Summary of Contents for ELC dmXLAN node3
- Page 1 Users manual for dmXLAN node3 dmXLAN node6x dmXLAN node8s dmXLAN node8gb...
- Page 2 / node6x / node8s / node8gb DMX Ethernet node with integrated Ethernet switch. All nodes have the same user interface: a graphical LCD screen and an encoder with push function. Connections: dmXLAN node3 WM and SM 3 Bi-Directional DMX ports on the front...
- Page 3 Either through the front panel or the dmXLAN control software. The software can be downloaded from the website at www.elclighting.com Control via the front panel. Main display dmXLAN node3 dmXLAN node6s dmXLAN ndoe8s/gb Encoder +/- change the view on the display, to see the ID, IP address, status, software...
- Page 4 - Set view mode 120 bars 40 bars decimal precentage - Select one of the ports to view - Back (go back to the setup menu) Select the view mode (press encoder when on Mode, and change it to the desired setting and press the encoder again).
- Page 5 The primary and secondary universes can be set to either Art-Net of sACN (streaming ACN, both Draft R2 and Release R3 are supported) Select the primary or secondary and press the encoder to change it. The universe edit screen appears Here you can change the universe type (Art-Net, sACN or disabled) for Art-Net you can set the Subnet and Id for sACN you can set the universe and the range.
-
Page 6: General Information
Set to unit back to it's default values General Information CE – Product The dmXLAN node3/node6x/node8s/node8gb permits to the CE requirements set up by the European Community. This can be recognized by this label on the outside of the product. Technical Specifications nodes 3 wm / sm:...
