Page 2
WARNING • Dangerously high voltages are present inside the TV. • Operate the TV only between 110 V AC. For your own safety, do not touch any part of the For children’s safety, do not leave children TV, the power cord and the antenna cable during alone with the TV.
Table of Contents Using Your New TV Getting Started ..................... 4 Step 1 : Connect the antenna ..............4 Step 2 : Insert the batteries into the remote .......... 5 Step 3 : Preset the channels automatically ..........5 Connecting optional components ............. 6 Securing the TV ....................
Using Your New TV Using Your New TV Getting Started CAUTION • Do not connect the power cord until you have completed making all other connections; otherwise a minimum leakage current might flow through the antenna and other terminals to ground. •...
Notes • With the “VIDEO MULTI SYSTEM” input terminal, you can also receive PAL, NTSC and SECAM video signals when using VIDEO IN 1 or 2 jacks at the rear of your TV or the VIDEO 2 INPUT jacks at the front of your TV. •...
Connecting optional components You can connect optional audio/video components, such as a VCR, multi disc player, camcorder, video game or stereo system. To watch the video input of the connected equipment, press VIDEO (see page 12). Connecting a camcorder/video game equipment using the VIDEO 2 INPUT jacks Front of TV Audio/Video cable (not supplied)
Page 7
Connecting a DVD player using the COMPONENT VIDEO (DVD) IN jacks 1 Connect R and L under COMPONENT VIDEO (DVD) IN on your TV to the LINE OUT, AUDIO R and L output connectors on your DVD player. 2 Using a component video cable, connect Y, C , and C under COMPONENT VIDEO (DVD) IN on your TV to the COMPONENT VIDEO OUT Y, C...
Securing the TV To prevent the TV from falling, secure the TV using one of the following methods: With the supplied screws, attach the band to the TV stand and to the rear of the TV using the provided hole. Put the cord or chain through the clamps to secure the TV against a wall or pillar.
Presetting MUTING DISPLAY POWER channels VIDEO You can preset cable TV, VHF or UHF broadcast channels using the remote and the buttons on your TV as well. JUMP SOUND MODE FAVORITE SELECT WAKE UP PIC MODE SLEEP AUTO ADD/ CABLE PROGRAM ERASE AUTO...
Page 10
Presetting channels (continued) Number buttons JUMP SOUND MODE CH +/– FAVORITE SELECT WAKE UP PIC MODE SLEEP AUTO ADD/ CABLE PROGRAM ERASE ADD/ERASE Presetting the channels manually To receive a new channel or a channel with a weak signal, preset the channel manually.
Watching the TV MUTING DISPLAY MUTING DISPLAY POWER POWER This section explains functions used VIDEO VIDEO while watching the TV. Most operations can be done using the remote. Number buttons JUMP JUMP SOUND VOL +/– MODE CH +/– FAVORITE SELECT WAKE UP SELECT PIC MODE...
Page 12
Watching the TV (continued) Additional tasks Do this Turn off temporarily Press POWER on the remote. The STANDBY indicator on the TV lights up red. Turn off completely Press ! on the TV. Mute the sound Press MUTING. Watch the video input Press VIDEO to select “VIDEO 1”...
Setting the Wake Up timer Press WAKE UP until the desired period of time WAKE UP TIMER:10M WAKE UP appears. After 10 minutes The Wake Up timer starts immediately WAKE UP TIMER:OFF WAKE UP TIMER:12H00M after you have set it. No Wake Up Timer After 12 hours Select the channel number or video input you want to display when you...
Advanced Operations Customizing the SOUND MODE picture and sound SOUND MODE FAVORITE SELECT WAKE UP SELECT You can customize the picture and + or – PIC MODE SLEEP sound by selecting the picture and PIC MODE sound modes or by adjusting its AUTO ADD/ CABLE...
Page 15
Adjusting the picture and sound settings Press SELECT until the SELECT desired setting appears. PICTURE Each time you press PICTURE COLOR BRIGHT HUE* SELECT, the setting item will change as follows: BALANCE TREBLE BASS SHARP Press + or – to adjust the item.
Page 16
Customizing the picture and sound (continued) Selecting the surround mode Press SELECT repeatedly SELECT until “SURROUND” SURROUND: MOVIE appears. Press + or – to select the desired surround sound. MOVIE MUSIC Selecting the wide mode Press SELECT repeatedly SELECT until “WIDE MODE” WIDE MODE: OFF appears.
Viewing your favorite channels Number buttons You can display six of your favorite JUMP channels for quick and easy selection. SOUND MODE You can program the favorite channel CH +/– as well. FAVORITE FAVORITE SELECT WAKE UP SELECT + or – PIC MODE SLEEP Selecting a favorite channel...
Blocking the MUTING DISPLAY POWER channels VIDEO (CHILD LOCK) You can lock some channel numbers to prevent children from watching certain channels, by using the buttons on the JUMP remote control. SOUND MODE FAVORITE SELECT WAKE UP SELECT PIC MODE PIC MODE SLEEP AUTO...
Enjoying stereo or bilingual MUTING DISPLAY POWER programs VIDEO You can enjoy stereo sound or bilingual programs of MTS stereo system. JUMP SOUND MODE FAVORITE SELECT WAKE UP STEREO PIC MODE SLEEP indicator Press MTS repeatedly until you receive the sound you want.
