- Page 1 OWNER’S GUIDE NV340ANZ ™ SLIM - LIGHT ™...
-
Page 2: Technical Specifications
For a list of what is included with this model, refer to inside flap of box. ® ™ ™ This Owner’s Guide is designed to help you get a complete understanding of If you should have a question about your Shark Rotator , please call ® ™... -
Page 3: Important Safeguards
READ ALL INSTRUCTIONS BEFORE USE IMPORTANT SAFEGUARDS When using an electrical appliance, basic safety precautions should 17 DO NOT put any objects into openings. DO NOT use with any opening always be observed, including the following: blocked; keep free of dust, lint, hair, and anything that may reduce air flow. 18 Keep your work area well lit. - Page 4 ASSEMBLY Place the vacuum body onto floor nozzle. Insert the wand into top of the vacuum. Insert the handle into the top of the wand. Insert the hose into the hose connector. Insert the dusting brush into the accessory holder as shown. CLICK CLICK CLICK...
- Page 5 WARNING: When vacuuming fine dust (sawdust, sand, flour, talcum powder, etc.) electrostatic charges build up naturally. Under certain conditions these electrostatic charges will be released. To avoid the unpleasant effects of static discharges, a metal strip has been incorporated into the right side of the handle.
- Page 6 LIFT-AWAY ™ Press LIFT-AWAY to lift the pod off the floor nozzle. CLEANING To clean with the hose, press the WAND or HANDLE release button, then lift the handle up. Use for portable cleaning without the wheels. Clean floors, stairs or anywhere with the Lift-Away pod.
- Page 7 LIFT-AWAY ™ Attach the desired cleaning tool. Should you need to increase or decrease the amount of suction, refer to Helpful Tips (page 11), SUCTION CONTROL. CLEANING NOTE: Select cleaning accessories are included with this model. Use for portable For a list of what is included with this model, refer to inside flap of box. cleaning without the wheels.
- Page 8 Dusting Brush 3050FC340 ACCESSORIES Cleans hard surfaces and upholstery. 3053FLI340 NOTE: Select cleaning accessories are included. For a list of what is included with this model, refer to inside flap of box. A U S T: 1 8 0 0 8 9 0 8 4 0...
-
Page 9: Helpful Tips
HELPFUL TIPS SUCTION CONTROL This unit is equipped with a suction control collar to help with push and pull on high pile carpets, area rugs and to release suction when dusting delicate objects or drapery. Located at base of top handle, rotate the collar 90° to minimise suction. Be sure to close again for maximum suction. POWER BUTTONS The POWER button turns on suction only. -
Page 10: Maintenance
MAINTENANCE EMPTY THE DUST CUP Pull up on the dust cup release latch and lift the dustcup off the pod. Holding the dust cup over a garbage bag or can, press the bottom empty release latch. Press the top dust cup release latch to access the dust screen and remove built-up debris as required. Turn the dust cup over and empty the upper chamber by holding it by the handle on the side of the dust cup. -
Page 11: Bottom Of Floor Nozzle
MAINTENANCE CHECK FOR BLOCKAGES REMOVE AND INSPECT: HOSE AND TUBES Remove floor nozzle and extension wand and shine a flashlight up from the bottom to check for possible blockage. Remove dustcup and hose to check intake opening and hose elbow. BOTTOM OF FLOOR NOZZLE Using a coin, turn the locking screws to the unlock position and pull up to expose the airway. - Page 12 Note: If vacuum still does not start, contact Customer care at: AUST: 1800 890 840 or NZ: 0800 002 999. Euro-Pro and Shark are registered trademarks of Euro-Pro Operating LLC. Rotator, Dust-Away and Lift-Away are trademarks of Euro-Pro Operating LLC.
- Page 13 NOTES N Z : 0 8 0 0 0 0 2 9 9 9...
- Page 14 NOTES A U S T: 1 8 0 0 8 9 0 8 4 0...
- Page 15 FIVE (5) YEAR LIMITED REPLACEMENT WARRANTY STATEMENT If your product becomes defective due to faulty material or workmanship within a period of 5 years from the date of purchase, we warrant to do the following: • For New Zealand Consumers: We will replace the product with a new product, free of charge, or repair the product at our cost, at our discretion. • For Australian Consumers: Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
- Page 16 GMA-102233-EA-007 NV340ANZ�31�IB�150604�1 Printed in China © 2015 Euro-Pro Operating LLC Illustrations may differ from actual product.
