Summary of Contents for Perfect Aire 1PAMSCH12

  • Page 1 Before using your multi-zone inverter mini-split system, please read Before using your air conditioner, please read Before using your air conditioner, please read Before using your air conditioner, please read Before using your air conditioner, please read Before using your air conditioner, please read Before using your air conditioner, please read Before using your air conditioner, please read Before using your air conditioner, please read...
  • Page 2: Table Of Contents

    CONTENTS SAFETY PRECAUTIONS Warning ............................2 Caution ............................2 INSTALLATION INSTRUCTIONS Selecting installation place.......................3 Wall-mounted type ...........................3 Accessories ......................4 Four-way cassette type ........................9 Outdoor unit installation ..........................15 REFRIGERANT PIPE CONNECTION Refrigerant pipe connection ......................16 ELECTRICAL WORK Electrical work ..........................17 AIR PURGING Air purging with vacuum pump ......................21 Safety and leakage check ........................22 TEST RUNNING...
  • Page 3: Safety Precautions

    SAFETY PRECAUTIONS Read the following SAFETY PRECAUTIONS carefully before installation. Electrical work must be installed by a licensed electrician. Be sure to use the correct rating of the power plug and main circuit for the model to be installed. Incorrect installation due to ignoring of the instructions will cause harm or damage. The seriousness is classified by the following indications.
  • Page 4: Installation Instructions

    INSTALLATION INSTRUCTIONS 1. Wall-mounted type Selecting installation place Read completely, then follow step by step. Indoor unit Do not expose the indoor unit to heat or steam. Select a place where there are no obstacles in front or around the unit. Make sure that condensation drainage can be conveniently routed away.
  • Page 5: Accessories

    INSTALLATION INSTRUCTIONS Tools needed for installation: Level gauge Vacuum pump Screwdriver Gauge manifold Electric drill, Hole core drill (2.5 inches (65mm)) Users manual Flaring tool set Thermometer Specified torque wrenches: 13.0 lb.ft., 30.4 lb.ft., Multimeter 39.8 lb.ft., 47.7 lb.ft. (different depending on model No.) Pipe cutter Spanner (half union) Measuring tape...
  • Page 6 INSTALLATION INSTRUCTIONS More than 6in.(15cm) Remote Remote Remote control control control Remote control Air out Loop a One-Two Zone connective cable One-Three Zone One-Four Zone Fig.3 CAUTIONS This illustration is for explanation purposes only. The actual shape of your air condtioner may be slightly different.
  • Page 7 INSTALLATION INSTRUCTIONS Indoor unit installation (wall-mounted type) Correct orientation of Installation Plate 1. Fit the Installation Plate 1. Fit the installation plate horizontally on structural parts of the wall with spaces around the installation plate. Fig.4 2. If the wall is made of brick, concrete or the like, drill five or eight 0.197 inches ( 5mm) 6in.(150mm) or more to ceiling diameter holes in the wall.
  • Page 8 INSTALLATION INSTRUCTIONS 2. When connecting extension drain hose, insulate the connecting part of extension drain hose with a shield pipe, do not let the drain hose slack. Connective pipe installation Fig.8 1. For the left-hand and right-hand piping, remove the pipe cover from the side panel.
  • Page 9 INSTALLATION INSTRUCTIONS 4. Indoor unit installation 1. Pass the piping through the hole in the wall. 2. Put the upper claw at the back of the indoor unit on the upper hook of the installation plate, move the indoor unit from side to side to see that it is securely hooked (see Fig.12).
  • Page 10: Four-Way Cassette Type

