Page 2
CAUTION! THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS, ADJUSTMENTS OR PERFORMANCE OF PROCEDURES OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RA- DIATION EXPOSURE. DO NOT OPEN COVERS AND DO NOT REPAIR YOURSELF. REFER SERVICING TO QUALIFIED PERSONNEL. 12-E-1 WARNUNG! DIESES PROUKT ERZEUGT LASERSTAHLUNG.
Page 3
Connect the equipment into an outlet on a circuit different from that to which the receiv- er is connected. Consult the Panasonic Service Center or an experienced radio/TV technician for help. Warning To assure continued compliance, use only shielded interface cables when connecting to a computer or peripheral.
Page 4
Compliance Notice - CE Mark This equipment is in conformance with the requirements of the European Council Direc- tive listed below: 73/23/EEC Low Voltage Directive with amendment 93/68/EEC 89/336/EEC EMC Directive with amendments 92/31/EEC and 93/68/EEC 1999/5/EC R&TTE 21-E-1 Übereinstimmungserklärung - CE-Marke Diese Ausrüstung erfüllt die Anforderungen der unten angegebenen EC-Direktive: 73/23/EEC Niederspannungsdirektive mit Abänderung 93/68/EEC 89/336/EEC EMC-Direktive mit Abänderungen 92/31/EEC und 93/68/EEC...
Introduction Thank you for purchasing the DVD-ROM & CD-R/RW Drive Pack for the Panasonic CF-30 notebook computer series* This drive connects to the computer through the multimedia pocket. Store this manual in a safe place after reading it. For information about the computer(s) for which the DVD-ROM & CD-R/RW Drive Pack can be used, refer to the catalogs, etc.
Handling Precautions Do Not Look Into the CD/DVD Drive Looking directly at the internal laser light source may result in damage to eyesight. Do Not Use Discs That Are Cracked or Deformed Because the discs rotate at high speeds, damaged discs may break apart causing injury. Discs that are not round and discs that have been repaired using adhesives are similarly dangerous, and so should not be used.
Page 7
<For recordable/rewritable discs> Use the Panasonic disc cleaner to clean these discs. Do not use a cloth, CD cleaners or any other such cleaners under any circumstances. How to hold a disc...
Using the Drive Inserting/Removing the Drive For details on how to insert and remove the drive, refer to “Multimedia Pocket” in the Reference Manual included with your computer. Preparations Confi rm that [Transfer Mode] is set to [DMA if available] in [start] - [Control Panel] - [Performance and Maintenance] - [System] - [Hardware] - [Device Manager] - [IDE ATA/ ATAPI controllers] - [Primary IDE Channel] - [Advanced Settings] - [Device 0].
Page 9
NOTE To remove a disc when the computer is powered off, insert a pointed object (e.g., the bent-out tip of a paper clip) into the emergency hole (D). Pushing it to the end allows the tray to come out. If the vibration of the drive is excessive, check the disc. If the disc is normal and is inserted correctly, set [DVD Drive Speed] to [Low] in the [Main] menu of the Setup Utility ( Reference Manual “Setup Utility”).
Using the Drive Information To play DVD-Video or MPEG2 files, install the DVD playback software using “DVD Drive Utility Disc” (included). For information on how to install the software, refer to page 18. Region Code Setting DVD-Video are allocated to region codes according to where they are sold. To play a DVD-Video, the player’s software and the drive must have the corresponding region code.
Page 11
Writing to Discs Writing software is required to write data to a disc. Install “EASY MEDIA CREATOR” using “DVD Drive Utility Disc” (included). page 14) Be sure to use discs conforming to the proper write speeds. ( If the write operation is to involve a long period of time, be sure to connect the AC adaptor of the computer.
Using the Software Install the software application contained in the “DVD Drive Utility Disc” (supplied): “EASY MEDIA CREATOR” and “WinDVD” Before Installing the Software Insert the drive into the multimedia pocket. ( Pocket”) CAUTION Do not install the software using a drive other than this drive. Be sure to insert this drive into your computer, and then insert the disc for installation.
