- Page 1 User’s manual 2.4 GHz Cordless Telephone/Answering System E2913B/ E1113B with caller ID/call waiting TONE REDIAL MUTE PAUSE DELETE...
- Page 2 Congratulations of this AT&T product. Before using this AT&T product, please read the Important safety instructions on pages 54-56 of this manual. Please thoroughly read the user’s manual for all the feature operation and troubleshooting information you need to install and operate your new AT&T product.
- Page 3 You must install and charge the battery before using the telephone. For customer service or product information, visit our website at CAUTION: To reduce the risk of fire or injury to persons or damage to the telephone, read and follow these instructions carefully: •...
-
Page 4: Table Of Contents
User's manual 2.4 GHz Cordless Telephone/Answering System E2913B/E1113B with caller ID/ call waiting Table of contents Getting started Quick reference guide ...2 Parts checklist ...4 Telephone base installation ...5 Battery installation & charging ...7 Installation options ...8 Belt clip & headset ...0 Telephone operation Basic operation ... -
Page 5: Getting Started
Getting started Quick reference guide Cordless handset CID/-VOLUME Press to scroll down while in menus. Press to display caller ID information (page 33). While entering names or numbers, press to move the cursor to the left (page 26). Press to decrease the listening volume while on a call (page 4). -
Page 6: Telephone Base
Getting started Quick reference guide Telephone base CHARGE/IN USE Flashes when another telephone on the same line or one of the handsets is in use. Flashes when the answering system is answering an incoming call. Flashes while an incoming call is ringing. On steady when the handset is properly positioned to charge in the telephone base. -
Page 7: Parts Checklist
Check to make sure the telephone package includes the following: User’s manual Quick start guide 2.4 GHz Cordless 2.4 GHz Cordless Telephone/Answering Telephone/Answering System E2913B/ System E2913B/ E1113B E1113B with caller ID/call waiting with caller ID/call waiting TONE TONE MUTE REDIAL MUTE... -
Page 8: Telephone Base Installation
Getting started Telephone base installation Choose a central location close to a telephone jack and a power outlet not connected to a wall switch. The telephone base can be placed on a flat sur- face or mounted on a standard wall plate. For optimum range and better reception, place the telephone base in a high and open location. - Page 9 Getting started Telephone base installation Plug one end of the telephone line cord into the telephone jack at the bottom of the telephone base. Plug the other end of the telephone line cord into a telephone jack. DSL filter (Optional for DSL users, see number four in the note section, below.) NOTES:...
-
Page 10: Battery Installation & Charging
Getting started Battery installation & charging After installing the battery, you may be able to make and receive short calls. For best performance, place the handsets in the telephone base or the charg- er and charge for 6 hours before use. You can keep the battery charged by returning the handsets to the telephone base or the charger after use. -
Page 11: Installation Options
Getting started Installation options Tabletop mount Wall mounting The telephone base comes with the bracket mounted for tabletop use. If wall mounting is desired, a telephone outlet wall mounting plate with mounting studs is required. This mounting plate with studs may be available for purchase from many hardware or consumer electronics retailers and may require professional installation. -
Page 12: Tabletop Mounting
Getting started Installation options 3. To attach the bracket for wall mounting, insert the tabs of the bracket into slots on the telephone base, then press the other bracket tabs into slots shown on the right. 4. Plug the power adapter into an electrical outlet not controlled by a wall switch. -
Page 13: Belt Clip & Headset
Getting started Belt clip & optional headset Install belt clip as shown below if desired. Snap belt clip into the notches on both sides of handset. For hands-free telephone conversations, use any industry standard 2.5 mm headset (purchased separately). For best results, use an AT&T 2.5 mm headset. To order an AT&T 2.5 mm headset, visit our website at www.telephones.att.com or call (800) 222-3;... -
Page 14: Telephone Operation
Elapsed time PHONE 00:00:30 TONE MUTE REDIAL DELETE PAUSE PREDIAL 555-234 SPEAKER 00:00:49 Telephone operation Basic operation Making and answering calls To answer an incoming call, press SPEAKER or any dial pad key (0-9, * or #) on the handset. To make a call, press SPEAKER then dial a number. - Page 15 Telephone operation Basic operation Last number redial Press REDIAL/ REDIAL called numbers (up to 32 digits). Press up to five recently called numbers. The handset 555-234 beeps twice at the beginning or end of the list. Press PHONE press PHONE to dial the most recently called number (up to 32 digits).
