  • Page 1 INSTALLATION AND OPERATION MANUAL System air conditioner FXSQ20M7V1B FXSQ25M7V1B FXSQ32M7V1B FXSQ40M7V1B FXSQ50M7V1B FXSQ63M7V1B FXSQ80M7V1B FXSQ100M7V1B FXSQ125M7V1B...
  • Page 2 ≥300 ≤45 1 - 1.5m...
  • Page 3 Control box IN/D OUT/D Control box IN/D OUT/D Control box IN/D OUT/D Control box OUT/D IN/D FORCED SETTING...
  • Page 4 fiˆ˜ ÚÔÛ‰ÈÔÚ›˙ÂÙ·È ÛÙÔ ∞Ú¯Â›Ô ∆¯ÓÈ΋˜ ∫·Ù·Û΢‹˜ DAIKIN.TCF.022 Î·È ÎÚ›ÓÂÙ·È ıÂÙÈο ·fi ÙÔ TNO Û‡Ìʈӷ Ì ÙÔ ¶ÈÛÙÔÔÈËÙÈÎfi 0301130401 . Nota tal como estabelecido no Ficheiro Técnico de Construção DAIKIN.TCF.022 e com o parecer positivo de TNO de acordo com o Certificado 0301130401. Bemærk som anført i den Tekniske Konstruktionsfil DAIKIN.TCF.022 og positivt vurderet af TNO i henhold til Certifikat 0301130401.
  • Page 5: Table Of Contents

    ELECTRIC SHOCK, SHORT-CIRCUIT, LEAKS, FIRE OR Screws for duct flanges OTHER DAMAGE TO THE EQUIPMENT. BE SURE ONLY 1 set TO USE ACCESSORIES MADE BY DAIKIN WHICH ARE FXSQ20•25•32 6 pieces Screws for fixing SPECIFICALLY DESIGNED FOR USE WITH THE FXSQ40•50...
  • Page 6: Selecting Installation Site

    For the following items, take special care during Use suspension bolts for installation. Check whether the ceiling is strong enough to support the weight of the indoor unit. If there construction and check after installation is finished is a risk, reinforce the ceiling before installing the unit. Tick ✓...
  • Page 7: Indoor Unit Installation

    Consult the builder for filter. details. Attach the paper pattern for installation to the unit with the For other installation than standard installation, contact your Daikin attached screws as shown in figure dealer for details.
  • Page 8: Drain Piping Work

    ■ Be sure to use both a spanner and torque wrench together when RAIN PIPING WORK connecting or disconnecting pipes to/from the unit. Rig the drain piping as shown in the figure and take measures Torque wrench against condensation. Improperly rigged piping could lead to leaks Spanner and eventually wet furniture and belongings.
  • Page 9: Electric Wiring Work

    LECTRIC WIRING WORK Caution for drain socket Do not remove the drain pipe plug. Water might leak out. General instructions The drain outlet is only used to discharge water if the drain pump is not used or before maintenance. Gently put in and ■...
  • Page 10: Wiring Example And How To Set The Remote Controller

    Setting of static pressure changeover connector IRING EXAMPLE AND HOW TO SET THE REMOTE CONTROLLER ■ According to the systems static pressure requirement, reposition the adaptors of the PC board inside the switch box as shown in the figure. How to connect wiring FXSQ20•32•40•50•63 FXSQ80•100•125 From the outside of the unit...
  • Page 11: Installation Of The Decoration Panel

    Second code No. NOTE It is not necessary to designate an indoor unit address when using group control. address Mode No. automatically set when the power is activated. First code No. Field set mode PRECAUTIONS ■ A single switch can be used to supply power to units on the Centralized control same system.
  • Page 12: Maintenance

    AINTENANCE bottom suction Caution ■ Only a qualified service person is allowed to perform maintenance. ■ Before obtaining access to terminal devices, all power supply circuits must be interrupted. ■ Do not use water or air of 50°C or higher for cleaning air filters and outside panels.
  • Page 13 How to clean air outlet and outside panels OTES ■ Clean with soft cloth. ■ When it is difficult to remove stains, use water of neutral detergent. ■ Clean the air inlet grille when it is shut. NOTE Do not use gasoline, benzene, thinner, polishing powder, liquid insecticide.
  • Page 14: Wiring Diagram

    IRING DIAGRAM : FIELD WIRING : BLACK : TERMINAL : BLUE : CONNECTOR : ORANGE : WIRE CLAMP : PINK : PROTECTIVE EARTH (SCREW) : RED : WHITE : YELLOW 33H......FLOAT SWITCH A1P ......PRINTED CIRCUIT BOARD A2P ......TERMINAL BOARD C1R ......CAPACITOR (FAN) F1U ......FUSE (250 V/10 A) F2U ......FIELD FUSE HAP......LIGHT EMITTING DIODE (SERVICE MONITOR - GREEN)
  • Page 15 NOTES NOTES...
  • Page 16 Zandvoordestraat 300, B-8400 Oostende, Belgium 4PWEN15110-1...
