Angled Surface Installation
Mount the angled mounting bracket to the wall or ceiling. Ensure that
STEP1
the bracket is pointing towards the area to be monitored.
Assemble the plate with the screw and align it so the arrows are
STEP2
vertical or horizontal.
STEP3
Install the Sensor Unit into the plate with the two screws.
Snap on the cover.
STEP4
