3,4,5,6 1,4,5,6,7 1,3,5,6,8 2,3,4,5,6 2,4,5,6,7...

  • Page 45: General Instructions For Installation And Operation

    GENERAL INSTRUCTIONS FOR INSTALLATION AND OPERATION Explanation of the meant one of audio settings and video settings Video settings section is after the mixer power-supply FT4896 VIDEO SETTINGS 1216 FT5801+ FT5714 1214/2 FT5801+ FT5714 1214/2 FT5801+ FT5714 1214/2 FT2428W/A 1214/2 FT4888 + FT1246 AUDIO SETTINGS FT1195...

  • Page 46: Mixer-Power Supply Ft4896

    Mixer-power supply FT4896 FT4896 must be supplied by means of transformer FT1246. Carry out the cabling and system connection prior to the connection of the power supply operations after disconnecting the mains supply. This unit is fitted with a protection PTC, device after a short-circuit, disconnect the power supply for approximately one minute to allow re-setting.

  • Page 47: Installation Rules For Video Door Entry Systems

    Installation rules for video door entry systems Avoid placing the riser wires near power supply cables The additional FT4834/9 must be preceded by the relative video (230/400V). signal amplifier FT4833/A (see variant 13 on page 66). A MAX of In the branches towards each user, insert terminal 1214/2 2 FT4834/9 in cascade can be inserted.

  • Page 48: Maximum Distances And Characteristics Of The Conductors Pag

    Maximum distances and characteristics of the conductors The connection of the apparatus is of the unpolarised type. reached or the good quality of the video signal, therefore only The use of conductors with characteristics other than those use the cables described in the tables below. prescribed does not guarantee certain system distances being Type of cable Max.
  • Page 49 Figures showing distances FT5801 FT5801 FT4896 FT4896 FT4833/A FT1195 FT5801 FT5801 FT5801 FT4896 FT1212/B FT5801 FT4834/9...

  • Page 50: Maximum Distances Which Can Be Reached By

    Maximum distances which can be reached by the conductors off additional monitor power supply and external unit Cross-section of the conductor Max. distance between transformer Max. distance between power supply FT1195 and external unit. FT1212/B and internal unit. 0.28 mm 10 m (Ø...

  • Page 51: Wiring Diagrams

    WIRING DIAGRAMS VARIATIONS OF SYSTEM DIAGRAMS Diagram System with 1 standard Series video entrance. page 50 Diagram Connection in cascade FT4834/9. page 66 Diagram System with 1 standard Series audio entrance. page 51 Diagram Connecting an amplifier FT4833/A. page 66 Diagram System with 2 standard Series video entrances.

  • Page 52: Diagram

    Diagram System with 1 standard Series video entrance. Only required if using push to exit button...

  • Page 53: Diagram

    Diagram System with 1 standard Series audio entrance. Only required if using push to exit button...

  • Page 54: Diagram

    Diagram System with 2 standard Series video entrances. Only required if using push to exit button...

  • Page 55: Diagram

    Diagram System with 2 standard Series audio entrances. Only required if using push to exit button...

  • Page 56: Diagram

    Diagram System with 1 standard serie video entrance and MAX 9 Mixers-power supplies FT4896. Please remove resistors from used outputs only Only required if using push to exit button...

  • Page 58: Diagram

    Diagram System with 1 main video entrance and MAX 9 standard series secondary videos. Please remove resistors from used outputs only Only required if using push to exit button...

  • Page 60: Diagram

    Diagram System with 1 main audio entrance and standard series secondary audios. Only required if using push to exit button...

  • Page 62: Diagram Connection Of A Max 9 Riser Branches For Each Mixer-Power Supply Ft4896

    Diagram Connection of a MAX 9 riser branches for each Mixer-power supply FT4896.

  • Page 63: Diagram

    Diagram Connection in derivation of mixer- power supply FT4896. Please remove resistors from used outputs only...

  • Page 64: Diagram Connection In Cascade Of Several Internal Units (Up To 25 For Branch From Ft4896)

    Diagram Connection in cascade of several internal units (up to 25 for branch from FT4896).

