X150 | WiFi Pro-Action Camera
USER GUIDE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Kaiser Baas X150

Summary of Contents for Kaiser Baas X150

  • Page 1 X150 | WiFi Pro-Action Camera USER GUIDE...
  • Page 2 /kaiserbaas Share your footage with us on our social media Register this product for 12 month warranty and updates. www.kaiserbaas.com/updates Need help? www.kaiserbaas.com/support For the full Kaiser Baas accesories range visit www.kaiserbaas.com...

  • Page 3: Table Of Contents

    Table of Contents Safety Precautions What’s in the Box Product Diagram Wrist Remote Diagram Set Up Your X150 Camera Installing the X150 into the Waterproof Case Using Your X150 Camera Video Mode Video Settings General Settings Slo-mo Mode Picture Mode...
  • Page 4 Using The Wrist Remote Saving And Viewing Options Specifications System requirements Contact Us...

  • Page 5: Safety Precautions

    Before using the X150 Camera please ensure you read and understand the safety precautions. • Do not attempt to open the case of the X150 or modify it in any way. If the X150 has been opened the warranty will be void. Maintenance and repairs should only be performed by Kaiser Baas.

  • Page 6: What's In The Box

    What’s in the Box Please ensure the product package has the following contents: Wrist Remote X150 Camera Waterproof Case 2 x 3M Adhesive Pads Micro USB Cable Quick Release Mount Screw Bolt Flat & Curved Base...

  • Page 7: Product Diagram

    Product Diagram WiFi Activation Button LED POWER Indicator LCD Screen Front Back...
  • Page 8 SHOOT(menu select) Micro SD Card Port Microphone Mini HDMI Interface POWER (and menu) Battery Micro USB Interface POWER SHOOT Left Side Right Side...

  • Page 9: Wrist Remote Diagram

    Wrist Remote Diagram NOTE: The Wrist Remote cannot turn the X150 on. Please ensure the remote is paired with the X150 before use. Please see instruction Using the Wrist Remote LED Indicators SHOOT Photo RECORD Video POWER Off - HOLD for 5...

  • Page 10: Set Up Your X150 Camera

    Set Up Your X150 Camera Turn the X150 on – press and HOLD the POWER button for a few seconds. When the X150 is on the Kaiser Baas logo will appear on the screen and the Red LED lights will glow. The X150 is now in Video Mode.

  • Page 11: Installing The X150 Into The Waterproof Case

    Installing the X150 into the Waterproof Case The X150 is designed to be used in the waterproof case. TIPS: • Ensure the case is dry and clean • Insert the X150, ensuring the lens fits neatly into the lens cavity. Close the security latch.

  • Page 12: Using Your X150 Camera

    Connect the X150 to a computer (or other USB POWER source) using the USB cable provided, to charge. If the X150 is on when charging, 3 red lights will blink until the battery is fully charged. Only one red light will blink if the X150 is off when charging.
  • Page 13 2. Press and HOLD the SHOOT button for 3 seconds to enter the General Settings. 3. Use the WiFi button on the front of the X150 to navi- gate down the menu. The Format card option is on the thirdpage of the General Settings.
  • Page 14 Buttons and Navigation POWER Button In Video PRESS - Video Mode Settings Mode HOLD - Off In Picture PRESS - Picture Mode Settings Mode HOLD - Off Menus PRESS - Back HOLD - Off SHOOT Button In Video PRESS - Start/Stop recording Mode 1st HOLD - Swap to Slo-mo Mode 2nd HOLD - Swap to Picture Mode...

  • Page 15: Video Mode

    Once the X150 is turned on, Video Mode is selected by default. Press the SHOOT button to start recording. When the recording starts, you will see all three red lights on the X150 start flashing. To end recording, press the SHOOT button again.

  • Page 16: Video Settings

    NOTE: The Setup menu accessed will depend on the current mode of the X150. If the “Video Mode ” is active, it will display video capture settings or if the “Picture Mode” is active, it will display the Image capture settings.
  • Page 17 Video Looping This allows you to set the recording mode: OFF – In this mode the X150 will generate a new file every 30 minutes. These files will be saved into the Video Folder. NOTE: When the SD card is full, the X150 will stop recording if Video Looping is OFF.
  • Page 18 • 2 Min – In this mode, the X150 will generate a new file every 2 minutes. • 5 Min - In this mode, the X150 will generate a new file every • 10 Min - In this mode, the X150 will generate a new file every 10 minutes.

  • Page 19: General Settings

    General Settings General Settings Screen (Page 1) This allows you to adjust the general device settings for the X150. To access the General Settings, press the POWER button to access the Video or Picture Settings, then HOLD the SHOOT button to swap to the General Settings.
  • Page 20 rate shows a rapid change over time. This technique is most effective when recording scenes or objects which have a slow state of change, e.g. a sunset or a flower blossoming. NOTE: This feature is inactive when the resolution is set to 2.7K. KB TIP: You can also set the Time-lapse feature just to capture Photos to save as a sequence of image files.
  • Page 21 Select OFF to keep the LCD running continuously during use. Auto POWER Off This will set the X150 to automatically power off after 1 minute, 3 minutes or 5 minutes. Select OFF to keep the X150 on during periods of inactivity. Beep Turn the key tone ON or OFF.
  • Page 22 Screen Rotation Rotate the screen. System • Factory Reset - Resets the X150 to factory default settings. • System Info - Checks the firmware version. • Card Info - See the SD card status.
  • Page 23 WiFi Passsword This will allow you to change the WiFi password. Use the WiFi button to change the digits, HOLD the SHOOT button to jump to the next digit. When finished, press the SHOOT button to save & exit. General Settings Screen (Page 2) WiFi SSID (SSID - Service Set Identifier) This will allow you to change the last 3 digits of the SSID.

