Summary of Contents for Daewoo DV-600
-
Page 1: Dvd Player
DVD PLAYER INSTRUCTION MANUAL DV-600 HELPLINE NUMBER 0870 100 2525... -
Page 2: Table Of Contents
TABLE OF CONTENTS IMPORTANT SAFETY PRECAUTIONS ... 2 FEATURES ... 5 ABOUT DISC ... 6 BEFORE OPERATION... 8 PREPARATIONS BEFORE OPERATION. 10 Front Panel ... 10 Rear Panel ... 11 VFD... 12 Names and Layout of Remote Controls ... 13 CONNECTIONS ... -
Page 3: Important Safety Precautions
IMPORTANT SAFETY PRECAUTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER- SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. WARNING : TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE. - Page 4 This set has been designed and manufactured to assure personal safety. Improper use can result in electric shock or fire hazard. The safeguards incorporated in this unit will protect you if you observe the following procedures for installation, use and servicing. This unit is fully transistorized and does not contain any parts that can be repaired by the user.
- Page 5 IMPORTANT SAFETY PRECAUTIONS 14 DISC TRAY Keep your fingers well clear of the disc as it is closing. It may cause serious personal injury. 15 OVERLOADING Do not overload wall outlets or extension cords as this can result in a risk of fire or electric shock. 16 OBJECT AND LIQUID ENTRY Never push objects of any kind into this unit through openings as they may touch dangerous voltage points or...
-
Page 6: Features
FEATURES OUTSTANDING SOUND QUALITY Dolby Digital system developed by Dolby Laboratories and DTS developed by DTS Inc., features high quality surround sound which can be played in DVD or CD disc at home, to reproduce high quality sound effects. HIGH DEFINITION The unit adopts MPEG2 coding format and brings the high horizontal resolution. -
Page 7: About Disc
ABOUT DISC PRINCIPLES FOR WRITING This manual mainly introduces how to use buttons on the remote control. You may operate the unit if the buttons on the unit have the same or similar names as or to those on the remote control. PLAYABLE DISCS •... - Page 8 TRACK In a CD, each track has a number to enable search functions. SCENE The menu pictures, motion and motionless pictures of a CD can be divided into some parts, these parts are scenes. Each scene has a number for search. REGION MANAGEMENT INFORMATION This unit is designed and manufactured to respond to the Region Management information that is recorded on a DVD disc.
-
Page 9: Before Operation
BEFORE OPERATION SECURITY • Before operation, check if the voltage of the unit is in line with the local voltage. • Hold the plug to disconnect it from the mains outlet. Do not pull the power cord. • When the plug of the unit is connected to the mains outlet , the unit will be still connected to AC even if the power is turned off. -
Page 10: Check Accessories
CHECK ACCESSORIES Check if you have all the accessories after the carton is opened. Remote control AAA batteries Video/Audio cord Instruction manual USE REMOTE CONTROL Check if you have all the accessories after the carton is opened. 1 Open the battery compartment. 2 Insert two AAA batteries, make sure to match "+"... -
Page 11: Preparations Before Operation
PREPARATIONS BEFORE OPERATION FRONT PANEL ! STANDBY/ON button To switch the unit On or Off when connected to AC power outlet @ OPEN/CLOSE button To open or close the disc tray. # PLAY button To play the loaded disc. Press this button to go to the preferred item when the menu is displayed on the TV screen. -
Page 12: Rear Panel
REAR PANEL & ! AUDIO OUT (L/R TRACK) Two phono sockets for analogue 2 Channel audio in order to a TV or stereo amplifier. @ VIDEO OUT Connects composite video signal to input AV or PHONO sockets of TV or monitor to achieve high fidelity colour reproduction. -
Page 13: Vfd
PREPARATIONS BEFORE OPERATION ! Recognized DISC TYPE indicator : DVD @ Recognized DISC TYPE indicator : HDCD # PBC indicator This indicator is lit up in selecting PBC ON while this indicator disappears in selecting PBC OFF. $ DVD/CD indicator Indicates the chapter or track number. -
Page 14: Names And Layout Of Remote Controls
NAMES AND LAYOUT OF REMOTE CONTROLS * After setting the mode by using SETUP menu (for example, PAL select in NTSC/PAL/AUTO setup), the setting is kept though you switch the unit off and turn it on. MUTE BUTTON POWER BUTTON SETUP BUTTON ANGLE BUTTON TITLE/PBC BUTTON... -
Page 15: Connections
CONNECTIONS Turn off all equipment before operation. The unit has many kinds of output modes like A/V output, S-VIDEO output and digital signal output (COAXIAL, OPTICAL). You may select as you need. CONNECTED TO A TV AND AN ORDINARY AMPLIFIER Connects either !, @+ Manufactured under license from Dolby Laboratories. -
Page 16: Basic Operations
• Each amplifier is different from another, please cancelled if you refer to the manual for the amplifier. (e.g., do not connect the audio output of the DVD player to connect it to the the DVD audio input of an amplifier.) amplifier. -
Page 17: System Setting
BASIC OPERATIONS SYSTEM SETTING According to the system of the TV to be connected, set the system of the unit to make it match the TV. Push SYSTEM button on the remote control, then choose TV TYPE. • When you press the [SYSTEM] button, the TV screen shows the information as : “If you want to change, press [SYSTEM] again.”... -
Page 18: Fast Play
FAST PLAY When playing disc, you may play it forward fast or reverse it fast to find what you need. N ote: Push √ √ to play forward fast. Each time Push PLAY to play you push the button, the speed of picture normally when changes like those shown on the right. -
Page 19: Select Audio Language