Page 13
EASY MEDIA CREATOR “EASY MEDIA CRAETOR” is CD writing software application developed by Roxio, Inc. Here, explanations are given on general information about “EASY MEDIA CRAETOR,” the installation procedure, and how to access the online manual. For further information, refer to the online manual of “EASY MEDIA CREATOR” ( General Information What you can do with this software application •...
Page 14
Using the Software Installing EASY MEDIA CREATOR To install the software application, follow the procedure below. CAUTION 1 GB of free space on the hard disk is needed to install all the components of “EASY MEDIA CREATOR.” Close all other software application before running the Setup program for “EASY MEDIA CRAETOR.”...
Page 15
Running EASY MEDIA CREATOR Click [start] - [All Programs] - [Roxio Easy Media Creator 7 Basic Edition]. You can run each utility from the [Roxio Easy Media Creator 7 Basic Edition] screen. You can also run each utility by following the procedure below. Creator Classic Click [start] - [All Programs] - [Roxio] - [Creator Classic].
Page 16
Using the Software How to access the Online Manual After running each utility, you can access the online manual. Creator Classic Click [Help] from the menu, and them click [Creator Classic Help Center]. Disc Copier Click [Help] from the menu, and them click [Disc Copier Help Center]. Label Creator Click [Help] from the menu, and them click [Label Creator Help Center].
Page 17
fi le fi rst for problems with the operating environment or opera- tions. Then install the latest Windows Service Pack. If you still cannot troubleshoot the problem, contact Panasonic Technical Support. For further information, refer to the following URL. http://www.roxio.com/...
Page 18
Using the Software WinDVD is a software application for DVD playback. Install “WinDVD” using “DVD Drive Utility Disc” ( Installing WinDVD 1 Log on to Windows as an administrator. 2 Set “DVD Drive Utility Disc” in the drive. 3 At the confi rmation message, click [OK]. [Utility Setup tool] screen will appear (allow some time for disc recognition).
Page 19
NOTE DVD-Audio cannot be played back using “WinDVD”. Do not start “WinDVD” while the hard disk drive indicator ately after the computer is turned on. While “WinDVD” is running, do not: • Enter standby or hibernation. • Switch the display by pressing Fn + F3 . During video playback, do not: •...
Page 20
Using the Software DVD Discs Created Using a DVD Recorder The following restrictions apply: Depending on the condition (record quality, cracks, dirt, modifi cation, copy protection, type of drive/disc maker used when creating the disc, etc.) of a disc, it may not be pos- sible to be read or play it correctly.
Troubleshooting The computer does not recog- nize the drive The Multimedia pocket device status indicator does not light Cannot play disc or read data from it “EASY MEDIA CREATOR” do not work properly Cannot eject disc The disc tray does not close Other disc operation problems Check the settings by following the instructions in “Preparations”...
Einführung Wir freuen uns, dass Sie sich für das DVD-ROM & CD-R/RW-Laufwerk-Pack für Ihr Panasonic-Notebook CF-30 entschieden haben* Dieses Laufwerk wird über das Multimedia Pocket an das Notebook angeschlossen. Sie sollten diese Bedienungsanleitung an einer sicheren Stelle verwahren. Informationen zu den Computern, in denen der DVD-ROM & CD-R/RW-Laufwerk-Pack ver- wendet werden kann, fi...
Vorsichtsmaßnahmen zum Gebrauch Nicht in das CD/DVD-Laufwerk blicken Der direkte Blick in die interne Laser-Lichtquelle kann zu Augenschäden führen. Keine CDs mit Rissen oder Verformungen verwenden Auf Grund der hohen Rotationsgeschwindigkeit können beschädigte CDs auseinander bre- chen und Verletzungen verursachen. CDs, die keine runde Form aufweisen oder mit Klebstoffen repariert wurden, sind ähn- lich gefährlich und sollten daher nicht verwendet werden.