-
Page 16: Handset Locator
Telephone operation Basic operation Handset locator If the handsets are misplaced, press LOCATOR on the telephone base. The handsets will play a paging tone for 60 seconds to help you locate them. To stop the paging tone, press PHONE SPEAKER, or any dial pad key (0-9, *, or #) on the handsets, or press the telephone base. -
Page 17: Options While On Calls
Volume Flash TONE MUTE REDIAL DELETE PAUSE Telephone operation Options while on calls Volume control -VOLUME to decrease the volume. Press CID/ Press /VOLUME+ to increase the volume. When changing the volume level, the new setting is saved. NOTE: The hands-free speakerphone and headset listening volume are adjusted separately. - Page 18 Tone TONE Mute MUTE REDIAL DELETE PAUSE Telephone operation Options while on calls Mute Press MUTE/ to silence the microphone. When DELETE mute is on, will show on the handset screen. You will be able to hear the caller, but your caller will not be able to hear you until you press MUTE/ again and resume speaking.
-
Page 19: Intercom
TONE TONE MUTE REDIAL MUTE REDIAL DELETE PAUSE DELETE PAUSE HANDSET 2:45PM INTERCOM TO: INTERCOM NOTE At any time, a maximum of two handsets can be used on an intercom call, and another handset can be used on an outside call at the same time. -
Page 20: Intercom Call Transfer
TONE TONE MUTE REDIAL MUTE REDIAL DELETE PAUSE DELETE PAUSE PHONE 00:05:30 INTERCOM TO: INTERCOM CALL FORWARDED NOTES . Before the intercom call is answered, you can cancel the transfer and return to the external call by pressing OFF/ PHONE/ CLEAR FLASH or INT. -
Page 21: Handset Settings
HANDSET 2:45PM MENU DIRECTORY SETTINGS SELECT then SETTINGS LANGUAGE DIAL TYPE CLOCK SETTING SETTINGS LANGUAGE DIAL TYPE CLOCK SETTING SELECT Telephone operation Handset settings Language This feature allows you to select the language used in all menus and screen displays. . -
Page 22: Clock Setting
HANDSET 2:45PM MENU DIRECTORY SETTINGS SELECT then SETTINGS LANGUAGE DIAL TYPE CLOCK SETTING SELECT Telephone operation Handset settings Clock setting To set the clock that is displayed on the handset screen: . Press MENU /SELECT 2. Press CID/-VOLUME to SETTINGS. Press 3. -
Page 23: Clear Voice Mail Indication
HANDSET NEW VOICE MAIL 2:45PM MENU DIRECTORY SETTINGS SELECT then SETTINGS DIAL TYPE CLOCK SETTING CLR VOICE MAIL SELECT CLR VOICE MAIL TURN INDICATOR OFF? SELECT Telephone operation Handset settings Clear voice mail indication If you subscribe to voicemail services provided by your local telephone company, NEW VOICE MAIL and a icon will appear on the handset display... -
Page 24: Sounds
HANDSET 2:45PM MENU DIRECTORY SOUNDS SELECT then SOUNDS RINGER MELODY KEY TONE SOUNDS RINGER MELODY KEY TONE SELECT Telephone operation Sounds Ringer melody This feature allows you to choose one of 0 ringer melodies. . Press MENU to enter the main menu. /SELECT 2. -
Page 25: Display
HANDSET 2:45PM MENU DIRECTORY DISPLAY SELECT then DISPLAY WALLPAPER CONTRAST BRIGHTNESS DISPLAY WALLPAPER CONTRAST BRIGHTNESS SELECT Telephone operation Display Wallpaper This feature allows you to select an image as wallpaper to be displayed in the background of your handset's display screen. . - Page 26 HANDSET 2:45PM MENU DIRECTORY DISPLAY SELECT then DISPLAY WALLPAPER CONTRAST BRIGHTNESS SELECT Telephone operation Display Brightness At this menu you can adjust screen brightness to one of five levels to maximize readability in dif- ferent lighting conditions. . Press MENU to enter the main menu.
