Panasonic SC-PM39D Operating Instructions Manual

Panasonic SC-PM39D Operating Instructions Manual

Dvd stereo system
Table of Contents

Advertisement

DVD Stereo System
Operating Instructions
SC-PM39D
Model No.
E
EE
EB
GN
GC
GCS
Region number supported
by this player
Region numbers are allocated to DVD
players and software according to where
they are sold.
For the United Kingdom, Continental
Europe, Saudi Arabia, Kuwait and the
Middle East
The region number of this player is "2".
The player will play DVD-Video
marked with labels containing "2" or
"ALL".
Example:
2
For Southeast Asia
The region number of this player is "3".
The player will play DVD-Video
marked with labels containing "3" or
"ALL".
Example:
For Australia and N.Z.
The region number of this player is "4".
The player will play DVD-Video
marked with labels containing "4" or
"ALL".
Example:
4
For Russia
The region number of this player is "5".
The player will play DVD-Video
marked with labels containing "5" or
"ALL".
Example:
5
Before connecting, operating or adjusting this
product, please read these instructions
completely. Please keep this manual for future
reference.
Note
"EB" on the packaging indicates the United
Kingdom.
RQT7502-3B
2
3
5
2
3
6
2
4
6
2
5
6
