Summary of Contents for ISASWISS ISA 9005
-
Page 1: User Manual
USER MANUAL Caliber 9005 ISA 9005 USER MANUAL Updated 22/02/2010_2 Page 1 / 16... -
Page 2: Table Of Contents
USER MANUAL Caliber 9005 MAIN DISPLAY ................................................3 SYNCHRONIZING THE HANDS..........................................3 Description of display for each mode .......................................... 4 3.1. Mode TIME1 ................................................4 3.2. Mode DATE ................................................4 3.3. Mode ALARM ................................................. 5 3.4. Mode CHRONO..............................................5 3.5. Mode YACHT ................................................. -
Page 3: Main Display
USER MANUAL Caliber 9005 MAIN DISPLAY Mode change each time crown is pushed. On each mode the movement indicates the moon phase. TIME 1 DATE ALARM CHRONO YACHT TIME2 TIME3 TIMER COMPASS NEUTRAL TIDE SYNCHRONIZING THE HANDS Enter in neutral mode by pushing the crown. Push A and B at Push A: Push B:... -
Page 4: Description Of Display For Each Mode
USER MANUAL Caliber 9005 Description of display for each mode 3.1. Mode TIME1 Indication of the Circular second mode synchronized with digital second Hour hand Minute hand synchronize with synchronized with digital hour digital minute 3.2. Mode DATE Day of the week: Circular second Thursday Month... -
Page 5: Mode Alarm
USER MANUAL Caliber 9005 3.3. Mode ALARM Circular second Alarm ON: Pictogram is lighted Indication of mode Hour of alarm Minute of alarm 3.4. Mode CHRONO Chrono before 1 hour Chrono after 1 hour Circular second Indication of mode Minute of chrono Hundredth second Hour of chrono Second of chrono... -
Page 6: Mode Yacht
USER MANUAL Caliber 9005 3.5. Mode YACHT Indication of mode Hour hand: indicate the minute for yachting Minute hand: indicate the second for yachting Digital time 3.6. Mode TIME2 and TIME3 Circular second Indication of mode synchronize with digital second Hands indicate TIME1 Minute of TIME2: Hour of TIME2... -
Page 7: Mode Timer
USER MANUAL Caliber 9005 3.7. Mode TIMER Indication of mode Circular second Second of TIMER Hands indicate TIME1 Minute of TIMER Hour of TIMER 3.8. Mode COMPASS Direction Hands indicate TIME1 Angle between direction and the north Indication of the north Updated 22/02/2010_2 Page 7 / 16... -
Page 8: Mode Neutral
USER MANUAL Caliber 9005 3.9. Mode NEUTRAL The neutral mode show Hands indicate TIME1 only the circular mode 3.10. Mode TIDE Position of the tide Indication of mode Hands indicate TIME1 Indicate the level of the tide coefficient: synchronize with the moon Updated 22/02/2010_2 Page 8 / 16... -
Page 9: Setting Of Each Mode
USER MANUAL Caliber 9005 Setting of each mode The movement is going out of setting mode when no button is pushed during 5 seconds. BLINKING 4.1. Mode TIME1 From each mode, TIME1 can be adjusted by pulling the crown. Push the crown to go in mode TIME1 and push the button B at least 1 second to enter in setting of TIME1 When you go out of the setting of TIME1 hands are going automatically indicate the new time. -
Page 10: Mode Alarm
USER MANUAL Caliber 9005 Push the crown to go in mode DATE and push the button B at least 1 second to enter in setting mode. Push B Go out of the setting mode Year is Change year Year is Change Month is Change date... -
Page 11: Mode Time2 And Mode Time3
USER MANUAL Caliber 9005 4.5. Mode TIME2 and Mode TIME3 Push the crown to go in mode TIME2 or TIME3 and push the button B at least 1 second to enter in setting mode. Push B Go out of the setting mode Hour of Change hour... -
Page 12: Mode Tide
USER MANUAL Caliber 9005 4.8. Mode TIDE Push on the crown to go in mode TIDE and push the button at least 1 second to enter in setting mode. Push B Go out of the setting mode, the new position of tide is calculated automatically Hour of next Change hour Hour is... -
Page 13: Chrono
USER MANUAL Caliber 9005 5.2. CHRONO Push on the crown to go in mode CHRONO 5.2.1. Measure of elapsed time Push on A to start the chrono. Push on A to stop the chrono, display sows the elapsed time. Push on B to reset the chrono. 5.2.2. -
Page 14: Yachting
USER MANUAL Caliber 9005 5.3. YACHTING Push on the crown to go in mode YACHTING. After 3 seconds, hour hand comes on the last selected regatta starting time (in minute). Minute hand comes on 12h. The regatta starting time can be between 1 and 10 minutes. Display shows TIME1. Push on A to start the regatta (count down): hour hand indicate minute and turn in 15 steps by minute. -
Page 15: Compass
USER MANUAL Caliber 9005 5.6. COMPASS Push on the crown to go in mode COMPASS. Compass mode is validated after few seconds and during 30 seconds. Push on A to reset the 30 seconds. The north direction is indicated by two dots of circular second indication After the 30 seconds the movement indicates: COMPA 5.7. -
Page 16: Description Of Watch
USER MANUAL Caliber 9005 Description of watch Circular second Button D Button A 5 Alphanumeric characters Crown Moon Icons: Button B Alarm Battery Chime For time indication 6 numerical characters Updated 22/02/2010_2 Page 16 / 16...
