- Page 1 X100 | Action Camera USER GUIDE...
- Page 2 /kaiserbaas Share your footage with us on our social media Register this product for 12 month warranty and updates. www.kaiserbaas.com/updates Need help? www.kaiserbaas.com/support For the full Kaiser Baas accesories range visit www.kaiserbaas.com...
-
Page 3: Table Of Contents
Table of Contents Safety Precautions What’s in the Box Product Diagram Remote Diagram Set Up Your X100 Video Mode Video Settings General Settings Picture Mode Using Your X100 Camera... - Page 4 Playback Mode Wi-Fi Setup Saving And Viewing Options Installing X100 Camera into waterproof case Specifications System Requirements Contact Us...
-
Page 5: Safety Precautions
If the X150 has been opened the warranty will be void. Maintenance and repairs should only be performed by Kaiser Baas. • Keep the X150 away from water and other liquids (unless housed in the waterproof case). Do not handle the X150 with wet hands (unless used in the waterproof case). -
Page 6: What's In The Box
What’s in the Box Please ensure the product package has the following contents: Flat Base X100 Camera Waterproof Case Curved Base Micro USB Cable 2 x 3Adhesive Pads Screw Bolt Wrist Remote control (not waterproof) Quick Release Mount... -
Page 7: Product Diagram
Product Diagram Wi-Fi Activation POWER (and button menu) LED power indicator USB interface LCD screen Micro SD card port SHOOT(menu select) Mini HDMI interface Microphone Battery Front Back... - Page 8 POWER SHOOT Left Side Right Side...
-
Page 9: Remote Diagram
Remote Diagram Please note: with the remote control you cannot turn the camera on. Please ensure the camera is switched on before using the remote. This item is not waterproof. LED Indicators SHOOT Photo RECORD Video POWER Off - HOLD for 5 seconds Micro USB Charging Port On the Back of Remote... -
Page 10: Set Up Your X100
Set Up Your X100 Turn the camera on – press and hold the POWER button for several seconds. When the camera is on the X100 logo will appear on the screen and the three red LED lights will glow red. The camera is now in video mode. -
Page 11: Video Mode
Video Mode 30fps 00:56:20 Video Mode Screen Once the camera is turned on, it goes to the video capture mode by default. Press SHOOT button to start recording. When the recording starts, you will see the red lights start flashing. To end recording, press the SHOOT button again. To enter the Settings menu, press the POWER button (press and release immediately –... -
Page 12: Video Settings
Video Settings Resolution Video Looping White Balance Microphone Timelapse+Video Enter Back SHOOT POWER Video Settings Screen (Page 1) This allows user to adjust Video quality settings. Navigation: Use Wi-Fi button to navigate, Shoot button to Enter/Confirm selection, Power button to go back Resolution This allows user to set the recording video resolution: •... - Page 13 This allows user to set recording duration: • OFF – In this mode, camera will generate new file on every 30 min • 2 Min – In this mode, camera will generate new file on every 2 min • 5 Min - In this mode, camera will generate new file on every 5 mins White Balance Factory default is Auto.
- Page 14 Date Stamp Enter Back SHOOT POWER Video Settings Screen (Page 2) Timelapse + Video This will enable auto image capture during the video recording: • Off – Disable Auto Image Capture • 10 Sec – Auto capture every 10 sec •...
-
Page 15: General Settings
Date Stamp • Off: to turn off displaying date stamp on captures • Date: to display date on captures • Date & Time: to display date & time on captures General Settings Auto Power O Auto LCD O Screen Rotation Date &... - Page 16 Navigation: Use Wi-Fi button to navigate, Shoot button to Enter/Confirm selection, Power button to go back Auto Power Off To set Auto Power off function Auto LCD Off This will determine if the LCD will turn off after 1min, 3min or 5min.
- Page 17 Light Frequency System Format Enter Back SHOOT POWER General Settings Screen (Page 2) Language To select the device language Light Frequency Selecting the correct light frequency will avoid the possibility for strobing*.
- Page 18 System • Factory Reset; To reset the camera to factory default. • System Info; To check the firmware version • Card Info; To see the SD card information WiFi Password Change the WiFi password. Default is 1234567890 WiFi SSID Change WiFi device name. Only the last 3 digits are available to change.
-
Page 19: Picture Mode
Picture Mode This mode will allow users to take snapshots 9999 Picture Mode Screen To activate this mode: Turn the camera on Press and hold the SHOOT button for 3 secs You will see P ( ) on top left corner of the screen Press SHOOT button to take snapshots... - Page 20 Picture Settings Resolution Quality Metering White Balance AUTO Enter Back SHOOT POWER Picture Settings Screen 1 To enter the SETUP menu for Picture Mode, press the POWER button (press and release immediately – if it is held too long the camera will switch off). Resolution To select the image resolution.
