Power Connector

Connects to the included DC 12V power adapter.
Reset/WPS Button
This button is used for both WPS and Reset function.
To use the RESET function, press and hold the button for more than five seconds.
Note that all settings will be restored to factory default.
To use the WPS function, ensure the camera has started.
Press the WPS button located on your router and then press the WPS button on
the Main Unit for one second, within 60 seconds.
While connecting, the Status Indicator LED will flash red. Please wait until the
camera reboots, then the Wi-Fi connection will be established.
Note: The WPS push button (also called QSS) option should be enabled on the
router for this function to work.
Status Indicator LED
After Main Unit is powered on, the indicator LED shows a green light then quickly
turns off which means the system is being started. When the indicator LED shows
a green light again, it means the system has started successfully.
The indicator LED flashes green light during data transfer and shows red light for
WPS connection status.
Sensor Unit and Cable
The sensor unit and main unit are connected by a 6 meters (20 ft) cable which will
provide flexibility for remote location placement.
The sensor unit must be connected to the main unit, it can't work independently.
NOTICE
The sensor unit for PLC-128 is not designed for outdoor use. It may only be
installed indoors.

Mounting Accessories

PLC-128 includes various mounting brackets for quick and easy installation.
The sensor unit can be mounted flat or angled on any surface, using the angled
mounting bracket. The camera can also be mounted covertly behind a thin wall,
cupboard, door and etc. With miniature size design it enables easy integration
into any hidden place.
General I/O Terminal
Used to connect the wired alarm devices, such as PIR sensor, detector, siren, etc.