Page 25
Sie von der Mitte gerade nach außen wischen, und wischen Sie dann mit ei- nem trockenen Tuch nach, um die verbleibende Feuchtigkeit aufzunehmen. <Für wieder beschreibbare Discs> Verwenden Sie das Panasonic Disc-Reinigungsmittel, um diese Discs zu reinigen. Verwenden Sie auf alle Fälle weder ein Tuch noch CD-Reinigungsmittel oder andere derartige Reinigungsmittel.
Gebrauch des Laufwerks Einsetzen/Entfernen des Laufwerks Hinweise zum Einsetzen/Entfernen des Laufwerks fi nden Sie unter „Multimedia Pocket“ Reference Manual, das mit Ihrem Computer mitgeliefert wird. Vorbereitungen Vergewissern Sie sich, dass [Übertragungsmodus] unter [Start] - [Systemsteuerung] - [Leistung und Wartung] - [System] - [Hardware] - [Geräte-Manager] - [IDE ATA/ATAPI- Controller] - [Primärer IDE-Kanal] - [Erweiterte Einstellungen] - [Gerät 0] auf [DMA, wenn verfügbar] eingestellt ist.
Page 27
HINWEIS Um die Disc bei ausgeschaltetem Computer zu entfernen, schieben Sie einen spitzen Gegenstand (z. B. eine aufgebogene Büroklammer) in die Notfallöffnung (D) ein. Durch Einschieben bis zum Anschlag öff- net sich das Fach. (Die genaue Lage der Notfallöffnung hängt von dem jeweiligen Laufwerkmodell ab.) Falls die Disc zu stark vibriert, überprüfen Sie sie.
Page 28
Gebrauch des Laufwerks Informationen Um DVD-Video-Discs oder MPEG2-Dateien abzuspielen, installieren Sie die DVD- Wiedergabe-Software mit Hilfe der „DVD Drive Utility Disc“ (im Lieferumfang). Informationen zur Installation der Software fi nden Sie auf Seite 36. Über die Regionalcodeeinstellung Alle DVD-Videos sind mit einem Regionalcode versehen, der sich je nach Verkaufsgebiet unterscheidet.
Page 29
Schreiben auf Discs Die Schreibsoftware ist erforderlich, um Daten auf eine andere Disc. Installieren Sie „EASY MEDIA CREATOR“ mit Hilfe der „DVD Drive Utility Disc“ (mitgeliefert). ( Seite 32) Verwenden Sie nur Discs, die die folgenden geeigneten Schreibgeschwindigkeiten auf- weisen. ( Seite 40) Falls der Schreibvorgang eine lange Zeit in Anspruch nehmen soll, schließen Sie immer den Netzadapter des Computers an.
Gebrauch von Software Installieren Sie die Software-Anwendung, die auf der „DVD Drive Utility Disc“ (mitgelie- fert) enthalten ist: „EASY MEDIA CREATOR“ und „WinDVD“. Bevor Sie die Software installieren Setzen Sie das Laufwerk in das Multimedien-Ablagefach ein. ( ual „Мultimedia Pocket“) VORSICHT Installieren Sie die Software nicht mit Hilfe eines anderen Laufwerks als diesem Laufwerk.
Page 31
EASY MEDIA CREATOR „EASY MEDIA CREATOR“ ist eine Software-Anwendungen zum Schreiben von CD, die von Roxio Inc. entwickelt wurde. Nachfolgend finden Sie allgemeine Erkläungen zu der Anwendung „EASY MEDIA CREATOR“, dem Installationsverfahren und dem Zugriff auf das Online-Handbuch. Weitere Informationen fi nden Sie im Online-Handbuch des „EASY MEDIA CREATOR“...
