Daewoo DV6T712D Service Manual page 47

ELECTRICAL PARTSLIST
LOC PARTS_CODE PARTS_NAME
IC141 1LC74793 IC VPS
IC251 1TDA9605H- IC HI-FI
IC252 1CD4052BCM IC CHIP SW
IC253 1CD4053BCM IC CHIP SW
IC255 1CD4053BCM IC CHIP SW
IC301 1LA71750M- IC A/V 1 CHIP
IC302 1CD4051BCD IC CHIP SW
IC303 1MM1510XNB IC CHIP AMP
IC361 1LA70100M- IC SECAM-L
IC601 168KT872TS IC MICOM
IC604 1BA7046F IC SYNC SRPA
ICD02 1DM74LS04M IC INVERT
ICD03 1NJM4580MC IC CHIP AMP
L163 HLX1210001 BEAD CHIP
L164 HLX1210001 BEAD CHIP
L211 HLX1210001 BEAD CHIP
L212 HLX1210001 BEAD CHIP
L213 HLX1210001 BEAD CHIP
Q151 T2SA1037KB TR CHIP
Q152 T2SA1037KB TR CHIP
Q153 T2SA1037KB TR CHIP
Q156 T2SA1037KB TR CHIP
Q157 T2SA1037KB TR CHIP
Q165 T2SC2412KB TR CHIP
Q252 T2SC2412KB TR CHIP
Q312 T2SC2412KB TR CHIP
Q904 T2SA1037KB TR CHIP
Q906 T2SC2412KB TR CHIP
R103 HRFS102JBA R CHIP
R105 HRFS201JBA R CHIP
R106 HRFS201JBA R CHIP
R109 HRFS102JBA R CHIP
R110 HRFS103JBA R CHIP
R113 HRFS102JBA R CHIP
R121 HRFS751JBA R CHIP
R122 HRFS751JBA R CHIP
R124 HRFS562JBA R CHIP
R125 HRFS562JBA R CHIP
R126 HRFS103JBA R CHIP
R127 HRFS102JBA R CHIP
R128 HRFS101JBA R CHIP
R129 HRFS101JBA R CHIP
R141 HRFS103JBA R CHIP
R142 HRFS562JBA R CHIP
R144 HRFS272JBA R CHIP
R148 HRFS103JBA R CHIP
R149 HRFS153JBA R CHIP
R176 HRFS750JBA R CHIP
R177 HRFS750JBA R CHIP
R178 HRFS273JBA R CHIP
R181 HRFS221JBA R CHIP
R188 HRFS750JBA R CHIP
R191 HRFS750JBA R CHIP
R201 HRFS822JBA R CHIP
R202 HRFS113JBA R CHIP
PARTS_DESCR REMARK
LC74793JM HI-FI
TDA9605H HI-FI
CD4052BCM
CD4053BCM
CD4053BCM MONO
LA71750M
CD4051BCM
MM1510XNRE SOT-26A
LA70100M SECAM
M37762MCA-1E4GP
BA7046F
DM74LS04MX
NJM4580M
TB201209Z121
TB201209Z121
TB201209Z121
TB201209Z121
TB201209Z121
2SA1037AKT146-R
2SA1037AKT146-R
2SA1037AKT146-R
2SA1037AKT146-R
2SA1037AKT146-R
2SC2412K-T146-BR
2SC2412K-T146-BR PAL
2SC2412K-T146-BR
2SA1037AKT146-R
2SC2412K-T146-BR
1/16 1K OHM J 1608
1/16 200 OHM J 1608
1/16 200 OHM J 1608
1/16 1K OHM J 1608
1/16 10K OHM J 1608
1/16 1K OHM J 1608
1/16 750 OHM J 1608 PAL
1/16 750 OHM J 1608 PAL
1/16 5.6K OHM J 1608 HI-FI
1/16 5.6K OHM J 1608 HI-FI
1/16 10K OHM J 1608
1/16 1K OHM J 1608
1/16 100 OHM J 1608 SECAM HI-FI
1/16 100 OHM J 1608 SECAM HI-FI
1/16 10K OHM J 1608 HI-FI
1/16 5.6K OHM J 1608 HI-FI
1/16 2.7K OHM J 1608 HI-FI
1/16 10K OHM J 1608
1/16 15K OHM J 1608
1/16 75 OHM J 1608
1/16 75 OHM J 1608
1/16 27K OHM J 1608
1/16 220 OHM J 1608
1/16 75 OHM J 1608
1/16 75 OHM J 1608
1/16 8.2K OHM J 1608
1/16 11K OHM J 1608
LOC PARTS_CODE PARTS_NAME
R203 HRFS334JBA R CHIP
