Summary of Contents for Panasonic CF-VDR301U
- Page 1 ORDER NO. CPD0701212C0 DVD-ROM & CD-R/RW Drive Pack CF-VDR301U Model No. © 2007 Matsushita Electric Industrial Co., Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law.
- Page 2 If you lose the fuse cover the plug must not be used until a replacement cover is obtained. A replacement fuse cover can be purchased from your local Panasonic Dealer. IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE REMOVED AND THE PLUG CUT OFF AND DISPOSED OF SAFELY.
- Page 5 Replacement Parts List Note : Important Safety Notice Components identified by mark have special characteristics important for safety. When replacing any of these components, use only manufacturer's specified parts. CF-VDR301U REF. NO and AREA PART NO. DESCRIPTION Q'TY Main Block Unit...
- Page 6 Exploded View K3-1 K3-4 K3-5 K3-2 K3-3 E2-2 E2-1 Screw tightening torque 0.13 _ 0.01N m (1.3 _ 0.1kgf cm) 0.09 _ 0.01N m (0.9 _ 0.1kgf cm) CF-VDR301U...