Page 32
Gebrauch von Software Installation von EASY MEDIA CREATOR Fünren Sie das folgende Verfahren durch, um zu installieren. VORSICHT Auf der Festplatte ist ein freier Speicherraum von 1 GB erforderlich, um alle Kom- ponenten von „EASY MEDIA CREATOR“ zu installieren. Schließen Sie alle anderen Software-Anwendungen, bevor Sie das Setup-Programm für die „EASY MEDIA CREATOR“...
Page 33
Verwenden von EASY MEDIA CREATOR Klicken Sie [Start] - [Alle Programme] - [Roxio Easy Media Creator Basic Edition-Start- fenster]. Sie können jedes Dienstprogramm auch vom Bildschirm [Roxio Easy Media Creator 7 Basic Edition] ausfüren. Sie können jedes Dienstprogramm auch mit Hilfe des folgenden Verfahrens ausfüren.
Page 34
Gebrauch von Software Zugriff auf das Online-Handbuch Nachdem Sie alle Dienstprogramme ausgefährt haben, haben Sie Zugriff auf die Online- Bedienungsanleitung. Creator Classic Klicken sie [Hilfe] aus dem Menü, und klicken Sie dann [Hilfecenter von Creator Clas- sic]. Disc Copier Klicken sie [Hilfe] aus dem Menü, und klicken Sie dann [Hilfecenter von Disc Copier]. Label Creator Klicken sie [Hilfe] aus dem Menü, und klicken Sie dann [Hilfecenter von Label Crea- tor].
Page 35
Betriebsvorgägen ausfi ndig zu machen. Installieren Sie dann das neueste Windows Service Pack. Falls das Problem auf diese Weise nicht behoben werden kann, wenden Sie sich bitte an den Panasonic-Kundendienst. Weitere Informationen fi nden Sie unter dem folgenden URL. http://www.roxio.com/...
Page 36
Gebrauch von Software WinDVD ist eine Software-Anwendung für die DVD-Wiedergabe. Installieren Sie die „WinDVD“ Hilfe der „DVD Drive Utility Disc“ ( Installation von WinDVD 1 Melden Sie sich bei Windows als Administrator an. 2 Legen Sie „DVD Drive Utility Disc“ in das Laufwerk. 3 Wenn die Bestätigungsabfrage erscheint, klicken Sie auf [OK].
Page 37
HINWEIS Eine DVD-Audiodisc kann mit „WinDVD“ nicht wiedergegeben werden. Starten Sie „WinDVD“ nicht, solange die Festplatten-Zugriffsleuchte dem Computerstart blinkt. Während „WinDVD“ ausgeführt wird, vermeiden Sie Folgendes: • Umschalten in den Bereitschafts- oder Ruhezustand. • Umschalten des Bildschirms mit Fn + F3 . Während der Wiedergabe vermeiden Sie Folgendes: •...
Page 38
Gebrauch von Software Wiedergabe von DVDs, die mit einem DVD-Recorder erstellt wurden Es gelten folgende Einschränkungen: Je nach Zustand der Disc (Aufnahmequalität, Kratzer, Schmutz, Einschränkungen, Ko- pierschutz, beim Erstellen der Disk verwendetes Laufwerk/Aufnahmegerät usw.) ist die Wiedergabe ggf. nicht möglich. Um andere Medien als DVD-RAM wiederzugeben, müssen diese fi...
Störungsbehebung Das Notebook erkennt das Laufwerk nicht Die Status-Anzeige des Geräts „Multimedia Pocket“ leuchtet nicht E i n e D i s c k a n n n i c h t abgespielt oder gelesen werden „EASY MEDIA CRE- ATOR“ funktionieren nicht richtig Die Disc wird nicht aus- geworfen...
Technische Daten Gegenstand Betriebsspannung Laufwerk Datenüber tragungsrate Unterstützte Discs/Formate Zwischenspeicher-Unterlauffehler- Verhütungsfunktion Cache-Speicher Schnittstelle Abmessungen (Breite × Tiefe × Höhe) 132 mm × 149 mm × 14,0 mm Gewicht Zulässige Umgebungsbedingungen Temperatur/Luftfeuchtigkeit Die Datenübertragungsrate pro DVD bei einfacher Geschwindigkeit (1X) beträgt 1.350 KB/s. Die Datenübertragungsrate pro CD bei einfacher Geschwindigkeit (1X) beträgt 150 KB/s.
