llation and Operation Instructions
þ
3.3
Wall or ceiling installation
3.4
Cable connections
1.
2.
3.
4.
- Length of single conductor 100 mm
- Length of stripped insulation 7 mm
- Strip plastic-sheathed cable flush with conduit.
bulbs
.co.uk
Pull cable through grommet, don't cut open!
Cut cable at least to length 180 mm and remove cable jacket at least 100 mm in length.
Connect fan according to wiring diagram (see page 5).
Run cable in the conduit. Ensure cable / grommett is sealed to maintain IP45.
