ACU-RITE 01036 Instruction Manual

Professional weather center
Hide thumbs Also See for 01036:
Table of Contents

Advertisement

Quick Links

CONTENTS
Package Contents .................. 2
Product Registration ............... 2
Features: Display ................... 4
Back of Display ...................... 6
Setup .................................... 7
5-in-1 Sensor Setup ................ 7
Display Setup ........................ 8
Set the Time & Date ............... 9
Measurement Units ...............10
Set Language .......................10
Placement Guidelines ............ 11
Questions?
(844) 228-5465 or visit www.AcuRite.com.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
Professional Weather Center
AcuRite Connect ...................13
Weather Underground ..........13
Weather Ticker .....................15
Programmable Alarms ...........17
Troubleshooting ....................19
Care & Maintenance ............ 22
Calibration .......................... 22
Specifications ........................24
FCC Information ...................24
Customer Support ................ 25
Warranty............................. 25
Contact Customer Support at
Instruction Manual
model 01036

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 01036 and is the answer not in the manual?

Questions and answers

Related Manuals for ACU-RITE 01036

Summary of Contents for ACU-RITE 01036

  • Page 1: Table Of Contents

    Instruction Manual Professional Weather Center model 01036 CONTENTS 5-in-1 Sensor Installation ..12 Unpacking Instructions ... 2 AcuRite Connect ....13 Package Contents ....2 Product Registration ....2 Weather Underground ..13 Features & Benefits: 5-in-1 ..3 Using the Weather Center ..14 Weather Ticker .....15...

  • Page 2: Unpacking Instructions

    Congratulations on your new AcuRite product. To ensure the best possible product performance, please read this manual in its entirety and retain it for future reference. Unpacking Instructions Remove the protective film that is applied to the LCD screen prior to using this product.

  • Page 3: Features & Benefits: 5-In-1

    Features & Benefits 5-in-1 SENSOR 5. Temperature & Humidity Sensors 1. Rainfall Collector Funnel (internal) 2. Solar Cell Panel 6. Mounting Point Converts sunlight into power to run 7. Wind Speed Anemometer internal aspirating fan. Internal Aspirating Fan 8. Wind Direction Vane (not shown) 9.

  • Page 4: Features: Display

    Features & Benefits Display 2 3 4 27 26 25 24 22 21...
  • Page 5 1. Current Wind Direction 22. Activate Weather Ticker Message 2. Touch Activated Backlight 23. “▲“/”▼“ to Select Category (#17) & Adjust Settings Momentary during battery power, always on/off for power adapter. 24. Weather Ticker Manual Cycle 3. Current Wind Speed Press to advance through messages.

  • Page 6: Back Of Display

    Back of Display BACK OF DISPLAY Clear Today Clears data recorded since 1. Plug-in for Power Adapter 12:00 am. 2. Plug-in for USB Cable 8. Clear All Clears all recorded data without 3. Integrated Hang Hole having to reset time and date. For easy wall mounting.

  • Page 7: Setup

    SETUP 5-in-1 Sensor Setup Set the A-B-C Switch cause alkaline batteries to function improperly. Use lithium batteries in Locate the A-B-C switch inside the the 5-in-1 sensor for temperatures battery compartment. Set the A-B-C below -4ºF / -20ºC. switch to A, B or C. You must select 1.

  • Page 8: Display Setup

    Display Setup Set the A-B-C Switch Write Down the MAC ADDRESS The A-B-C switch is located inside 12 digit unique ID needed for the battery compartment. It can online connectivity functions. be set to A, B or C. However, you must select the same letter Install or Replace Backup choices for both the sensor and Batteries (optional)

  • Page 9: Set The Time & Date

    Set the Time & Date The clock and calendar are utilized to time stamp history records and other data, so it is important to set the time and date soon after you power on the display. Set the Time 1. Press the “▲“ or “▼“ buttons until “SET CLOCK?”...

  • Page 10: Measurement Units

    Select Measurement Units To select between standard units (mph, ºF, etc.) or metric units (kph, ºC, etc.): 1. Press the “▲“ or “▼“ buttons until “SET UNITS?” is displayed on the Selectable Category part of the display. 2. Press the “ ”...

  • Page 11: Placement Guidelines

    Placement for Maximum Accuracy AcuRite sensors are sensitive to surrounding environmental conditions. Proper placement of both the display and the sensor are critical to the accuracy and performance of this product. Display Placement Place the display in a dry area free of dirt and dust. To ensure accurate temperature measurement, place out of direct sunlight and away from heat sources or vents.

  • Page 12: 5-In-1 Sensor Installation

    5-in-1 Sensor Installation Guidelines INSTALLATION HEIGHT Mount the sensor at least 5 feet (1.5 meters) off the ground in an open area. Higher is better for wind measurement- the National Weather Service recommends 33 feet (10 meters) high! MOUNTING OPTIONS The included mounting bracket is designed to screw directly onto wooden posts or surfaces that are 2”x 4”...

