Page 1: Instruction Manual
S06HS MODEL ONLY USE WITH Caffitaly System Capsules INSTRUCTION MANUAL Imported by Roasting Australia Holdings Pty Limited Safety 11 Hoyle Avenue, Castle Hill, NSW 2154 Phone: 02 9846 0307 E-Mail: info@maranathaimport.com.au... -
Page 2: Table Of Contents
General Operating Indications Cleaning and Maintenance: • Daily Maintenance • Descaling • Changing the Gasket • Saving Energy Miscellaneous: • Restore Original Settings (RESET) • Troubleshooting • Technical Data • Instructions for Use and Disposal • Caffitaly System Care Contact... -
Page 3: Introduction
New Caffitaly System S06HS Machine. You can now savour your favourite hot beverages at any time, day or night with the Caffitaly System S06HS by choosing one of the many compatible Caffitaly System capsules available. -
Page 4: Safety Warnings
• This appliance is intended to be used in domestic environments. Not suitable for Professional use. • Use ONLY Caffitaly System compatible capsules. Damage caused by using incorrect capsules will void the guarantee. • Use the TEA button (Blue) for Tea ONLY! Incorrect use of this button will cause damage to the machine and void the guarantee. -
Page 5: Symbols Guide
SAFETY WARNINGS - Continued • This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety. -
Page 6: Machine Components
MACHINE COMPONENTS Hot Water/Steam Control Lever Indicator Light Orange=Descale Red=Check System Single Espresso Button 30ml (Lit White) Double Espresso Button 60ml (Lit White) TEA Button -120ml (Lit Blue) Diagram 1: Water Tank Water Tank Cover Capsule Compartment Hot Water/ Steam Control Lever Dispensing Spout (adjustable) -
Page 7: First Time Use
ONLY USE WITH FIRST TIME USE Caffitaly System Capsules We recommend following these steps Please ensure you only use Caffitaly after not having used the machine for System Capsules which can be a long period of time. identified by the Caffitaly logo. -
Page 8: Correct Use Of The Buttons
FIRST TIME USE - Continued WARNING: When all the During the priming button lights remain steadily lit, and rinsing stage, rinse by pressing HOT WATER will the Double be collected in Espresso button. the used capsule Press again to drawer. Danger of repeat cycle. -
Page 9: Dispensing Beverages - Using Factory Settings
DISPENSING BEVERAGES - Using Factory Settings Plug in appliance. Raise the lever to Switch machine open the capsule on using the On/ compartment. Off Switch. Insert the Close the lever capsule, pressing fully and place it gently into a cup or mug place. -
Page 10: Turning On The Appliance
TURNING ON THE APPLIANCE - DAILY USE Fill the water tank Switch machine with fresh, still on using the water (either by On/Off Switch. filling through the water tank cover or removing the water tank). When all the When all the button lights blink button lights are continuously,... -
Page 11: Frothing / Dispensing Steam
FROTHING / DISPENSING STEAM WARNING! During preparation there may be some brief splashes of hot water and the steam wand * Special Rubber reaches very high temperatures Grip - Danger of scalding! The Tube must only be handled using the *special rubber grip. -
Page 12: Programming The Quantity Of Beverage In A Cup
FROTHING / DISPENSING STEAM - Continued Add milk to your When you have beverage and enjoy! finished heating or frothing the Remember to clean milk, return the the tube with a damp control lever to cloth after each use. the centre. WARNING: Steam wand tube will be hot. - Page 13 PROGRAMMING THE QUANTITY OF BEVERAGE IN A CUP ... CONTINUED Switch the Raise the lever to machine on open the capsule using the On/Off compartment. Switch. Wait for approx. 1 min. for the machine to warm up. Insert the Close the lever fully and place capsule, pressing it gently into...
-
Page 14: General Operating Indications
GENERAL OPERATING INDICATIONS DESCALING SIGNAL: HEATING: Indicator light blinks When all the ORANGE and then button lights remains on without continuously blink, blinking, it is advisable the machine is to perform the warming up. descaling cycle. (This will take See Page 15 for approx. -
Page 15: Daily Maintenance
DAILY MAINTENANCE Remove the Pull out the used capsule drawer water tank, and drip tray. empty, rinse and Remove the grill, replace the tank. empty and rinse with water. Dry NOTE: The water and replace back tank is NOT dishwasher safe. into the machine. -
Page 16: Descaling
DESCALING INSTRUCTIONS DESCALING SIGNAL: When the indicator light blinks ORANGE and the machine emits 3 beeps, please perform the descaling cycle as illustrated. (Please note: you may miss the beeps if there is a lot of background noise, the indicator light will alert you that descaling is required.) PLEASE DO NOT LEAVE THE MACHINE DURING THE DESCALING PROCESS. - Page 17 DESCALING INSTRUCTIONS - Continued Place an empty Turn the control container (at lever forward least 1 litre) (towards you). under the coffee dispensing spout and the steam wand. Double Espresso Press and hold button will be lit the Single and and indicator light Double Espresso will blink...
- Page 18 DESCALING INSTRUCTIONS - Continued RINSING: Rinse water Place a container tank and fill it under the coffee with still fresh dispensing spout drinking water (at least 600ml). to the Max line. Beep Press the Double When the rinse Espresso button cycle is complete, to start the rinse the machine beeps...
-
Page 19: Changing The Gasket
CHANGING THE GASKET CAUTION! If the gasket shows signs of wear, such as small cuts or cracks and warping, you can replace it easily using the spare gasket supplied in the pack. Perform the following actions only when the machine is cold. Contact with the inside surfaces of the machine could cause scalding. -
Page 20: Restore Original Settings (Reset)
RESTORE ORIGINAL SETTINGS (RESET) These instructions will allow you to reset the machine back to its original factory settings – Helpful if you experience an issue with the machine, or you have changed the pour levels for example and cannot change them back to their original levels. Start with the Switch the lever up and... -
Page 21: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE SOLUTION No coffee comes out. - The water tank is empty. - Fill the tank with fresh water. indicator light blinks RED. Press the Double Espresso button to refill the circuit. When the buttons remain steadily lit, the machine is ready for use. - Page 22 Refer to ‘Restore Original Settings’ on Page 19. Coffee grinds in the cup. - Incorrect capsules being - Only Caffitaly System compatible used. capsules can be used. - There may be residual grinds remaining in the system if you did not cycle water through on the last dispensed beverage.
-
Page 23: Technical Data
All materials and objects in contact with food products comply with the requirements of European Regulation 1935/2004. CAFFITALY SYSTEM CARE CONTACT Phone: 02 9846 0307 E-Mail: info@maranathaimport.com.au For more information on the machine operation, available capsules and other useful hints and tips go to the Caffitaly website: www.caffitalysystem.com.au... - Page 24 This unique design is why other capsules on the market do not work with the Caffitaly System Machine. Only use capsules displaying the Caffitaly System logo with this machine.
