Page 1: User Manual
Mini WiFi Cam MODEL NO: WF81 USER MANUAL Please ensure that you read the complete user manual carefully before using any part of the product. - Keep this copy safe for future reference in case of operational difficulties. -
Page 2: Table Of Contents
Content Safety Directions ..............1 Product Accessories ............2 Product Structure .............2 Operation Guide ...............3 Smartphone Software Installation ………......4 Product Specifications .............18 Indicator status ..............18... -
Page 3: Safety Directions
SAFETY DIRECTIONS Please go through the following Safety Directions before you start using our product: - The Mini IP Cam is NOT waterproof or dustproof, so don’t use it outdoors, in adverse environments or during rain. - In order to avoid any damage to the device, the risk of electric shock to you or starting a fire, use original DC power-supply. -
Page 4: Product Accessories
PRODUCT ACCESSORIES Bracket x 3 Neck lanyard x 1 Card reader x 1 Mini IP Cam x 1 Silicone case x 1 User Manual x 1 USB Cable x 1 Warning sticker x 1 PRODUCT STRUCTURE Record/Stop indicator hole for neck strap Camera Power on/off Mode Button... -
Page 5: Operation Guide
QUICK GUIDE FOR CHARGING AND RECORDING 1) Charging - The Mini IP Cam comes with a built-in rechargeable battery(200mah). Before you can start using it, please use the provided USB cable to fully charge it first. - The red indicator will stay on during charging, it goes off when the camera is fully charged. -
Page 6: Smartphone Software Installation
QUICK GUIDE FOR SMARTPHONE SOFTWARE INSTALLATION AP Connection steps: 1) Scan the QR code or download "MINI IP CAM" from the App store or Google Play and install it. Android Mini IP Cam 2) Power on the camera and switch it to AP mode ( The default is AP mode already) - Page 7 3) Click the setting from your cell phone and find the camera hotspot wifi,the wifi name should be : IPCAM_XXXXXX (where xxxxxx are 6 digits). And connect it.
- Page 8 4)Go back to the APP to add the camera and then auto search ,the camera will be found in the AP mode. 5) Now the user can click on "IPC-xxxxx" so as to view the camera via its hotspot. IPC-E8ABFA2E8062 RCAM-007250-NZCZS...
- Page 9 6) Although not suggested, just in case your camera’s LAN search is not working properly, you can use the Manual add to input ID on the camera’s back, User name default as: admin. Then rename it the way you want and save it.
- Page 10 P2P Connection steps: Whenever Wi-Fi Internet is available, you can use this device as an IP camera. 1) On finishing AP Connetion,click setting from the APP and click the wifi list to find your local wifi...
- Page 11 2) Input your password and save it to connect the camera with your local wifi network. 3) Wait for 1 minute around for the camera to be rebooted.
- Page 12 4) After reboot is finished.Pls Switch the AP mode to P2P mode from the camera on the right side 5) Then wait the red signal to be green dot and shown the wifi icon...
- Page 13 6）Now you are able to view the camera remotely.
- Page 14 THE MENUS ON CAMERA'S MAIN INTERFACE 1) Camera: - You will see all the cameras successfully added. 2) Gallery: - All photos and videos recorded in your mobile can be seen here.
- Page 15 3) System: - Receive Push message: This must be enabled if you set mail setting and alarm setting - Software Version Information: This indicates the software version for future upgrades. 4)Setting tool Click on that,you will see a sub-menu as below:...
- Page 16 4.1) TF: Click here to check the files recorded in the Micro SD card of the Mini IP camera. 4.2) Adjust: While in P2P mode, click in order to adjust the camera’s time same as you would do with your mobile.
- Page 17 4.3) Edit: Click to name/rename your camera, or create a password for your camera. Important Remind: Pls carefully make note of your password if you'd like to change it.Since this camera doesn't allow any password reset to default for a security purpose! 4.4) Delete: Click here to delete the camera you've already installed.
- Page 18 4.5) Settings: 4.5.1) User Settings: This allows you to add other user as visitor of your camera 4.5.2) Wifi Settings: This allows you to connect your camera to your local wifi network as stated above for P2P connection. 4.5.3) Mail Settings: This allows you to set the receivers of Mail alarm.
- Page 19 5.1) Vido resolution ： This allows you to change the video resolution as you want. 5.2) Record video : This allows you to record video to your app's Gallary 5.3) Take photo : This allows you to take photo to your app's Gallary...
-
Page 20: Product Specifications
PRODUCT SPECIFICATIONS Video Format ASF 640x480 @ 30FPS, with audio. Camera Lens Color-pinhole. Focal Distance 2.8 mm. Memory Support Up to 32 GB. USB Port USB 2.0. File Overwrite Auto Resolution VGA /QVGA. Record Time Display Size of Video File Approx.
