- Page 1 Robot vacuum cleaner User manual SR10J50 Series • Before operating this unit, please read the instructions carefully. • For indoor use only.
-
Page 2: Installation
Installation Installation Power of the charger must be on at all times. Power lamp (Red) Install it in a place without obstacles and danger of falling. About 0.5 m About 1 m About 0.5 m NOTE • Install the charger in a place where the floor and wall are level. • Install the charger along the grain of wooden floors. • If the power switch is off, the robot vacuum cleaner will not charge even if it is docked on the charger. • Always turn on the power of the charger. – If power is not supplied to the charger, the robot vacuum cleaner cannot find it and cannot automatically recharge. – If the robot vacuum cleaner is left detached from the charger, the battery will drain naturally. • If the robot vacuum cleaner is in energy-saving mode, power will not come on even if the power switch is turned off and then on. Press and hold the Start/Stop button on the robot vacuum cleaner. - Page 3 Accessories Batteries Remote control (Option) User manual [AAA type (Option)] Spare filter (Option) Cleaning brush Virtual guard (Option)
- Page 4 Charging It takes approximately 120 minutes to completely charge when charging for the first time after purchase and can be used for approximately 90 minutes. Charging lamp during charging (green) WARNING Rated input voltage of this product is 220 - 240 V ~ . 1 Turn on the power switch on the bottom. You must turn on the power switch to turn on the robot vacuum cleaner. 2 Manually charge the robot vacuum cleaner by placing it on the charger. Make sure the charge pins of the robot vacuum cleaner and the charger is aligned. 3 Check the charging status. “...
-
Page 5: Automatic Charging
Automatic charging When the battery indicator blinks during cleaning, the robot vacuum cleaner will return to the charger to charge itself automatically. Recharge You can command the robot vacuum cleaner to recharge at the charger while it is in cleaning process. Low battery (Lo) Manually charge the robot vacuum cleaner by placing it on the charger. Steps to take if recharging is not being executed. Check the installation status of the charger when: • the charger is located in a place where the robot vacuum cleaner cannot easily access. • distance between the charger and robot vacuum cleaner is over 5 m apart. – It may take a long time for the robot vacuum cleaner to return to the charger for recharging. Manually charge the robot vacuum cleaner when: • the charger is located in a corner. - Page 6 Installing the virtual guard (Optional) Infrared ray from the Virtual guard will restrict the robot vacuum cleaner from approaching certain areas. Virtual guard The distance of virtual wall is 2.5 m at minimum and may differ depending on surroundings and movement status of the robot vacuum cleaner. 1 Press the Power button to turn it on. Power lamp (Red) will blink. 2 Install the Virtual guard where you want to restrict the robot vacuum cleaner’s entrance. Make sure that the distance sensor is facing in the desired direction you want to create a invisible barrier (which will restrict the robot vacuum cleaner’s approach).
-
Page 7: Part Name Of The Virtual Guard
Part name of the virtual guard Power button Robot vacuum cleaner detection sensor Power lamp Power on: Red lamp blinks Power off: Lamp is off Distance detection sensor (Infrared ray sensor) Battery cover Inserting batteries Batteries for the Virtual guard must be purchased separately. 1 Open the battery cover of the Virtual guard by pressing the locking tab and lift it up. 2 Insert the batteries (D type) as shown in the illustration (check the +, - polarity). - Page 8 Operations Using the robot vacuum cleaner You must turn on the power switch before using the robot vacuum cleaner. Turning the power on/off Turn on/off the power switch on the bottom of the robot vacuum cleaner. WARNING • When the robot vacuum cleaner is not used for 10 minutes, power will turn off automatically. Using auto clean mode The robot vacuum cleaner moves and cleans automatically until it cleans an entire space once. Stop cleaning: Press the button shortly Using the cleaning modes You can select the desired cleaning mode. Recharge You can command the robot vacuum cleaner to recharge at the charger automatically while it is in cleaning process. Setting schedule You can set or cancel on-time or daily schedule.
-
Page 9: Selecting Cleaning Mode
Selecting cleaning mode Cleaning mode How to select Displayed icon Press once Auto clean Press twice Spot clean Press 3 times Max clean Press 4 times Manual clean Direction control can be done only by the remote control. Press 5 times Edge clean When the robot vacuum cleaner is being charged, you can only select the Auto clean, Max clean or Edge clean mode. - Page 10 Cleaning method for each mode Auto clean Spot clean About 1.5 m Cleans automatically Cleans a localized until an entire space area intensely. It is cleaned once. can be used to clean bread or cookie crumbs. Max clean Manual clean Cleans until the You can move the battery is depleted. robot vacuum cleaner with the remote control to clean the desired spot. Edge clean Cleans the corners by reaching to them as close as possible.
-
Page 11: Point Cleaning
05 Point cleaning Only available with A type remote control You can use the remote control to point and clean the desired spot while the 40 cm robot vacuum cleaner is in cleaning process. • Point the red light on the floor within 40 cm around the robot vacuum cleaner’s location. • Press and hold the Point cleaning button to move the red light to the desired spot. The the robot vacuum cleaner will follow the light while cleaning. Operating distance of the remote control Height of the 0.5 m 1.5 m... -
Page 12: Name Of Each Part
Name of each part 01 Quick Empty cover (Option) 02 Dustbin button 03 Dustbin 04 Display panel 05 Remote control sensor 06 Obstacle sensor 07 Virtual guard sensor (Option) 08 Bumper sensor Bottom 01 Cliff sensor 02 Side brush 03 Charge pin 04 Roller 05 Driving wheel 06 Battery cover 07 Power brush 08 Power brush cover 09 Power switch Display panel 01 Start/Stop button 02 Number display 03 Daily schedule... -
Page 13: Cleaning And Maintaining
Maintenance Cleaning and maintaining You must turn off the power switch before cleaning the robot vacuum cleaner. Cleaning the dustbin Clean the dustbin if there’s too much dust in the dustbin. 1 Remove the 2 Open the dustbin dustbin cover 3 Remove the 4 Remove dust in lter from the the dustbin and dustbin the lter 5 Wash the 6 Reassemble the dustbin and the lter into the lter... -
Page 14: Cleaning The Driving Wheel
Emptying the dustbin (Quick Empty) Use the Quick Empty cover for emptying the dustbin easily. 1 Open the Quick 2 Remove dust Empty cover in the dustbin with a vacuum cleaner 3 Close the Quick Empty cover Cleaning the driving wheel 1 Put a soft cloth 2 Use a blunt rod on the oor and or tweezers place the robot... -
Page 15: Cleaning The Power Brush
Cleaning the power brush 1 Remove the 2 Remove the dustbin power brush cover 3 Remove the 4 Clean the power power brush brush 5 Reassemble the 6 Reassemble the power brush power brush cover... -
Page 16: Cleaning The Side Brush
Cleaning the side brush Clean the side brush if there’s foreign matter on the brush. 1 Dip soft cloth 2 Wrap the into warm water side brushes with the cloth for about 10 seconds and then wipe it If hair or string is caught between the main unit and the side brush, follow the below steps. 1 Remove the side 2 Clean the side brushes brushes 3 Reassemble the side brushes...
