Window installation instructions.
3
Remove the Air Conditioner From the Case
Remove the screw from each side of the case.
A
Keep them in a safe location.
Pull to unlatch the lower corners of the inlet
B
grille and lift it up and off.
Using the tab, pull up slightly on the filter
C
to release it and pull it down to remove.
Remove the three grille frame screws.
D
12
Grasp the lower corners of the grill frame
E
while pressing in on the case sides with your
finger tips. Pull out to release and lift it up.
NOTE: Do not pull the
bottom edge toward
you more than 3 " or
you may damage the
tabs of the grille.
Remove the screw securing the ground wire to
F
the left side of the face of the unit.
Ground wire
Slide the air conditioner from the case by
G
gripping the base pan handle and pulling
forward while bracing the case.
Grille
frame
screws
Screw
