8. When a dual view head is being used, please note that one side has a
"straight" eyetube and the other has a "diopter adjustable" eyetube
on the other. Focus the specimen using the straight eyetube first,
then focus the other eyetube by adjusting the diopter ring to obtain
the clearest image.
It is desirable to use immersion oil with the 100XRD objective. Using oil
slightly increases the resolution and brightness of the image being
viewed through the microscope. Drop a tiny amount of oil onto the slide
prior to focusing with the 100XRD objective (between the slide and the
objective tip). It is essential to thoroughly clean the objective tip after
use. Please contact Swift Optical or your authorized Swift dealer for the
appropriate immersion oil to use.
IMPORTANT: The focal distance of the 40XRD and 100XRD objectives
to the slide surface is very close and although the 40XRD objective on
the M7000 Series is sealed to prevent immersion oil contamination, it
is a good practice to avoid dragging the 40XRD objective through an
oiled slide.
OCULAR HEAD REPLACEMENTS
MA11002 Monocular
MA11003 Binocular
MA11004 Trinocular
MA11013 Dual-view
EYEPIECE REPLACEMENTS
MA10512 W10XD, 18mm Eyepiece (single)
MA10513 W10XD, 18mm Eyepiece with pointer (single)

OIL IMMERSION

PARTS AND ACCESSORIES

8
