Appendix

Specifications

General
Rated power source ............... 14.4 V DC
Earthing system ....................... Negative type
Maximum current consumption
........................................... 10.0 A
Dimensions (W × H × D):
AVIC-F77DAB
DIN
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 188 mm × 118 mm ×
D
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 171 mm × 97 mm × 21 mm
AVIC-F70DAB
DIN
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 188 mm × 118 mm ×
D
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 171 mm × 97 mm × 20 mm
AVIC-F970DAB
DIN
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 188 mm × 118 mm ×
D
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 170 mm × 97 mm × 8 mm
AVIC-F970BT
DIN
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 188 mm × 118 mm ×
D
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 170 mm × 97 mm × 8 mm
AVIC-F9770DAB
DIN
Chassis ..................... 178 mm × 100 mm ×
(allowable voltage range:
12.0 V to 14.4 V DC)
157 mm
29 mm
164 mm
157 mm
27 mm
164 mm
157 mm
16 mm
164 mm
157 mm
16 mm
164 mm
157 mm
Nose ........................... 188 mm × 118 mm ×
D
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 170 mm × 97 mm × 8 mm
AVIC-F9770BT
DIN
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 188 mm × 118 mm ×
D
Chassis ..................... 178 mm × 100 mm ×
Nose ........................... 170 mm × 97 mm × 8 mm
Weight:
AVIC-F77DAB .................. 2.1 kg
AVIC-F70DAB .................. 2.1 kg
AVIC-F970DAB ................ 1.8 kg
AVIC-F970BT .................... 1.8 kg
AVIC-F9770DAB ............. 1.8 kg
AVIC-F9770BT .................. 1.8 kg
NAND flash memory ............. 16 GB
Navigation
GPS receiver:
System ................................ L1, C/Acode GPS
Reception system .......... 50-channel multi-channel
Reception frequency .... 1 575.42 MHz
Sensitivity .......................... –140 dBm (typ)
Position update frequency
........................................... Approx. once per second
GPS aerial:
Aerial ................................... Micro strip flat aerial/right-
Aerial cable ...................... 3.55 m
Dimensions (W × H × D)
........................................... 33 mm × 14.7 mm × 36 mm
Weight ................................ 73.7 g
Display
Screen size/aspect ratio:
AVIC-F77DAB .................. 6.95 inch wide/16:9
AVIC-F70DAB .................. 6.95 inch wide/16:9
AVIC-F970DAB ................ 6.2 inch wide/16:9
AVIC-F970BT .................... 6.2 inch wide/16:9
AVIC-F9770DAB ............. 6.2 inch wide/16:9
AVIC-F9770BT .................. 6.2 inch wide/16:9
Effective display area:
AVIC-F77DAB .................. 156.6 mm × 81.6 mm
16 mm
164 mm
157 mm
16 mm
164 mm
SPS (Standard Positioning
Service)
reception system
handed helical polarisation
Engb