Introduction Merci d’avoir choisi le Lecteur DVD-ROM & CD-R/RW pour l’ordinateur portable Pana- sonic CF-30* Le lecteur se connecte à l’ordinateur par l’intermédiaire du Multimedia Pocket. Conservez précieusement ce manuel après l’avoir lu. Pour plus d’informations sur les ordinateurs avec lesquel s le Lecteur DVD-ROM & CD-R/RW peutêtre utilisé, consultez le catalogues, etc.
Précautions de manipulation Ne pas regarder dans le lecteur de CD/DVD Regarder directement le faisceau laser interne risque d'endommager la vue. Ne pas utiliser de disques fendus ou déformés Les disques tournant à vitesse élevée, les disques endommagés risquent de casser et de vous blesser.
Page 43
<Pour les disques enregistrables/réinscriptibles> Utilisez le produit de nettoyage pour disque Panasonic pour nettoyer ces disques. N’utilisez jamais de tissu, produit de nettoyage pour CD ou autre produit similaire. Comment tenir le disque...
Utilisation du lecteur Insertion/Retrait du lecteur Pour de plus amples informations sur la façon d’insérer ou de retirer le lecteur, reportez- vous à “Multimedia Pocket” dans le Préparatifs Vérifi ez que [Mode de transfert] est réglé sur [DMA si disponible] dans [démarrer] - [Panneau de confi...
Page 45
REMARQUE REMARQUE Pour retirer un disque lorsque l’ordinateur est éteint, insérez un objet pointu tel que le bout d’un trombone, d’un crayon ou d’un stylo à bille dans l’orifi ce d’urgence (D). En l’insérant complètement, vous dégagerez le tiroir qui pourra alors être sorti complètement. (L’empla- cement de l’orifi...
Page 46
Utilisation du lecteur Informations Pour lire un DVD-Vidéo ou des fi chiers MPEG2, installez le logiciel de lecture de DVD au moyen du “DVD Drive Utility Disc”(fourni). Pour plus d’informations sur la manière d’installer le logiciel, reportez-vous à la page 54. Réglages de zone Les DVD-Vidéo possèdent un code de zone qui est assigné...
Page 47
Pour écrire sur des disques Un logiciel d’écriture est nécessaire pour écrire des données sur un disque. Installez “EASY MEDIA CREATOR” au moyen du “DVD Drive Utility Disc” (fourni). page 50) Veillez à utiliser des disques conformes aux vitesses d’écriture correctes. ( Si l’écriture doit prendre beaucoup de temps, assurez-vous d’avoir branché...
Utilisation du logiciel Installez les applications logicielles que contient le disque “DVD Drive Utility” (fourni) : “EASY MEDIA CREATOR” et “WinDVD” Avant d’nstaller le logiciel Insérez le lecteur dans l’appareil Multimedia Pocket. ( “Multimedia Pocket”) ATTENTION N’installez pas le logiciel en utilisant un lecteur autre que ce lecteur. Assurez-vous d’ insérer ce lecteur dans votre ordinateur, puis insérez le disque pour l’installation.
Page 49
EASY MEDIA CREATOR “EASY MEDIA CRAETOR” est une application logicielle de gravure de CD développée par Roxio. Inc. Les explications données ici sont des informations généales sur “EASY MEDIA CRAETOR”, la procédure d’nstallation et la façon d’accéder au manuel en ligne. Pour plus d’informations, consultez le manuel en ligne de “EASY MEDIA CREATOR”...
Page 50
Utilisation du lecteur Installation de EASY MEDIA CREATOR Pour installer, suivez la procédure décrite ci-dessous. ATTENTION 1 Go d’espace libre sur le disque dur est nécessaire pour installer tous les compo- sants de “EASY MEDIA CREATOR”. Fermez toutes les autres applications logicielles avant d’exécuter le programme d’ installation des “EASY MEDIA CREATOR”.
