INSTALLING THE LEG STANDS/ WALL MOUNTS

The Condor can be either propped up using leg stands, or mounted onto a wall using mounting
brackets (both sets of stands come included).
INSTALLING THE LEG STANDS
To install the leg stands onto the Condor:
‣ Align the teeth on the stands with the snap holes on the Condor.
‣ Push into place, making sure to use enough force for the stands to be securely clinked
in. This can be done in any of the four stand insert locations.
INSTALLING THE MOUNTING BRACKETS
To mount the Condor onto a wall, you will need the two mounting brackets, and 4 screws (As
wall types vary, screws are not included).
Align the teeth on the mounting brackets with the snap holes on the Condor, and click
‣
into place. This can be done in any of the four stand insert locations.
‣ Set the Condor against the desired position on the wall, and mark the wall from inside
the holes of the mounting brackets.
‣ Separate the brackets from the Condor, and screw them into the wall using 4 screws.
‣ Once mounted securely on the wall, click brackets into place on the Condor, making
sure to use enough force for the brackets to be securely clinked in.
