Ransomes Matador 71 Parts Manual

Ransomes Matador 71 Parts Manual

Reel mower
Hide thumbs Also See for Matador 71:
Table of Contents

Advertisement

Quick Links

Parts Manual

Ransomes Matador 71
71 Matador
Product Code: LDDD704
Series: EH4
WARNING: If incorrectly used this machine can cause severe
injury. Those who use and maintain this machine should be
trained in its proper use, warned of its dangers and should
read the entire manual before attempting to set up, operate,
adjust or service the machine.
Ransomes Jacobsen Limited reserves the right to make design changes without obligation to make these
changes on units previously sold and the information contained in this manual is subject to change without notice.
RJL 100 May 2014
© 2013, Ransomes Jacobsen Limited. All Rights Reserved
WARNING
25068G (rev 1)
®
®

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Matador 71 and is the answer not in the manual?

Questions and answers

Related Manuals for Ransomes Matador 71

Summary of Contents for Ransomes Matador 71

  • Page 1: Parts Manual

    Ransomes Jacobsen Limited reserves the right to make design changes without obligation to make these changes on units previously sold and the information contained in this manual is subject to change without notice.
  • Page 2 Ransomes Jacobsen Limited reserves the right to make design changes without obligation to make these changes on units previously sold and the information contained in this manual is subject to change without notice. © Ransomes Jacobsen Limited. All Rights Reserved...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION PAGE SECTION PAGE 1 ENGINE GROUP.............8 2 MAINFRAME AND GRASSBOX ......10 3 THROTTLE LINKAGE ..........12 4 CUTTING UNIT .............14 5 LANDROLL CLUTCH ..........16 6 CONTROLS AND HANDLES ........18 7 BRAKES ROLLER AND SCRAPER ......20 8 FRONT ROLLERS ..........22 9 LANDROLL.............24 10 71CM ROLLERS ..........26 11 TRAILING SEAT ..........28...
  • Page 4 2 INTRODUCTION IMPORTANT__________________________________________________________ The Ransomes MATADOR is a Petrol engined Pedestrian REEL mower. The traction drive and the cutting unit are Chain Driven. IMPORTANT: Do the maintenance indicated in this manual to make sure that the quality of cut is kept at a high level.

  • Page 5: Product Identification

    INTRODUCTION 2 PRODUCT IDENTIFICATION ___________________________________________ Maximum front axle load in Kg (for machines being West Road driven on the highway) Ransomes Europark Ipswich IP3 9TT Gross weight (mass) in Kg England Maximum rear axle load in Kg (for machines being...
  • Page 6 “General discarded materials” area. • Do not burn discarded materials. Change the machinery records to show that the machine is not in service and is discarded. Supply this serial number to Ransomes Jacobsen Warranty Department to close their records. en-4...
  • Page 7 INTRODUCTION 2 PARTS MANUAL ______________________________________________________ In compliance with the ISO14001 standard, Ransomes Jacobsen Limited does not send a paper parts manual with every product. To refer to a parts list for this mower you have four options: Website – www.ransomesRansomes Jacobsen.com. Select the “GENUINE PARTS” tab followed by the “ONLINE PARTS LOOK-UP”...
  • Page 8 2 INTRODUCTION ASSEMBLY __________________________________________________________ The Mower is fitted to a container at the factory and will need assembly before operation. Some tools will be needed for assembly. Discard the container according to the applicable local environmental requirement. Remove the mower from the container. The handles are found around the chassis - Figure 1.
  • Page 9 INTRODUCTION 2 NOTES en-7...

  • Page 10: Engine Group

    MATADOR Engine Group Illustration: 4300619_Group_Engine_71cm Parts- 8...
  • Page 11 MATADOR ITEM PART NO. DESCRIPTION NOTES/SERIAL NO. 006890150 Engine Honda GX160 K1-Q4 670000116 Washer - Fibre 25/64 X 5/8 X 1/16 MBG6288 Drain Plug Extension 450474 Screw Hex M8-1.25 X 40 MBF1058 Mounting Plate - Welded 450479 Screw Hex M10-1.5 X 25 4135990 Torque, Clutch 4300711...

