Split-type Air-Conditioner
MXZ-6D122VA
MXZ-4E83VAHZ
English is original.
Übersetzung des
Originals
Traduction du texte
d'origine
Vertaling van het
origineel
Traducción del
original
Traduzione
dell'originale
Μετάφραση του
αρχικού
Tradução do
original
Oversættelse af
den originale tekst
Översättning från
originalet
Orijinalin çevirisi
Версията на английски
език е оригинал.
Installation Manual
• This manual only describes the installation of outdoor unit.
When installing the indoor unit, refer to the installation manual of indoor unit.
Installationsanleitung
• Diese Installationsanleitung gilt nur für die Installation des Außengerätes.
Zur Installation des Innengeräts siehe die Installationsanleitung für Innengeräte.
Notice d'installation
• Cette notice ne décrit que l'installation de l'appareil extérieur.
Lors de l'installation de l'appareil intérieur, consultez la notice d'installation de cet
appareil.
Installatiehandleiding
• Deze handleiding beschrijft alleen de installatie van de buitenunit.
Raadpleeg de installatiehandleiding van de binnenunit wanneer u deze instal-
leert.
Manual de instalación
• En este manual sólo se describe la instalación de la unidad exterior.
Para instalar la unidad interior, consulte el manual de instalación de dicha uni-
dad.
Manuale per l'installazione
• Questo manuale descrive solo l'installazione dell'unità esterna.
Per l'installazione dell'unità interna, fare riferimento al relativo manuale di instal-
lazione.
Εγχειρίδιο εγκατάστασης
• Στο παρόν εγχειρίδιο περιγράφεται μόνο η εγκατάσταση της μονάδας εξωτερικού χώρου.
Για την εγκατάσταση της μονάδας εσωτερικού χώρου, ανατρέξτε στο εγχειρίδιο
εγκατάστασης της μονάδας εσωτερικού χώρου.
Manual de Instalação
• Este manual descreve apenas a instalação da unidade exterior.
Quando proceder à instalação da unidade interior, consulte o manual de instalação
da unidade interior.
Installationshåndbog
• Denne håndbog beskriver kun, hvordan udendørsenheden installeres.
Vedrørende installation af indendørsenheden henvises til installationshåndbogen
for indendørsenheden.
Installationsanvisning
• Denna installationsanvisning beskriver endast installation av utomhusenheten.
Se den separata installationsanvisningen för inomhusenheten.
Kurulum Kılavuzu
• Bu kılavuzda yalnızca dış ünitenin kurulumu açıklanmaktadır.
İç ünite kurulum işlemini yaparken iç ünite kurulum kılavuzuna bakın.
Ръководство за монтаж
• Това ръководство описва само монтажа на външното тяло.
При монтиране на вътрешното тяло вижте ръководството за монтаж на
вътрешното тяло.
For INSTALLER
Für INSTALLATEUR
Destinée à l'INSTALLATEUR
Voor de INSTALLATEUR
Para el INSTALADOR
Per il TECNICO INSTALLATORE
Για τον ΤΕΧΝΙΚΟ
Para o INSTALADOR
Til INSTALLATØREN
För INSTALLATÖREN
TESİSATÇI İÇİN
За ИНСТАЛАТОРА
English
Deutsch
Français
Nederlands
Español
Italiano
Ελληνικά
Português
Dansk
Svenska
Türkçe
Български
Advertisement
Table of Contents
Related Manuals for Mitsubishi Electric MXZ-4E83VAHZ
Summary of Contents for Mitsubishi Electric MXZ-4E83VAHZ
- Page 1 Split-type Air-Conditioner MXZ-6D122VA MXZ-4E83VAHZ For INSTALLER Installation Manual English is original. English • This manual only describes the installation of outdoor unit. When installing the indoor unit, refer to the installation manual of indoor unit. Für INSTALLATEUR Installationsanleitung Übersetzung des Deutsch • Diese Installationsanleitung gilt nur für die Installation des Außengerätes.
