1
Unpack your printer
Paper Feed
button
Paper support
Setup booklet
Remove all tape and packing material from the
Lexmark 1100 Color Jetprinter™.
Do not install the print cartridge
prompted to do so during the software installation.
Print
cartridge
Setup
software
Paper exit tray
User's Guide
Power cord
until you are
2
Attach the paper exit tray
2a.
Rotate the printer onto its
back
Advertisement
Table of Contents
Related Manuals for Lexmark 1100
Summary of Contents for Lexmark 1100
-
Page 1: Unpack Your Printer
Paper exit tray Paper support User’s Guide Setup booklet Power cord Remove all tape and packing material from the Lexmark 1100 Color Jetprinter™. Do not install the print cartridge until you are prompted to do so during the software installation. - Page 2 Attach the exit tray Rotate the printer to its upright position Align the tabs on the paper exit tray with the slots on the base of the printer. Gently press the printer and paper exit tray together until the exit tray snaps into place.
-
Page 3: Install The Paper Support
Use a parallel cable that supports bidirectional Locate the slots on the back of the printer. communication (IEEE 1284-compatible), such as Lexmark P/N 1329605. Push the paper support tabs into the slots until they snap into place. Make sure the paper support is in the upright... -
Page 4: Plug In Your Printer
Plug in your printer Secure the connections Power cord Connect the power cord to the printer. Plug the power cord into an electrical outlet. Fasten the metal clips on the printer to the parallel You will hear some movement inside the printer cable. -
Page 5: Load Paper
Load paper Pull the paper load lever Insert paper toward you Load up to 30 sheets of paper against the right side of the sheet feeder. Note: Overloading the printer may cause paper jams or misfeeds. - Page 6 Adjust the paper guide Push the paper load lever away from you Slide the paper guide to the left edge of the paper.
-
Page 7: Install The Printer Software
If Windows 95 or 98 displays a New Hardware Found screen and prompts you to install a printer Refer to the Lexmark 1100 User’s Guide for more driver, choose Do not install a driver and click information about installing from diskettes. -
Page 8: Install The Printer Driver
Install the printer driver Make sure Windows is running on your computer. Insert the Lexmark 1000 Series CD into your CD- ROM drive. • If the menu screen appears after a few moments, continue with Step • If nothing appears on the screen after a few... -
Page 9: Install The Print Cartridge
Install the print cartridge Open the front cover Unpack the print cartridge Sticker and tape Do not touch the copper contact area! Remove the new print cartridge from its packaging. Remove the sticker and the transparent tape covering the copper area on the cartridge. -
Page 10: Insert The Cartridge
Insert the cartridge Snap the cartridge into place When the Install New Cartridge dialog appears, the cartridge carrier automatically moves to the load position inside the printer. Insert the print cartridge into the cartridge carrier as Push back on the cartridge until it snaps securely shown. -
Page 11: 8E. Close The Front Cover
Close the front cover Click “Cartridge Installed ” Install New Cartridge Open the printer’s front cover and install a new cartridge then click on <Cartridge Installed> to indicate completion. If you are not installing a new cartridge, please click <Cancel>. Color Cartridge Installed Black Cartridge Installed Cancel... - Page 12 You have successfully set up your printer. See the If you decide to align the cartridge, the printer prints Lexmark 1100 User’s Guide for information on how a test page with a bidirectional alignment pattern. to get the best performance from your printer.