  • Page 12: Mainframe And Grassbox

    MATADOR MAIN FRAME AND GRASS BOX Illustration: 4299911_Main Frame and Grass Box Parts- 10...
  • Page 13 MATADOR ITEM PART NO. DESCRIPTION NOTES/SERIAL NO. 001191331 Screw Pan M5-0.8 X 16 002090580 Bearing 17 X 47 X 22.2 002920713 Spring Disc 8.2 X 20 X 0.8 009148598 Acoustic Pad 4300272 Chassis 450191 Screw Hex M8-1.25 X 20 450324 Nut Hex M8-1.25 450357 M6-1.0 Nutsert...

  • Page 14: Throttle Linkage

    MATADOR THROTTLE LINKAGE Illustration: 4299991_Throttle_Linkage Parts- 12...
  • Page 15 MATADOR ITEM PART NO. DESCRIPTION NOTES/SERIAL NO. 4108643 Spring, Throttle Plate 4136549 Cable Guide 4136554 Cable Stop Collar 4137299 Screw, # 6-32.1875 Hex Socket Set 4299989 Spacer, Cable Guide 4299987 Spring, Engine Throttle 450528 Screw Pan M5 450322 Nut Hex M5 4301754 Cable Guide Parts- 13...

  • Page 16: Cutting Unit

    MATADOR CUTTING UNIT Illustration: lmac067_Matador_Cutting_Unit Parts- 14...
  • Page 17 MATADOR ITEM PART NO. DESCRIPTION NOTES/SERIAL NO. 001090799 Screw-adjuster M10-1.5 X 240 001993020 Insert Helicoil M10 X 1.5 002036057 Bearing 25 X 52 X 15 002190069 Bush Oilite 28 X 33 X 20 002910710 Spring Compression 55 X 2.64 X 28 002953192 Grommet-10 X 22 X 7.5 002993013...

  • Page 18: Landroll Clutch

    MATADOR LANDROLL CLUTCH Illustration: 302r0007_Matador_Drive.eps Parts- 16...
  • Page 19 MATADOR ITEM PART NO. DESCRIPTION NOTES/SERIAL NO. 001191315 Screw Countersunk M5 X 16 001431004 Pin, 8 X 98.5 002100834 Bush Oilite 12 X 16 X 12 002106513 Bush Oilite 25x30x20 002190035 Bush Oilite 60.397 X 66.764 X 14.85 002911009 Spring Compression 8.7 I/d X 30 002920852 Spring Disc 12.2 X 25 X 0.7 009131941...

  • Page 20: Controls And Handles

    MATADOR HANDLES AND CONTROLS Illustration: 4299912_Handles_Matador_71cm Parts- 18...
  • Page 21 4145245 Landroll Clutch Cable 009067840 Landroll Clutch Cable 009060770 Control Cable MBF2097 Brake Lever 4130979 Handle Bracket 008111400 Lever Landroll Clutch, Pedestrians 006500400 Recoil Rope Guide 4298191 Handlebar Support MBF2150 Handlebar Matador 71 Standard 450323 Nut Hex M6-1.0 Parts- 19...

  • Page 22: Brakes Roller And Scraper

    MATADOR BRAKES ROLLER AND SCRAPER Illustration: 302r0004_Matador_Brakes_Roll_Scraper.eps Parts- 20...
  • Page 23 MATADOR ITEM PART NO. DESCRIPTION NOTES/SERIAL NO. 009067820 Cable Brake 009151220 Brake Band 450000 Bolt Hex M6-1.0 X 25 450191 Screw Hex M8-1.25 X 20 450192 Screw Hex M8-1.25 X 25 450377 Nut Hex M6-1.0 450378 Nut Hex M8-1.25 450389 Washer M6 X 12.5 X 1.8 450390 Washer M8 X 17 X 1.8...