Page 51
Lancement de EASY MEDIA CREATOR Cliquez sur [démarrer] - [Tous les programmes] - [Écran d’accueil de Roxio Easy Media Creator 7 Basic Edition]. Vous pouvez exécuter chaque utilitaire depuis l’écran [Roxio Easy Media Creator 7 Basic Edition]. Vous pouvez aussi exécuter chaque utilitaire en suivant la procédure ci-dessous. Creator Classic Cliquez sur [démarrer] - [Tous les programmes] - [Roxio] - [Creator Classic].
Page 52
Utilisation du lecteur Comment accéder au manuel en ligne Après exécution de chaque utilitaire, vous pouvez accéder au manuel en ligne. Creator Classic Cliquez sur [Aide] dans le menu, puis cliquez sur [Creator Classic - Aide en ligne]. Disc Copier Cliquez sur [Aide] dans le menu, puis cliquez sur [Disc Copier - Aide en ligne].
Page 53
Sur les copies <Pour la France> Panasonic rappelle que le logiciel ROXIO fourni avec le présent produit Panasonic est conçu pour vous aider à reproduire des œuvres dont vous êtes titulaires des droits d’auteur, ou pour lesquelles vous avez obtenu une autorisation auprès du titulaire des droits d’auteur.
Page 54
Utilisation du lecteur WinDVD est une application logicielle pour la lecture de DVD. Installez “WinDVD” au moyen du “DVD Drive Utility Disc” ( Installation de WinDVD 1 Ouvrez une session Windows en tant qu’administrateur. 2 Insérez “DVD Drive Utility Disc” dans le lecteur. 3 Lorsque le message de confi...
Page 55
REMARQUE REMARQUE Les DVD-Audio ne peuvent être lus à l’aide de “WinDVD”. Ne lancez pas “WinDVD” pendant que le témoin du disque dur diatement après le démarrage de l’ordinateur. Pendant l’exécution de “WinDVD”, n’effectuez pas les opérations suivantes: • Entrer en mode de veille ou d’hibernation. •...
Page 56
Utilisation du lecteur Disques DVD créés avec un enregistreur DVD Les restrictions suivantes s’appliquent : La lecture d’un disque peut ne pas être possible en fonction des conditions (qualité d’ enregistrement, fi ssures, poussières, modifi cation, protection contre la copie, type de lecteur/logiciel d’enregistrement utilisé...
Dépannage L’ordinateur n’identifi e pas le lecteur Le témoin d’état de l’appareil Multimedia Pocket ne s’ allume pas Impossible de lire le disque ou d’accéder à ses données “EASY MEDIA CREATOR” ne fonctionnent pas correcte- ment Le disque ne peut pas être éjecté...
Spécifi cations Article Tension de fonctionnement Lecteur Taux de transfert des donnée* Disques/ formats pris en charge* Fonction de prévention de sous- utilisation de la mémoire tampon Mémoire cache Interface Dimensions (largeur × profondeur × hauteur) Poids Température en fonctionnement/ taux d’humidité...
Page 68
ソフトウェアを使う EASY MEDIA CREATOR 「EASY MEDIA CREATOR」は、Roxio 社によって開発された CD ライティング ソフトウェアです。 本紙では、 「EASY MEDIA CREATOR」の概要、インストールのしかた、オンラ インヘルプの見かたなどについて説明しています。詳しくは、 「EASY MEDIA CREATOR」のオンラインヘルプをご覧ください。 ( 概要 「EASY MEDIA CREATOR」でできること ・ 音楽 CD の作成、データ CD の作成 : 「Creator Classic」ユーティリティを使用します。 ・ バックアップ CD の作成: 「Disc Copier」ユーティリティを使用します。 ・ CD ラベルなどの作成: 「Label Creator」ユーティリティを使用します。...
