RU Antenna Alignment
Polarization Vertical, horizontal electronically selectable
Frequency 5.2 to 5.9 GHz
Gain +24 dBi
Azimuth Beamwidth 9 degrees
Elevation Beamwidth 9 degrees
Mount Heavy Duty Universal Mount.
Radio Waves SPD3-5.2 Parabolic Dish for P5830S-SU-EXT
Type Parabolic Prime Focus 36" Dish
Polarization Vertical, horizontal electronically selectable
Frequency 5.2 to5.9 GHz
Gain +31 dBi (30 dBi with Cable Loss)
Azimuth Beamwidth 4.2 degrees
Elevation Beamwidth 4.2 degrees
Cross Polarization 30 dB
Front/Back Ratio 40 dB