- Page 21 Metering Metering mode refers to the way in which a camera determines the exposure. White Balance Factory default is Auto. If you switch Auto OFF, remember to adjust when lighting conditions change Exposure Self Timer Date Stamp Timelapse Enter Back SHOOT POWER Picture Settings Screen 2...
- Page 22 Exposure This allows user to set the light exposure value Self-timer This allows user to set the timer for auto image capture Date & Time This allows user to adjust the date &time. Note: Use the Wi-Fi button to change the date and time, use shoot button to confirm.
-
Page 23: Using Your X100 Camera
Using Your X100 Camera Preparation Charging the battery Before using the X100 camera for the first time you should fully charge the battery. Procedure: Connect X100 camera to a computer (or other USB power source) using the USB cable (provided) A: If the Camera is on when charging, 3 red lights will blink until the battery is fully charged. - Page 24 Insert the Micro SD* • It is recommended to use Class 6 (or higher) TF card to shoot smooth video files. Lower class cards may cause the video to be blurry or jerky. • * Micro SD cards are also called TF cards. •...
- Page 25 Video Recording Once the camera is turned on, it goes to the video capture mode by default. Press the SHOOT button to start recording. When the recording starts, you will see the red lights start flashing. To end recording, press the SHOOT button again. Image Capturing To take a snapshot, you will need to switch the camera from video mode to image capture mode.
-
Page 26: Playback Mode
Playback Mode Navigation: Use Wi-Fi button to navigate, Shoot button to Enter/Confirm selection, Power button to go back This will allow you to watch the captured videos & images. Enter the Picture mode first , then press and hold the SHOOT button for 3 secs. - Page 27 Connecting to TV You can display the camera LCD screen on a TV Screen Note: You will need a Mini HDMI to HDMI cable • Turn the camera on • Connect Mini HDMI end to the port on the camera and HDMI end to HDMI port on the TV •...
-
Page 28: Wi-Fi Setup
Download the App onto your Smart Phone: www.kaiserbaas.com/apps/x100-app Kaiser Baas X100 Activate Wi-Fi on your X100 camera by pressing Wi-Fi button. Go to the Wi-Fi settings on your Phone, you will see Kaiser Baas X100 in the list of available Wireless networks (WIFI_CAM_000). - Page 29 Connect your Phone to the Kaiser Baas X100 via Wi-Fi The WiFi Password for the X100 is: 1234567890 Open the app ‘Kaiser Baas X100’ Important: Before connecting camera via Wi-Fi, you need to download the ‘Kaiser Baas X100’ app on your smartphone or tablet.
-
Page 30: Saving And Viewing Options
Saving And Viewing Options Transferring files to PC Use the USB cable supplied (C) to connect the camera to your computer. The camera LCD will display MSDC icon and your computer will see your camera as an external storage device. Alternatively you can remove the Micro SD card and use a card reader (not included) to achieve the same result. -
Page 31: Installing X100 Camera Into Waterproof Case
Installing X100 Camera into waterproof case The X100 camera is designed to be used in the water proof case (B). Before inserting the X100 camera in the case, select video or picture mode. Notes: • Ensure the case is dry and clean •... -
Page 32: Faq
Q. Why are the red LEDs flickering? A. The battery is running low. You must recharge the camera. Q. My X100 camera will NOT turn on. Why? A. The battery is flat. You need to recharge it (full recharge from flat will take about 5 hours). Q. -
Page 33: Specifications
Specifications Underwater Down to 30m (with waterproof casing) Sensor 1/2.5" 5.0 megapixels CMOS sensor Resolution Video: 1080P@30fps Still photo: 5 megapixel (12 megapixel interpolated) Storage type Micro SD card up to 32GB (not included) Lens 150°- view fixed lens Lens aperture F/2.5 f=2.65mm Lens Focus 0.5m to infinity... -
Page 34: System Requirements
Format Video: MOV H.264 Still photo: JPEG Power supply 3.7V/1000mAh Li-Battery Battery life Video: 2.5 hours without WiFi Language English Dimensions 54x37x51mm Casing 49.5×76×84mm System Requirements Operating Windows XP / Vista / 7 / 8 / MAC OS system Apple iOS & Android Requirements Interface HDMI (HDMI cable not included) -
Page 35: Contact Us
Contact Us Need further assistance? Please visit: www.kaiserbaas.com/support Or email: helpdesk@kaiserbaas.com For the full Kaiser Baas accessories range visit www.kaiserbaas.com...