    INSTALLATION INSTRUCTIONS 2. Four-way cassette type Attached fittings Please check whether the following fittings are of full scope. If there are some attached fittings free from use, please restore them carefully. (on some models) (on some models) 5.Outlet pipe sheath ......1 11.
  • Page 11 INSTALLATION INSTRUCTIONS The length could be calculated from Fig.17: Length = 8.3 inches + L (in general, L is half of the whole length of the installation hook) Hook Body c. Please adjust the hexangular nuts on the four installation hooks evenly, to ensure the balance of the body.
  • Page 12 INSTALLATION INSTRUCTIONS (2) Install the panel Drain side a. Align the swing motor on the panel to the water receiver of the body properly. (Refer to Fig.23) Drain side b. Hang the four fixed ropes of the main body to the Steel rope installation cover and the other three covers of the swing motor: (Refer to Fig.23 )
  • Page 13 INSTALLATION INSTRUCTIONS (4) Water-pump drainage The maximum lifting height is 29.5 inches. 7.9in. 39.4-59.1in. Fig.28 3. Drainage pipe installation (1) Installation principle Ensure at least 1/100 slope of the drainage pipe. Adopt suitable pipe diameter. Adopt nearby condensate water discharge. Before installing condensate water pipeline, determine its route and elevation to avoid intersection with other pipelines and ensure...
  • Page 14 INSTALLATION INSTRUCTIONS For horizontal drainage pipe (The following table is for reference) Attention: Use DWV/PVC40 or bigger pipe to be the main pipe according to code. The horizontal pipe layout should avoid converse flow or bad flow: Drainage pipe Drainage pipe Drain tee Drainage pipe Water flow...
  • Page 15 INSTALLATION INSTRUCTIONS (3) Water storage pipe setting If the indoor unit has high extra static pressure and without water pump to elevate the condensate water, such as high extra static pressure duct unit, the water storage pipe should be set to avoid converse flow or blow water phenomena. Indoor unit More than 1.97in.(50mm) Plug...
  • Page 16: Outdoor Unit Installation

    INSTALLATION INSTRUCTIONS Outdoor unit installation Outdoor installation precaution Install the outdoor unit on a rigid base to prevent increasing noise level and vibration. Determine the air outlet direction where the discharged air is not blocked. In the case that Strong the installation place is exposed to strong wind wind such as a seaside, make sure the fan is operating...
  • Page 17: Refrigerant Pipe Connection

    REFRIGERANT PIPE CONNECTION Drain joint installation NOTE: The drain joint differs from appliance to appliance. Fit the seal into the drain joint, then insert the drain joint into the base pan hole of outdoor unit, Base pan hole of rotate 90 to securely assemble them. Drain joint Seal outdoor unit...
  • Page 18: Electrical Work

    Tightening Connection Align the center of the pipes. Sufficiently tighten the flare Indoor unit tubing Flare nut Pipings nut with fingers, and then tighten it with a spanner and torque wrench as shown in Fig.58 & 59 Fig.58 Outer Tightening Additional tightening diam.
  • Page 19: Connect The Cable To The Outdoor Unit

    ELECTRICAL WORK Wiring connection Minimum nominal cross-sectional area NOTE: Before performing any electrical of conductors: work, turn off the main power to the system. Nominal cross-sectional Rated current of appliance area (mm ) CAUTIONS 0.75 >3 and <6 Do not touch the capacitor even if you >6 and <10 have disconnected the power for there is still high voltage power on it, or electric...
  • Page 20 ELECTRICAL WORK NOTE:please refer to the following figures, if the client wants to wire by themselves. Indoor Outdoor One-two models: Model B Model A One-three models: S(A) L(A) N(A) Model B Model A One-four models: L(A) N(A) S(A) Model B Model A Fig.63...
  • Page 21 ELECTRICAL WORK CAUTION CAUTION CAUTION CAUTION Prepare the wiring as follows: 1) Never fail to have an individual power circuit specifically for the air conditioner. As for the method of wiring, be guided by the circuit diagram posted on the inside of control cover.
  • Page 22: Air Purging

    AIR PURGING Air purging Air and moisture in the refrigerant system have undesirable effects as indicated below: Pressure in the system rises. Operating current rises. Cooling or heating efficiency drops. Moisture in the refrigerant circuit may freeze and block capillary tubing. Water may lead to corrosion of parts in the refrigeration system.
  • Page 23: Safety And Leakage Check

    AIR PURGING When Using the Vacuum Pump (For method of using a manifold valve, refer Manifold valve to its operation manual.) Compound meter Pressure gauge 1. Completely tighten the flare nuts, A, B, C, D, connect the manifold valve charge hose to a -76cmHg charge port of the low-pressure valve on the gas pipe side.
  • Page 24: Test Running

    TEST RUNNING Gas leak check 1. Soapy water method: Apply a soapy water or a liquid neutral detergent on the indoor unit connection Indoor unit check point or outdoor unit connections by a soft brush to check for leakage of the connecting points of the piping.