-
Page 27: Ringer Volume
HANDSET 2:45PM MENU DIRECTORY RINGER VOLUME SELECT then RINGER VOLUME SELECT Telephone operation Ringer volume The ringer volume level can be adjusted (-6) or turned off (0). . Press MENU to enter the main menu. /SELECT 2. Press CID/-VOLUME RINGER VOLUME. -
Page 28: Directory
DIRECTORY Pat Williams 555-234 TONE MUTE REDIAL DELETE PAUSE Directory Shared directory The directory is stored in the telephone base and is shared by all handsets. Changes made to the directory on any handset will apply to all hand- sets. NOTE: Only one handset can review the directory or call- er ID log at a time. -
Page 29: New Directory Entries
HANDSET 2:45PM MENU DIRECTORY SELECT DIRECTORY REVIEW STORE DIRECTORY REVIEW STORE SELECT DIRECTORY ENTER NUMBER TONE MUTE REDIAL DELETE PAUSE DIRECTORY ENTER NUMBER 555-234 SELECT Directory New directory entries To create a new directory entry Press , then press MENU/ SELECT DIRECTORY. - Page 30 DIRECTORY ENTER NAME TONE MUTE REDIAL DELETE PAUSE DIRECTORY ENTER NAME Pat Williams SELECT DIRECTORY Pat Williams 555-234 Directory New directory entries To enter a name When ENTER NAME is prompted, use the dialpad to enter a name (up to 6 characters). When you enter names the handset will automatically make the first letter of every word uppercase and the following letters lowercase.
-
Page 31: Directory Search
HANDSET 4:30 PM DIRECTORY Andrew 555-6789 DIRECTORY Barbara 555-9876 - OR - DIRECTORY Jennifer 555-432 DIRECTORY 555-234 Directory Directory search To browse through the directory Press DIR to display the first listing in /VOLUME+ the directory. Press CID/-VOLUME to browse through the directory for a specific entry. -
Page 32: To Dial, Delete Or Edit Entries
HANDSET 4:30 PM DIRECTORY Andrew 555-6789 SELECT DIRECTORY EDIT NUMBER 555-6789 TONE MUTE REDIAL DIRECTORY DELETE PAUSE EDIT NUMBER 555-432 SELECT DIRECTORY EDIT NAME Andrew TONE MUTE REDIAL DELETE PAUSE DIRECTORY EDIT NAME Andy SELECT DIRECTORY Andy 555-432 Directory To dial, delete or edit entries To dial a displayed number When any directory entry is displayed, press... -
Page 33: Caller Id Operation
CHRISTINE SMITH 908-555-000 NOV23 0:0AM TONE MUTE REDIAL DELETE PAUSE Information about caller ID with call waiting This product has a caller ID function with call waiting feature which works with service from your local telephone company. Caller ID with call waiting lets you see the name and telephone number of the caller before answering the telephone, even while on another call. - Page 34 CHRISTINE SMITH 908-555-000 NOV23 0:0AM 0:0AM TONE MUTE REDIAL DELETE PAUSE Shared caller ID log The caller ID log is stored in the telephone base, and is shared by all handsets. Changes made on any handset will apply to all. NOTE: Only one handset can review the directory or caller ID log at a time.
- Page 35 Chris 908-555-000 NOV23 0:0AM TONE MUTE REDIAL DELETE PAUSE HANDSET 4 MISSED CALLS 0:0AM Caller ID operation About names Names of callers will be displayed only if the information is provided by your local telephone company. If the telephone number of the caller matches an exact number in the directory, the name that appears on screen will match the name already in the directory.
-
Page 36: To Review The Call Log
HANDSET 4 MISSED CALLS 4:30 PM CALL LOG Pat Williams 555-234 NOV 23 0:3AM CALL LOG Jeffrey Adams 555-9876 NOV 23 0:2AM CALL LOG Chris Thompson 908-555-000 NOV 23 0:AM PHONE - OR - CALL LOG Chris Thompson -908-555-000 NOV 23 0:AM CALL LOG Chris Thompson... -
Page 37: Answering System Operation
Message counter Number of messages (or during playback, mes- sage number currently playing) Press repeatedly to hear setup options (page 37). Press to review or set clock (page 35). Press to delete mes- sage currently play- ing, press and hold to delete all old mes- sages (page 38). -
Page 38: Day And Time Announcements
CLOCK The system will announce the current clock setting, then announces "To set the clock, press CLOCK." CLOCK The system will announce the current day setting, then announces "To change the day, press SKIP or REPEAT, to change the hour, press CLOCK."... -
Page 39: Outgoing Announcements
Elapsed recording time (sec- onds). Press to stop recording. ANNC “Announcement. Press PLAY or press RECORD.” PLAY/STOP (Plays announce- ment previously recorded). - OR - ANNC “Announcement. Press PLAY or press RECORD.” RECORD “Record after the tone. Press STOP when you are done.”... -
Page 40: Changing Feature Options
SETUP until desired feature is heard (see list at right). SKIP or REPEAT until desired selection is heard. SETUP to set selection and move to next menu option. - OR - /STOP PLAY to set selection and exit menu. NOTES: . -
Page 41: Message Playback
