Denver GSP-100 User Manual

Senior phone
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Senior Phone
GSP-100
www.facebook.com/denverelectronics

User Guide

1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GSP-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Denver GSP-100

Summary of Contents for Denver GSP-100

  • Page 1: User Guide

    Senior Phone GSP-100 www.facebook.com/denverelectronics User Guide...

  • Page 2: Table Of Contents

    ··················································································· 4 Put in/Take out battery ······························································ 4 Insert/Take out SIM card··························································· 7 Battery Charging ······································································ 8 Switch On /Off phone································································ 9 ·················································································10 Stand by Mode ······································································10 Key Functions··········································································12 Voice Volume Key····································································14 ···················································································14 Dial out ····················································································14 Emergency Dial ·······································································14 Make an International Call ·······················································15 Dial extension No.
  • Page 3 Silent mode ·············································································21 Settings ···················································································21 Network setting ········································································22 PIN ··························································································23 Calculator ················································································23 Alarm ······················································································24 Birthday reminder ····································································24 Restore factory ········································································24 ·····················································································24 ················································································25 English Letters Input Method ···················································25 Numeral input method ·····························································25 Punctuation input method ························································25 Care and Maintenance ·································································25...

  • Page 4: Put In/Take Out Battery

    Put in/Take out battery Put in battery 1. Open the battery cover 2. Put battery into the battery slot. Keep three metal points of battery facing downward and matching with the three metal connection points on phone.
  • Page 5 3. Put on battery cover. Make sure that cover is completely matched and the cover matching sound could be heard. Take battery out 1. Open battery cover.
  • Page 6 2. Press the battery side and lift it up to take it out from battery slot. 3. Close the cover. Make sure that cover is completely matched and the cover matching sound could be heard.

  • Page 7: Insert/Take Out Sim Card

    Remark： ： ： ： Shut down all devices and cut the connection with charger when removing battery. Please use battery which is matched with this phone only. Insert/Take out SIM card 1. Insert SIM card： ： ： ： Remove battery cover； Insert and slide the SIM card with the metal part facing downward by following below arrow direction at battery slot until SIM card is completely inserted in right position.

  • Page 8: Battery Charging

    Remark： ： ： ： Phone must be power off when put in and take out battery. SIM card and the contact point will be easily damaged due to scratch and bending. Please be careful when inserting and taking out the SIM card. Battery Charging Phone could be charged when phone is power off or power Make sure that battery is inserted in phone before...

  • Page 9: Switch On /Off Phone

    Remark： ： ： ： Battery indication will be displayed after several minutes if battery is over-discharged. Battery Level Indication Bar Charging Charged Not enough battery alert Phone will give alert when battery is not enough and display a message of low battery on screen. Please charge battery. Please charge battery when you receive the alert of low battery during calling in order to keep the calling.

  • Page 10: Stand By Mode

    Warning： ： ： ： SIM card will be locked if you type wrong code for three times. And it will inform you to type in PUK code. (Please contact your network service vendor to unlock it if needed.） Switch Off Long press this key to switch off the phone at standby mode.

  • Page 12: Key Functions

    Icons on Screen Icons might be displayed on screen. Battery status Signal status Alarm Unread message Message Full Call transfer Missed call Silent mode Roaming Keypad Lock Headset Lock keypad message indication keypad lock mode. Missed call indication keypad lock mode. New message and missed call indication at keypad lock mode.
  • Page 13 Standby mode ： press to enter Navigation phonebook Operating ： press to move cursor Down key down Phone Off：Long press to switch on; Phone On：Long press to switch off; End Key Operating ： Press to go back to (Red Key) previous menu Long press it at non-editing screen to go back to standby screen.

  • Page 14: Voice Volume Key

    Keypad Push up to unlock keypad and push Lock down to lock keypad Emergency Call is ON： Long press to dial emergency call Emergency Emergency Call is OFF：Long press Call this key. It will prompt out a message Reopened? Then press answer key to set it on.

  • Page 15: Make An International Call

    at phone back side. It will prompt a message on phone screen: Reopened? Then you can press answer key to set it on. 3. When emergency call is set ON: phone will send a message to set emergency numbers and then call those numbers one by one if you already set the emergency call number.