  • Page 13: Acurite Connect

    AcuRite Connect AcuRite Connect works with Windows PC’s to provide access to your Weather Center data in the following ways: • Data File: Display logs (or stores) data so that you can download it to a PC in a data file (CSV, or comma-separated values file). •...

  • Page 14: Using The Weather Center

    After AcuRite Connect is installed on the computer, the initial configuration will begin automatically. When selecting where to save weather data downloaded from the display, a folder named “AcuRite Weather Station” will be created on the computer. (PC) When prompted by the software to plug in the display, connect the USB (larger end of the cable) into a USB port on the computer.

  • Page 15: Weather Ticker

    Weather Select = Heat Index Features weather data groups shown at right. To change = Dew Point “Weather Select” category, press the selection arrow = Wind Chill button just to the left of the = Indoor Conditions weather select display area. = Rainfall Rate (in./hour) Rainfall Event The rainfall feature tracks rain accumulation over all-time, the current month,...
  • Page 16 Additional Messages Include: NO RAIN RECORDED SINCE ____ NEW HIGH TEMPERATURE RECORD WEATHER ALARM MESSAGES NEW LOW TEMPERATURE RECORD SENSOR BATTERIES LOW NEW WIND SPEED RECORD TODAY SENSOR SIGNAL LOST CURRENT RAINFALL RATE CURRENT RAIN EVENT STARTED Adjust the Weather Ticker Speed 1.

  • Page 17: Programmable Alarms

    Programmable Weather Alarms Each Selectable Weather Category features an alarm option. When an alarm sounds, the display emits audible beeping and flashes the affected category, its alarm settings, and any other relevant data. Some alarms can be customized to alert you when your programmed value is reached.
  • Page 18 ICON DEFINITIONS = Alarm On = Alarm Off = Adjust Mode = Low Value = High Value BUTTON FUNCTIONS Silence a Sounding Alarm Press to activate or The alarm sounds initially for a few minutes, deactivate an alarm. then silences itself. The alarm then sounds every Press and hold to set few minutes afterwards until one of the or adjust an alarm...

  • Page 19: Troubleshooting

    Troubleshooting Problem Possible Solution • Relocate the display and/or the 5-in-1 sensor. The units must be within 330 ft (100 m) of each other. • Make sure both units are placed at least 3 feet (.9 m) away from electronics that may interfere with the wireless communication (such as TVs, microwaves, computers, etc).
  • Page 20 Troubleshooting Problem Possible Solution • Make sure both the display and 5-in-1 sensor are placed away from any heat sources or vents (see page 11). Inaccurate • Make sure both units are positioned away from moisture sources (see page 11). temperature or humidity •...
  • Page 21 Troubleshooting Problem Possible Solution • Verify that the status in the AcuRite Connect software on your PC indicates that the data was received from the display. • Verify that you created an account or logged into an existing account at www.acu-link.com or in the AcuRite app, and that you input the display’s MAC ADDRESS as a part of the account setup.

  • Page 22: Care & Maintenance

    Care & Maintenance Display Care Clean with a soft, damp cloth. Do not use caustic cleaners or abrasives. Keep away from dust, dirt and moisture. Clean ventilation ports regularly with a gentle puff of air. 5-in-1 Sensor Care Clean the Sensor Clean with a soft damp cloth.
  • Page 23 “▲“ or “▼“ buttons 3. Press the to calibrate the data value higher or lower from the actual reading. 4. Press the “ ” button to confirm the calibration adjustment. Note: The “ ” icon remains illuminated next to calibrated values.

  • Page 24: Specifications

    Specifications TEMPERATURE RANGE Outdoor: -40ºF to 158ºF; -40ºC to 70ºC Indoor: 32ºF to 122ºF; 0ºC to 50ºC HUMIDITY RANGE Outdoor: 1% to 99% Indoor: 16% to 98% WIND SPEED 0 to 99 mph; 0 to 159 kph WIND DIRECTION 16 points INDICATORS RAINFALL 0 to 99.99 in;...

  • Page 25: Customer Support

    Customer Support AcuRite customer support is committed to providing you with best-in- class service. For assistance, please have the model number of this product available and contact us in any of the following ways: (844) 228-5465 info@chaney-inst.com AcuRite 24/7 support at www. .com Installation Videos Register your Product...
  • Page 28 Weather Temperature Weather Kitchen Clocks Stations & Humidity Alert Radio Thermometers & Timers It’s More than Accurate, it’s AcuRite offers an extensive assortment of precision instruments, designed to provide you with information you can depend on to Plan your day with confidence ™...