Number of messages (or during playback, message number currently playing). Press PLAY/ STOP begin or end message play- back. /STOP PLAY “You have [xx] new messages and [xx] old messages” Message playback begins. See options at right. /STOP PLAY to end message playback. NOTES: . -
Page 42: Recording And Playing Memos
Elapsed Press recording to stop time (sec- recording. onds). RECORD “Record after the tone. Press STOP when you are done.” Speak into microphone. Microphone /STOP PLAY “Recorded, beep,” the memo has been recorded. Answering system operation Recording and playing memos Memos are messages you record yourself. -
Page 43: Message Counter Displays
Message counter Answering system operation Message counter displays The message counter usually displays the total number of memos and incoming messages. See the list below for explanations of other displays in this counter. Message counter displays No messages. 0 (flashing) The clock needs to be set (page 35). -
Page 44: Answering System Mode
ANSWER ON until the system announces “Calls will not be answered.” "Beep," The system has been turned off. - OR - ANSWER ON until the system announces “Calls will be answered.” Calls will be answered.” .” "Beep." The system has been turned on. -
Page 45: Remote Access
Dial your telephone number from any touch- tone telephone. When system answers, enter two digit remote access code (19 unless you have changed it). Enter remote commands (see list at right). Hang up to end call and save all undeleted mes- sages. -
Page 46: Appendix
Appendix Screen icons, indicator lights & tones Screen icons & alert tones Screen icons HANDSET 6 MISSED CALLS 2:45PM TONE MUTE REDIAL DELETE PAUSE Handset alert tones The volume level is at the maximum or minimum setting. Two short beeps Four short beeps Low battery warning. -
Page 47: Handset Display Screen Messages
Appendix Handset display screen messages TONE MUTE REDIAL DELETE PAUSE Screen display messages XX MISSED CALLS There are new calls in the caller ID log. ALREADY SAVED The telephone number you have entered is already stored in the direc- tory. CALL LOG EMPTY You are accessing an empty call log. -
Page 48: Screen Display Messages
Appendix Handset display screen messages TONE MUTE REDIAL DELETE PAUSE Screen display messages NOT AVAILABLE AT THIS TIME NO SIGNAL, CALL ENDED ** PAGING ** PHONE PLACE IN CHARGER SPEAKER SAVED NOT AVAILABLE WARNING CHECK BATTERY! Someone else is already using the directory or call log which you are trying to access. -
Page 49: Troubleshooting
Appendix Troubleshooting If you have difficulty with your telephone, please try the suggestions below. For Customer Service, visit our website at www.telephones.att.com, or call (800) 222-3; in Canada, call (866) 288-4268. My telephone • Make sure the battery is installed and charged correctly does not work at all. - Page 50 Appendix Troubleshooting I cannot dial out. • First, try all the above suggestions. • Make sure there is a dial tone before dialing. It is normal if • Check that all the telephones connected to the same tel- • Makes sure the telephone is set to the correct dial mode •...
- Page 51 Appendix Troubleshooting • It may be necessary to purchase a new battery. Please refer • The telephone might be malfunctioning. Please refer to the The CHARGE • Clean the metallic charging contacts on the cordless hand- light is off. • Make sure the power adapter and telephone line cords are •...
- Page 52 Appendix Troubleshooting • Other electronic products can cause interference to your • Test a working telephone at the same telephone jack. If • The telephone line cord might be malfunctioning. Try install- • Remove and re-install the battery and place the cordless •...
- Page 53 Appendix Troubleshooting • Other electronic products can cause interference with your There is noise or • The handset may be out of range. Move it closer to the interference dur- ing a telephone • Appliances or other cordless telephones plugged into the conversation.
- Page 54 Appendix Troubleshooting • Disconnect the telephone base from the modular jack and • Other cordless telephones and 802. wireless routers that • Do you have DSL service? If yes, you need to have a DSL I hear other calls • Disconnect the telephone base from the telephone jack. when using the telephone.
- Page 55 Appendix Troubleshooting The system does • Make sure you subscribe to caller ID with call waiting fea- not receive caller ID or the system • The caller may not be calling from an area which supports does not display caller ID during •...
- Page 56 Appendix Troubleshooting The announce- • When recording the announcement, make sure you speak in ment message is not clear. • Make sure there is no background noise (television, music, traf- The answering • Make sure the answering system is on. system does not •...