  • Page 16: Dial Extension No. Of A Fixed Line

    Dial extension No. of a Fixed line Some extension numbers of fixed line couldn’t be dialed directly. You need to dial telephone exchange first and then dial the extension number. Type in a P symbol between telephone exchange number and extension number, this phone will dial the extension number automatically.

  • Page 17: Adjust Volume

    to enter menu and select [Make session]. Conference Call: Method（two sides are incoming calls） ： 1. Pick up first call 2. Pick up second call：When the second call is coming, it will show the message of this incoming call (phone will hold current call automatically).

  • Page 18: Read And Reply Sms

    Send message(to one person)：Press answer key to enter [option] send. Then you can press answer key to enter number typing in page to type in the number or you can press answer key to choose number from phonebook (press navigation up and down key to search contacts and press answer key to get it).

  • Page 19: Voice Mail

    Voice mail Voice box is a kind of network service， you must apply for the service before using it. If you want to get more information about your voice box, please consult your network service operator. You can dial voice box by long pressing 1 (if it is set as voice box number in advance).

  • Page 20: Copy Contact

    If you want to delete the contact information in phone or SIM card, you can select menu [Contact] [Delete contact] delete or delete all. If you select delete all, then you need to choose whether delete from SIM card or cell phone. You can also enter phone book and press answer key to go to option delete contact to delete the record one by one.

  • Page 21: Dialed Call

    delete records, Indicate number and save number which you select. Dialed call Show recent 20 dialed numbers. Please refer to the operation of received call. Missed call Show recent 20 missed numbers. Please refer to the operation of received call. Delete all records Delete all history of dialed call, missed call and received call.

  • Page 22: Network Setting

    You can adjust the brightness of the screen according your demands. Press navigation key up, you can get high contrast while down for low contrast. Language: Select language for phone. Date&Time setting: you can set the time and date with this function, including setting date format.

  • Page 23: Pin

    A．Restricted outgoing calls: all of the outgoing call is forbidden (except emergency call) B．Restricted Incoming calls: all of the incoming call is forbidden Network select: you can set the mode of network searching of cell phone by this function: choose automatic search or manual search.

  • Page 24: Alarm

    Alarm The phone is with alarm clock function, you can set up alarm time and alarm ring tone according to your requirement. (Settings Settings Ring tone type Alarm ring). 1. Enter into the alarm clock setup interface. The cursor has been set to stay over the area for time on hour.

  • Page 25: English Letters Input Method

    radio page. Press end key (red key) to continue. 5. Long press # key to lock keypad and press it again to unlock. 6. Volume adjust: when listening, press volume key “+,-” to adjust radio volume. 7. Plug in earphone. Then long press volume + key to listen to FM from outside, Long press volume - key to listen from earphone.
  • Page 26 battery and allow the device to dry completely before replacing the battery in it. Do not use or store the device in dusty, dirty areas. Its moving parts and electronic components can be damaged. Do not store the device in hot areas. High temperatures can shorten the life of electronic devices, damage batteries, and warp or melt certain plastic parts.
  • Page 27 the air bag or in the air bag deployment area. If in-vehicle wireless equipment is improperly installed and the air bag inflates, serious injury could result. Wireless phones can cause interference. Using them in aircraft is both illegal and dangerous.。 Potentially Explosive Atmospheres Switch off your phone when in any area with a potentially explosive atmosphere and obey all signs and instructions.
  • Page 28 The exposure standard for mobile devices employs a unit of measurement known as the Specific Absorption Rate, or SAR. The SAR limit stated in the international guidelines is 2.0 watts/kilogram (W/kg)*. Tests for SAR are conducted using standard operating positions with the device transmitting at its highest certified well below the maximum value.
  • Page 29 Additional information is available at the technical department of your city. ALL RIGHTS RESERVED DENVER ELECTRONICS A/S WWW.DENVER-ELECTRONICS.COM Importer: DENVER ELECTRONICS A/S...
  • Page 30 Stavneagervej 22 DK-8250 EGAA DENMARK...