  • Page 66: Diagram

    Diagram Video door entry system with 1 main entrance and porter switchboard FT1998A. Only required if using push to exit button...

  • Page 67: Diagram

    Diagram Audio door entry system with 1 main entrance and porter switchboard FT1998A. Only required if using push to exit button...

  • Page 68: Diagram

    Diagram Connection in cascade FT4834/9. In case it is necessary to have more than the 9 branches provided by a concentrator FT4834/9, it is possible to connect a second 4834/9 on the output of the first. Connect an amplifier FT4833/A for each additional concentrator FT4834/9. In this configuration, use at MAX 3 outputs on the first FT4834/9 in order to obtain a MAX total of 33 branches.

  • Page 69: Diagram

    Diagram FT1256 branched on the external unit. Only required if using push to exit button Diagram Secondary door opening with FT1256 branched after FT4896.

  • Page 70: Secondary Door Opening With Ft1256 Branched Before Ft4896

    Diagram Secondary door opening with FT1256 branched before FT4896. Diagram Branched connection of monitors with the same user code supplied by a riser. • Ignition up only of Main monitor on a call. • Lighting up on push-button 2 of the Secondary monitors being pressed after a call (Video request).

  • Page 71: Connection In Cascade Of Monitors With The Same User Code Supplied From A Riser

    Diagram Connection in cascade of monitors with the same user code supplied from a riser. • Ignition up on a call of Main monitor only. • Ignition up on pressing push-button 2 of the Secondary monitors after a call (Video request). •...

  • Page 72: Telephones In Cascade

    Diagram Connection of users audio in mixed system. Telephones in cascade. MAIN MONITOR Diagram Connection of users audio in mixed system. Branched telephones. MAIN MONITOR...

  • Page 73: Connection Of Additional Audio Handset In Cascade From Monitor

    Diagram Connection of additional audio handset in cascade from monitor. Diagram Connection of call repetition devices on bracket FT4784, FT5714 and telephone FT2428W/A. The total sum of the number of internal units with the same user code and of the number of call repetition devices connected to the abovementioned internal units cannot exceed the number of 4.

  • Page 74: Installation Of Ft1256 In Mixed Audio/Video Systems

    Diagram Installation of FT1256 in mixed Audio/Video systems. Diagram VARIANT D: door bell function. In case of more telephones or brackets with the same user code, connect the CFP button only on one; all devices will ring together. *20m MAX...

  • Page 75: Variant With Video Door Entry System With Digital Entrance Ft3340/Ft3342

    Diagram Variant with video door entry system with digital entrance FT3340/FT3342. Only required if using push to exit button Diagram Variant to connect the timed local lock button (Request to exit). Only required if using push to exit button...

  • Page 76: Connection With Modules Ft3262/0 (Combined With Module Ft1602) Or Ft3268/0 (Combined With Module Ft4660)

    Diagram Connection with modules FT3262/0 (combined with module FT1602) or FT3268/0 (combined with module FT4660). Only required if using push to exit button Diagram Audio and video settings with external audio-video unit vandal resistant and FT3064/A. Use and programming of modules FT3063/A and FT3064/A.

  • Page 77: Audio And Video Settings With External Audio-Video Unit Vandal Resistant And Ft3064B

    Diagram Audio and video settings with external audio-video unit vandal resistant and FT3064B. Only required if using push to exit button See programming stage at page 41. Diagram Vandal combined access and standard combined access electronic digital key in audio and video settings. Only required if using push to exit button Only required if using...
  • Page 78 Diagram Access control device standard lock and vandal resistant lock in audio and video settings. Only required if using push to exit button Only required if using push to exit button Diagram Variant for trade facility. Serie unit standard video entrance. Only required if using push to exit button programmed with the same code setting on FT1256 dip switch.

  • Page 79: Serie Vandal Resistant Video Entrance

    Diagram Variant for trade facility. Serie vandal resistant video entrance. Only required if using push to exit button programmed with the same code setting on FT1256 dip switch.
