OPTION ONE- CONNECTING A LOUDSPEAKER DIRECTLY
‣
Connect the Condor to your conferencing interface/ device. Make sure the Condor is
selected as both the microphone and speaker for this device.
‣
Connect an external amplified loudspeaker to the Condor using either the Optical OUT
connector, or the Analog Speaker OUT connectors, located in the back panel of the
Condor.
OPTION TWO- FEEDING THE REFERENCE SIGNAL INDIRECTLY
‣
Connect the Condor to your conferencing interface/device. Make sure the Condor is
selected as just a microphone.
‣
Connect your external amplified loudspeaker directly to your conferencing device. Make
sure you select that loudspeaker as the Audio OUT.
‣
Connect your loudspeaker's output (Speaker OUT) to the Condor via the Optical IN
connector or Analog Speaker IN connectors, located in the back panel of the Condor.
DEVICE/ INTERFACE
CONNECTING TO A DIGITAL CONNECTION (USB)
This connection is for any session using your computer, such as Voice over IP applications
(Skype, etc.).
Using the USB cable provided, plug the micro USB side of the cable into the Condor
‣
(USB connector located on the connector panel behind the unit).
‣ Plug the USB end of the cable into any USB port on your computer or conferencing
device.
No additional drivers or steps are needed. However, we do recommend downloading and using
our "Phoenix Audio Setup Utility" for optimal audio control and performance. This utility can be
found on our website:
Page 6
www.phnxaudio.com/downloads/audiosetup/