-
Page 57: Important Safety Instructions
Appendix Important safety instructions This symbol is to alert you to important operating or servicing instructions that may appear in this user’s manual. Always follow basic safety precautions when using this product to reduce the risk of injury, fire, or electric shock. Safety information •... - Page 58 Appendix Important safety instructions Especially about cordless telephones • Privacy: The same features that make a cordless phone convenient create some limitations. Telephone calls are transmitted between the base and the handset by radio waves, so there is a possibility that your cordless phone con- versations could be intercepted by radio receiving equipment within range of the cordless handset.
-
Page 59: Save These Instructions
Appendix Important safety instructions • Nickel-metal hydride rechargeable batteries: Dispose of these batteries in a safe manner. Do not burn or puncture. Like other batteries of this type, if burned or punctured, they could release caustic material which could cause injury. Precautions for users of implanted cardiac pacemakers Cardiac pacemakers (applies only to digital cordless telephones): Wireless Technology Research, LLC (WTR), an independent research entity, led... -
Page 60: Fcc Part 68 And Acta
Appendix FCC Part 68 and ACTA This equipment complies with Part 68 of the FCC rules and with technical require- ments adopted by the Administrative Council for Terminal Attachments (ACTA). The label on the back or bottom of this equipment contains, among other things, a product identifier in the format US: AAAEQ##TXXXX. - Page 61 Appendix FCC Part 68 and ACTA If this product is equipped with a corded or cordless handset, it is hearing aid compatible. If this product has memory dialing locations, you may choose to store emer- gency telephone numbers (e.g., police, fire, medical) in these locations. If you do store or test emergency numbers, please: •...
-
Page 62: Fcc Part 5
Appendix FCC Part 15 This equipment has been tested and found to comply with the requirements for a Class B digital device under Part 5 of the Federal Communications Commission (FCC) rules. These requirements are intended to provide reasonable protection against harm- ful interference in a residential installation. -
Page 63: Limited Warranty
Appendix Limited warranty The AT&T brand is used under license - any repair, replacement or warranty service, and all questions about this product should be directed to: In the United States of America call (800) 222-3 or visit www.telephones.att. com; In Canada, call (866) 288-4268. . - Page 64 Appendix Limited warranty 4. What is not covered by this limited warranty? This limited warranty does not cover: • PRODUCT that has been subjected to misuse, accident, shipping or other physical damage, improper installation, abnormal operation or handling, neglect, inundation, fire, water, or other liquid intrusion; or •...
- Page 65 Appendix Limited warranty 6. What must you return with the PRODUCT to get warranty service? You must: a. Return the entire original package and contents including the PRODUCT to the service location along with a description of the malfunction or dif- ficulty;...
-
Page 66: Technical Specifications
Appendix Technical specifications Telephone operating range This cordless telephone operates with the maximum power allowed by the Federal Communications Commission (FCC). Even so, the handset(s) and tele- phone base can communicate over only a certain distance - which can vary with the locations of the telephone base and handset(s), the weather, the lay- out, and the construction of your home or office. -
Page 67: Index
Appendix Index AC Adapter, 6 Alert tones, 43 Answering calls, Answering system, 34-42 Announcement, 36 Battery charging, 7 Battery installation, 7 Belt clip, 0 Brightness, 23 Call log, 30 Call transfer, 7 Call waiting, 4 Caller ID, 30-33 Clear voice mail indication, 20 Contrast, 22 Delete call log entries, 33 Delete redial entries, 2... - Page 68 Appendix Index Operating range, 63 Part checklist, 4 Predial, Quick reference guide, 2-3 Receiving calls, Recharging, 7 Redial, 2 Remote access, 42 Ring silencing, 2 Ring melody, 2 Ringer volume, 24 Screen display messages, 44 Screen icons, 43 Search for names, 28 Set day and time, 35 Speakerphone, ...
-
Page 69: Remote Access Wallet Card
Turn system off or on ...0 End remote access call ...8 (or hang up) 2.4 GHz Cordless Telephone/Answering System E2913B/E1113B Copyright © 2006 Advanced American Telephones. All rights reserved. AT&T and the Globe symbol are trademarks of AT&T Knowledge Ventures, licensed to Advanced American Telephones. - Page 70 www.telephones.att.com Copyright © 2006 Advanced American Telephones. All rights reserved. AT&T and the Globe symbol are trademarks of AT&T Knowledge Ventures, licensed to Advanced American Telephones. Printed in China. Issue 1 AT&T 12/06. 91-001095-010-100...
