Page 1: User Manual
OWI INC USER MANUAL 2X2AMP-R2S61 / 2X2AMP-R2S61SVC Speaker Combination Models 2X2AMP-R2S62 / 2X2AMP-R2S64 2X2AMP-R2S62SVC / 2X2AMP-R2S64SVC Established 1978 OWI Incorporated 17141 Kingsview Ave. Carson CA 90746-1207 USA Tel. 310-515-1900 Fax 310-515-1606 info@owi-inc.com www.owi-inc.com Technical Support 310-515-1900... -
Page 2: Proprietary, Copyright Notices
IT IS THE OWNERS’ RESPONSIBILITY TO ESTABLISH THE DATE OF PURCHASE BY ACCEPTABLE EVIDENCE AT TIME SERVICE IS SOUGHT. 2. Any unit, which in the judgment of OWI INC, is defective or develops defects under normal use will be replaced or repaired without cost within the warranty period. -
Page 3: Table Of Contents
OWI User Manual: Model 2X2AMP-R2S61/62/64 Speaker Amplifier Table of Contents Description Page Proprietary, Copyright Notices Unpacking and Inspection Warranty Information Return Shipping Instructions Table of Contents Important Safety Instructions 4 - 5 Introduction Specifications 7 - 8 Illustration: Connection and Control... -
Page 4: Important Safety Instructions
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s instructions. - This OWI product should be situated so that its location or position does not interfere with its proper ventilation. For example, the component should not be situated on a bed, sofa, rug, or similar surface that may block any ventilation openings, or placed in a built-in installation such as a bookcase or cabinet that may impede the flow of air through ventilation openings. - Page 5 18. OWI recommends that this apparatus be placed on a switched power outlet, one that switches both sides and has contact separation of at least 3 millimeters.
-
Page 6: Introduction
OWI User Manual: Model 2X2AMP-R2S61/62/64 Speaker Amplifier INTRODUCTION The OWI 2X2AMP-R2S61 is a self powered speaker/amplifier on a 2X2 tile and backcan enclosure. This unit can drive up to four speakers connected series parallel to have a net impedance of 8 ohms. With an included UL Listed, Level 5 (Energy Star), 15 volt, 3.5 ampere power supply, the amplifier can output 40 watts, or 10 watts per speaker in a four speaker hook-up. -
Page 7: Specifications
OWI User Manual: Model 2X2AMP-R2S61/62/64 Speaker Amplifier SPECIFICATIONS (MODEL 2X2AMP-R2S61) 2X2AMP-R2S61 SPECIFICATIONS Woofer Diameter 6.5 inches Weight of Amplifier/Speaker Assembly 9 pounds Height of Amplifier/Speaker Assembly 4.5 inches Backcan Enclosure 2X2 Tile Support Truss ELECTRICAL AMPLIFIER 2X2AMP-R2S61 SPECIFICATIONS Input voltage, nominal... - Page 8 OWI User Manual: Model 2X2AMP-R2S61/62/64 Speaker Amplifier Wire gauge and length Minimum 18 gauge up to 40 feet maximum length Electrical, Power Supply UL Listed, Level 5 (Energy Star) Weight 0.45 pounds 4.7”H x 2”W x 1.2”D Size CAUTION: The Power Supply is not to be used in air handling spaces.
-
Page 9: Illustration: Connection And Control
OWI User Manual: Model 2X2AMP-R2S61/62/64 Speaker Amplifier ILLUSTRATION: CONNECTION AND CONTROL OWI INC. www.owi-inc.com... -
Page 10: Chained Self Amplified Speakers Wiring
OWI User Manual: Model 2X2AMP-R2S61/62/64 Speaker Amplifier 2X2AMP-R2S61 TO ANOTHER 2X2AMP-R2S61 SPEAKER WIRING SINGLE LINE DIAGRAM CHAINED SELF AMPLIFIED SPEAKERS WIRING OWI INC. www.owi-inc.com... -
Page 11: One, Two, Four Speaker Combination Wiring
OWI User Manual: Model 2X2AMP-R2S61/62/64 Speaker Amplifier ONE, TWO, FOUR SPEAKER COMBINATION WIRING OWI INC. www.owi-inc.com... -
Page 12: Input Connectors Wiring
OWI User Manual: Model 2X2AMP-R2S61/62/64 Speaker Amplifier INPUT CONNECTORS WIRING Note: Jack Line In is the same as STEREO LINE IN, immediately below. OWI INC. www.owi-inc.com... -
Page 13: Volume Control Wiring Diagram
OWI User Manual: Model 2X2AMP-R2S61/62/64 Speaker Amplifier VOLUME CONTROL WIRING DIAGRAM OWI INC. www.owi-inc.com... -
Page 14: Speaker Installation
The 2X2AMP-R2S61 Combination carton includes items 1 to 3 above plus the following: 1. 8 ohms in-ceiling speaker on a 2X2 Tile and backcan Model 2X2IC6NA *Note: Quantity of 8 Ohms Ceiling speakers ON A 2x2 tile depends on the SKU of the 2X2AMP-R2S61 Combination Program. -
Page 15: Warranty
However, we will pay the return shipping charges to any destination within the U.S.A. if the repairs are covered by the warranty. 3. Any unit which in the judgment of OWI Inc. is defective or develops defects under normal use will be replaced or repaired without cost within the warranty period. -
Page 16: Back Cover
OWI User Manual: Model 2X2AMP-R2S61/62/64 Speaker Amplifier Established 1978 OWI Incorporated 17141Kingsview Ave. Carson CA 90746-1207 USA Tel. 310-515-1900 Fax 310-515-1606 WWW.OWI-INC.COM 091715 OWI INC. www.owi-inc.com...