  • Page 24: Slo-Mo Mode

    Slo-mo Mode Slo-mo Mode Screen One of the great features of X150 is the ability to capture slow motion footage. NOTE: Slo-mo mode can only be activated at a video resolution of 1080P @ 60fps or 720P @ 120fps. To activate this mode: •...

  • Page 25: Picture Mode

    • Turn the X150 on. • Press and HOLD the SHOOT button for 3 seconds. • The X150 will enter into Slo-mo mode, press and HOLD the SHOOT button again. • You will see ( ) on top left corner of the screen.

  • Page 26: Picture Settings

    Picture Settings Picture Settings Screen To enter the Set-up menu for Picture Mode, ensure the X150 is set in Picture Mode and press the POWER button (press and release immediately – don’t forget, if it is held too long, the X150 will switch off).
  • Page 27 Metering Metering refers to the way in which a camera determines the exposure. White Balance The factory default is Auto. If you switch Auto OFF, remember to adjust when lighting conditions change. Picture Settings Screen 2 This is the measurement of how sensitive a camera sensor is to light.
  • Page 28 Exposure This allows you to set the light exposure value. Self-timer This allows you to set the timer for auto image capture. Date Stamp Off: Turn off the date stamp display on images. Date: Display the date stamp on images Date &...
  • Page 29 Playback Mode Playback Mode Screen Navigation: Use the WiFi button to navigate, SHOOT button to Enter/Confirm selection and the POWER button to go back. This will allow you to view captured videos & images. Enter the Picture Mode first, then press and HOLD the SHOOT button for 3 seconds.
  • Page 30 • Turn the X150 OFF. • Connect the Mini HDMI cable-end to the port on the X150 and the HDMI end to HDMI port on the TV. • Select the right source on the TV. • Turn the X150 ON.

  • Page 31: Wifi Setup

    Kaiser Baas X150 in the list of available Wireless Net- works. Connect your device to the Kaiser Baas X150 via WiFi The password will be displayed on the screen of the X150 once the WiFi is turned ON (e.g. 1234567890).
  • Page 32 Once your device is connected to the X150, launch the ‘Kaiser Baas X150’ app. Important: Make sure the app is downloaded on to your Smart Phone or Tablet before co nnecting it to the X150 via WiFi. App Interface Diagram...

  • Page 33: Using The Wrist Remote

    Using The Wrist Remote The water-resistant Wrist Remote connects wirelessly to your X150 and allows easy ‘hands-free’ operation, when the X150 is mounted in hard-to-reach places; your helmet, vehicle etc. Your X150 camera will already be paired with the wrist remote.
  • Page 34 KB TIP: You can check the battery status of the Wrist Remote by pressing Image Capture button (located between the LED lights and Red button) when the X150 is OFF. If the Wrist Remote has charge in it, the green light will flash.
  • Page 35 X150 is turned off. Solid Purple Light : This light will appear when the wrist remote is being charged whilst the X150 is turned on. You can still use the Wrist Remote when it is charging. Red : This indicates that the Wrist Remote is being charged or that the X150 is not be paired, nor in range.

  • Page 36: Saving And Viewing Options

    Saving And Viewing Options Transferring files to a PC Use the USB cable supplied to connect the X150 to your computer. Mass Storage Mode will appear on the X150 screen and the computer will detect the X150 as an external storage device.
  • Page 37 Using the X150 as a Webcam Connect the X150 to your PC using the Micro USB cable, when you see Mass Storage Mode on the X150 screen, press and HOLD the SHOOT button for 3 seconds. NOTE: You will not be able to record video or take...

  • Page 38: Faq

    (e.g. Time-lapse with 2.7K). Q. The volume is too low on my video recordings. Why? A. When the X150 is secured in a Waterproof case, it is normal to find a decrease in recording volume. Try using an...
  • Page 39 Q. The volume is too low on my video recordings. Why? A. When the X150 is secured in a Waterproof case, it is normal to find a decrease in recording volume. Try using an exoshell or skeleton case.

  • Page 40: Specifications

    Specifications Waterproof Down to 30m (with waterproof casing) Sensor 1/2.5" 8.0 megapixels CMOS sensor Resolution Video: 2.7K@15fps, 1440P@30fps, 1080P@60fps, 1080P@30fps, 720P@120fps,720P@60fps. Still photo: 12M(4032*3024), 8M(3264*2448), 5M(2592*1944), 3M(2048*1536) Storage type Micro SD card up to 32GB (not included) 150°- view fixed lens Lens aperture F/2.8 f=2.65mm Lens Focus...

  • Page 41: System Requirements

    Format Video: MOV H.264 Still photo: JPEG POWER supply 3.7V/1000mAh Li-Battery Battery life Video: 2 hours without WiFi Language English Dimensions 54x37x51mm Casing 49.5×76×84mm System requirements Operating system Windows XP / Vista / 7 / 8 / MAC OS App Requirements Apple iOS &...

  • Page 42: Contact Us

    Contact Us Need further assistance? Please visit: www.kaiserbaas.com/support Or email: helpdesk@kaiserbaas.com For the full Kaiser Baas accesories range visit www.kaiserbaas.com...
