EEMAX
PROADVANTAGE
ELECTRIC INSTANTANEOUS WATER HEATER
INSTALLATION GUIDE AND OWNERS MANUAL
MODELS COVERED
Triple Module Models PA018208T2T,
PA024208T2T, PA018277T2T, PA024277T2T,
PA032277T2T Single Phase Model PA028240T2T
WARNING
BEFORE ATTEMPTING INSTALLATION OF THIS UNIT OR MAKING ANY ADJUSTMENTS
TO THE UNIT ALWAYS BE SURE MAIN CIRCUIT BREAKER IS OFF TO PREVENT DANGER
OF SERIOUS ELECTRIC SHOCK.
INSTALLER/ CONSUMER RESPONSIBILITIES
PLEASE TAKE THE TIME TO READ NOT ONLY THIS MANUAL BUT ALSO THE
WARRANTY CARD ENCLOSED. WARRANTY OF THIS HEATER WILL DEPEND ON PROPER
INSTALLATION AND OPERATION. THE WARRANTY SHALL BE VOID IF THE DESIGN OR
STRUCTURE OF THE WATER HEATER HAS BEEN ALTERED IN ANY WAY WHATSOEVER. THE
MANUFACTURER OF THIS WATER HEATER WILL NOT BE LIABLE FOR ANY DAMAGES
BECAUSE OF FAILURE TO COMPLY WITH THE INSTALLATION AND OPERATING
INSTRUCTIONS OUTLINED ON THE FOLLOWING PAGES.
IF YOU REQUIRE ANY HELP OR HAVE ANY QUESTIONS RELATING TO THE
INSTALLATION OR PERFORMANCE OF THIS HEATER, PLEASE CALL OUR TECHNICAL
SERVICE DEPARTMENT TOLL-FREE:
1-800-543-6163
HAVE THE INFORMATION LISTED BELOW BEFORE CALLING
MODEL :
ELEMENT RESISTANCE:
OHMS
SERIAL NO :
SWITCH ON FLOW RATE:
GPM
OPERATING TEMPERATURE
INSTALLATION DATE :
MIN
MAX
Advertisement
Table of Contents
Related Manuals for EemaX PA018208T2T
Summary of Contents for EemaX PA018208T2T
- Page 1 EEMAX PROADVANTAGE ELECTRIC INSTANTANEOUS WATER HEATER INSTALLATION GUIDE AND OWNERS MANUAL MODELS COVERED Triple Module Models PA018208T2T, PA024208T2T, PA018277T2T, PA024277T2T, PA032277T2T Single Phase Model PA028240T2T WARNING BEFORE ATTEMPTING INSTALLATION OF THIS UNIT OR MAKING ANY ADJUSTMENTS TO THE UNIT ALWAYS BE SURE MAIN CIRCUIT BREAKER IS OFF TO PREVENT DANGER OF SERIOUS ELECTRIC SHOCK.
-
Page 2: General Safety
GENERAL SAFETY The “Eemax ProAdvantage” heater is specifically designed to take in hot or cold water and heat it to temperatures suitable for normal domestic usage up to a maximum of 140 F(60 C). To obtain optimum performance and energy savings, the unit should be located as near as possible to the point of use. -
Page 3: Mounting The Unit
Kitchen 277 - * 3Φ 277/480V - Series 3 Requirements Max Output: 18.0 kW @ 208 volts 24.0 kW @ 208 volts Eemax 18.0 kW @ 277 volts 24.0 kW @ 277 volts 32.0 kW @ 277 volts Hot outlet Cold inlet 28.0 kW @ 240 volts... - Page 5 Replacement Elements PA018208T2T- EX720 PA024208T2T- EX560 PA018277T2T- EX1280 PA024277T2T- EX960 PA032277T2T- EX720 PA028240T2T- EX630 TRIAC PART# EX18 PART# EX256 208V PART# EX257B 277V PART# EX255B 240V DISPLAY BOARD CONTROL BOARD PART# EX309-240V PART# EX284E-309-240V 208/240V 208/240V PART# EX309-277V PART# EX309-284-277V...
-
Page 6: Plumbing Hook-Up
II. PLUMBING HOOK-UP 1) The unit is supplied with ¾’’ NPT fittings (Figure 3), USE THESE. DO NOT USE PIPE DOPE AND DO NOT SOLDER TO THE INLET OR OUTLET. 2) Take care to ensure that the pipes are correctly aligned with the inlet and outlet bosses in order to avoid excessive stress on the heater body molding. -
Page 7: Electrical Hook-Up
III. ELECTRICAL HOOK-UP WARNING THIS UNIT HAS MULTIPLE POWER SUPPLIES. ENSURE TO DISCONNECT ALL POWER SUPPLIES BEFORE SERVICING THE WATER HEATER. “Eemax ProAdvantage” heaters are manufactured to the following specifications: Figure 4 MODEL TYPE Voltage kW output AMPERAGE PA 018208T2T... - Page 8 IV COMMISSIONING YOUR HEATER IMPORTANT BEFORE SWITCHING “ON” THE POWER AT THE MAIN CIRCUIT BREAKER PANEL MAKE SURE THAT THE HOT WATER CIRCUIT IS FREE OF AIR POCKETS OR ELSE PREMATURE FAILURE OF THE ELEMENT WILL OCCUR. TO DO THIS OPEN ALL HOT WATER OUTLETS ONE AT A TIME FOR A MINUTE OR TWO UNTIL THE WATER FLOW IS CONTINUOUS AND FREE FROM “GULPING”...
-
Page 9: Troubleshooting
The resistance reading should be roughly 6.0 ohms. If the resistance is much greater than this value, call Eemax for a replacement element. 5) ECO TRIPPED (High Limit Thermostat) TURN OFF THE FOUR MAIN CIRCUIT BREAKERS! Reset by pushing in red button on each heater module.
