Appearance View - Sharp R-310B Service Manual

4
5
1. Ventilation openings
2. Oven lamp
3. Door hinges
4. Door safety latches
5. See through door
DEFROST
MED LOW
LOW
0
DEFROST(kg)
DINNER PLATE
1 SERVE
SOUP
REHEAT 1 cup
FRESH VEGETABLES
COOK
DEFROST

APPEARANCE VIEW

2
3
7
10 12
6
6. Door seals and sealing surfaces
7. Coupling
8. Door open button
9. Control panel
10.Waveguide cover
TOUCH CONTROL PANEL
MED
MED HIGH
HIGH
2
3
1
4
5
6
7
8
9
10
30
11
0.5
25
12
20 13
15 14
1.0
MED
(400g) 5-6
min.
HIGH
(250ml) 2-2
1/2min.
HIGH
500g 4-5
min.
Check chart in Operation Manual
13
9
11
8
14
11.Power supply cord
12.Rating label
13.Turntable tray
14.Turntable support
VARIABLE COOKING CONTROL
There are five power levels. The approximate
percentage of microwave power for each setting
is:
HIGH
MED HIGH (MEDIUM HIGH)
MED (MEDIUM)
MED LOW/DEFROST
(MEDIUM LOW/DEFROST)
LOW
LIGHT UP DIAL (0-30 minutes)
Turn to set cooking time or weight of defrost food.
MEAT DEFROST GUIDE
3
R-310B
1
100%
70%
50%
30%
10%