BASIC OPERATIONS SELECT AUDIO LANGUAGE You can choose the language according to your choice when playing a multi- language DVD. Press “AUDIO” button, select different languages. AUDIO *Attention: Please select the AUDIO language in SETUP menu to keep the setting!!! SELECT CHANNELS (CD, MP3) You may select the right channel or left channel or stereo from a multi-channel. -
Page 20: Microphone Control
Select either the Left, Right, Mixed or Stereo mode, using channel button on the remote control. Adjust to a comfortable volume using the volume (+/-) button on the remote control of the DVD player and the volume on the Monitor/TV. -
Page 21: Tone Control
MICROPHONE CONTROL TONE CONTROL You may change the pitch to adapt to your voice • Push to raise the pitch. Each time you push the button, the pitch is raised by one step. It can be raised by 7 steps at the most. •... -
Page 22: Playing A Desired Scene
PLAYING A DESIRED SCENE TO SKIP SCENES IN A DISC Push √ √ to move to the next chapter (or track). The current chapter (or track) moves to the next chapter (or track). Push œ œ to move to previous chapter (or track). The current chapter (or track) moves to the previous chapter (or track) or first scene of current chapter (or track). -
Page 23: Playing A Disc Containing Mp3 Files
PLAYING A DESIRED SCENE PLAYING A DISC CONTAINING MP3 FILES When a MP3 disc is loaded, the MP3 menu screen is displayed automatically depending on MP3 disc’s folder structure. Use the direction button to select the folder you want to play, by pressing the [PLAY] button. -
Page 24: Repeating A Defined Period From A To B
REPEATING A DEFINED PERIOD FROM A TO B You may press the A-B to enjoy some parts repeatedly when playing a disc. N ote: 1. Press “A-B” to set a starting point A. A MP3 disc may 2. Press “A-B” twice for an end point B. not be repeated Afterwards, the unit plays from A to B. -
Page 25: Searching
PLAYING A DESIRED SCENE SEARCHING SEARCHING DVD WITH A TITLE/CHAPTER NUMBER OR A TIME You may directly enter a title or chapter number to search fast on a disc. The unit plays from the point. 1 If you want to search with a chapter or a title number, press the [SEARCH] button. -
Page 26: Play Discs In Various Ways
PLAY DISCS IN VARIOUS WAYS SELECT ANGLE N ote: Some discs have images with different screen angles, you may select among them. For example, when you watch a running train, you may select to watch it from the Multi Angle front, the left window or the right window without stopping it. -
Page 27: Program Play (Dvd)
PLAY DISCS IN VARIOUS WAYS PROGRAM PLAY (DVD) You may program the title and chapter on a disc and play them in the programmed order. Push the "PROGRAM" button, the screen shows: PROGRAM N ote: Input the sequence number you want to program playing. -
Page 28: Digest Play (Dvd)
DIGEST PLAY (DVD) Press the "INTRO" button when the unit is playing a disc, the screen shows : Press the direction button to select the digest type. And press the “PLAY” button. N ote: • TITLE DIGEST The player will play about 5 seconds of each title. After moving the cursor in the position “--”, press NUMBER button to select the title and press the PLAY button. -
Page 29: Play Mp3 Or Jpeg
PLAY DISCS IN VARIOUS WAYS PLAY MP3 OR JPEG SELECT TRACKS The screen will display as right after the disc is loaded Each time you press the PROGRAM button, FOLDER and FILE LIST appear one by one. At this time you can select the item in the list. You can select the file you want using the direction buttons. -
Page 30: Function Setting
FUNCTION SETTING MENU SETTING According to the recorded information and external equipment, set the following functions for DVD to obtain the best playing status. Push "SETUP" button to set the main menu. BASIC NAVIGATION Navigate through the setting on the screen, use the direction buttons to scroll through the list of settings and use the “PLAY”... -
Page 31: General Setup
FUNCTION SETTING GENERAL SETUP TV TYPE You may select according to the colour system of the TV to be connected. • Select "PAL" for a PAL TV. • Select "AUTO" for a multi-system TV. • Select "NTSC" for a NTSC TV. TV DISPLAY NORMAL/PS This is selected when the unit is connected... -
Page 32: Dolby Digital Setup
Dolby Digital, DTS and MPEG DVD is played, the optical or coaxial port will output in PCM 2-channel format. • PCM Select this when the DVD player is connected with a TV or a power amplifier through an audio cord. CAPTIONS The hidden subtitle is shown or turned off. -
Page 33: Preference Setup
FUNCTION SETTING PREFERENCE SETUP AUDIO Selecting an audio language. Set it as the preferred audio language. Where the audio language is set and recorded in the DISC, it is automatically played in the set language on every playing. For example, If English is set and recorded as the audio language in the DISC, it is played in English. -
Page 34: Others
OTHERS TROUBLESHOOTING If you experience the following problems while using the unit, this troubleshooting guide can help you. • NO SOUND - Check if the unit is connected securely. - Make sure you operate the TV or amplifier correctly. • NO IMAGE , IMAGE ROLLS AND NO COLOUR - Check if the unit is connected securely. -
Page 35: Technical Specifications
OTHERS TECHNICAL SPECIFICATIONS Laser Video Frequency response Signal/noise ratio Channel separation Dynamic range Analog Output Digital Audio Composite Output Video S-video Power supply Power consumption Dimensions (W x H x D) Weight (Gross/ Net) Notes : Design and specifications in this owner’s manual are subjected to change without prior notice to improve quality and function. - Page 36 CONNECTING YOUR PLAYER REAR PANEL VIDEO/AUDIO CORD & SCART LEAD CONNECT VIDEO/AUDIO CORD AS SHOWN CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK. DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PRESONNEL.
- Page 37 DAEWOO HELPLINE 0870 100 2525...
