Chamberlain OPI User Manual

Overview
The Portable Intercom allows multiple simultaneous
conversations, using a 900 Mhz secure digital radio
link. The intercoms form an exclusive network and
respond only to other intercoms in the network.
The Intercom is compatible with various Liftmaster
Wireless Products.
Carton Inventory
Intercom
Operation & Features
Volume Button
Talk
(Power - On)
Channel/Remote
Button
Learn Button
Talk Button: To talk, hold down the
Talk button. All intercoms in the
network that are on the same
channel will receive the signal.
Release the Talk button when done
talking and within 10-15 seconds
press and hold the Talk button of a
different intercom to make a secure channel between
the two. Once the connection is made the other
intercoms in the network cannot hear the
conversation.
Rubber Pads
AC Adapter
Dipswitch #1
Dipswitch #2
Channel Selection: Press the
Channel/Remote button to set
intercom to one of four secure
channels or the Paging channel.
The default channel for the intercom
is the Paging channel where all four
channel lights will flash in sequence.
An intercom on a channel can only hear an intercom
on the same channel or on the Paging channel.
Command Gate: A gate can be
opened with a call from an intercom.
When an intercom has been
activated by another intercom, the
talk button can be pressed to
secure a channel to the gate. To
allow access from the gate, press
and release the Remote button to open the gate.
The gate can also be opened without a call from an
intercom. Press and hold the Remote button and an
initial beep will be heard. Continue to hold until a
second beep is heard, then release.
If pressing the Remote button did not open the gate,
a siren noise will be heard. No siren noise indicates a
successful signal transmission.
Volume: Pressing the Volume
button repeatedly will cycle through
volume levels.
Battery: The AA Alkaline batteries
(not provided) will last up to a year
depending on use. When batteries
are low intercom will emit two beeps
every ten minutes.
An AC Adapter (not provided) can
also be used to power the intercom.
In this case, both the power and
channel lights will remain on.
On/Off: To turn intercom ON, press any button.To
turn intercom OFF, hold down the Volume button for
5 seconds.
1
Model OPI
Portable Intercom
OPTIONAL