Count the number of times the STANDBY indicator flashes. Press ! to turn off your TV. Inform your nearest Sony service center about the number of times the STANDBY indicator flashes. Be sure to note the model name and serial number located on the rear of your TV.
Troubleshooting If you find any problem while viewing your TV, please check the following guide. If any problem persists, contact your Sony dealer . Page Symptom Possible cause Solutions • Connection is loose or Snowy picture • Check the antenna cable and connection the cable is damaged.
Page 22
• Adjust the antenna direction – etc. for minimum interference. Contact a Sony dealer for advice. – • Broadcast signals are • Use a highly directional Double images or reflected by nearby antenna.
Page 23
TV, VCR switches on and off or is and on the wall. distorted. • Adjust the antenna direction. • The antenna direction is Contact a Sony dealer for inappropriate. The sound switches advice. between monaural and stereo frequently.
Overview of controls TV front panel STANDBY/ TV/VIDEO VOLUME CHANNEL STEREO/ VIDEO 2 INPUT VIDEO (MONO) AUDIO SELECT AUTO WAKE UP PROGR Button Function Page AUTO PROGR Preset channels automatically. CHANNEL +/– Select channel number. Turn off completely or turn on the TV. Adjust volume.
Remote Control Button Function Page MUTING DISPLAY POWER Select the cable TV. CABLE VIDEO POWER Turn off temporarily or turn on the TV. AUTO PROGRAM Preset channels automatically. CH +/– Select channel number. ADD/ERASE Preset channels manually. Input numbers. Confirm input number. JUMP VOL +/–...
Specifications Note KV-XJ29N90 Power requirements 110 V AC, 60 Hz Power consumption (W) Indicated on the rear of the TV Television system Color system NTSC3.58, PAL*, PAL 60*, SECAM*, NTSC 4.43* * AV IN only Stereo/bilingual system Channel coverage VHF : 2 to 13 UHF : 14 to 69 CATV : 1 to 125 8 (Antenna)
Page 27
Serial number: Indicated on the rear of the TV Manufacturer country: Malaysia Manufacturer: Sony EMCS (Malaysia) Sdn. Bhd. Importer: Sony Electronics Marketing of Taiwan Ltd. Address: 5F., No.145, Changchun Road, Taipei 104, Taiwan. Contact number for service and inquiries: 449-9000...
連接選購的裝置 本電視機可與錄影機﹑影碟機﹑攝影機﹑電視遊戲機或立體聲音響等選購的影像/聲 音裝置相連接- 要觀看所連接裝置的影音輸入時﹐按壓 VIDEO(影音)鍵(請參考第 12 頁)- 用影音 2 輸入插口與攝影機/電視遊戲機相連接 電視機前面 聲音/影像電纜(未提供) 至 VIDEO 2 INPUT 至聲音和影像輸出 (影音輸入) 攝影機 或 L ( MONO ) VIDEO 2 INPUT VIDEO AUDIO 電視遊戲機 :信號流向 注 • 當您使用電視機背後的 VIDEO IN 1 或 2(影音輸入)插口或電視機前面的 VIDEO 2 INPUT(影音 2 輸入)插口時﹐您也可通過“多系統視訊入端子” 接收...
Page 34
用 COMPONENT VIDEO(DVD)IN(聲音/色差端子 (DVD)輸入)插口與 DVD 播放機相連接 1. 將電視機上的 COMPONENT VIDEO(DVD)IN(聲音∕色差端子(DVD)輸入)R (右)和 L(左)與 DVD 播放機上的 LINE OUT(線路輸出)的 AUDIO(聲音)R (右)和 L(左)輸出插口連接起來。 2. 用 DVD 影音電纜將電視機上的 COMPONENT VIDEO (DVD) IN(聲音∕色差端子 (DVD)輸入)Y﹐C 和 C 插口連接至 DVD 播放機上的 COMPONENT VIDEO OUT (DVD 影音輸出)Y﹐C 和 C 插口。...
預設頻道 MUTING DISPLAY POWER 您可用遙控器或電視機上的按鍵預設 VIDEO 有線電視頻道﹐VHF 或 UHF 的廣播頻 道- JUMP SOUND MODE FAVORITE SELECT WAKE UP PIC MODE SLEEP AUTO ADD/ CABLE PROGRAM ERASE AUTO PROGRAM AUTO PROGR (自動頻道記憶) CABLE (有線電視) 自動預設頻道 按壓電視機上的 !(電源) 鍵以接通電視機電源- 按壓 CABLE (有線電視) CABLE 鍵以選擇“有線電視:...
Page 37
預設頻道(續) 數字鍵 JUMP SOUND MODE CH +/– (頻道) FAVORITE SELECT WAKE UP PIC MODE SLEEP AUTO ADD/ CABLE PROGRAM ERASE ADD/ERASE (記憶/刪除) 手動預設頻道 要接收某一個新的頻道或接收一個信號微弱的頻道時﹐請手動預設頻道- 按壓數字鍵以選擇您所要的頻道號碼﹐然後按壓 ENT 鍵- 按壓 ADD/ERASE(記憶/ ADD/ ERASE 刪除)鍵- “+”顯示於頻道號碼旁 邊﹐這表示頻道預設已完 成- 解除頻道號碼 解除了不用或不要的頻道號碼後﹐當按壓 CH +/–(頻道)鍵時﹐您就可跳躍那些 頻道號碼- 按壓...