R204 HRFS201JBA R CHIP
R205 HRFS303JBA R CHIP
R212 HRFS512JBA R CHIP
R213 HRFS473JBA R CHIP
R217 HRFS103JBA R CHIP
R221 HRFS123JBA R CHIP
R223 HRFS103JBA R CHIP
R224 HRFS101JBA R CHIP
R226 HRFS181JBA R CHIP
R242 HRFS512JBA R CHIP
R244 HRFS512JBA R CHIP
R257 HRFS680JBA R CHIP
R259 HRFS242JBA R CHIP
R260 HRFS242JBA R CHIP
R263 HRFS242JBA R CHIP
R264 HRFS242JBA R CHIP
R265 HRFS333JBA R CHIP
R266 HRFS272JBA R CHIP
R267 HRFS393JBA R CHIP
R268 HRFS272JBA R CHIP
R269 HRFS333JBA R CHIP
R272 HRFS103JBA R CHIP
R273 HRFS511JBA R CHIP
R274 HRFS511JBA R CHIP
R277 HRFS133JBA R CHIP
R278 HRFS153JBA R CHIP
R279 HRFS133JBA R CHIP
R280 HRFS153JBA R CHIP
R281 HRFS225JBA R CHIP
R282 HRFS225JBA R CHIP
R301 HRFS122JBA R CHIP
R302 HRFS822JBA R CHIP
R304 HRFS202JBA R CHIP
R307 HRFS392JBA R CHIP
R312 HRFS221JBA R CHIP
R328 HRFS682JBA R CHIP
R330 HRFS472JBA R CHIP
R335 HRFS393JBA R CHIP
R337 HRFS103JBA R CHIP
R338 HRFS753JBA R CHIP
R340 HRFS222JBA R CHIP
R342 HRFS102JBA R CHIP
R345 HRFS203JBA R CHIP
R346 HRFS203JBA R CHIP
R348 HRFS102JBA R CHIP
R350 HRFS102JBA R CHIP
R353 HRFS202JBA R CHIP
R354 HRFS222JBA R CHIP
R361 HRFS103JBA R CHIP
R362 HRFS103JBA R CHIP
R363 HRFS102JBA R CHIP
R372 HRFS154JBA R CHIP
R374 HRFS431JBA R CHIP
R376 HRFS000-BA R CHIP
46
PARTS_DESCR REMARK
1/16 330K OHM J 1608
1/16 200 OHM J 1608
1/16 30K OHM J 1608
1/16 5.1K OHM J 1608
1/16 47K OHM J 1608
1/16 10K OHM J 1608
1/16 12K OHM J 1608
1/16 10K OHM J 1608
1/16 100 OHM J 1608
1/16 180 OHM J 1608
1/16 5.1K OHM J 1608 MONO
1/16 5.1K OHM J 1608 MONO
1/16 68 OHM J 1608
1/16 2.4K OHM J 1608 HI-FI
1/16 2.4K OHM J 1608 HI-FI
1/16 2.4K OHM J 1608 HI-FI
1/16 2.4K OHM J 1608 HI-FI
1/16 33K OHM J 1608 HI-FI
1/16 2.7K OHM J 1608 HI-FI
1/16 39K OHM J 1608 HI-FI
1/16 2.7K OHM J 1608 HI-FI
1/16 33K OHM J 1608 HI-FI
1/16 10K OHM J 1608 HI-FI
1/16 510 OHM J 1608 HI-FI
1/16 510 OHM J 1608
1/16 13K OHM J 1608 PAL
1/16 15K OHM J 1608 PAL
1/16 13K OHM J 1608 PAL
1/16 15K OHM J 1608 PAL
1/16 2.2M OHM J 1608 PAL
1/16 2.2M OHM J 1608 PAL
1/16 1.2K OHM J 1608
1/16 8.2K OHM J 1608
1/16 2K OHM J 1608 SECAM
1/16 3.9K OHM J 1608
1/16 220 OHM J 1608
1/16 6.8K OHM J 1608
1/16 4.7K OHM J 1608
1/16 39K OHM J 1608
1/16 10K OHM J 1608
1/16 75K OHM J 1608
1/16 2.2K OHM J 1608
1/16 1K OHM J 1608
1/16 20K OHM J 1608
1/16 20K OHM J 1608
1/16 1K OHM J 1608
1/16 1K OHM J 1608
1/16 2K OHM J 1608
1/16 2.2K OHM J 1608
1/16 10K OHM J 1608 SECAM
1/16 10K OHM J 1608 SECAM
1/16 1K OHM J 1608 SECAM
1/16 150K OHM J 1608 SECAM
1/16 430 OHM J 1608
1/16 0 OHM 1608