  • Page 24: Front Rollers

    MATADOR FRONT ROLL Illustration: 302r0005_Matador_Front_Roll.eps Parts- 22...
  • Page 25 MATADOR ITEM PART NO. DESCRIPTION NOTES/SERIAL NO. MBF2238 Front Roll Cross Shaft 450192 Screw Hex M8-1.25 X 25 450324 Nut Hex M8-1.25 450411 Lock Washer M8 X 12.75 X 2 MBC3218 Ferrule 001993020 Insert Helicoil M10 X 1.5 002990552 M10 Hand Wheel 450325 Nut Hex M10-1.5 009071030...

  • Page 26: Landroll

    MATADOR LANDROLL Illustration: 302r0006-2_Matador_Landroll.eps Parts- 24...
  • Page 27 MATADOR ITEM PART NO. DESCRIPTION NOTES/SERIAL NO. 001490658 Cotter Pin 002036049 Bearing 20 X 47 X 14 002920501 Spring disc 8.2 X 16 X 0.9 450000 Bolt Hex M6-1.0 X 25 450020087 Nut Hex 3/8-24 450190 Screw Hex M8-1.25 X 16 450192 Screw Hex M8-1.25 X 25 450391...

  • Page 28: 71Cm Rollers

    MATADOR SIDE ROLLS Illustration: LLMAA614B_Side_Roller ITEM PART NO. DESCRIPTION NOTES/SERIAL NO LMAA614B Side Rollers 002101377 • Bush Oilite 20 X 25 X 20 002920836 • Spring Disc 10.2 X 23 X 1 002993013 • Lubricator M6 Straight 450214 • Screw Hex M10-1.5 X 25 450394 •...
  • Page 29 MATADOR OUTRIGGER ROLLS Illustration: LMAA630B_Outrigger_Roll ITEM PART NO. DESCRIPTION NOTES/SERIAL NO 590000564 • Bush Oilite 3/4 X 1 X 1-1/4 842000044 • Lubricator 1/4" 450394 • Washer M20 X 37 X 3.3 454000297 • Split Pin-1/8 X 1-1/4 LSD5027 • Side Roll MBC3439 •...

  • Page 30: Trailing Seat

    MATADOR TRAILING SEAT Illustration: LMAA628_Matador_Seat.eps MATADOR TOW BAR 71cm Parts- 28...
  • Page 31 MATADOR ITEM PART NO. DESCRIPTION NOTES/SERIAL NO. LMAA628 Trailing Seat for MATADOR 71 MBC5881C Seat Frame 699524927 Seat MBA5360 Land Roll MBA5364 Spindle 452200087 Lock Washer-3/8 X .590 X.092 456110066 Screw Hex 3/8-16 X 1 456010789 Screw Hex 1/2-20 X 7/8 452200168 Lock Washer-1/2 X .763 X .116...

  • Page 32: Landroll - Rubber Covered

    MATADOR LANDROLL - RUBBER COVERED Illustration: 302R0006_rubber coated.eps Parts- 30...
  • Page 33 MATADOR ITEM PART NO. DESCRIPTION NOTES/SERIAL NO. MBC9298 Housing A203604 Bearing 20 X 47 X 14 451977 Circlip Internal 47 X 1.75 450190 Screw M8 X 16 002920501 Spring Disc 8.2 X 16 X 0.9 MBC4829A Shaft, Matador-71 452045 Circlip External 20 X 1.2 MBC4830 Adjusting Collar 450968...

  • Page 34: Decals

    MATADOR DECALS Illustration: Decals.eps Parts- 32...
  • Page 35 009034940 • Decal - Cylinder Hazard 009034920 • Decal - Hot 009034890 • Decal - Bystander Warning 4311751 • Decal - Ransomes Matador 71 41999982 • Decal - Ransomes 4130883 • Decal - OPC/Brake 009114240 • Decal - Unleaded Petrol 009034900 •...
  • Page 36 Europe & Rest of The World Except North & South America Ransomes Jacobsen Limited West Road, Ransomes Europark, Ipswich, IP3 9TT English Company Registration No. 1070731 www.ransomesjacobsen.com North & South America Jacobsen, A Textron Company 11108 Quality Drive, Charlotte, NC 28273, USA...
