MULTI-ZONE
DUCTED INDOOR UNIT
AB A6 SERIES, HEAT PUMP
USER MANUAL
Middle Static Pressure Type
FOR MODELS:
3PAMSDH09
3PAMSDH12
3PAMSDH18
3PAMSDH24
Before using your air conditioner, please
read this manual carefully and keep it for
future reference, along with your receipt.
COMFORT...BUILT TO LAST

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AB A6 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Perfect Aire AB A6 Series

  • Page 1 COMFORT...BUILT TO LAST MULTI-ZONE DUCTED INDOOR UNIT AB A6 SERIES, HEAT PUMP USER MANUAL Middle Static Pressure Type FOR MODELS: 3PAMSDH09 3PAMSDH12 3PAMSDH18 3PAMSDH24 Before using your air conditioner, please read this manual carefully and keep it for future reference, along with your receipt.
  • Page 2 Table of Contents Owner’s Manual Safety Precautions ............ SAFETY FIRST Indoor Unit Parts and Major Functions ..05 Manual Operations ............
  • Page 3: Table Of Contents

    Care and Maintenance ......a. Unit Maintenance ........b. How to Clean the Air Filter ....... c. Repairing Refrigerant Leaks ...... d. Preparation for Periods of Non-use ..09 Troubleshooting ......... a. Common Problems ......b. Troubleshooting Tips ......Disposal Guidelines ..................
  • Page 4: Safety Precautions

    Safety Precautions Thank you for purchasing this air conditioner. This manual will provide you with information on how to operate, maintain, and troubleshoot your air conditioner. Following the instructions will ensure the proper function and extended lifespan of your unit. Please pay attention to the following signs: Failure to observe a warning may result in death.
  • Page 5: Indoor Unit Parts And Major Functions

    An all-pole disconnection device which has at The indoor unit must be installed 2,5m above • • least 3mm separation distance in all pole and oor. a residual current device (RCD) with the rating This appliance is not intended for use by persons •...
  • Page 6 Features Default Setting Louver Angle Memory Function (Optional) When the air conditioner restarts after a power Some models are designed with a louver angle failure, it will default to the factory settings memory function. When the unit restarts after a (AUTO mode, AUTO fan, 24°C (76°F)).
  • Page 7: Manual Operations

    Manual Operations This display panel on the indoor unit can be used to operate the unit in case the remote control has been misplaced or is out of batteries. Manual button LED display Operation indicator Infrared receiver Alarm indicator Timer indicator PRE-DEF (pre-heating/defrost) indicator...
  • Page 8: Care And Maintenance

    Care And Maintenance WARNING: DO NOT REMOVE OR Safety Precautions CLEAN THE FILTER BY YOURSELF Contact an authorized service technician for • repair or maintenance. Improper repair and Removing and cleaning the lter can be maintenance may cause water leakage, dangerous.
  • Page 9: Repairing Refrigerant Leaks

    3. Remove the air lter. Repairing Refrigerant Leaks 4. Clean the air lter by vacuuming the surface or washing it in warm water with mild WARNING detergent. A. If using a vacuum cleaner, the inlet side If the refrigerant leaks, turn o the air •...
  • Page 10: Troubleshooting

    Troubleshooting CAUTIONS If one of the following conditions occurs, switch o the power supply immediately and contact your dealer for further assistance. The operation light continues to ash rapidly after the unit has been restarted. • The remote control buttons do not work. •...
  • Page 11: Troubleshooting Tips

    Problem Possible Causes Dust is emitted from The unit may accumulate dust during extended periods of non-use, which either the indoor or will be emitted when the unit is turned on. This can be mitigated by covering outdoor unit the unit during long periods of inactivity. The unit may absorb odors from the environment (such as furniture, cooking, The unit emits a cigarettes, etc.) which will be emitted during operations.
  • Page 12 Indoor EEPROM (Electrically Erasable Programmable Read-Only Memory) error Indoor and outdoor unit communication malfunction Indoor fan speed malfunction Indoor room temperature sensor error Evaporator coil temperature sensor error Refrigerant leak detection system malfunction Water level alarm malfunction Dual indoor unit (twin model only) communication malfunction Other twin model malfunction Overload protection...
  • Page 13 This appliance contains refrigerant and other potentially hazardous materials. When disposing of this appliance, the law may require special collection and treatment. DO NOT dispose of this product as household waste or unsorted municipal waste. When disposing of this appliance, you have the following options: Dispose of the appliance at designated municipal electronic waste collection facility.
  • Page 14 The design and speci cations are subject to change without prior notice for product improvement.Consult with the sales agency or manufacturer for details. QSBPT2U-046AEN(I)(DZ) 16123000A16062 20170914   Page 14...
  • Page 15 Distributed by: Perfect Aire, LLC 5401 Dansher Rd. Countryside, IL 60525 844-4PA-AIRE | 844-472-2473 www.perfectaire.us Specification and performance data is subject to change without notice. Printed in China PA/3PAMSDH/10202021...
