UNVENTED GAS
CAST IRON STOVE
INSTALLATION AND OPERATING
INSTRUCTIONS
SINGLE DOOR MODELS:
CSVF20SNV CSVF30SNV
CSVF20SPV CSVF30SPV
DOUBLE DOOR MODELS:
VFCS20DNV VFCS30DNV
VFCS20DPV VFCS30DPV
Natural Gas or
Propane/LPG
Milli-Volt Control
This appliance may be installed in
an aftermarket, permanently located,
manufactured (mobile) home, where
not prohibited by local codes.
This appliance is only for use
with the type of gas indicated on
the rating plate. This appliance is
not convertible for use with other
gases.
This is an unvented gas-fired heater.
It uses air (oxygen) from the room
in which it is installed. Provisions for
adequate combustion and ventilation
air must be provided. Refer to page 8.
If the information in this manual is not followed
exactly, a fire or explosion may result causing
property damage, personal injury or loss of life.
– Do not store or use gasoline or other flammable
– WHAT TO DO IF YOU SMELL GAS
– Installation and service must be performed by
READ AND SAVE THESE INSTRUCTIONS
WARNINGS
WARNINGS
vapors and liquids in the vicinity of this or any
other appliance.
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Immediately call your gas supplier from a
neighbor's phone. Follow the gas supplier's
instructions.
• If you cannot reach your gas supplier, call the
fire department.
a qualified installer, service agency or the gas
supplier.
O N
O F
F
Advertisement
Table of Contents
Related Manuals for Monessen Hearth Double Door VFCS20DNV
Summary of Contents for Monessen Hearth Double Door VFCS20DNV
- Page 1 UNVENTED GAS CAST IRON STOVE INSTALLATION AND OPERATING INSTRUCTIONS SINGLE DOOR MODELS: CSVF20SNV CSVF30SNV CSVF20SPV CSVF30SPV DOUBLE DOOR MODELS: VFCS20DNV VFCS30DNV VFCS20DPV VFCS30DPV Natural Gas or Propane/LPG Milli-Volt Control This appliance may be installed in an aftermarket, permanently located, manufactured (mobile) home, where not prohibited by local codes.
-
