Summary of Contents for Essentials Twister AK8000AS
- Page 1 www.zephyronline.com Twister AK8000AS Tornado I AK8100AS Model number: Serial Number: Date of Purchase: Sales Dealer: JAN08.0201 © 2008 Zephyr Corporation READ AND SAVE THESE INSTRUCTIONS...
- Page 2 www.zephyronline.com...
- Page 3 SAFETY NOTICE ..............LIST OF MATERIALS ............INSTALLATION Ducting Calculation Sheet ........Mounting Height & Clearance ........ Ducting Options ............Specifi cations ............... Electrical ................. Installing the Power Pack ........FEATURES & CONTROLS Slide Controls ............... MAINTENANCE Cleaning and Installing Filters .......
- Page 4 www.zephyronline.com READ AND SAVE THESE INSTRUCTIONS WARNING TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT USE THIS FAN WITH ANY SOLID-STATE CONTROL DEVICE. WARNING TO REDUCE THE RISK OF FIRE ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: a.
-
Page 5: Operation
WARNING TO REDUCE THE RISK OF FIRE, USE ONLY METAL DUCTWORK. CAUTION To reduce risk of fi re and to properly exhaust air outside - Do not vent exhaust air into spaces within walls, ceilings, attics, crawl spaces or garages. OPERATION Always leave safety grilles and fi... -
Page 6: Hardware Package Contents
www.zephyronline.com MODELS: AK8000AS AND AK8100AS PARTS SUPPLIED AK8000AS and AK8100AS 1 - Power Pack 1 - Metal mesh fi lter (AK8000AS), 1 - Decorative mesh fi lter (AK8100AS) 2 - Halogen light bulbs (pre-installed) 1 - Single internal blower (pre-installed) 1 - Hardware package HARDWARE PACKAGE CONTENTS Suction Cup (1) - Page 7 Equivalent number Equivalent number Duct pieces Duct pieces length x used T otal length x used T otal 3-1/ 4” x 10” 1 Ft. 6” Round 30 Ft. Rect., wall cap straight with damper 6” Round, 1 Ft. 6” Round, 30 Ft.
- Page 8 www.zephyronline.com Minimum mount height between range top to hood bottom should be no less than 26”. Maximum mount height should be no higher than 36”. It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat damage and fi...
- Page 9 WARNING FIRE HAZARD NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or garages. All exhaust must be ducted to the outside. Use metal ductwork only. Fasten all connections with sheet metal screws and tape all joints with certifi ed Silver Tape or Duct Tape. Some Ducting Options side wall cap side wall cap...
- Page 10 www.zephyronline.com 10-5/8” 5-7/8” 4-1/8” 11-13/16” 26-9/16” 27-9/16” front 27-9/16” 25-3/4” 10-5/16” 15” 1-5/16” 18-15/16” bottom side...
- Page 11 ELECTRICAL WARNING All Electrical work must be performed by qualifi ed electrician or person with similar technical know how and background. For personal safety, remove house fuse or open circuit breaker before beginning installation. Do not use extension cord or adapter plug with this appliance. Follow national electrical codes or prevailing local codes and ordinances.
- Page 12 www.zephyronline.com CAUTION: At least two installers are ” required due to the weight and size of the hood. 1. Install optional AK08xxAS Stainless Steel Liner. Review manual included with liner for more details. 2. If no liner is used cut out an opening in the bottom of the cabinet by following the dimensions in FIG 1.
- Page 13 Blower On/Off Speed Selection Lights Bright/Dim/Off I I I BLOWER ON/OFF/SPEED SELECTION 0 is off, I is low speed, II is medium speed and III is high speed. LIGHTS BRIGHT/DIM/OFF 0 is off, I is dim, and II is bright.
-
Page 14: Surface Maintenance
www.zephyronline.com SURFACE MAINTENANCE: Clean periodically with hot soapy water and clean cotton cloth. Do not use corrosive or abrasive detergent, or steel wool/ scoring pads which will scratch and damage surface. Do not use products containing chlorine bleach or orange cleaners. For heavier soil use liquid degreaser. - Page 15 DUCTLESS RECIRCULATING (AK8000AS ONLY): Ductless recirculating is intended for applications where an exhaust duct work is not possible to be installed. When converted, the power pack functions in air “purifying” mode rather than exhausting the air. Fumes and exhaust from cooking is drawn and fi ltered by a charcoal fi lter. The air is then purifi ed and recirculated back into the kitchen.
-
Page 16: Replacing Light Bulbs
www.zephyronline.com REPLACING LIGHT BULBS CAUTION: Light bulb becomes extremely hot when turned on. DO NOT touch bulb until switched off and cooled. Touching hot bulbs could cause serious burns. Make sure all power is turned off and bulbs are not hot. Remove by turning bulb counter clockwise. - Page 17 TROUBLESHOOTING PROCEDURES FOR TWISTER AND TORNADO 1 Issue Cause What to do After installation, 1. The power source is not turned ON. 1. Make sure the circuit breaker and the unit’s the unit doesn’t power is ON. work. 2. The power line and the cable locking connector 2.
- Page 18 www.zephyronline.com DESCRIPTION PART # Replacement Parts Light Bulb MR16 (GU10) 35W (each) Z0B-0023 Metal Mesh Filter (each) 50200022 Decorative Mesh Filter (each) 50200024 Optional Accessories Liner,30” AK0800AS Liner,36” AK0836AS Recirculating Kit (AK8000AS ONLY) ZRC-0100 To order parts, visit us online at http://store.zephyronline.com or call us at 1.888.880.8368...
