Public Address System
8-Channal PA Amplifier
Public Address System
8-Channel PA Amplifier
PB8060
Operating Instructions
Welcome to use our Public Address System. For better use of this equipment, please read this manual thoroughly
before use.
LY International Electronics Co., Ltd
http：//www.lyintlcorp.com
1
Advertisement
Table of Contents
Related Manuals for LY International Electronics PB8060
Summary of Contents for LY International Electronics PB8060
-
Page 1: Operating Instructions
Public Address System 8-Channal PA Amplifier Public Address System 8-Channel PA Amplifier PB8060 Operating Instructions Welcome to use our Public Address System. For better use of this equipment, please read this manual thoroughly before use. LY International Electronics Co., Ltd http：//www.lyintlcorp.com... - Page 2 Public Address System 8-Channal PA Amplifier Installation Considerations Never block the vent hole. If the power cable is damaged, immediately stop using it. The power plug shall be compatible with the socket. This machine is not disconnected from the electric grid after you press down POWER OFF switch. To avoid accident, please unplug the power socket if the machine is to be put out of use for a long time.
- Page 3 Public Address System 8-Channal PA Amplifier Appearance and Functions 1． ． ． ． Description of Back Panel 1-8 PA output channel terminal Power input Master Power Switch Radiating Window 1-8 Audio Input Channel Port Radiating Window Notes on Interface Connection: Each channel independent...
- Page 4 Public Address System 8-Channal PA Amplifier Noted on Input Connection (with INPUT1 Channel as example) Eight audio input channels correspond to eight PA output channels. For example, the audio source connected to INPUT1 is output from the channel corresponding to OUTPUT1. That is, the input channel 1-8 corresponds to the output channel 1-8 each by each.
-
Page 5: Description Of Front Panel
Public Address System 8-Channal PA Amplifier 2. Description of Front Panel 1-8 Channel PA Control Panel Note: On front panel, there are 8 independent control boards, which correspond to 8 PA output channels on back panel, including the control over the PA volume, tone and power switch state. Take the first channel as example to illustrate the functions of control board. - Page 6 ● This equipment shall not be exposed to water drip or spatter. And do not place the vase or other water-filled articles onto the equipment. ● To avoid electric shock, please do not open the cover plate of the machine. If needed, it shall be repaired by qualified professionals. LY International Electronics Co., Ltd.
