ASSEMBLY AND SET-UP

Turn power switch off before conducting any maintenance procedures.
Attaching the Front Wheel/Handlebars
Tool Required: Phillips screwdriver
Front
Arrow
1
Facing the front of the unit, insert front wheel assembly.
Note: Make sure the connector is on the left side of the
wheel (opposite side of the foot pedal) before attaching
the handlebars.
3
Insert the handlebars into the steering tube. Align the
hole on the handlebars with the hole on the steering tube.
5
Carefully turn unit over and plug the white connector
on the front wheel into the white connector on
the control module.
Foot pedal
(Right Side)
Connector
(Left Side)
2
4
Remove nut and bolt from handlebars.
Re-insert the nut and bolt and tighten securely in place.
4
Note: Failure to secure the
handlebars can cause the
handlebars to come out while riding.
