3. Initial Setting Mode: Initial settings of the controller and communication parameters
LED Explanation
INPUT: Select input temperature sensor type
(Please refer to the contents of the "Temperature Sensor Type and Temperature Range" for detail)
Engineering Unit(°F or °C): Select engineering unit F or C.
T-High: Upper limit for temperature range.
T-Low: Lower limit for temperature range.
CONTROL METHOD (ON/OFF, PID, or manual tuning [
point value.
Control Action (Direct or Reverse Acting): Cooling [Cool] or heating [HEAT].
ALARM 1: Alarm 1 setting. (See Alarm Output Section for set values and descriptions).
ALARM 2: Alarm 2 setting. (See Alarm Output Section for set values and descriptions).
C WE: Write-in function disabled/enabled. Can be set only when unit is equipped with serial
communication.
C NO: Address setting. Can be set only when unit is equipped with serial communication.
BPS: Baud rate setting. Can be set only when unit is equipped with serial communication.
Length: Data length setting. Can be set only when unit is equipped with serial communication.
Parity: Parity bit setting. Can be set only when unit is equipped with serial communication.
Stop Bit: Stop bit setting. Can be set only when unit is equipped with serial communication.
Execution :
The programming execution is initiated through
When is set to
When is set to
5
Temperature control can be achieved either by heating or cooling. Please refer to the following for the operation: Settings for heat or
cool operation are found in the initial settings mode under
Select , for heating (reverse) control on Output 1.
Select , for cooling (forward) control on Output 1

Input Error Indication

Setting
Temperature sensor is not connected
value
PV
SV
6
Depending on the controller model, there can be up to two alarm outputs. Each alarm output can be configured for an alarm type
listed below. Alarm types are set in the initial setting mode. The alarm output is activated whenever the process temperature value
(PV) is getting higher or lower than the set point of alarm limit.
Set
Value
0 Alarm function disabled
Deviation upper- and lower-limit:
1 This alarm output operates when PV value is higher than the setting value
SV+(AL-H) or lower than the setting value SV-(AL-L).
Deviation upper-limit:
2 This alarm output operates when PV value is higher than the setting value
SV+(AL-H).
Deviation lower-limit:
3 This alarm output operates when PV value is lower than the setting value
SV-(AL-L).
Reverse deviation upper- and lower-limit:
4 This alarm output operates when PV value is in the range of the setting value
SV+(AL-H) and SV-(AL-L).
, the program will start to execute in order from the step 0 of the start pattern.
, the program will stop and the control output is disabled
Measured temperature value exceeds
Alarm Type
]): Sets the control method for the set
in the operation mode.
Heating and Cooling
.
the temperature range
Alarm Outputs
Unknown input
Alarm Output Operation
Output OFF
ON
OFF
SV SV+(AL-H)
SV-(AL-L)
ON
OFF
SV SV+(AL-H)
ON
OFF
SV
SV-(AL-L)
ON
OFF
SV-(AL-L) SV SV+(AL-H)
Default
PT2
o
C
500.0
-20.0
PID
HEAT
0
0
OFF
1
9600
7
E
1
