- Page 1 DGE-500T 32-bit PCI 10/100/1000Mbps Nway Gigabit Ethernet Card User’s Guide Rev.02 (Jun. 2001) 6012-9600089 Printed In Taiwan RECYCLABLE...
-
Page 2: Limited Warranty
One (1) Year Spare parts and spare kits Ninety (90) days D-Link’s sole obligation shall be to repair or replace the defective Hardware at no charge to the original owner. Such repair or replacement will be rendered by D-Link at an Authorized D-Link Service Office. - Page 3 Hardware will be refunded by D-Link upon return to D-Link of the defective Hardware. All Hardware (or part thereof) that is replaced by D-Link, or for which the purchase price is refunded, shall become the property of D-Link upon replacement or refund.
- Page 4 Registration Card. Th manual must be completed and returned to an Authorized D-Link Service Office for each D-Link product within ninety (90) days after the product is purchased and/or licensed. The addresses/telephone/fax list of the nearest Authorized D-Link Service Office is provided in the back of this manual.
- Page 5 This limited warranty provided by D-Link does not cover: Products that have been subjected to abuse, accident, alteration, modification, tampering, negligence, misuse, faulty installation, lack of reasonable care, repair or service in any way that is not contemplated in the documentation for the product, or if the model...
-
Page 6: Copyright Statement
WARRANTY SERVICE) RESULTING FROM THE USE OF THE PRODUCT, RELATING TO WARRANTY SERVICE, OR ARISING OUT OF ANY BREACH OF THIS LIMITED WARRANTY, EVEN IF D-LINK HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. THE SOLE REMEDY FOR A BREACH OF THE FOREGOING LIMITED WARRANTY IS REPAIR, REPLACEMENT OR REFUND OF THE DEFECTIVE OR NON-CONFORMING PRODUCT. -
Page 7: Fcc Warning
FCC Warning This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. -
Page 8: Table Of Contents
ABLE OF ONTENTS INTRODUCTION ................................ EATURES ..........IGABIT THERNET ECHNOLOGY ..........THERNET ECHNOLOGY UNPACKING AND INSTALLATION ..................... NPACKING ......NSTALLING THE IGABIT THERNET ......... ONNECTING THE ETWORK ABLE OFTWARE NSTALLATION ............LED INDICATORS ............. TECHNICAL SPECIFICATIONS ...... -
Page 9: Introduction
Thank you for choosing the 10/100/1000Mbps NWay Gigabit Ethernet Card for 32-bit PCI Bus-equipped personal computers. The DGE-500T NWay Gigabit Ethernet Card is ideal for speeding up data transfers for network servers and other computers, such as those used for video-conferencing that send and/or receive large amounts of data. -
Page 10: Gigabit Ethernet Technology
• 802.3x Full duplex flow control, including automatic transmission of Pause frames based on Rx FIFO thresholds • 802.1Q priority queuing support. • Six LED indicators for easy diagnostic Gigabit Ethernet Technology Gigabit Ethernet is an extension of IEEE 802.3 Ethernet utilizing the same packet structure, format, and support for CSMA/CD protocol, full duplex, and management objects, but with a tenfold increase in... -
Page 11: Fast Ethernet Technology
as well as significantly speed up the traffic between your subnets. Gigabit Ethernet enables Twisted-Pair cable connections to support video conferencing, complex imaging, and similar data-intensive applications. Likewise, since data transfers occur 10 times faster than Fast Ethernet, servers outfitted with Gigabit Ethernet NIC’s are able to perform 10 times the number of operations in the same amount of time. - Page 12 Ethernet environments, it provides a straightforward upgrade and takes advantage of the existing investment in hardware, software, and personnel training.
-
Page 13: Unpacking And Installation
NPACKING AND NSTALLATION This chapter provides unpacking and installation information for the 32-bit PCI 10/100/1000Mbps NWay Gigabit Ethernet Card. Unpacking CAUTION: Under ordinary circumstances, 32-bit 10/100/1000Mbps NWay Gigabit Ethernet Card will not be affected by static charge as may be received through your body during handling of the unit. -
Page 14: Installing The Gigabit Ethernet Card
Installing the Gigabit Ethernet Card Shut down the computer, unplug its power cord, and remove the chassis cover. 2. Insert the contact edge of the Gigabit Ethernet card into the connector of any available PCI Bus Master expansion slot. Press the card firmly into the connector such that the card’s contacts are fully seated in the connector. -
Page 15: Connecting The Network Cable
Software Installation For installation with Operating systems Window 98SE, 98 ME and Win2000 • Install the DGE-500T to a open PCI slot. • Turn on the computer. • Windows will automatically detect new hardware, which will prompt for the driver location. - Page 16 Software installation Windows NT 4.0 • Turn off computer. • Install DGE-500T to an open PCI slot. • Turn on computer. • Right click Network Neighborhood> Properties >Add Adapters • Operating System will prompt driver location. Select Floppy drive, Click OK.
-
Page 17: Led Indicators
LED I NDICATORS 1000Mbps Gigabit Ethernet Link (1000) • This indicator lights green when the Gigabit Card is connected to 1000Mbps Gigabit Ethernet Network. 100Mbps Fast Ethernet Link (100) • This indicator lights green when the Gigabit Card is connected to 100Mbps Fast Ethernet Network. -
Page 18: Technical Specifications
ECHNICAL PECIFICATIONS General Standards IEEE 802.3 10Base-T Ethernet IEEE 802.3u 100Base-TX Fast Ethernet IEEE 802.3ab 1000Base-T Gigabit Ethernet IEEE 802.3u Auto-Negotiation and Parallel Detection IEEE 802.3x Flow Control 802.1Q priority queuing support. Protocol CSMA/CD Data Transfer Ethernet: 10Mbps (half), 20Mbps (full) Rate Fast Ethernet: 100Mbps (half), 200Mbps (full) Gigabit Ethernet: 1000Mbps (half), 2000Mbps (full)