-
Page 2: Table Of Contents
32 A 25 m / 80 m 25 / 80 20 g/m *10 55 dB (A) 3-core 4-core 230 V 50 Hz 15 m 57 dB (A) 4.0 mm 1.0 / 1.5 mm MXZ-4E83VAHZ 30 A 25 m / 70 m 25 / 70 20 g/m *11 53 dB (A) *1 Connect to the power switch which has a gap of 3 mm or more when open *8 Be sure to use the insulation of specified thickness. Excessive thickness to interrupt the source power phase. (When the power switch is shut off, it may cause incorrect installation of the indoor unit and insufficient thickness must interrupt all phases.) may cause dew drippage. *2 Use wires in conformity with design 60245 IEC 57. Use the indoor/outdoor *9 If the outdoor unit is installed higher than the indoor unit, max. height connecting wire in conformity with the wire specifications specified in the difference is reduced to 10 m. -
Page 3: Selecting The Installation Location
If the diameter of connection pipe does not match the port size of outdoor unit, use optional different-diameter joints according to the following table. (Unit: mm (inch)) Optional different-diameter joints (port size of outdoor unit → diameter of connection pipe) Port size of outdoor unit 6.35 (1/4) → 9.52 (3/8) : PAC-493PI MXZ-4E83VAHZ MXZ-6D122VA Liquid / Gas 9.52 (3/8) → 12.7 (1/2) : MAC-A454JP 9.52 (3/8) → 15.88 (5/8) : PAC-SG76RJ... -
Page 4: Installation Diagram
1-5. INSTALLATION DIAGRAM After the leak test, apply insulat- ing material tightly so that there ACCESSORIES (MXZ-6D122VA only) is no gap. Check the following parts before installation. (1) Drain socket When the piping is to be attached to a wall containing metals (tin plated) (2) Drain cap or metal netting, use a chemically treated wooden piece 20 mm or thicker between the wall and the... -
Page 5: Outdoor Unit Installation
Indoor/outdoor unit <OUTDOOR UNIT> connecting wire (MXZ-6D122VA) (MXZ-4E83VAHZ) Terminal block for power supply Terminal block Terminal block 15 mm 35 mm Lead wire POWER SUPPLY ~/N 230 V 50 Hz Terminal block Terminal block <INDOOR UNIT> <INDOOR UNIT> (MXZ-6D122VA) D (MXZ-4E83VAHZ) • Be sure to attach each screw to its correspondent terminal when securing the cord and/or the wire to the terminal block. • Make earth wire a little longer than others. (More than 35 mm) • For future servicing, give extra length to the connecting wires. En-4... -
Page 6: Flaring Work And Pipe Connection
3. FLARING WORK AND PIPE CONNECTION 3-1. FLARING WORK 1) Cut the copper pipe correctly with pipe cutter. (Fig. 1, 2) 2) Completely remove all burrs from the cut cross section of pipe. (Fig. 3) No good Good • Aim the copper pipe downward while removing burrs to prevent burrs Copper from dropping in the pipe. pipe 3) Remove flare nuts attached to indoor and outdoor units, then put them on pipe having completed burr removal. (Not possible to put them on after flaring work.) Tilted Uneven Burred 4) Flaring work (Fig. 4, 5). Firmly hold copper pipe in the dimension shown in the table. Select A mm from the table according to the tool selected. Fig. - Page 7 4-2. GAS CHARGE Model Indoor unit Perform gas charge to unit. MXZ-6D122VA A - F 1) Connect gas cylinder to the service port of stop valve. MXZ-4E83VAHZ A - D 2) Perform air purge of the pipe (or hose) coming from refrigerant gas cylinder. 3) Replenish specified amount of the refrigerant, while operating the air conditioner for cooling. Stop valve Liquid Union Note: pipe In case of adding refrigerant, comply with the quantity specified for the refrigerat- Union ing cycle. Indoor Outdoor unit unit CAUTION: Union...
-
Page 8: Test Run
4-6. TEST RUN • Test runs of the indoor units should be performed individually. See the installation manual coming with the indoor unit, and make sure all the units operate properly. • If the test run with all the units is performed at once, possible erroneous connections of the refrigerant pipes and the indoor/outdoor unit connecting wires cannot be detected. Thus, be sure to perform the test run one by one. About the restart protective mechanism Once the compressor stops, the restart preventive device operates so the compressor will not operate for 3 minutes to protect the air conditioner. Wiring/piping correction function This unit has a wiring/piping correction function which corrects wiring and piping combination. When there is possibility of incorrect wiring and piping combi- nation, and confirming the combination is difficult, use this function to detect and correct the combination by following the procedures below. Make sure that the following is done. • Power is supplied to the unit. - Page 9 DECLARAÇÃO DE CONFORMIDADE CE ДЕКЛАРАЦИЯ СООТВЕТСТВИЯ НОРМАМ ЕС MITSUBISHI ELECTRIC CONSUMER PRODUCTS (THAILAND) CO., LTD AMATA NAKORN INDUSTRIAL ESTATE 700/406 MOO 7, TAMBON DON HUA ROH, AMPHUR MUANG, CHONBURI 20000, THAILAND hereby declares under its sole responsibility that the air conditioners and heat pumps described below for use in residential, commercial and light-industrial environments: erklärt hiermit auf seine alleinige Verantwortung, dass die Klimaanlagen und Wärmepumpen für das häusliche, kommerzielle und leicht-industrielle Umfeld wie unten beschrieben:...
