VACUUM CLEANER
SERVICE MANUAL
CAUTION
BEFORE SERVICING THE UNIT,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.
MODEL: VUP152NJP
Table of
Contents
Previous
Page
Next
Page
1
2
3
4
5
Advertisement
Table of Contents
Related Manuals for LG VUP152NJP
Vacuum Cleaner LG V-UP142NJP Owner's Manual
Upright vacuum cleaner (41 pages)
Vacuum Cleaner LG VTUP61NB Owner's Manual
Upright vacuum cleaner (16 pages)
Vacuum Cleaner LG V-UP851NB Owner's Manual
(27 pages)
Vacuum Cleaner LG VTUP61NB Service Manual
(16 pages)
Vacuum Cleaner LG V-UP255NB Owner's Manual
(21 pages)
Vacuum Cleaner LG V-UP881NB Owner's Manual
(26 pages)
Vacuum Cleaner LG VK9820SCSNY Owner's Manual
(28 pages)
Vacuum Cleaner LG VK7920 Series Owner's Manual
(31 pages)
Vacuum Cleaner LG VR94070NCAQ Owner's Manual
Cordless vacuum cleaner (96 pages)
Vacuum Cleaner LG V-K80101HFR Owner's Manual
(28 pages)
Vacuum Cleaner LG VR627 Series Owner's Manual
(44 pages)
Vacuum Cleaner LG VK89302H Owner's Manual
(28 pages)
Vacuum Cleaner LG VK79 Series Owner's Manual
New type (25 pages)
Vacuum Cleaner LG VC3319YM Owner's Manual
New type cyclone vacuum cleaner (14 pages)
Vacuum Cleaner LG VK79 N Series Owner's Manual
(24 pages)
Vacuum Cleaner LG VC4918 Series Owner's Manual
(25 pages)
Summary of Contents for LG VUP152NJP
Page 1: Vacuum Cleaner
Internal Use Only Website http://biz.lgservice.com VACUUM CLEANER SERVICE MANUAL CAUTION BEFORE SERVICING THE UNIT, READ THE SAFETY PRECAUTIONS IN THIS MANUAL. MODEL: VUP152NJP...
Page 2: Table Of Contents
TROUBLESHOOTING ..................7 REMOVING CLOGS .................... 8 DISASSEMBLY ....................10 SCHEMATIC DIAGRAM ..................14 EXPLODED VIEW ....................15 REPLACEMENT PARTS LIST................17 Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 3: Important Safeguards
If the cleaner still does not run, contact a qualified electrician. SAVE THESE INSTRUCTIONS THIS PRODUCT IS FOR HOUSEHOLD USE ONLY LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 4: Cleaner Description
Cord length 7.7m Weight (approx.) 6.3kg PARTS Model VUP152NJP Belt 4400FI3348A 3210FI2434D Exhaust Filter(Washable HEPA) These parts are available from your dealer. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 5: Replacement Instructions
To install the bottom plate, hook the front end of bottom plate into the slots on the front of nozzle. (Fig. D) Press the bottom plate then tighten the screws. LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 6
MODERATE - (used 2-3 times/week) every week LIGHT - (used 1time/week) every 2 months Replacement part are avaiable from your dealer. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 7: Troubleshooting
2. Pre-motor filter cap installed the handle. container incorrectly 2. Make sure the pre-motor filter is in place and seated correctly. LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 8: Removing Clogs
(Fig. C) Stand the vacuum cleaner back up in an upright position before plugging into the electrical outlet. Agitator Suction Inlet Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 9
(Fig. F) LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 10: Disassembly
Remove screw and pull out the handle. Cord Remove screw and disassemble cord hanger, spring Hanger and washer. Washer Screw Spring Step 2: Disassembling Dust tank Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 11
Step 3: Disassembling hose Remove the lower end of stretch hose from the cleaner. Pull the hose strongly to remove. LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 12
Push the right edge of connector pipe to turn and set the position to remove. Side connector pipe of the head cover. Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 13
Unscrew and remove the body cover from the body base. Disconnect wires and remove motor. Disconnect wires and disassemble switch, and power cord. LGE Internal Use Only Copyright © 2007 LG Electronics. Inc. All right reserved. Only for training and service purposes...
Page 14: Schematic Diagram
SCHEMATIC DIAGRAM Live Neutral Switch Capacitor Motor Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 15: Exploded View
MCQBA1 MEGBH1 MHJBA1 EADBC1 3 BLOCK MCQBM1 EAUBA1 MCQBA2 MCKTD1 2 BLOCK MDSTA1 ADQTC1 MFGCA1 MGJTC2 MHYCC1 MGJTC1 MJHTB1 MJMTD1 MCKCB1 Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 16
MDFAA1 MJDHA1 MFCLA1 MAKAA1 MGJBB1 MCDAB1 MKBBA2 MHJAA1 MDSBA3 MDFAA2 MCDAB2 MASBA1 FADAC1 4BLOCK 6 BLOCK AGRPT1 ABCBF1 AEMAF1 MFVBC1 ABCAD1 Copyright © 2007 LG Electronics. Inc. All right reserved. LGE Internal Use Only Only for training and service purposes...
Page 17: Replacement Parts List
P/NO : 3828FI5874B...
