Carrier HUMXXSFP1012 Owner's Manual

Carrier HUMXXSFP1012 Owner's Manual

Small fan powered humidifier and humidistat

Advertisement

Quick Links

HUMXXSFP1012
Fig. 1 - - Small Fan Powered Humidifier
Owner's Guide
READ AND SAVE THESE INSTRUCTIONS
NOTE: This manual should be left with the equipment user.
Thank you for purchasing this humidifier.
To assure its dependability, spend a few minutes now with this
booklet. Learn about the operation of your humidifier and the
small amount of maintenance it takes to keep it operating at peak
efficiency.
With minimal care, your humidifier will provide you and your
family with moist, spring- -fresh air, from season to season and year
to year.
Proper humidity control can alleviate problems caused by
excessive dryness. Furnishings and fabrics take on a more lustrous
appearance. Houseplants thrive. Static electricity is significantly
reduced in a properly humidified home. Your family will breathe
more easily and find relief from the cool, drafty feeling commonly
experienced in overly dry homes. The additional moisture supplied
by your humidifier may enable you to reduce the temperature
setting on your thermostat — without any loss of indoor comfort.
HOW YOUR HUMIDIFIER WORKS
Your humidifier adds water molecules to the air inside your home.
Although the rate of humidification is variable, it may exceed
one- -half gallon of water per hour. That's a healthy drink for a dry
household. The typical process of humidification begins when
water flows through the humidifier valve and soaks the water
panel. Hot, dry air from the furnace passes through the panel and
absorbs the water. Then, this moisture- -laden air is distributed
throughout the house via the ductwork. See Fig. 2 and 3.
A13314
Small Fan Powered Humidifier
and Humidistat
INTRODUCTION
DRY
AIR
Fig. 2 - - Airflow
WATER
PANEL
HUMIDIFIED
AIR
DRAIN
A14306

Advertisement

loading
Need help?

Need help?

Do you have a question about the HUMXXSFP1012 and is the answer not in the manual?

Questions and answers

Summary of Contents for Carrier HUMXXSFP1012

  • Page 1 HUMXXSFP1012 Small Fan Powered Humidifier and Humidistat Owner’s Guide READ AND SAVE THESE INSTRUCTIONS NOTE: This manual should be left with the equipment user. INTRODUCTION Thank you for purchasing this humidifier. To assure its dependability, spend a few minutes now with this booklet.
  • Page 2 EVAP COIL VERTICAL A13363 Fig. 4 - - Humidistat A13330 Fig. 3 - - Typical Installation S Supply- - and return- -air grilles should not be blocked by items such as drapes, furniture, and toys. Restricted airflow reduces the OPERATING YOUR HUMIDIFIER efficiency of the humidifier, as well as that of the whole comfort Your new humidifier is designed to operate as part of your home system.
  • Page 3 Regular inspection allows you to determine the cleaning schedule structed. Contact your dealer for replacement water panel best suited to your humidifier’s operating conditions. The Part No. CAR- -0909. frequency for required maintenance will depend most upon the quality of the available water supply. In areas where hard water and Distribution Tray high mineral content are prevalent, more frequent cleaning and servicing may be required.
  • Page 4 Record the model and serial numbers of your new humidifier in the following spaces. This information, along with the other ready- -reference facts requested below, may be required if you should ever need information or service. Model No. HUMXXSFP1012 Serial No. Date Installed Dealer Name Address...
